  • Page 1: User Manual

    格式化: 縮排: 左 8 字元 刪除: AVIC-S1 User Manual 刪除:...
  • Page 2 Trademarks The Bluetooth word mark and logo are owned by the Bluetooth SIG, Inc. All other brand and product names are trademarks or registered trademarks of their respective companies. Note The information in this document is subject to change without notice.

  • Page 3: Table Of Contents

    Table of Contents Notice ....................iii Getting Started ................1 1.1 Understanding Hardware Features ..........1 Front Components ................1 Back Components................2 Right-Side Components ..............3 Top Components ................3 Bottom Components ................ 4 1.2 Performing the Initial Startup............5 1.3 Connecting to AC Power and Charging the Battery ......6 1.4 Turning Your Device On and Off ............
  • Page 4 Troubleshooting and Maintenance..........18 3.1 Resetting Your System ..............18 3.2 Troubleshooting ................19 Power Problems................19 Screen Problems ................19 Connection Problems..............20 GPS Problems ................20 3.3 Maintaining Your Device ..............21...

  • Page 5: Notice

    Notice Read “Important Information for the User” (a separate manual) before using this product. This manual provides hardware and Bluetooth® information. For information on the GPS navigation software, see the “Operation Manual.”...

  • Page 7: Getting Started

    Getting Started 1.1 Understanding Hardware Features Front Components Component Description 刪除: radio Bluetooth Flashes in blue to indicate that Bluetooth is on. The Indicator Bluetooth is always on when your device is turned on. 刪除: radio Power Glows bright amber to indicate that the battery is charging, Indicator and turns green when the battery is fully charged.

  • Page 8: Back Components

    Antenna external GPS antenna with magnetic mount (not available 刪除: optional through Pioneer), which may be positioned on top of the car for better signal reception in areas with poor reception. Contact Pioneer Support for recommendations on available party products.

  • Page 9: Right-Side Components

    Right-Side Components Component Description SD Slot Accepts an SD (Secure Digital) card for future map and software upgrades. Reset Button Restarts your device (soft reset). Top Components Component Description Power Button Turns the device on and off by pressing for at least 2 seconds.

  • Page 10: Bottom Components

    Bottom Components Component Description Mini-USB Connects to the AC adapter or USB cable. Connector Car Kit Connects to the TMC Kit (European model only). Connector Microphone For Bluetooth hands-free calling.

  • Page 11: Performing The Initial Startup

    1.2 Performing the Initial Startup 1. Slide the ON/OFF switch to the ON position. after you have 2. Your device turns on and displays a warning screen. Tap read the entire warning, and if you agree 3. The Main Menu appears. 4.

  • Page 12: Connecting To Ac Power And Charging The Battery

    1.3 Connecting to AC Power and Charging the Battery When charging the battery for the very first time, you should charge it for at least 8 hours. 1. Connect the AC adapter cable to the mini-USB connector on your device. 2.

  • Page 13: Turning Your Device On And Off

    1.4 Turning Your Device On and Off Press and hold the power button for at least 2 seconds to turn on and off your device. When you press the power button to turn off the unit, your device actually enters into a suspend state and the system stops operating.

  • Page 14: Navigating On The Screen

    Your device has a SD slot where you can insert an Secure Digital storage card 刪除: optional for future software and application upgrades sold by Pioneer. To use a SD card, insert it into the slot, with the connector pointing to the slot and its label facing the front of the device.

  • Page 15: Bluetooth Hf Phone

    1. Initiate the Bluetooth searching process on your mobile phone. You should see “Pioneer AVIC-S1” in the device list after searching is completed. 2. Select “Pioneer AVIC-S1” to create the connection. Use the 0000 default passkey to connect. 3. Your...

  • Page 16: Starting Bluetooth Mobile Phone

    2.3 Starting Bluetooth Mobile Phone 1. Press and hold the MENU button on your device for at least 2 seconds. - or - Settings Phone on the Main Menu. Tap twice and then tap Menu 2. The Bluetooth HF Phone main screen appears. The status bar at the bottom shows the name of the mobile phone connected.

  • Page 17: Placing A Call

    2.4 Placing a Call After pairing with your mobile phone, you can place a call using any of the four Keypad Contact Call History buttons ( , and Redial ) on the Bluetooth HF Phone main screen. Keypad Keypad By tapping the button on the Bluetooth HF Phone main screen, you can enter the telephone number with the onscreen keypad.

  • Page 18: Contacts

    Contacts You can exchange business cards between Bluetooth devices via OPP (Object Push Profile). As long as you have sent such information to your device, the information is available in Bluetooth HP Phone. Contact To call a contact, tap the button on the Bluetooth HF Phone main screen.

  • Page 19: Call History

    Call History NOTE: Bluetooth HF Phone cannot access the call history stored in a connected mobile phone. Call History Tap the button on the Bluetooth HF Phone main screen to display the recent incoming, outgoing, or missed calls together with information such as date, time, and duration of each call.

  • Page 20: Redial

    Redial Redial Tap the button on the Bluetooth HF Phone main screen to dial the last number you called or received. Mute Cancel 2.5 Operations During a Call During a call, four functions are available: Mute Switch to Delete All mobile phone.

  • Page 21: Receiving A Call

    Mute Tap the button to mute your sound so that the other party cannot hear you. To end the mute mode, tap the same button again. Ignore Tap the button to end the call. Transfer Tap the button to switch the call to your mobile phone. To switch back to your device, tap the same button again.

  • Page 22: Connecting To A Paired Phone

    2.7 Connecting to a Paired Phone Once you have established a Bluetooth connection with a mobile phone, it will be stored in your device. You can initiate the connection from your device. 1. Start Bluetooth HF Phone as described in section 2.2 Connect 2.

  • Page 23: Closing Bluetooth Hf Phone

    2.9 Closing Bluetooth HF Phone To hide the Bluetooth HF Phone screen, tap the button on the Bluetooth HF Phone main screen. Bluetooth HF Phone is still running in the background. 2.10 Ending the Bluetooth Connection When you turn off your device, the connection is ended. You can also end the connection from your mobile phone.

  • Page 24: Troubleshooting And Maintenance

    Troubleshooting and Maintenance Troubleshooting and Maintenance This chapter gives solutions to common problems you may encounter. It also provides guidelines on how to take care of your device. NOTE: If you encounter a problem you cannot solve, contact an authorized service center for assistance.

  • Page 25: Troubleshooting

    4. Your device turns on. 3.2 Troubleshooting Power Problems Power does not turn on when using battery power The remaining battery power may be too low to run your device. Connect the AC adapter to your device and then to AC power. Then, turn on your device.

  • Page 26: Connection Problems

    Screen responds slowly Make sure that your device is not running out of battery power. If the problem still exists, reset your system. Screen freezes Reset your system. Screen is hard to read Make sure that the backlight of the display is on and if necessary adjust the brightness.

  • Page 27: Maintaining Your Device

    3.3 Maintaining Your Device Taking good care of your device will ensure trouble-free operation and reduce the risk of damage to your device. Keep your device away from excessive moisture and extreme temperatures. Avoid exposing your device to direct sunlight or strong ultraviolet light for extended periods of time.

  • Page 28: Fcc Regulations

    FCC Regulations: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
