IMPORTANT MANUAL
OWNER'S MANUAL
MODEL NUMBER:
PP11H30ES

SNOW THROWER

Always Wear Eye Protection During Operation
Do Not Throw Away
WARNING:
Read the Owner's Manual and
fol low all Warnings and Safety
In struc tions. Fail ure to do so
can result in serious injury.
408373 08.16.06 BY
Printed in U.S.A.

Advertisement

Table of Contents
loading

Related Manuals for Poulan Pro 408373

Summary of Contents for Poulan Pro 408373

  • Page 1: Snow Thrower

    Always Wear Eye Protection During Operation Do Not Throw Away WARNING: Read the Owner's Manual and fol low all Warnings and Safety In struc tions. Fail ure to do so can result in serious injury. 408373 08.16.06 BY Printed in U.S.A.

  • Page 2: Safety Rules

    Safe Operation Practices for Walk-Behind Snow Throwers This snow thrower is capable of amputating hands and feet and throwing objects. Failure to observe the following safety instructions could result in serious injury. Look for this symbol to point out im- por tant safety precautions.

  • Page 3: Table Of Contents

    6. When cleaning, repairing or inspecting the snow thrower, stop the engine and make certain the collector/impeller and all moving parts have stopped. Disconnect the spark plug wire and keep the wire away from the plug to prevent someone from accidentally starting the en- gine.
  • Page 4 PARTS PACKED SEPARATELY IN CARTON...

  • Page 5: Assembly / Pre-Operation

    ASSEMBLY / PRE-OPERATION Read these instructions and this manual in its entirety before you attempt to assemble or operate your new snow thrower. Reading the entire manual will familiar- ize you with the unit, which will assist you in assembly, operation and maintenance of the product.
  • Page 6 ASSEMBLY / PRE-OPERATION INSTALL TRACTION DRIVE CONTROL ROD (See Figs. 3 and 4) The traction drive control rod has the long loop on the end of the spring as shown. 1. Slide rubber sleeve up rod and hook end of spring into eye of cable with loop opening down as shown.

  • Page 7: Assembly / Pre-Operation

    ASSEMBLY / PRE-OPERATION INSTALL DISCHARGE CHUTE / CHUTE ROTATOR HEAD (See Fig. 7) NOTE: The multi-wrench provided in your parts bag may be used to install the chute rotator head. 1. Place discharge chute assembly on top of chute base with discharge opening toward front of snow thrower.

  • Page 8: Operation

    OPERATION KNOW YOUR SNOW THROWER READ THIS OWNER'S MANUAL AND ALL SAFETY RULES BEFORE OPERATING YOUR SNOW THROWER. Compare the illustrations with your snow thrower to familiarize yourself with the location of various controls and adjustments. Save this manual for future reference. These symbols may appear on your snow thrower or in literature supplied with the product.
  • Page 9 SPARK PLUG SAFETY IGNITION CHOKE CON- TROL THROTTLE / ENGINE CONTROL RECOIL POWER (AUXILIARY) CORD STARTER PLUG ELECTRIC HANDLE START BUTTON PRIM ER NOTE: ITEMS ABOVE ARE SHOWN IN THEIR TYPICAL LOCATION ON THE ENGINE. ACTUAL LOCATION MAY VARY WITH THE ENGINE ON YOUR UNIT.
  • Page 10 The operation of any snow thrower can result in foreign objects thrown into the eyes, which can result in severe eye damage. Always wear safety glasses or eye shields while operating your snow thrower or performing any ad just - 00155 ments or repairs.

  • Page 11: To Move Forward And Backward

    AUGER CONTROL LEVER FIG. 15 USING THE CLEAN-OUT TOOL (See Fig. 16) In certain snow conditions, the discharge chute may be- come clogged with ice and snow. Use the clean-out tool to dislodge this blockage. When cleaning, repairing, or in spect ing, make certain all controls are disengaged and the auger/impeller and all moving parts have stopped.

  • Page 12: Before Starting The Engine

    1. Shut off engine and wait for all moving parts to stop. 2. Adjust skid plates by loosening the rear 1/2" hex nut only, then moving skid plate to desired position. Be sure both plates are adjusted evenly. Tighten securely. HIGH POSITION (LOW GROUND CLEARANCE)
  • Page 13 • Be sure your house is a 120 Volt A.C. three-wire ground ed system. If you are uncertain, consult a li censed electrician. WARNING: Do not use the electric start er if your house is not a 120 Volt A.C. three-wire grounded system. Se- ri ous per son al injury or damage to your snow thrower could result.

  • Page 14: Maintenance

    GENERAL REC OM MEN DA TIONS The warranty on this snow thrower does not cover items that have been sub ject ed to operator abuse or negligence. To receive full value from the warranty, operator must maintain snow thrower as in struct ed in this manual. Some ad just - ments will need to be made periodically to properly maintain your snow thrower.

  • Page 15: To Change Engine Oil

    AUGER GEAR CASE • The gear case was fi lled with lubricant to the proper level at the factory. The only time the lubricant needs attention is if service has been performed on the gear case. • If lubricant is required, use only Ronex ED #1 grease.

  • Page 16: Service And Adjustments

    SERVICE AND ADJUSTMENTS WARNING: To avoid serious injury, before performing any service or ad just ments: 1. Be sure throttle is in STOP position. 2. Remove safety ignition key. 3. Make sure the augers and all mov ing parts have completely stopped. 4.

  • Page 17: Service And Adjustments

    SERVICE AND ADJUSTMENTS WARNING: Belt replacement requires separation of the snow thrower. While separating the auger housing from the frame assembly, it is important that an assistant stand in the operating po si tion and hold the snow thrower han dles. Se- rious personal injury and/or damage to the unit could occur if the snow thrower should fall during the belt chang ing...

  • Page 18: Storage

    SERVICE AND ADJUSTMENTS ENGINE See engine manual. CARBURETOR Your carburetor is not adjustable. Engine performance should not be affected at altitudes up to 7,000 feet (2,134 meters). If your engine does not operate properly due to suspected carburetor problems, take your snow thrower to a qualifi...

  • Page 19: Troubleshooting

    TROUBLESHOOTING See appropriate section in manual unless directed to a qualifi ed service centre. PROBLEM CAUSE Does not start 1. Fuel shut-off valve (if so equipped) in OFF position. 2. Safety ignition key is not inserted. 3. Out of fuel. 4.

  • Page 20: Repair Parts

    REPAIR PARTS SNOW THROWER - MODEL PP11H30ES (96192001401) AUGER HOUSING / IMPELLER ASSEMBLY...
  • Page 21 REPAIR PARTS AUGER HOUSING / IMPELLER ASSEMBLY KEY PART DESCRIPTION 191079 Pulley, Impeller 188909 Bearing Assembly, Flange 198541 Nut, Hex Flange 5/16-18 180355 Bolt, Flat Head, Carriage 5/16-18 x 5/8 72270505 Bolt, Carriage 5/16-18 199879 Bolt, Hex Head 404927X428 Housing, Auger 404933X479 Bar, Scraper 178675X008...
  • Page 22 REPAIR PARTS SNOW THROWER - MODEL PP11H30ES (96192001401) CONTROL PANEL / DISCHARGE CHUTE...
  • Page 23 REPAIR PARTS CONTROL PANEL / DISCHARGE CHUTE KEY PART NOTE: All component dimensions given in U.S. inches. IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts. Failure to do so could be hazardous, damage your snow thrower and void your warranty. SNOW THROWER - MODEL PP11H30ES (96192001401) DESCRIPTION 183334...
  • Page 24 REPAIR PARTS SNOW THROWER - MODEL PP11H30ES (96192001401) HANDLES...
  • Page 25 REPAIR PARTS HANDLES KEY PART NOTE: All component dimensions given in U.S. inches. IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts. Failure to do so could be hazardous, damage your snow thrower and void your warranty. SNOW THROWER - MODEL PP11H30ES (96192001401) DESCRIPTION 405999X479 Lever, Auger Control, RH...
  • Page 26 REPAIR PARTS DRIVE SNOW THROWER - MODEL PP11H30ES (96192001401)
  • Page 27 REPAIR PARTS DRIVE KEY PART NOTE: All component dimensions given in U.S. inches. IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts. Failure to do so could be hazardous, damage your snow thrower and void your warranty. SNOW THROWER - MODEL PP11H30ES (96192001401) DESCRIPTION 198584 Screw, Hex Head 5/16-18 x 1/2...
  • Page 28 REPAIR PARTS SNOW THROWER - MODEL PP11H30ES (96192001401) CHASSIS / ENGINE / PULLEYS...
  • Page 29 REPAIR PARTS CHASSIS / ENGINE / PULLEYS KEY PART NOTE: All component dimensions given in U.S. inches. IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts. Failure to do so could be hazardous, damage your snow thrower and void your warranty. SNOW THROWER - MODEL PP11H30ES (96192001401) DESCRIPTION 192873...
  • Page 30 REPAIR PARTS WHEELS / DECALS SNOW THROWER - MODEL PP11H30ES (96192001401)

  • Page 31: Repair Parts

    Wheel Assembly, 16", Power Steering, RH Clip, Retainer Ring, Retaining Screw, Hex Head, Tapping 5/16-18 x 5/8 DESCRIPTION Decal, Danger Decal, Poulan Pro, 11 HP / 30" Decal, Danger, Defl ector Decal, Danger Decal, Poulan Pro Decal, Instruction Decal, Traction Lever...

  • Page 32: Warranty

    This is a limited Warranty within the meaning of that term as defi ned in the Magnuson-Moss Act of 1975. LIMITED WARRANTY In Canada contact: Poulan Pro, Customer Service Department 5855 Terry Fox Way Mississauga, Ontario L5V 3E4...
