Summary of Contents for Sharp Shuttle PN-SPCi5W7
- Page 1 PN-SPCi5W7H INSTALLATION GUIDE...
-
Page 2: Table Of Contents
CONTENTS INSTALLATION INSTRUCTIONS Computer Bracket Installation Power Adapter Bracket Installation Peripheral Connection SOFTWARE Power On-Off Instruction Windows 8 Language Options Recovery Partition COMPUTER HARDWARE Computer Specifications Warranty Statement Windows Product Key Location... -
Page 3: Installation Instructions
INSTALLATION INSTRUCTIONS COMPUTER BRACKET INSTALLATION: VESA Mount Instruction Remove the PC Media Player from the packaging and begin to remove the two thumb screws by twisting counter-clockwise. After removing the thumb screws, separate the PC Media Player from the VESA mount. You should have the PC Media Player in one hand and the VESA mount in the other. - Page 4 INSTALLATION INSTRUCTIONS Take the Computer and position the Power Button facing outwards. Place the bottom of the Computer on the two pins and push the top of the Computer into the VESA Mount. Now to install the Computer to the Aquos Board using the VESA Mount.
-
Page 5: Power Adapter Bracket Installation
INSTALLATION INSTRUCTIONS POWER ADAPTER BRACKET INSTALLATION Remove the Power Adapter Bracket from the Accessory box. Position the long solid edge inwards and the empty edge facing outwards. Screw the Power Adapter Bracket onto the available holes to the left of the panel. -
Page 6: Peripheral Connection
INSTALLATION INSTRUCTIONS PERIPHERAL CONNECTION GUIDE PN-L603A/B, PN-L703A/B Series RJ11 Installation RJ11 cable must be connected to the two pins furthest to the right above the power icon. Please insure that the yellow cable is on the top pin. -
Page 7: Software
SOFTWARE POWER ON-OFF INSTRUCTION GUIDE... -
Page 8: Windows 8 Language Options
SOFTWARE WINDOWS 8 LANGUAGE OPTIONS 1] Hover over the right corner of your screen and select the settings button. 2] Click Change PC Settings 3] Select Time and Language... - Page 9 SOFTWARE WINDOWS 8 LANGUAGE OPTIONS CONT. 4] Select Region and Language 5] Click on Add a Language 6] Select French Language...
- Page 10 SOFTWARE 7] Once the download completes, click on the language and set as primary. 8] Click the right corner of your tray and select French (Canada.)
-
Page 11: Recovery Partition
SOFTWARE RECOVERY PARTITION GUIDE Turn on the unit and when the boot screen appears, press F12. Next, the system will go into recover mode. Allow a few seconds for the files to load. Once the files are loaded, the Recovery Welcome Screen will appear. - Page 12 SOFTWARE Select the “Start WIN7 Recovery” button. Click “OK” to confirm process system recovery. Warning: Restoring your computer to the factory settings will remove all files and programs except those it came with. You will lose all personal files, including photos, emails and programs, if you do not back up your files and data.
-
Page 13: Computer Hardware
COMPUTER HARDWARE COMPUTER SPECIFICATIONS FRONT 1) Microphone Input 5) Power Button 2) Headphone Input 6) SD Card Reader 3) Power LED 7) 4 x USB 2.0 4) Hard Disk LED BACK A) 2 x WiFi Antenna H) 2 x USB 2.0 Input I) 2 x DisplayPort(DP) B) RS232/RS422/RS485... -
Page 14: Windows Product Key Location
COMPUTER HARDWARE WINDOWS PRODUCT KEY LOCATION Your Microsoft CD Key is an important item of your PC’s identity. This CD Key can be used when asking for technical support, reformatting the computer or showing authenticity of your Microsoft license. This guide will show you how to find your Microsoft CD Key.
