Lock/Arm
Check with your installation center for features and functions operational on your system.
To Operate System:
1) Press the lock button to lock the doors and arm the alarm if installed.
2) Press the unlock button to unlock the doors and disarm the alarm if installed.
3) Press and hold the Trunk/Start button for 3 seconds to unlock the trunk.
4) Press the Trunk/Start button two times in succession to start the vehicle. The vehicle will start
and run the predetermined time set up during installation (5 to 60 minutes selectable).
Anytime during the run cycle, enter the vehicle by first unlocking the doors with your transmitter,
insert your key and turn it to the run, NOT START, position, then step on the brake, the vehicle is
now in control of the ignition key.
NOTE: For push to start vehicles contact your installation center for proper procedure.
Consult your installation center for operation and information on convenience options 1 & 2
which may have been connected or added to your vehicle.
PATENTED: www.voxxintl.com/company/patents
Model PE1M2LCD
Operators Manual
RF Upgrade Kit
PRESTIGE
S
24
A
Trunk Release/ Remote Start
1 2
Z
Z
Option
F Function Button
IGN
INHIBIT
AM
PM
Unlock/Disarm
128-9484
Page 1

Advertisement

loading

Related Manuals for Prestige PE1M2LCD

Summary of Contents for Prestige PE1M2LCD

  • Page 1 Model PE1M2LCD Operators Manual RF Upgrade Kit PRESTIGE Trunk Release/ Remote Start Option F Function Button INHIBIT Lock/Arm Unlock/Disarm Check with your installation center for features and functions operational on your system. To Operate System: 1) Press the lock button to lock the doors and arm the alarm if installed.
  • Page 2 24 Hour Start Timer Active (21) Battery Save Indicator (20) (1) Vibrate Mode On (2) Transmit Icon Battery Charge Indicator (19) PRESTIGE (3) Siren Chirps Active Or Inactive Sensor Activated Indication (18) (4) Lock or Unlock Indicator Prime or Secondary Car Mode (17)
  • Page 3 TRANSMITTER TRANSMITTER ICON TONE/VIBRATE FUNCTION BUTTON DISPLAYED SELECTION PRESS FOR 18:88 TIMING ADJUST 2 BEEP TONES 5 SECONDS MODE (HRS) TIMING ADJUST 18:88 USE KEY BUTTON OR OPTION PRESS 1X MODE (MINS) BUTTON TO SELECT ALARM CLOCK 18:88 USE KEY BUTTON OR OPTION PRESS 2X ADJUST MODE (HRS) BUTTON TO SELECT...
  • Page 4 ADDITIONAL REMOTE FEATURES: The two way remote control unit allows you to access status information from the vehicle, check temperature, light the display, toggle the transmitter from beep tones to vibrate mode, initiate daily start timer, and temperature start. Selection of these and other features are shown below: NOTE: Transmitter must be within operating range of the vehicle, approximately 2500ft.

  • Page 5: Battery Indicator

    NOTE: To insure accurate 24 Hour Start up, it is advisable to reset the start time periodically as time may drift slightly each day. Timing Count Down The unit offers an additional count down timer for situations where an alert tone may be needed to remind you of something important.

  • Page 6: Alarm Clock

    ALARM CLOCK This icon will be toggled on and off when the “F” + Trunk/Key buttons are pressed simul- taneously. The feature must be set in the feature selection menu of the transmitter. COUNT DOWN TIMER The unit offers an additional count down timer for situations where an alert tone may be needed to remind you of something important.
  • Page 7 The one way transmitter included with this kit operates in a similar fashion as the two way trans- mitter with respect to the buttons and are shown below for your reference. Lock Button Press once to lock and arm alarm. Unlock Button Press and hold 3 seconds for panic alarm where applicable...
  • Page 8 (Alarm & Keyless Systems Only) PROGRAMMING YOUR CUSTOM OVERRIDE CODE Unlike override switches easily found, and defeated, this security system allows the consumer to program a personal override code, offering a higher level of security. To take advantage of this option, programmable feature # 9 must be selected for the Custom Code Option.

  • Page 9: Remote Starting The Vehicle

    (Alarm Systems Only) MANUALLY OVERRIDING YOUR SYSTEM: USING THE CUSTOM CODE OVERRIDE Assuming the override code programmed has not been changed, and the default override code of 11 is in the system’s memory. 1) Enter the vehicle and turn the ignition switch to the on position. NOTE: The siren will sound.
  • Page 10 OPERATING ON AUTOMATIC START UP TIMER MODE Your system has the ability to automatically start the vehicle every 2 or 4 hours over a 48 hour period. This feature is especially useful in cold climates where the only means to keep the engine and engine fluids warm is to periodically start the engine.
  • Page 11 From step 3 above: a) Press and release the valet/programming button 3 additional times to get to channel 4, then Press any unused transmitter button or button combination to program channel 4. b) From a, press and release the valet/programming button 1 time to get to channel 5, then press any unused transmitter button or button combination to program channel 5 c) From b, press and release the valet/programming button 1 time to get to channel 6, then press any unused transmitter button or button combination to program channel 6 .

  • Page 12: Fcc Compliance

    To purchase replacement transmitters or to get additional product information go to: www.prestigecarsecurity.com FCC COMPLIANCE This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
