IMPORTANT MANUAL
OPERATOR'S MANUAL
MODEL:
PP21H42
LAWN TRACTOR
ALWAYS WEAR EYE PROTECTION DURING OPERATION
Visit our website: www.poulan-pro.com
532 40 36-87 Rev. 3 06.30.08 SBW
Do Not Throw Away
03076
WARNING:
Read this Man u al and follow all Warnings
and Safety Instructions. Fail ure to do so can
re sult in serious in ju ry.
Printed in the U.S.A.
Advertisement
Table of Contents
Related Manuals for Poulan Pro 532 40 36-87
Summary of Contents for Poulan Pro 532 40 36-87
- Page 1 MODEL: PP21H42 LAWN TRACTOR ALWAYS WEAR EYE PROTECTION DURING OPERATION Visit our website: www.poulan-pro.com 532 40 36-87 Rev. 3 06.30.08 SBW Do Not Throw Away 03076 WARNING: Read this Man u al and follow all Warnings and Safety Instructions. Fail ure to do so can re sult in serious in ju ry.
-
Page 2: Safety Rules
Safe Operation Practices for Ride-On Mowers DANGER: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROW ING OBJECTS. FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH. WARNING: In order to prevent ac- ci den tal starting when setting up, trans port ing, ad just ing or making re- pairs, al ways dis con nect spark plug... - Page 3 Safe Operation Practices for Ride-On Mowers III. CHILDREN Tragic accidents can occur if the operator is not alert to the presence of children. Children are often attracted to the ma chine and the mowing activity. Never assume that children will remain where you last saw them. •...
-
Page 4: Table Of Contents
PRODUCT SPECIFICATIONS Gasoline Capacity 4.0 Gallons and type: Unleaded Regular Oil Type (API-SG-SL): SAE 30 (above 32°F) SAE 5W-30 (below 32°F) Oil Capacity: W/Filter: W/O Filter: 60 oz. Spark Plug: Champion QC12YC (Gap: .040") Ground Speed (MPH): Forward: Reverse: Charging System: 3 Amps Battery 5 Amps Headlights Battery:... -
Page 5: Unassembled Parts
UNASSEMBLED PARTS Steering Wheel Steering Wheel Insert (1) Hex Bolt 5/16-18 x 4 Steering Wheel Adapter (1) Seat (1) Oil Drain Tube For Future Use Keys (2) Keys (1) Large Flat Washer (1) 5/16 Lock Washer Steering Boot Seat (1) Washer (1) Knob Slope Sheet Steering... -
Page 6: Assembly
Your new tractor has been assembled at the factory with exception of those parts left unassembled for shipping purposes. To ensure safe and proper operation of your tractor all parts and hardware you assemble must be tightened securely. Use the correct tools as necessary to insure proper tightness. TOOLS REQUIRED FOR ASSEMBLY A socket wrench set will make assembly easier. -
Page 7: Assemble Gauge Wheels To Mower
SEAT SEAT PAN FLAT WASHER ADJUSTMENT KNOB FIG. 2 CONNECT BATTERY (See Fig. 3) CAUTION: Do not short battery termi- nals by allowing a wrench or any other object to contact both terminals at the same time. Before connecting battery, remove metal bracelets, wristwatch bands, rings, etc. - Page 8 RETAINER SPRING SHOULDER BOLT AD JUST ING GAUGE WHEEL 3/8 WASH ER FIG. 4 CHECK TIRE PRESSURE The tires on your tractor were overinflated at the factory for shipping purposes. Correct tire pressure is important for best cutting performance. • Reduce tire pressure to PSI shown on tires.
-
Page 9: Operation
These symbols may appear on your tractor or in literature supplied with the product. Learn and understand their meaning. REVERSE NEUTRAL REVERSE ENGINE OFF OPERATION SYSTEM (ROS) LIGHTS ON BATTERY FUEL ATTACHMENT ATTACHMENT CLUTCH DISENGAGED CLUTCH ENGAGED FREE WHEEL (Automatic Models only) Failure to follow instructions could result in serious injury or death. - Page 10 KNOW YOUR TRACTOR READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TRACTOR Compare the illustrations with your tractor to familiarize yourself with the locations of various controls and ad just ments. Save this manual for future reference. SERVICE CHOKE CONTROL REMINDER/HOURMETER...
-
Page 11: How To Use Your Tractor
The operation of any tractor can result in foreign objects thrown into the eyes, which can result in severe eye dam age. Always wear safety glass es or eye shields while op- erating your tractor or per form ing any adjustments or repairs. We rec om mend a wide vision safety mask over spectacles or stan dard safety glasses. - Page 12 TO USE THROTTLE CONTROL (See Fig. 5) Always operate engine at full speed (fast). • Operating engine at less than full speed (fast) reduces engine's operating efficiency. • Full speed (fast) of fers the best mower per for mance. TO MOVE FORWARD AND BACKWARD The direction and speed of movement is controlled by the forward and reverse drive pedals.
- Page 13 CAUTION: Do not operate the mower without either the en tire grass catcher, on mowers so equipped, or the deflector shield in place. REVERSE OPERATION SYSTEM (ROS) (See Fig. 9) Your tractor is equipped with a Reverse Operation System (ROS). Any attempt by the operator to travel in the reverse direc- tion with the attachment clutch engaged will shut off the engine unless ignition key is placed in the ROS "ON"...
-
Page 14: Before Starting The Engine
BEFORE STARTING THE ENGINE CHECK ENGINE OIL LEVEL The engine in your tractor has been shipped, from the factory, already filled with sum mer weight oil. • Check engine oil with tractor on level ground. • Remove oil fill cap/dipstick and wipe clean, reinsert the dipstick and screw cap tight, wait for a few seconds, remove and read oil level. -
Page 15: Operation
• Place tractor safely on a level surface - that is clear and open - with engine off and parking brake set. • Disengage transmission by placing freewheel control in freewheeling position (See “TO TRANSPORT” in this section of manual). •... -
Page 16: Maintenance Schedule
MAINTENANCE SCHEDULE Check Brake Operation Check Tire Pressure Check Operator Presence & ROS Systems Check for Loose Fasteners Check/Replace Mower Blades Lubrication Chart Check Battery Level Clean Battery and Terminals Check Transaxle Cooling Check Mower Levelness Check V-Belts Check Engine Oil Level Change Engine Oil (with oil filter) Change Engine Oil (without oil filter) Clean Air Filter... -
Page 17: Maintenance
TRACTOR Always observe safety rules when per form ing any main- te nance. BRAKE OPERATION If tractor requires more than five (5) feet to stop at highest speed in high est gear on a level, dry concrete or paved surface, then brake must be checked and ad just ed. (See “TO ADJUST BRAKE”... -
Page 18: Clean Air Screen
TO CLEAN BATTERY AND TERMINALS Corrosion and dirt on the battery and terminals can cause the battery to “leak” power. • Remove terminal guard. • Disconnect BLACK battery cable first then RED bat- tery cable and remove battery from tractor. •... - Page 19 CLEAN AIR INTAKE/COOLING AREAS To insure proper cooling, make sure the grass screen, cooling fins, and other external surfaces of the engine are kept clean at all times. Every 100 hours of operation (more often under extremely dusty, dirty conditions), remove the blower housing and other cooling shrouds.
-
Page 20: Service And Adjustments
SERVICE AND ADJUSTMENTS WARNING: TO AVOID SERIOUS INJURY, BEFORE PERFORMING ANY SER VICE OR AD JUST MENTS: • Depress brake pedal fully and set parking brake. • Place attachment clutch in “DISENGAGED” position. • Turn ignition key to “STOP” and remove key. •... -
Page 21: Service And Adjustments
SERVICE AND ADJUSTMENTS SIDE-TO-SIDE ADJUSTMENT (See Fig. 17) • Raise mower to its highest position. • At the midpoint of both sides of mower, measure height from bot tom edge of mower to ground. Distance “A” on both sides of mower should be the same or within 1/4"... - Page 22 SERVICE AND ADJUSTMENTS BELT REMOVAL - • Remove mower from tractor (See “TO REMOVE MOW ER” in this section of this manual). • Work belt off both mandrel pulleys and idler pulleys. • Pull belt away from mower. BELT INSTALLATION - •...
-
Page 23: Interlocks And Relays
SERVICE AND ADJUSTMENTS TRANSMISSION REMOVAL/REPLACEMENT Should your transmission require removal for service or replacement, it should be purged after reinstallation and before operating the tractor. See “PURGE TRANS MIS SION” in the Operation section of this manual. TO ADJUST STEERING WHEEL ALIGNMENT If steering wheel crossbars are not horizontal (left to right) when wheels are positioned straight forward, remove steer-... -
Page 24: Service And Ad Just Ments
SERVICE AND ADJUSTMENTS TO REPLACE FUSE Replace with 20 amp automotive-type plug-in fuse. The fuse holder is located behind the dash. TO REMOVE HOOD AND GRILL ASSEMBLY (See Fig. 26) • Raise hood. • Unsnap headlight wire connector. • Stand in front of tractor. Grasp hood at sides, tilt toward engine and lift off of tractor. -
Page 25: Storage
Immediately prepare your tractor for storage at the end of the season or if the tractor will not be used for 30 days or more. WARNING: Never store the trac tor with gas o line in the tank inside a building where fumes may reach an open flame or spark. -
Page 26: Trou Ble Shoot Ing
TROUBLESHOOTING POINTS PROBLEM CAUSE Will not start Out of fuel. Engine not “CHOKED” properly. Engine flooded. Bad spark plug. Dirty air filter. Dirty fuel filter. Water in fuel. Loose or damaged wiring. Carburetor out of adjustment. Engine valves out of adjustment. Hard to start Dirty air filter. -
Page 27: Trou Ble Shoot Ing
TROUBLESHOOTING POINTS PROBLEM CAUSE Engine continues to run Faulty operator-safety presence control system. when operator leaves seat with attachment clutch engaged Poor cut - uneven Worn, bent or loose blade. Mower deck not level. Buildup of grass, leaves, and trash under mower. Bent blade mandrel. - Page 28 SERVICE NOTES...
- Page 30 SERVICE NOTES...
- Page 31 SERVICE NOTES...
