IMPORTANT MANUAL
OPERATOR'S MANUAL
MODEL:
XT24H48YT
LAWN TRACTOR
ALWAYS WEAR EYE PROTECTION DURING OPERATION
Visit our website: www.poulan-pro.com
Do Not Throw Away
02153
WARNING:
Read this Man u al and follow all Warnings and
Safety Instructions. Fail ure to do so can re sult
in serious in ju ry.
196712 Rev. 1 02.14.05 TR
Printed in U.S.A.
Advertisement
Table of Contents
Related Manuals for Poulan Pro 196712
Summary of Contents for Poulan Pro 196712
- Page 1 Visit our website: www.poulan-pro.com Do Not Throw Away 02153 WARNING: Read this Man u al and follow all Warnings and Safety Instructions. Fail ure to do so can re sult in serious in ju ry. 196712 Rev. 1 02.14.05 TR Printed in U.S.A.
-
Page 2: Safety Rules
Safe Operation Practices for Ride-On Mowers IMPORTANT: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROW ING OBJECTS. FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH. WARNING: In order to prevent ac- ci den tal starting when setting up, trans port ing, ad just ing or making re- pairs, al ways dis con nect spark plug... - Page 3 Safe Operation Practices for Ride-On Mowers III. CHILDREN Tragic accidents can occur if the operator is not alert to the presence of children. Children are often attracted to the ma chine and the mowing activity. Never assume that children will remain where you last saw them. •...
-
Page 4: Table Of Contents
PRODUCT SPECIFICATIONS Gasoline Capacity 4.0 Gallons and Type: Unleaded Regular Oil Type (API-SG-SL): SAE 30 (above 32°F) SAE 5W-30 (below 32°F) Oil Capacity: W/Filter: W/O Filter: 3.75 Pints Spark Plug: Champion QC12YC (Gap: .040") Ground Speed (MPH): Forward: Reverse: Tire Pressure: Front: Rear: Charging System:... -
Page 5: Unassembled Parts
UNASSEMBLED PARTS Steering Wheel Steering Wheel Adapter (1) Large Flat Washer (1) Hex Bolt 1/4-28 x 1-1/4 Seat (1) Washer 17/32 x 1-3/16 x 12 Gauge (1) Knob (2) Retainer Springs (single loop) (1)Front Plate Steering Assembly Wheel Insert (4) Adjusting Bar Steering Sleeve (4) Retainer Springs... -
Page 6: Assembly
Your new tractor has been assembled at the factory with exception of those parts left unassembled for shipping purposes. To ensure safe and proper operation of your tractor all parts and hardware you assemble must be tightened securely. Use the correct tools as necessary to insure proper tightness. TOOLS REQUIRED FOR ASSEMBLY A socket wrench set will make assembly easier. - Page 7 SEAT SEAT PAN FLAT WASHER ADJUSTMENT KNOB FIG. 2 CHECK BATTERY (See Fig. 3) • Lift hood to raised position. • If this battery is put into service after month and year indicated on label (label located between terminals) charge battery for minimum of one hour at 6-10 amps. (See "BAT TERY"...
-
Page 8: Install Mower And Drive Belt
• Adjust gauge wheels before operating mower. See “TO ADJUST GAUGE WHEELS” in the Operation sec tion of this manual. RETAINER SPRING SHOULDER AD JUST ING BOLT GAUGE WHEEL 3/8 WASH ER FIG. 4 INSTALL MOWER AND DRIVE BELT (See Figs. 5 and 6) Be sure tractor is on level surface and mower suspension arms are raised with attachment lift control. -
Page 9: Assembly
• Connect anti-sway bar to chassis bracket under left foot rest and retain with double loop retainer spring. • If equipped, turn height adjustment knob clock wise to remove slack from mower sus pen sion. • Raise deck to highest position. •... -
Page 10: Operation
These symbols may appear on your tractor or in literature supplied with the product. Learn and understand their mean- ing. REVERSE NEUTRAL REVERSE ENGINE ON ENGINE OFF OPERATION SYSTEM (ROS) OIL PRESSURE FUEL OVER TEMP LIGHT ATTACHMENT ATTACHMENT CLUTCH DISENGAGED CLUTCH ENGAGED LIGHTS ON FREE WHEEL... - Page 11 KNOW YOUR TRACTOR READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TRACTOR Compare the illustrations with your tractor to familiarize yourself with the locations of various controls and ad just ments. Save this manual for future reference. THROTTLE CONTROL CLUTCH/BRAKE PEDAL...
-
Page 12: To Move Forward And Backward
The operation of any tractor can result in foreign objects thrown into the eyes, which can result in severe eye dam age. Always wear safety glass es or eye shields while op- erating your tractor or per form ing any adjustments or repairs. We rec om mend a wide vision safety mask over spectacles or stan dard safety glasses. - Page 13 TO ADJUST GAUGE WHEELS (See Fig. 8) Gauge wheels are properly adjusted when they are slightly off the ground when mower is at the desired cutting height in operating position. Gauge wheels then keep the deck in proper position to help prevent scalping in most terrain conditions.
-
Page 14: Before Starting The Engine
• Avoid stopping or changing speed on hills. • If slowing is necessary, move throttle control lever to slower position. • If stopping is absolutely necessary, push clutch/brake pedal quickly to brake position and engage parking brake. • Move motion control lever to neutral (N) position. IMPORTANT: THE MOTION CONTROL LEVER DOES NOT RETURN TO NEUTRAL (N) POSITION WHEN THE CLUTCH/... - Page 15 WARM WEATHER STARTING (50° F and above) • When engine starts, slowly push choke control in until the engine begins to run smoothly. If the engine starts to run roughly, pull the choke control out slightly for a few seconds and then continue to push the control in slowly. •...
-
Page 16: Maintenance Schedule
MAINTENANCE SCHEDULE FILL IN DATES AS YOU COMPLETE REGULAR SERVICE Check Brake Operation Check Tire Pressure Check Operator Presence and ROS Systems Check for Loose Fasteners Sharpen/Replace Mower Blades Lubrication Chart Check Battery Level Clean Battery and Terminals Check Transaxle Cooling Check V-Belts Check Engine Oil Level Change Engine Oil (with oil filter) -
Page 17: Maintenance
TRACTOR Always observe safety rules when per form ing any main- te nance. BRAKE OPERATION If tractor requires more than fi ve (5) feet to stop at highest speed in high est gear on a level, dry concrete or paved surface, then brake must be checked and ad just ed. - Page 18 CENTER HOLE 5/8" BOLT OR PIN FIG. 13 BATTERY Your tractor has a battery charging system which is suf fi cient for normal use. However, periodic charging of the battery with an automotive charger will extend its life. • Keep battery and terminals clean. •...
- Page 19 • Unlock drain valve by pushing inward and turning coun ter clock wise. • To open, pull out on the drain valve. • After oil has drained completely, close and lock the drain valve by pushing inward and turning clockwise until the pin is in the locked position as shown.
-
Page 20: Service And Adjustments
SERVICE AND ADJUSTMENTS WARNING: TO AVOID SERIOUS INJURY, BEFORE PERFORMING ANY SER VICE OR AD JUST - MENTS: • Depress clutch/brake pedal fully and set parking brake. • Place motion control lever in neutral (N) position. • Place attachment clutch in “DISENGAGED” position. •... -
Page 21: To Level Mower Housing
SERVICE AND ADJUSTMENTS • Position front plate assembly between front mower brackets. Raise deck and plate assembly to align holes and insert fl anged pins. Secure pins with double loop retainer springs between the plate assembly and mower brack ets. NOTE: To assist in locating hole in fl... -
Page 22: To Replace Mower Drive Belt
SERVICE AND ADJUSTMENTS BOTH FRONT PLATE LINKS MUST BE EQUAL IN LENGTH NUT “D” FRONT PLATE AS- SEM BLY FIG. 21 TO REPLACE MOWER DRIVE BELT MOWER DRIVE BELT REMOVAL (See Fig. 22) • Park tractor on a level surface. En gage parking brake. - Page 23 SERVICE AND ADJUSTMENTS TO REPLACE MOWER BLADE (SEC OND ARY) DRIVE BELT (See Fig. 23) Park the tractor on level surface. En gage parking brake. • Remove mower (See “TO REMOVE MOWER” in this section of manual). • Remove screws from R.H. and L.H. mandrel covers and re move covers.
-
Page 24: To Replace Motion Drive Belt
SERVICE AND ADJUSTMENTS • If distance is other than 1-9/16", loosen jam nut and turn nut “A” until distance becomes 1-9/16". Retighten jam nut against nut “A”. • Engage transmission by placing freewheel control in “trans mis sion engaged” position. •... - Page 25 SERVICE AND ADJUSTMENTS MOTION CONTROL LEVER FIG. 26 TRANSMISSION REMOVAL/REPLACEMENT Should your transmission require removal for service or replacement, it should be purged after reinstallation and before operating the tractor. See “PURGE TRANS MIS SION” in the Operation section of this manual. TO AD JUST STEER ING WHEEL ALIGN- MENT If steering wheel crossbars are not horizontal (left to right)
- Page 26 SERVICE AND ADJUSTMENTS REPLACING BATTERY (See Fig. 29) WARNING: Do not short battery ter mi nals by allowing a wrench or any other object to contact both terminals at the same time. Before connect- ing battery, remove metal bracelets, wristwatch bands, rings, etc. Positive terminal must be connected fi...
-
Page 27: Storage
Immediately prepare your tractor for storage at the end of the season or if the tractor will not be used for 30 days or more. WARNING: Never store the trac tor with gas o line in the tank inside a building where fumes may reach an open fl... -
Page 28: Trou Ble Shoot Ing
TROUBLESHOOTING POINTS PROBLEM CAUSE Will not start Out of fuel. Engine not “CHOKED” properly. Engine fl ooded. Bad spark plug. Dirty air fi lter. Dirty fuel fi lter. 7. Water in fuel. Loose or damaged wiring. Carburetor out of adjustment. Engine valves out of adjustment. -
Page 29: Trou Ble Shoot Ing
TROUBLESHOOTING POINTS PROBLEM CAUSE Engine dies when 1. Reverse operation system tractor is shifted (ROS) is not "ON" while into reverse mower or other attachment is engaged. Engine continues to run Faulty operator-safety presence control system. when operator leaves seat with attachment clutch engaged Poor cut - uneven... -
Page 30: Warranty
The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in materi- als and work man ship. For a period of two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we fi... - Page 31 SUGGESTED GUIDE FOR SIGHTING SLOPES FOR SAFE OPERATION WARNING: To avoid serious injury, operate your tractor up and down the face of slopes, never across the face. Do not mow slopes greater than 15 degrees. Make turns gradually to prevent tipping or loss of control.
-
Page 32: Parts And Service
