Summary of Contents for Thunder TDR17011
- Page 1 CONGRATULATIONS ON YOUR PURCHASE OF YOUR THUNDER CAMERA For your personal safety read, understand and follow the information provided in this instruction manual. WI-FI CONNECTIVITY USB & HDMI 30M WATERPROOF 1080P FULL HD VIDEO 12MP STILL CAMERA 170° WIDE LENS...
- Page 2 THE BASICS Shutter/Select Button MicroSD Slot Microphone Micro USB Power/Mode Button Status Indicator Light Lens Micro HDMI Port Status Up Button Indicator Light Speaker Screen Charging Status Light Wi-Fi On-Off/ Down Button Copyright © 2016 GPC Asia Pacific Pty Ltd ABN 97 097 993 283...
-
Page 3: Waterproof Housing
THE BASICS Battery Door WATERPROOF HOUSING Select/Shutter Button Latch Power/Mode Button Up Button Wi-Fi On-Off/ Down Button... - Page 4 ACCESSORIES Waterproof Handle Bar/ Housing Pole Mount Suction Cup Mount 1 Mount 2 Mount 3 Mount 4 Mount 5 Helmet Mount 6 Clip 1 Clip 2 Mounts Battery 3M Adhesives USB Cable Charger Car Charger Lens Cloth User Manual...
-
Page 5: Mounting Your Camera
MOUNTING YOUR CAMERA Attach your camera to helmets, gear and equipment. Step 1. Attach a case Step 2. Add a mount... - Page 6 MOUNTING YOUR CAMERA (continued) Step 3. Attach your camera to helmets, gear or equipment.
-
Page 7: Getting Started
GETTING STARTED To power on: Press the Power/Mode Button. To power off: Press and hold the Power/Mode Button. OVERVIEW Turn the camera on and repeatedly press the Power Mode Buttons to cycle through the camera modes and settings. The modes will appear in following order: Video Photo Burst Photo Time Lapse... - Page 8 OVERVIEW (continued) Video Record video. Photo Capture a single photo. Burst Photo Capture photo bursts. Shoot a series of photos Time Lapse at set time intervals. Adjust camera settings, Settings resolution and more. SETTINGS Press the Shutter/Select Button to enter the settings menu.
- Page 9 SETTINGS (continued) Video Resolution: 1080p 30fps/720p 60fps MicroSD Card 1080p 30fps 720p 60fps 32GB 240 mins 320 mins 16GB 120 mins 160 mins 60 mins 80 mins 30 mins 40 mins Looping Video: Off/On Time Stamp: Off/Date/Date & Time Exposure: +-2.0/+-1.7/+-1.3/+-1.0/+-0.7/+-0.3/0 Photo Resoultion: 12M/8M/5M/2M Burst Photo: Off/3 Photos Time Lapse: Off/2s/3s/5s/10s/20s/30s/60s...
- Page 10 SETTINGS (continued) Upside Down: On/Off Screen Saver: Off/1min/3min/5min Power Saver: Off/1min/3min/5min Format: No/Yes Reset: No/Yes VIDEO MODE To record Video, verify the camera is in Video mode. If the Video icon on your camera’s LCD screen is not showing, press the Power/Mode Button repeatedly until it appears.
-
Page 11: Burst Photo Mode
PHOTO MODE To capture a Photo, verify the camera is in Photo mode. If the Photo icon on your camera’s LCD screen is not showing, press the Power/Mode Button repeatedly until it appears. To take a Photo: Press the Shutter/Select Button. The camera will emit the camera shutter sound. - Page 12 TIME LAPSE PHOTO MODE To capture a Time Lapse series, verify the camera is in Time Lapse mode. If the Time Lapse icon on your camera’s LCD screen is not showing, press the Power/Mode Button repeatedly until it appears. In Time Lapse mode, your camera captures a series of photos at 2, 3, 5, 10, 20, 30 or 60 seconds intervals.
- Page 13 4. Press the Shutter/Select Button. 5. To exit, hold down the Shutter/Select Button for three seconds. PLAYBACK Playing Back Videos and Photos To enter the Playback menu: 1. Verify the camera is in Camera Mode. 2. Press the Up/Playback Button to enter the Playback menu.
-
Page 14: Storage/Micro Sd Cards
STORAGE/MICRO SD CARDS This camera is compatible with 4GB, 16GB and 32GB capacity micro SD, micro SDHC and micro SDXC memory cards. You must use a micro SD card with a Class 10 speed rating. We recommend using brand name memory cards for maximum reliability in high-vibration activities. - Page 15 iSMART DV APP Connecting to the iSmart DV App The iSmart DV App lets you control your camera remotely using a smartphone or tablet. Features include full camera control, live preview, photo playback and sharing of select content and more. 1.
- Page 16 iSMART DV APP (continued) Press and hold the Down/Wi-Fi Button for three seconds to turn off Wi-Fi. The iSmart DV App is compatible with smartphones and tablets listed below. Compatibility varies by device. Content playback, sharing and access to the camera’s memory card might not be available on some devices.
