- Page 1 Mini Component System Model: A X W - 2 1 7 A X W - 1 1 7 A M I - 9 2 6 LW/ R W AXW-217 AXW-117 AMI-926LW/RW DAEWOO ELECTRONICS CO., LTD. http : //svc.dwe.co.kr Sep. 2002...
-
Page 2: Table Of Contents
A X W - 1 1 7 A M I - 9 2 6 LW/ R W Table of Contents SAFETY PRECAUTIONS....................2 ADJUSTMENTS......................4 EXPLODED VIEW AND PARTS LIST .................6 AXW-217..............................6 AXW-117..............................8 AMI-926LW/RW..........................10 WIRING DIAGRAM ...................... 12 BLOCK DIAGRAM ......................13 SCHEMATIC DIAGRAM ....................14 MAIN..............................14 TUNER..............................15 TAPE..............................16... -
Page 3: Safety Precautions
Safety Precautions WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE laundry tub, in a wet basement, or near a swimming pool, THIS APPLIANCE TO RAIN OR MOISTURE. and the like. 2. Carts and Stands - The appliance PORTABLE CART CAUTION should be used only with a cart or RISK OF ELECTRIC SHOCKS... -
Page 4: Fig.2
Safety Precautions 13.Outdoor Antenna Grounding - If an outside antenna is 15.Object and Liquid Entry - Care should be taken so that objects do not fall and liquids are not spilled into the enclosure through connected to the receiver be sure the antenna system is openings. -
Page 5: Adjustments
Adjustments... -
Page 6: Tape Section
Adjustments 2. TAPE SECTION Output Level Measurement Input Point Scope Point 47 kohm R-CH VTVM Input Level Measurement Point L-CH 47 kohm Test Tape be used Tape Contents MTT-111N 3 KHz Tape Speed Adjustment MTT-114N 10 KHz Head Azimuth Adjustment MTT-5511 Blank Record Frequency Property... -
Page 7: Exploded View And Parts List
Exploded View and Mechanical Parts List Model : AXW-217... - Page 8 9CD1339000 ACRYL PCB CD KNOB FUNCTION 9CD1338900 ACRYL PCB JACK OPTION KNOB CONTROL 9CD1338800 PLATE FUNCTION 9CD0911100 PVC SHEET BADGE DAEWOO 9CD1500900 WINDOW FLT 9CD1616200 ACRYL CASSETTE DECK LOGIC 9CD6007800 ADR-243AMW 1 217 PANEL FRONT 9CD0307700 MIPS DOOR CD 9CD1811000...
-
Page 9: Axw-117
Exploded View and Mechanical Parts List Model : AXW-117 XL-115R... - Page 10 Exploded View and Mechanical Parts List Model : AXW-117 PARTS NAME PARTS CODE DESCRIPTION Q'TY REMARKS PARTS NAME PARTS CODE DESCRIPTION Q'TY REMARKS WINDOW DOOR "A" 9CD18173A0 ACRYL COVER SIDE "R" 9CD0410000 MIPS WINDOW DOOR "B" 9CD18173B0 ACRYL CHASSIS BOTTOM...
-
Page 11: Ami-926Lw/Rw
Exploded View and Mechanical Parts List Model : AMI-926LW/RW... - Page 12 DESCRIPTION REMARKS PARTS NAME PARTS CODE COVER ANT 9CD0410400 PANEL FRONT 9CD0307700 MIPS HOLDER PCB 9CD2304800 MIPS H926LW BADGE DAEWOO 9CD1500900 DOOR COVER A/B 9CD18109A0/B0 MIPS each1 BRACKET HEAT TR 9CD2414400 SUS 0.3T 726LW/826LW each1 BRACKET HEAT TR 9CD2414600 SECC 1.0T...
-
Page 13: Wiring Diagram
Wiring Diagram Model : AXW-217/ AXW-117/ AMI-926LW/RW... -
Page 14: Block Diagram
Block Diagram Model : AXW-217/ AXW-117/ AMI-926LW/RW... -
Page 15: Schematic Diagram
Schematic Diagram Model : AXW-217/ AXW-117/ AMI-926LW/RW Ass’y Name : MAIN... -
Page 16: Tuner
Schematic Diagram Model : AXW-217/ AXW-117/ AMI-926LW/RW Ass’y Name : TUNER V REG DECORDER COMP DRIVER VSS VT VT-IN FM/AM IF N.C AM/FM IF REQ AM OSC MUTE FM OSC X-IN ST/MO X-OUT... -
Page 17: Tape
Schematic Diagram Model : AXW-217/ AXW-117/ AMI-926LW/RW Ass’y Name : TAPE... - Page 18 Schematic Diagram Model : AXW-217/ AXW-117/ AMI-926LW/RW Ass’y Name : CD...
-
Page 19: Front(Axw-217)
Schematic Diagram Model : AXW-217 Ass’y Name : FRONT... - Page 20 Schematic Diagram Model : AXW-117 Ass’y Name : FRONT...
-
Page 21: Front(Ami-926Lw/Rw)
Schematic Diagram Model : AMI-926LW/RW Ass’y Name : FRONT... -
Page 22: Power
Schematic Diagram Model : AXW-217/ AXW-117/ AMI-926LW/RW Ass’y Name : POWER... -
Page 23: Pcb Pattern Layout
P.C.B Pattern Layout Model : AXW-217/ AXW-117/ AMI-926LW/RW Ass’y Name : MAIN PCB... - Page 24 P.C.B Pattern Layout Model : AXW-217/ AXW-117/ AMI-926LW/RW Model : AXW-217/ AXW-117/ AMI-926LW/RW Ass’y Name : POWER PCB Ass’y Name : TAPE PCB...
- Page 25 P.C.B Pattern Layout Model : AXW-217/ AXW-117/ AMI-926LW/RW Ass’y Name : CD PCB...
- Page 26 P.C.B Pattern Layout Model : AXW-217 Ass’y Name : FRONT PCB...
- Page 27 P.C.B Pattern Layout Model : AXW-117 Ass’y Name : FRONT PCB...
- Page 28 P.C.B Pattern Layout Model : AMI-926LW/RW Ass’y Name : FRONT PCB...
-
Page 29: Electrical Part List
Electrical Parts List Model : AXW-217/ AXW-117/AMI-926LW/RW MODEL MODEL PART-NAME LOCATION PART-CODE PART-DESC PART-NAME LOCATION PART-CODE PART-DESC AMI- AMI- -217 -117 926W -217 -117 926W PCB MAIN AS 10000 9CDC056904 AMI-926LW-SEMP 71 C ELECTRO CE812~813 CEXF1H479V 50V RSS 4.7MF (5X11) TP... - Page 30 Electrical Parts List Model : AXW-217/ AXW-117/AMI-926LW/RW MODEL MODEL PART-NAME LOCATION PART-CODE PART-DESC PART-NAME LOCATION PART-CODE PART-DESC AMI- AMI- -217 -117 926W -217 -117 926W 141 TR Q816 TKRC107M-- KRC 107-M (TAPPING) 211 R CARBON FILM R449~450 RD-AZ104J- 1/6 100K OHM J...
- Page 31 Electrical Parts List Model : AXW-217/ AXW-117/AMI-926LW/RW MODEL MODEL PART-NAME LOCATION PART-CODE PART-DESC PART-NAME LOCATION PART-CODE PART-DESC AMI- AMI- -217 -117 926W -217 -117 926W 20 C CERA CC532 CCXF1H473Z 50V F 0.047MF Z (TAPPING) 90 R CARBON FILM R544...
- Page 32 Electrical Parts List Model : AXW-217/ AXW-117/AMI-926LW/RW MODEL MODEL PART-NAME LOCATION PART-CODE PART-DESC PART-NAME LOCATION PART-CODE PART-DESC AMI- AMI- -217 -117 926W -217 -117 926W 41 IC IC701 1M38199280F U-COM M38199-280FP 111 R CARBON FILM R746 RD-AZ102J- 1/6 1K OHM J...
- Page 33 Electrical Parts List Model : AXW-217/ AXW-117/AMI-926LW/RW MODEL MODEL PART-NAME LOCATION PART-CODE PART-DESC PART-NAME LOCATION PART-CODE PART-DESC AMI- AMI- -217 -117 926W -217 -117 926W 34 CONN AS CN702 9728812100 FFC 16P P1.25X150MM R 104 R CARBON FILM R735~736 RD-AZ102J- 1/6 1K OHM J...
- Page 34 Electrical Parts List Model : AXW-217/ AXW-117/AMI-926LW/RW MODEL MODEL PART-NAME LOCATION PART-CODE PART-DESC PART-NAME LOCATION PART-CODE PART-DESC AMI- AMI- -217 -117 926W -217 -117 926W 24 C CERA CC726~727 CCXF1H223Z 50V F 0.022MF Z (TAPPING) 94 R CARBON FILM R332...
- Page 35 Electrical Parts List Model : AXW-217/ AXW-117/AMI-926LW/RW MODEL MODEL PART-NAME LOCATION PART-CODE PART-DESC PART-NAME LOCATION PART-CODE PART-DESC AMI- AMI- -217 -117 926W -217 -117 926W PCB POWER AS 13000 9CDC057103 AMI-926LW-SEMP 52 TR Q637 TZTA1266Y- KTA1266Y- (AUTO)(1015Y) CORD AC AC901...
