Summary of Contents for Bultaco BRINCO R
- Page 1 QUICK GUIDE BULTACO BRINCO R...
- Page 2 Index 1. Welcome kit 2. Know your Brinco 3. Get your Brinco ready 4. Drive and enjoy...
- Page 3 And Brinco is something completely new, ground-breaking, it is the result of the will to transfer the Bultaco spirit to a new era, with a new language, but always true to the classic brand values: passion, innovation, competition.
- Page 4 WELCOME KIT The Welcome Kit of your new Brinco contains the items listed below: Bultaco Battery Charger Brinco Wristband Key Bultaco Tools kit 2 Key Cards (includes keys to disassemble - Security Master battery and rear wheel) (marked with a yellow sticker)
- Page 5 KNOW YOUR BRINCO / OVERVIEW Front suspension adjustment Battery safety lock Battery connector Power Cell Li-Ion Matrix Battery Three phase permanent magnet motor DC/AC Three phase controller Overdrive Rear shifter To prevent the derailleur from coming loose, Implement Overdrive - Low Range Gearbox by pressing the button located always lean it on its left side.
- Page 6 KNOW YOUR BRINCO / HANDLEBAR CONTROLS Rear brake Front brake Dashboard WARNING handle lever IDENTIFY CORRECTLY BRAKES POSITIONING. The front brake lever is on the right. The rear brake lever is on the left handlebar grip. Always make sure, before switching ON your Brinco, that the accelerator returns correctly to its Shifter...
- Page 7 KNOW YOUR BRINCO / DASHBOARD WARNING Battery level Driving mode NFC Antenna to lock/unlock Speedometer your Brinco WARNING INDICATOR. Activation Indicator Flashing light: keep driving and enjoying your Brinco. The self-protection system will regulate the power delivery to decrease your Brinco’s level of demand.
- Page 8 GET YOUR BRINCO READY Before riding your Brinco, ensure everything works properly 1. Seat: adjust the height to your size 2. Handlbar: adjust the height to your size 3. Mechanical Components: make sure that all items are correctly set. 4. Brakes: adjust the position of the handles, check its operation and familiarise with the brake levers.
- Page 9 The following charger indicators will inform you about battery charge state: Unplug the power cord from Enter the key provided by Bultaco to the battery by hand turning the unlock the battery safety lock. connector housing a quarter turn...
- Page 10 DRIVE AND ENJOY Start riding your Moto- Bike in 5 simple steps First of all make sure that the stop button WARNING is in OFF position (pressed). 1. Put your key card on the rear side of the dashboard (warning light will be Always ride responsibly.
- Page 11 DRIVE AND ENJOY The Ultimate Brinco Dual traction: experience optimized riding Although the pedaling and motor systems are independent, combine both for enhanced riding pleasure. 3 riding modes: choose the one you like best ·Sport: (up to 50km*): maintaining every capacity ·Tour (up to 75 km)*: more range, but without giving up capacities ·Eco (up to 100 km*): gives you the greatest range, for longer rides.Use it on climbs, in combination with the pedals.
- Page 12 bultaco.com...
