  • Page 1 Quick Guide © 2017 ZOOM CORPORATION Copying or reprinting this manual in part or in whole without permission is prohibited. Product names, registered trademarks and company names in this document are the property of their respective companies. All trademarks and registered trademarks in this document are for identification...
  • Page 2 Introduction Thank you very much for purchasing a ZOOM LiveTrak L-12 ( ). The has the following features. 12-channel digital mixer & multitrack recorder combines a digital mixer with 12 total input channels (8 mono and 2 stereo), a multitrack recorder that can simultaneously record up to 14 tracks, and a 14-in/4-out USB audio interface.

  • Page 3: Quick Start

    Quick start Turning the unit on 2 、 6 1 、 7 Confirm that the output devices connected to the are turned off.
  • Page 4 Quick start Confirm that is set to OFF . Plug the AD-19 adapter designed for this unit into an outlet. Set all knobs and faders to their minimum values. Connect instruments, mics, speakers and other equipment. HINT See P .20 for connection examples. to ON.

  • Page 5: Setting The Date And Time

    Quick start Setting the date and time 2 、 3 Press This opens the display MENU screen. Select SYSTEM > DATE/TIME. Move cursor: Turn Confirm: Press Set the date and time. Move cursor or change value: Turn Select item/confirm change: Press Press The first time you turn the power on after purchase, you must set the date/ time.

  • Page 6: Outputting Input Sounds From Output Devices

    Quick start Outputting input sounds from output devices Outputting sound from speakers 3 、 5 to adjust the input signals while inputting sound from instru- ments and mics. NOTE Set them so that SIG indicators do not light red. SIG indicator Turn off (unlit) for the MASTER and the channels with sound you want to output.
  • Page 7 Quick start Outputting sound from headphones ［MONITOR OUT PHONES A］端子 ［MONITOR OUT A PHONES］ノブ ［MONITOR OUT A］スイッチ Connect headphones to the MONITOR OUT PHONES A jack. to MASTER ( to adjust the volume.

  • Page 8: Adjusting The Tone And Panning

    Quick start Adjusting the tone and panning Press to light it for the channel for which you want to adjust tone and panning. Use the knobs and buttons to adjust the tone and panning. Adjusting the tone: Adjusting the panning: NOTE •...

  • Page 9: Using The Built-In Effects

    Quick start Using the built-in effects has 16 types of send effects 3 、 6 Turn to select the effect type, and press to confirm. Lit: Effect selected Press to turn it off, unmuting the EFX RETURN. Set the SEND EFX RETURN fader to 0. Press the for the channel that you want to use the effect on to light...
  • Page 10 Quick start to adjust the amount for each channel. Use the SEND EFX RETURN fader to adjust the overall effect amount. to adjust the send effect parameters. NOTE See Online Reference for the parameters of each effect that can be adjusted by...

  • Page 11: Preparing To Record

    Quick start Preparing to record Inserting SD cards to OFF . Open the SD card slot cover, and insert an SD card all the way into the slot. To remove an SD card, push it further into the slot and then pull it out. NOTE •...
  • Page 12 Quick start Creating new projects manages recording and playback data in units called projects. Press This opens the display MENU screen. Select PROJECT > NEW PROJECT. Move cursor: Turn Confirm: Press to select YES,and press NOTE • When a new project is created, it will start with the current mixer settings. HINT •...
  • Page 13 Quick start Recording and playing tracks has recorder functions that enable simultaneous recording of up to 14 tracks and simultaneous playback of up to 12 tracks. The signals from every channel after they pass through their compressors and from the master fader output can be recorded. These recordings can also be played back.
  • Page 14 Quick start Press to start recording standby. HINT If a recorded file already exists, and is off, pressing will create a new project and then start re- cording standby. Press to start recording. Press to stop recording. NOTE • The signals for each channel are recorded after passing through their compressors. •...

  • Page 15: To Stop Playback

    Quick start Playing recordings Press for the channels you want to play, lighting these buttons green. Press to start playback. PLAY/PAUSE indicator Lit: Playing back Blinking: Paused Press to stop playback. NOTE • Playback signals are added before the equalizer section, so their EQ and panning settings can be adjusted during playback.

  • Page 16: Turning The Power Off

    Quick start Turning the power off Minimize the volume of devices connected to the Turn off the power of output devices connected to the to OFF . The following screens appear and the power turns off. NOTE When the power is turned off, the current mixer settings are saved in the project on the SD card. If they can- not be saved to the SD card, they will be saved in the unit.
  • Page 18 ZOOM CORPORATION 4-4-3 Kanda-surugadai, Chiyoda-ku, Tokyo 101-0062 Japan http://www.zoom.co.jp xxx-xxxx-xx...
