IMPORTANT MANUAL
OPERATOR'S MANUAL
MODEL:
PBGT26H54
GARDEN TRACTOR
ALWAYS WEAR EYE PROTECTION DURING OPERATION
Visit our website: www.poulan-pro.com
434534 Rev. 1
06.21.10 JA
Do Not Throw Away
03032
WARNING:
Read this Man u al and follow all Warnings
and Safety Instructions. Fail ure to do so can
re sult in serious in ju ry.
Printed in the U.S.A.
Advertisement
Table of Contents
Related Manuals for Poulan Pro 434534
Summary of Contents for Poulan Pro 434534
- Page 1 IMPORTANT MANUAL OPERATOR'S MANUAL MODEL: PBGT26H54 GARDEN TRACTOR ALWAYS WEAR EYE PROTECTION DURING OPERATION Visit our website: www.poulan-pro.com 434534 Rev. 1 06.21.10 JA Do Not Throw Away 03032 WARNING: Read this Man u al and follow all Warnings and Safety Instructions. Fail ure to do so can re sult in serious in ju ry.
-
Page 2: Safety Rules
Safe Operation Practices for Ride-On Mowers DANGER: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROW ING OBJECTS. FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH. WARNING: In order to prevent ac ci den tal starting when setting up, trans port ing, ad just ing or making repairs, al ways dis con nect spark plug wire and place... -
Page 3: Safety Rules
Safe Operation Practices for Ride-On Mowers III. CHILDREN Tragic accidents can occur if the operator is not alert to the presence of children. Children are often attracted to the ma chine and the mowing activity. Never assume that children will remain where you last saw them. •... -
Page 4: Table Of Contents
PRODUCT SPECIFICATIONS Gasoline Capacity 4 Gallons and type: Unleaded Regular Oil Type (API-SG-SL): SAE 30 (above 32°F) SAE 5W-30 (below 32°F) Oil Capacity: W/ Filter: W/O Filter: Spark Plug: Champion QC12YC (Gap: .040") Ground Speed (MPH): Forward: Reverse: 0 - 2.1 Charging System: 16 AMPS @ 3600 RPM Battery:... -
Page 5: Unassembled Parts
UNASSEMBLED PARTS Mower (2) Rear Lift Link Assemblies (1) Small Retainer Springs (1) Front Lift Link Assembly (5) Large Retainer Springs If Equipped (1) Anti-Sway Bar (1) Small Retainer Springs Mower Front Wheel (1) Shoulder Bolt (1) Wheel (1) Oil Drain Tube Keys (1) 3/4 O.D. -
Page 6: Assembly
Your new tractor has been assembled at the factory with exception of those parts left unassembled for shipping purposes. To ensure safe and proper operation of your tractor all parts and hardware you assemble must be tightened securely. Use the correct tools as necessary to ensure proper tightness. TOOLS REQUIRED FOR ASSEMBLY A socket wrench set will make assembly easier. - Page 7 LIFT LEVER Fig. 4 2. ASSEMBLE FRONT GAUGE WHEEL (W) TO FRONT OF MOWER (See Fig. 5) Fig. 5 3. TURN STEERING WHEEL LEFT AND POSITION MOWER (See Fig. 6) • Turn steering wheel to the left as far as it will go and position mower on right side of tractor with deflector shield (Q) to the right.
- Page 8 ANTI-SWAY BAR (S) LOCATION Fig. 10 NOTE: Depending on model, bracket (T) may be differ- ent than shown but hole for anti-sway bar will be in same position/location. • Pivot the integrated washer end of anti-sway bar (S) towards mower deck bracket on right side of mower. Insert integrated washer end of bar into hole in rear mower bracket (D).
- Page 9 9 INSTALL BELT ON ENGINE CLUTCH PULLEY (M) (See Fig. 7 & 15) • Disengage belt tension rod (K) from locking bracket (L). • Install belt onto engine clutch pulley (M). M. ENGINE CLUTCH PULLEY Fig. 15 IMPORTANT: Check belt for proper routing in all mower pulley grooves and under mandrel covers.
-
Page 10: Operation
These symbols may appear on your tractor or in literature supplied with the product. Learn and understand their meaning. REVERSE NEUTRAL REVERSE ENGINE OFF OPERATION SYSTEM (ROS) LIGHTS ON BATTERY FUEL ATTACHMENT ATTACHMENT CLUTCH DISENGAGED CLUTCH ENGAGED FREE WHEEL (Automatic Models only) Failure to follow instructions could result in serious injury or death. - Page 11 KNOW YOUR TRACTOR READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TRACTOR Compare the illustrations with your tractor to familiarize yourself with the locations of various controls and ad just ments. Save this manual for future reference. Our tractors conform to the applicable safety standards of the American National Standards Institute. (A) ATTACHMENT LIFT LEVER - Used to raise and lower the mower or other attachments mounted to your trac tor.
-
Page 12: How To Use Your Tractor
The operation of any tractor can result in foreign objects thrown into the eyes, which can result in severe eye dam age. Always wear safety glass es or eye shields while operating your tractor or per form ing any ad just ments or repairs. We rec om mend standard safety glasses or a wide vision safety mask worn over spectacles. - Page 13 TO ADJUST MOWER CUTTING HEIGHT (See Fig. 21) The position of the attachment lift lever (A) determines the cutting height. Fig. 21 • Put attachment lift lever in desired cutting height slot. • Slide pointer tab (T) to desired cutting height as a reminder for next time you mow.
- Page 14 USING THE REVERSE OPERATION SYSTEM (See Fig. 24) Only use if you are certain no children or other bystanders will enter the mowing area. • Move motion control lever to neutral (N) position. • With engine running, turn ignition key counterclockwise to ROS "ON"...
- Page 15 CAUTION: Alcohol blended fuels (called gas o hol or using ethanol or methanol) can attract mois- ture which leads to sep a ra tion and for ma tion of acids during storage. Acidic gas can damage the fuel system of an engine while in storage. To avoid engine problems, the fuel system should be emptied before stor age of 30 days or longer.
- Page 16 MOWING TIPS • Tire chains cannot be used when the mower hous ing is attached to tractor. • Mower should be properly leveled for best mowing performance. See “TO LEVEL MOWER HOUSING” in the Service and Adjustments section of this manual. •...
-
Page 17: Maintenance Schedule
MAINTENANCE SCHEDULE Check Brake Operation Check Tire Pressure Check Operator Presence & ROS Systems Check for Loose Fasteners Check/Replace Mower Blades Lubrication Chart Check Battery Level Clean Battery and Terminals Clean Debris Off Steering Plate ck Transaxle Cooling Check Mower Levelness ck V-Belts Check Engine Oil Level Change Engine Oil (with oil filter) -
Page 18: Maintenance
TRACTOR Always observe safety rules when per form ing any main te nance. BRAKE OPERATION If tractor requires more than five (5) feet to stop at highest speed in high est gear on a level, dry concrete or paved surface, then brake must be checked and ad just ed. (See “TO CHECK BRAKE”... -
Page 19: Clean Air Screen
V-BELTS Check V-belts for deterioration and wear after 100 hours of operation and replace if necessary. The belts are not ad just able. Re place belts if they begin to slip from wear. TRANSAXLE MAINTENANCE The transmission fan and cooling fins should be kept clean to assure proper cooling. - Page 20 IN-LINE FUEL FILTER (See Fig. 30) The fuel filter should be replaced once each season. If fuel filter becomes clogged, ob struct ing fuel flow to car bu re tor, re place ment is re quired. • With engine cool, remove filter and plug fuel line sec tions. •...
-
Page 21: Service And Adjustments
SERVICE AND ADJUSTMENTS WARNING: TO AVOID SE RI OUS IN JU RY, BEFORE PERFORMING ANY SERVICE OR ADJUSTMENTS: • Depress brake pedal fully and set parking brake. • Place motion control lever in neutral position. • Place attachment clutch in “DISENGAGED” position. •... - Page 22 SERVICE AND ADJUSTMENTS TO LEVEL MOWER Make sure tires are properly inflated to the PSI shown on tires. If tires are over or under inflated, it may affect the appearance of your lawn and lead you to think the mower is not adjusted properly.
- Page 23 SERVICE AND ADJUSTMENTS TO REPLACE MOTION DRIVE BELT (See Fig. 39) Park the tractor on level surface. En gage parking brake. For as sis tance, there is a belt installation guide decal on bottom side of left footrest. BELT REMOVAL - 1.
- Page 24 SERVICE AND ADJUSTMENTS FRONT WHEEL TOE-IN/CAM BER Your new tractor front wheel toe-in and camber is set at the factory and is normal. The front wheel toe-in and camber are not adjustable. If damage has occurred to affect the factory set front wheel toe-in or camber, contact a qualified service center.
- Page 25 SERVICE AND ADJUSTMENTS TO REPLACE HEADLIGHT BULB • Raise hood. • Pull bulb holder out of the hole in the backside of the grill. • Replace bulb in holder and push bulb holder securely back into the hole in the backside of the grill. •...
-
Page 26: Storage
Immediately prepare your tractor for storage at the end of the season or if the tractor will not be used for 30 days or more. WARNING: Never store the trac tor with gas o line in the tank inside a building where fumes may reach an open flame or spark. -
Page 27: Troubleshooting
PROBLEM CAUSE 1. Out of fuel. Will not start 2. Engine not “CHOKED” properly. 3. Engine flooded. 4. Bad spark plug. 5. Dirty air filter. 6. Dirty fuel filter. 7. Water in fuel. 8. Loose or damaged wiring. 9. Carburetor out of adjustment. 10. -
Page 28: Trou Ble Shoot Ing
PROBLEM CAUSE Engine continues 1. Faulty operator-safety presence control system. to run when oper- ator leaves seat with attachment clutch engaged 1. Worn, bent or loose blade. Poor cut - uneven 2. Mower deck not level. 3. Buildup of grass, leaves, trash under mower. 4. -
Page 30: Warranty
The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in materi- als and work man ship. For a period of two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we find to be defective due to materials or workmanship.
