O p e r a t i o n
M a n u a l
LIMITED WARRANTY
This product is warranted to be free from defects in material and/or
workmanship for a period of one (1) year from date of original
installation, not to exceed 30 months from date of shipment from
our factory. Any component which proves to be faulty in material
and/or workmanship will be replaced or repaired (at the option of
Prince Castle, Inc.) without cost to the customer for parts or labor.
This warranty covers on location service (i.e., trip charges and/or
mileage). Travel mileage is limited to 100 miles (200 kilometers)
round trip (one trip warranty) from an authorized service agency or
its sub-service agency.
This warranty is subject to the following exceptions/conditions:
•
Use of any non-genuine Prince Castle parts voids this warranty.
•
All labor shall be performed during regular work hours.
Overtime premium will be charged to the buyer.
•
Damage caused by carelessness, neglect, and/or abuse (e.g.,
dropping, tampering or altering parts, equipment damaged in
shipment, by fire, flood or an act of God) is not covered under
this warranty.
630-500
Product Identification
The 630-ROM4 Romar Pasta Cooker automates fresh
cooking and dispensing of individual servings of dry
pasta. At the touch of a button, a pasta hopper
dispenses an individual portion of dry pasta, then uses
pressure, water and steam to rapidly cook the pasta to
perfection every time in about 3 minutes per serving.
355 East Kehoe Blvd. • Carol Stream, IL 60118
Phone: 630-462-8800 • Toll Free: 1-800-PCASTLE
Fax: 630-462-1460 • www.PrinceCastle.com
TABLE OF CONTENTS
P r o d u c t I d e n t i f i c a t i o n . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
S a f e t y I n f o r m a t i o n . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
I m p o r t a n t ! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
I n s t a l l a t i o n . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
C o o k i n g P a s t a . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
P e r i o d i c M a i n t e n a n c e & C l e a n i n g . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
SPECIFICATIONS
•
Power Voltage.........................................................................240 VAC
•
Power Amps........................................................................... 27 Amps
•
Phase................................................................................................... 3
•
Frequency ............................................................................... 50/60 Hz
•
Boiler Controller Power ............................................................24VAC
•
Control Power ...........................................................................24 VAC
•
Max Pressure ............................................................................100 PSI
•
Working Pressure...................................................................... 80 PSI
Romar Pasta Cooker
630-ROM4
Printed in USA 0404 © 2004
Advertisement
Summary of Contents for Prince Castle 630-ROM4
-
Page 1: Table Of Contents
Any component which proves to be faulty in material and/or workmanship will be replaced or repaired (at the option of Prince Castle, Inc.) without cost to the customer for parts or labor. This warranty covers on location service (i.e., trip charges and/or mileage). -
Page 2: Safety Information
• When connecting the steam generator blow-down outlet, ensure that the valve (provided by Prince Castle) is reachable (arms length) from the front of the unit. The connecting “black pipe” must be installed behind the unit and below the counter, away from easy reach. -
Page 3: General Preparation & Operation
B. Repeat feathering several times, as necessary. The broken, unusable pieces that remain in the bottom of the bowl may be discarded. The feathered long-cut pasta is now ready to be cooked. Printed in USA 0404 © 2004 630-ROM4... - Page 4 A. Fill loading box with approx. 1 lb. of long-cut pasta. B. Fill hoper with up to 14 lbs. of the same long-cut pasta. Use only pasta recommended by Prince Castle. Using other types of pasta or food may cause severe damage and void all warranties and maintenance contracts.
- Page 5 All the cooking chambers are sanitized for 60 secs. at 280°F each time the machine is switched Romar Pasta Cooker 630-ROM4 Serving Strainer Drainage Strainer Printed in USA 0404 © 2004...
- Page 6 Romar Pasta Cooker 630-ROM4 On the back of the unit, turn the power button to the ON position. Power button The power button lights up and the unit proceeds through its start-up process. The boiler begins to fill. The boiler is completely filled when the water level has filled the Sight Glass halfway.
-
Page 7: Cooking Pasta
The unit shuts down. At the end of each day, perform the Daily Blow-Down procedure (see Daily Blow-Down Procedure in the Maintenance & Troubleshooting manual). Also, clean the unit thoroughly (see Daily or Weekly Cleanup below). Printed in USA 0404 © 2004 630-ROM4... - Page 8 Use a standard long-handle 3.5 scrub brush head and mild detergent only. No other cleaning tools or detergents other than those supplied by Prince Castle may be used. Do NOT use any boiler cleaning components. This clean-up procedure is the last procedure to be performed at the end of the day.
- Page 9 When the cleaning cycle is finished (approx. 30 secs.), the unit automatically shuts down. Slide the three dispensers forward to their normal position. Ensure that they are secure in their appropriate slots as shown. Funnels Romar Pasta Cooker 630-ROM4 Printed in USA 0404 © 2004...
