- Page 1 Vodafone R209-Z Quick Guide ZTE CORPORATION NO. 55, Hi-tech Road South, ShenZhen, P.R.China Postcode: 518057 Confidential and Proprietary Information of ZTE CORPORATION 1...
- Page 2 ZTE Corporation. The manual is published by ZTE Corporation. We reserve the right to make modifications on print errors or update specifications without prior notice. Version No. : R1.0 Edition Time : 3.2014...
-
Page 3: Getting To Know Your Device
Wi-Fi is active. Wi-Fi Blue blinking WPS is active. LED light off Wi-Fi is off or your device is in sleep mode. Blue solid You have unread messages. Blue blinking You have new messages. Confidential and Proprietary Information of ZTE CORPORATION 3... - Page 4 Internet Wi-Fi Mode: Your device will connect to other WLAN device (hotspot device, wireless router, etc.) via Wi-Fi to access the Internet. The WLAN device has already connected to the Internet. 4 Confidential and Proprietary Information of ZTE CORPORATION...
-
Page 5: Installing Your Device
1. Slide the back cover and remove it 2. Insert the (U)SIM card. IMPORTANT: Your device does not support Micro/Nano or any other nonstandard SIM cards. To avoid device damage, please do not use them. Confidential and Proprietary Information of ZTE CORPORATION 5... -
Page 6: Connecting To Your Device
Connecting to Your Device Via Wi-Fi 1. Power on your device directly. It will take 1~2 minutes to initialize. 2. Use your normal Wi-Fi application on the client to search for the available wireless networks. 6 Confidential and Proprietary Information of ZTE CORPORATION... - Page 7 3. Select the SSID of your device, and then click Connect. NOTE: Please check the label on your device to get the default SSID. 4. Input the password, and then click Connect. Confidential and Proprietary Information of ZTE CORPORATION 7...
-
Page 8: Accessing The Internet
Internet directly. Log in the webGUI configuration page, and select Settings > Manual Network Settings > Network Selection > Manual (To change current setting, please disconnect from network), then Apply. 8 Confidential and Proprietary Information of ZTE CORPORATION... - Page 9 4. Connect to the Wi-Fi device. There are two methods for your reference. Input the Wi-Fi device information in the Wi-Fi Setting area, and then click Apply. Click for more help. Confidential and Proprietary Information of ZTE CORPORATION 9...
-
Page 10: Configuring Your Pc
Follow the following steps and figures for Windows XP to configure the Internet Protocol for your Wi-Fi connection. 1. Right-click My Network Places, and then select Properties. 2. Right-click Wireless Network Connection, and then select Properties. 3. Select Internet Protocol(TCP/IP), and then click Properties. 10 Confidential and Proprietary Information of ZTE CORPORATION... -
Page 11: Warning And Notice
• inside and outside your device, so don’t use it until it becomes dry. Handle your device carefully. Do not drop, bend or strike it. Otherwise your device will be damaged. • Confidential and Proprietary Information of ZTE CORPORATION 11... -
Page 12: Using Battery
ZTE shall not be liable for any loss of profits or indirect, special, incidental or consequential damages resulting from or arising out of or in connection with using of this product, whether or not ZTE had been advised, knew or should have known of the possibility of such damages, including, but not limited to lost profits, interruption of business, cost of capital, cost of substitute facilities or product, or any downtime cost. -
Page 13: Specific Absorption Rate (Sar)
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Confidential and Proprietary Information of ZTE CORPORATION 13... -
Page 14: Troubleshooting
If you changed the password and forgot the new password, you need to restore the device to the factory default settings. For more assistance, please: Send E-mail to mobile@zte.com.cn • Visit http://www.ztedevice.com • Call Service Hotline: +86–755–26779999 • 14 Confidential and Proprietary Information of ZTE CORPORATION... - Page 15 VODAFONE R209-Z Quick Guide Confidential and Proprietary Information of ZTE CORPORATION 15...
