3. Inserting microSD memory card
• A microSD memory card is included and already inserted in the camcorder.
It is installed between the batteries in the front compartment.
EZ208
User Manual
• To remove card, push card in until a click is heard and the card will pop
RCA Small Wonder Camcorder
out slightly, then remove the card.
www.rcaaudiovideo.com
• To insert card, align card with Card Symbol on camcorder and slide in until
Congratulations on purchasing your new RCA High Defi nition Small Wonder Camcorder.
a click is heard. The card icon (
Please read these instructions for quick tips on using the product.
card inserted.
1. Content of the box
• SmallWonder Camcorder • Carrying Case
4. Setting date and time
• AV cable • User Manual
• USB cable • Owner Registration card 1. Press or
• 2 x AA Batteries • 4GB microSD card (installed in the date/time values.
2. Press or
• Wrist strap camcorder)
press DELETE to exit without saving.
2. Battery Installation • Date and time setting can be accessed by pressing and holding PLAY/PAUSE and ON/OFF
together while the camcorder is turned off .
1. Push (to the right) and hold the front cover
lock at the bottom of the camcorder. 2
2. Slide the front cover down and then lift up to
open.
1
3. Replace or install 2 AA batteries.
• Make sure you align the battery polarities as 3
indicated.
• In the case of low battery, a low battery icon
4
( ) will fl ash on the screen. Please change
batteries when battery icon is fl ashing.
• Alkaline batteries are recommended for best
results under normal use. For extended video
shooting, Energizer e2 Lithium AA batteries
are recommended.
4. Replace the front cover and slide up to lock.
5. Using your camcorder
microSD card
Turn on/off
1. Press and hold ON/OFF to turn on.
2. Press and hold ON/OFF to turn off .
• Camcorder will automatically turn off after 2 minutes if not in use.
) appears on the screen with memory
Record
Press and release the red RECORD button (after
Front compartment
"READY" appears on the screen) to begin recording.
While recording:
to shift among month, date, hour and minute and press + or – to set the
• A red and the elapsed time appears at the top
left corner of the screen.
to select DONE and then press the red RECORD button to save settings. Or
• The red recording light on the camcorder front
turns on.
Pausing a recording:
• Press PLAY/PAUSE.
• A pause indicator II replaces the red
left corner and "Recording Paused" fl ashes in the
middle of the screen.
• To resume recording, press and release PLAY/
PAUSE again.
Stop
While playing or recording, press and release the red
RECORD button to stop the playing or recording.
Play
1. Press PLAY/PAUSE to start playback of the most recent recording or the selected video.
To select another video, refer to Selecting videos.
LCD screen
2. Press and hold PLAY/PAUSE for three seconds to play all videos.
For self recordings, the LCD
o • If no video is selected after playback has fi nished, recording mode will resume after 5 seconds.
screen can be rotated 180 .
Search forward/backward:
• Hold down to fast forward the selected video during playback.
• Hold down to fast rewind the selected video during playback.
Pausing video playback:
• Press PLAY/PAUSE to pause playback (a pause indicator
time fl ash at the top left corner of the screen).
• Press PLAY/PAUSE again to resume playback.
Selecting videos:
• Press and release to cue the next video.
• Press and release to cue the previous video.
Delete
at the top
1. Press DELETE and the last recording and "DELETE VIDEO ?" appear on the screen.
• To select another video, refer to Selecting videos.
2. Press and hold DELETE until the selected video is deleted.
3. To delete all videos, press & hold DELETE for 3 seconds and then repeat step 2.
Take photo
• Press and release WEB PHOTO to take photo (photo resolution: 1280 x 960 pixel).
Back view
Zoom
Volume
Audio speaker
Before or during recording: During playback:
• Press + to zoom in. • Press + to increase volume.
• Press – to zoom out. • Press – to decrease volume.
Microphone
Recording indicator
Lens
Right view
II and the remaining playback
AV output
Audio/Video output for connecting to TV or other
AV equipment with the included AV cable.
• Refer to "Viewing videos on TV" and "Recording videos to VHS
tape or DVD" overleaf for more information.
Front view
Front cover
Refer to Battery installation for more
information.
Bottom view
Front cover lock Tripod screw mount
Video quality selector
HQ: High Quality mode
webQ: Web quality mode
• The selected setting (HQ or webQ) appears on the display screen during recording.
• The HQ setting is recommended when planning to view video on a TV directly from the
camcorder.
Settings Quality Approximate recording duration*
HQ Near DVD 2 hours
Camcorder strap hole
webQ GOOD 8 hours
* Recording duration is based on 4 GB microSD card. Actual recording
capacity depends on type of video content being recorded.
USB Connector ARM
Extending the USB Connector ARM:
1. Rotate the LCD screen 180 o to show the USB Connector ARM.
2. Rotate the USB Connector ARM 180 o to extend it.
3. Replace the LCD screen.
• Refer to "Connecting to a PC" overleaf for more information.
• Use USB Extension Cable (provided) if USB Connector ARM is obstructed or space does not
permit connection to PC.
• Reverse the steps above to retreat the ARM.
1
2
3
Left view
