Fits with Curtis Roof Kit: Contact Curtis for Details.
Fits with Curtis Alternator Kit: Contact Curtis for Details.
Product Specifications
25" x 36" x 7"
Weight: 47 lbs.
Air Flow: 260 CFM
Cooling Capacity: 12,000 BTU / hr
Voltage: 12 VDC
Amp Draw: 68
Refrigerant: R134a, 2.1 lb. Charge
The contents of this envelope are the property of the owner. Leave with the owner when installation is complete.
Air Conditioner
p/n: 1ACUNIT-G1
Approximate Installation Time *
Experienced Dealer Technician – 1 Hours
Average Dealer Technician – 1.5 Hours
Do-It-Yourself – 2 Hours
1 of 10
Rev. B, 10/30/2017
p/n: IM-1ACUNIT-G1
Advertisement
Related Manuals for Curtis 1ACUNIT-G1
Summary of Contents for Curtis 1ACUNIT-G1
- Page 1 1 of 10 Air Conditioner p/n: 1ACUNIT-G1 Fits with Curtis Roof Kit: Contact Curtis for Details. Fits with Curtis Alternator Kit: Contact Curtis for Details. Product Specifications Approximate Installation Time * 25” x 36” x 7” Experienced Dealer Technician – 1 Hours Weight: 47 lbs.
-
Page 2: Table Of Contents
2 of 10 TABLE OF CONTENTS WARNINGS ....................3-4 FEATURES & OPERATION ................5 CARE AND MAINTENANCE ................5 REFRIGERANT FLOW DIAGRAM ..............6 TROUBLESHOOTING GUIDE ................. 7 SERVICE PARTS ..................8-10... -
Page 3: Warnings
3 of 10 WARNINGS Curtis air conditioners feature an assembly of parts designed for your vehicle which require adjustment and alignment of components to accommodate vehicle variations and provide proper weather protection. For accurate installation, proper operation, and years of satisfaction, please read and understand the Service &... - Page 4 4 of 10 WARNINGS Your new air conditioner should arrive laying down flat. Do not receive the air conditioner from the shipping company if the air conditioner is standing up on end as Take care to protect the switches and louvers at the bottom of shown.
-
Page 5: Features & Operation
5 of 10 FEATURES & OPERATION Your new Curtis Air Conditioner is designed to make your driving experience more comfortable in hot weather. Turn the 4 POSITION VENTILATION SWITCH to activate the blower. The air conditioner may be used as a fan in this manner. -
Page 6: Refrigerant Flow Diagram
6 of 10 REFRIGERANT FLOW DIAGRAM... -
Page 7: Troubleshooting Guide
7 of 10 TROUBLESHOOTING GUIDE Some air conditioners have a time delayed start (5 seconds), to allow the vehicle’s motor to get up to speed before engaging the auxiliary alternator. The air conditioner’s compressor has a built in reset time between stopping and restarting in order to allow refrigerant pressure to equalize. -
Page 8: Service Parts
8 of 10 1ACUNIT-G1 SERVICE PARTS CONDENSER FAN BRACKET CONDENSER EVAPORATOR ASSEMBLY P/N: 8SV-110-00040 P/N: 8SV-304-00006 P/N: 8SV-304-00001 HIGH PRESSURE LINE 12V SOLENOID CONDENSER TO DRIER LINE P/N: 8SV-305-00009 P/N: 9SV-1TBP61A P/N: 8SV-305-00011 DRIER TO EVAPORATOR LINE LOW PRESSURE RETURN LINE... - Page 9 9 of 10 1ACUNIT-G1 SERVICE PARTS PRESSURE SWITCH, 2-28KG/CM2 EXPANSION VALVE COMPRESSOR, 12 VDC P/N: 9SV-9AC-00005 P/N: 9SV-9AC-00004 P/N: 9SV-9AC-00006 THERMOSTAT HIGH PRESSURE COMPRESSOR AXIAL FAN P/N: 9SV-9AC-00008 FITTING W/ O-RING P/N: 9SV-9AC-00007 P/N: 9SV-9AC-00024 AIR INTAKE GRILL LOW PRESSURE COMPRESSOR 2.8"...
