Summary of Contents for AT&T SPB3200
- Page 1 User’s Manual SPB3200 Battery Case Charger for Samsung Galaxy S®4...
-
Page 2: Features
Welcome | Thank you for purchasing SPB3200 Introduction Features - Micro USB port to charge the Battery Case - Rechargeable 2500 mAh Lithium-polymer battery - Power Indicator – 4 LEDs power display - Lightweight, thin design Page 2... -
Page 3: What's Included
What’s Included Unpack the battery case and make sure all accessories are put aside so they will not be lost. USB to Micro USB Cable Battery Case Page 3... - Page 4 Checking the Battery Case Power Level Inserting Your Galaxy S4 into the Battery Case Charging Your Galaxy S4 Using the SPB3200 Battery Case Charging the Galaxy S4 Battery When Inserted in the SPB3200 Switching Your SPB3200 Battery Case to Standby Mode Troubleshooting...
-
Page 5: Important Safety Instructions
Take special note of all warnings listed in this user’s manual and on the SPB3200. 1. Attachments - Do not use attachments that are not recommended by the manufacturer. -
Page 6: Location Of Main Unit Controls
Getting Started Location of Main Unit Controls 1. USB connector 2. Power ON/OFF button 3. Micro USB input 4. LED Power indicators 5. Galaxy S4 speaker port 6. Battery case slide/lock Page 6... -
Page 7: Charging Your Spb3200 Battery Case
- Plug the USB cable into any USB powered device, such as a personal computer, USB wall adapter or USB enabled battery pack. - Upon initial use, or after a prolonged storage period, the SPB3200 should be fully charged in approximately 4 hours. -
Page 8: Inserting Your Galaxy S4 Into The Battery Case
- Plug the USB cable into any USB powered device, such as a personal computer, USB wall adapter or USB enabled battery pack. - Press the SPB3200 power button to turn it “On” and the Galaxy S4 battery indicator will show that the Galaxy S4 is charging. -
Page 9: Switching Your Spb3200 Battery Case To Standby Mode
Operational Instructions Switching Your SPB3200 Battery Case to Standby Mode - The power button on the front of the SPB3200 allows you to choose between standby mode and charging mode. - To use your phone’s internal battery, press the SPB3200 power button to turn it “Off”... -
Page 10: Troubleshooting
Troubleshooting Symptom Solution No power Verify that there is power left in the battery case. Recharge the battery case, as needed. Page 10... -
Page 11: Compliance With Fcc Regulations
Compliance with FCC Regulations Caution! The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. The equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 12: Warranty Information
Warranty Information Limited Warranty The AT&T brands are used under license. Any repair, replacement, or warranty service, and all questions about this product should be directed to Concept 101 LLC at www.att.com/electronics or call 1 (888) 920-8680 from the USA or Canada. - Page 13 Obtaining Service: To obtain service, product literature, supplies or accessories please call 1 888-920-8680, or visit our website, www.att.com/electronics, to create a ticket for exchange/repair. Please make sure to provide the date of purchase, model number and a brief description of the problem.
-
Page 14: Specifications
Specifications - Input: DC5.0V-500mA - Output: DC5.0V-500mA(max) - Capacity: 2500 mAh lithium polymer battery - Dimensions: 146 x 75 x 18mm - Weight: 98g Page 14... - Page 15 www.att.com/electronics © 2017 Concept 101 LLC. All Rights Reserved. AT&T and the AT&T logo are trademarks of AT&T Intellectual Property licensed to Concept 101 LLC, New York, New York 10018. D Issue 2.0 AT&T 9/2017. Galaxy S® is a trademark of Samsung Electronics Co. Other trademarks and trade names are those of their respective owners.
