  • Page 1 USER'S GUIDE eGO-note Handheld PC SAMSUNG...
  • Page 2 Notice The information within this manual is subject to change without notice. The manufacturer shall not be held liable for technical or editorial errors or omissions contained in herein; nor for incidental or consequential damages resulting from the furnishing, performance or use of this material.
  • Page 3 • This computer is powered by an internal battery pack or by an external AC power source through an external AC adapter. Use of another battery pack or external AC adapter may present risk of fire or explosion. • This product is equipped with a 2-wire type plug. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet.

  • Page 4: Battery Disposal

    • Unplug this product from the wall outlet and refer problems to the service representative under the following conditions: - When the power cord or plug is damaged or frayed. - If liquid has been spilled into product. - If the product has been exposed to rain or water. - If the product does not operate normally when the operating instructions are followed, adjust only those controls that are covered by the operating Instructions.
  • Page 5 • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. If necessary, the user should consult the dealer or an experienced radio/ television technician for additional suggestions.

  • Page 6: Table Of Contents

    Special Features of Manual ............1 Using the Software User Documentation ........2 Introducing the eGO-note ..............3 Using the eGO-note for the First Time ........... 5 Installing the Rechargeable Battery Pack ........5 Turning On the eGO-note ............. 9 Tips for Using the eGO-note ............

  • Page 7: Using Your Documentation

    Using your Documentation Congratulation on your purchase of the Samsung eGO-note with Microsoft operating system, Windows CE HPC-pro(Handheld PC-Pro). Special Features of Manual Three types of messages with icons appear in the manual: A note informs you of special circumstances.

  • Page 8: Using The Software User Documentation

    Using the Software User Documentation The eGO-note shipped from the factory with several software programs installed. The software may include its own online or printed documentation. Refer to the documentation or the Help options in the software for more information.

  • Page 9: Introducing The Ego-Note

    Introducing the eGO-note The eGO-note is a lightweight handheld PC that includes features to meet your computing needs at home or on the road. Item Check list: • eGO-note • Case (Black) • Serial cable • Monitor cable • AC adapter •...
  • Page 10 Mic jack Headphone jack Battery USB port compartment Serial port Speaker AC adapter Video jack port Figure 2. Back View of eGO-note Docking Battery pack connector open latch Battery compartment Battery pack lock latch RAM Memory module compartment ROM Memory...

  • Page 11: Using The Ego-Note For The First Time

    AA size Alkaline battery pack and • AC adapter separate from the eGO-note. If you would like to use the eGO-note immediately, then install six AA size Alkaline batteries into the Alkaline battery pack. Installing the Rechargeable Battery Pack To install the rechargeable battery pack: 1.
  • Page 12 Figure 4. Installing the Rechargeable Battery Pack 4. Push the battery straight until it snaps into place. 5. Plug in the eGO-note with the eGO-note AC adapter. 6. Connect the power cord to the AC adapter and then to an electrical outlet.(Figure 5)
  • Page 13 The battery charges in about 3.5 hours either the eGO-note is turned on or off. If “Backup battery is low” message comes up, connect the AC adapter, or synchronize the eGO-note to your desktop computer to save data.
  • Page 14 2. Insert three Alkaline batteries first into the battery pack according to the direction of the indication. And insert other three Alkaline batteries in the opposite direction. The battery life varies with brands. We recommand you to use one of DURACELL ULTRA-MX1500(AA) or PANASONIC Alkaline batteries with this product.

  • Page 15: Turning On The Ego-Note

    Turning On the eGO-note The methods of turning on and setting the eGO-note’s power for the first time are explained here. 1. Push to the right and hold the cover latch on the front of the cover.

  • Page 16: Tips For Using The Ego-Note

    7. Fill your personal information in Owner Properties. Then a message tells you, “Setup is now complete.” and click Done. Now your eGO-note is set. If you want to make changes, click Start > Setting > Control Panel and use World Clock, Owner icons.

  • Page 17: Handling Spills

    Exposure to excessive heat may damage eGO-note components. If you have left your eGO-note in a hot place, let it cool down slowly to room temperature (with the LCD panel open) before using it.

  • Page 18: Storing The Ego-Note For Long Periods

    This helps extend the life of the battery and keeps the battery fully charged. If you will not be using the eGO-note for a long period of time (a month or more), you should charge the battery until it is completely full. After you have done so, remove the battery from the unit.

  • Page 19: Operating Notes

    This part will help you with understanding the basic usage of the eGO- note. Keyboard Your eGO-note has an 65-key keyboard. By pressing designated key combinations, you can have access to almost all the key functions of a full-sized keyboard.

  • Page 20: Touchpad

    Contrast down: Decreases the LCD contrast. Touchpad Your eGO-note is equipped with a touchpad, which is an integrated- pointing device that is used to perform standard mouse functions (Figure 10). The touchpad is an advanced and reliable pointing device that works with a touch of your finger.

  • Page 21: Indicator Lights

    Devices”. Indicator lights System Status lights show the status of battery charge and alarm functions. The lights appear on the left edge of the eGO-note (Figure 11). Figure 11. Indicator lights Battery charge light: When the power cord is connected, light gives information about the battery charge.

  • Page 22: Voice Recording

    See Microsoft Windows CE User’s Guide for more information about Voice Recording. Infrared Communications You can use infrared(IR) beaming for wireless transfer of information between the eGO-note and another eGO-note, or any other notebook PC that is IR-ready. To use infrared beaming: 16 User’s Manual...

  • Page 23: Battery Management

    • Position the eGO-note IR port and the IR port of the other device so that they are lined up and within three feet (one meter) of each other without blocking. • Turn off fluorescent lights in the immediate area or move to a location with different lighting.

  • Page 24: Connecting Peripheral Devices

    Connecting Peripheral Devices The connectors on the eGO-note enables you to attach peripheral devices to the eGO-note.(Figure 13) Turn off your eGO-note before you connect a Video cable. Connecting a Video cable with your eGO-note turned on may seriously damage the connected device or your eGO- note.

  • Page 25: Connecting Modem

    Port replicator is optional good. The port replicator is optional. If you order a port replicator, please refer to a port replicator user’s guide. Connecting Modem The eGO-note integrated 56K soft modem with RJ_11 connector. Connecting Peripheral Devices 19...

  • Page 26: Port Replicator (Optional)

    Refer to the Windows CE user’s Guide for the system setting for the modem. Port replicator (Optional) The eGO-note is expandable by connecting a port replicator. You have to purchase a port replicator for it is optional product. Make sure to power off the eGO-note before connecting a port replicator.
  • Page 27 2. Press eject buttons on side edge of a port replicator. (Figure 16) Locking hook Eject Eject Button Button Figure 16. Pressing the eject buttons on a Port replicator 3. Place the eGO-note straight on a port replicator and press firmly. Then eject buttons pops out.(Figure 17) Connecting Peripheral Devices 21...
  • Page 28 Figure 17. Connecting the eGO-note to a Port replicator 4. Connect the AC adapter on back of a port replicator. Connect the serial cable to a serial port on a port replicator when the eGO-note is with a port replicator.

  • Page 29: Synchronizing The Ego-Note With A Computer

    Synchronizing the eGO-note with a Computer You can synchronize the eGO-note and a desktop PC to make the up-to date information. To connect the eGO-note and a PC and set a PC: 1. Connect the serial cable to the serial port on the eGO-note and the other side of the cable to the serial port on the a PC.
  • Page 30 Mobile Devices window with the message “Connected, Up- to-date” in the lower right corner. During installation, Windows CE Services places a Mobile Devices shortcut on the eGO-note. For details about the Mobile Devices program window, see the Microsoft handheld PC-professional User’s Guide .

  • Page 31: Upgrading The Ego-Note

    By installing PC Cards, you can add functions to the eGO-note similar to notebook computers. You can install Type I or II cards in the slots to the eGO-note. And you can install PC Cards while the eGO-note is on.

  • Page 32: Cf Card (Compact Flash Data Storage Card)

    Windows CE automatically assigns eGO-note’s resources (such as communication ports and memory addresses) to a PC Card installed in your eGO-note. For further information on configuring a PC Card in Windows CE, see the user’ documentation. CF Card (Compact Flash data storage Card)

  • Page 33: Memory Module

    You can increase the memory by installing an optional memory module. 16 MB RAM is on board and upgradable to 48 MB. To avoid possible system problems, use only approved memory module in your eGO-note. Before You Install Memory Back up your data before increasing a memory module by synchronizing with a general computer.

  • Page 34: Installing A Memory Module

    • Before you remove the memory module compartment door, turn off the eGO-note, unplug the power cord, and remove the battery. Also, disconnect any peripheral devices. • Before handling a memory module, discharge any static electricity by touching a grounded surface or using a grounding wrist strap.
  • Page 35 Figure 24. Installing a Memory Module 6. Align a memory module compartment door and push the door down until it snaps into place. 7. Reinstall the screw you removed. 8. Follow the information of the enclosed documentation with a memory module. Upgrading the eGO-note 29...

  • Page 36: Troubleshooting

    Troubleshooting If you have difficulty running the eGO-note, follow these steps: 1. Consult the following sections for advice on how to handle HPC problems or Window CE user’s guide. 2. If steps 1 does not help you to resolve the problem, contact your reseller for assistance.
  • Page 37 • Remove AC adapter and the battery pack for few seconds, then connect it and wait for 5 seconds before turn the power on. The battery doesn’t last long enough. • See “Battery Management” on page 17. Troubleshooting 31...

  • Page 38: Specifications

    Specifications Table 4 gives the specifications for your eGO-note. Table 4. System Specifications Dimension Width 8.9 in (227 mm) Height 1.1 in (28 mm) Depth 7.76 in (197 mm) Weight (with Li-Ion battery) 2.4 lb (1090 g) LCD viewing area (8.03 DSTN) 6.7 x 4.93 in (167 x 125.3 mm)
  • Page 39 External AC Adapter Operating voltage 100 VAC to 240 VAC Line frequency 50-60 Hz Input current 0.5 A 100 V—0.23 A 240 V Output current 2.0 A Output voltage 10 VDC Specifications 33...
