IMPORTANT MANUAL
OWNER'S MANUAL
MODEL:
PPR2042STA
LAWN TRACTOR
Always Wear Eye Protection During Operation
Do Not Throw Away
02478
Read the Owner's Manual and follow
all Warnings and Safety Instructions.
Failure to do so can result in serious
injury.
181377 Rev. 1 4.2.02 TR
Printed in U.S.A.

Advertisement

Table of Contents
loading

Related Manuals for Poulan Pro 181377

Summary of Contents for Poulan Pro 181377

  • Page 1 LAWN TRACTOR Always Wear Eye Protection During Operation Do Not Throw Away 02478 Read the Owner's Manual and follow all Warnings and Safety Instructions. Failure to do so can result in serious injury. 181377 Rev. 1 4.2.02 TR Printed in U.S.A.

  • Page 2: Safety Rules

    SAFE OPERATION PRACTICES FOR RIDE-ON MOWERS IMPORTANT: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROWING OBJECTS. FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH. I. GENERAL OPERATION • Read, understand, and follow all instructions in the manual and on the machine before starting.

  • Page 3: Table Of Contents

    Safe Operation Practices for Ride-On Mowers • Be sure the area is clear of other people before mowing. Stop machine if anyone enters the area. • Never carry passengers or children even with the blades off. • Do not mow in reverse unless absolutely necessary. Always look down and behind before and while backing.

  • Page 4: Product Specifications

    PRODUCT SPECIFICATIONS GASOLINE CAPACITY 2.00 GALLONS AND TYPE: UNLEADED REGULAR OIL TYPE (API-SF-SJ): SAE 30 (above 32°F) SAE 5W-30 (below 32°F) OIL CAPACITY: 3.75 PINTS SPARK PLUG: CHAMPION RC12YC (GAP: .040") GROUND SPEED (MPH): FORWARD: REVERSE: TIRE PRESSURE: FRONT: REAR: CHARGING 3 AMPS BATTERY 5 AMPS HEADLIGHTS...
  • Page 5 UNASSEMBLED HARDWARE Steering Wheel Steering Extension Shaft Steering Steering Wheel Insert Sleeve (1) Large Flat Washer (1) Hex Bolt 5/16-18 x 1-1/4 (1) Washer 17/32 x 1-3/16 x 12 Gauge (1) Hex Bolt 3/8-16 x 1 (1) Knob (1) Lock washer Keys (2) Keys...

  • Page 6: Assembly

    Your new tractor has been assembled at the factory with exception of those parts left unassembled for shipping purposes. To ensure safe and proper operation of your tractor all parts and hardware you assemble must be tightened securely. Use the correct tools as necessary to insure proper tightness.
  • Page 7 SEAT PAN FIG. 2 INSTALL SEAT (See Fig. 3) Adjust seat before tightening adjustment knob. • Remove adjustment knob and flat washer securing seat to cardboard packing and set aside for assembly of seat to tractor. • Pivot seat upward and remove from the cardboard packing.
  • Page 8 I M P O R T A N T : F O R S H I P P I N G P U R P O S E S , T H E MULCHER PLATE WAS PREATTACHED TO YOUR MOWER. THE MULCHER PLATE MUST ONLY BE USED WITH THE MULCHING BLADES THAT CAME PACKED SEPARATELY IN THE CARTON.

  • Page 9: Operation

    OPERATION These symbols may appear on your tractor or in literature supplied with the product. Learn and understand their meaning. BATTERY CAUTION OR REVERSE FORWARD FAST SLOW WARNING ENGINE ON ENGINE OFF OIL PRESSURE CLUTCH LIGHTS ON OVER TEMP LIGHT FUEL CHOKE MOWER HEIGHT...
  • Page 10 KNOW YOUR TRACTOR READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TRACTOR Compare the illustrations with your tractor to familiarize yourself with the locations of various controls and adjustments. Save this manual for future reference. AMMETER CHOKE CONTROL CLUTCH/BRAKE PEDAL THROTTLE...

  • Page 11: How To Use Your Tractor

    The operation of any tractor can result in foreign objects thrown into the eyes, which can result in severe eye damage. Always wear safety glasses or eye shields while operating your tractor or performing any adjustments or repairs. We recommend a wide vision safety mask over spectacles or standard safety glasses.

  • Page 12: To Operate On Hills

    TO ADJUST GAUGE WHEELS (See Fig. 7) Gauge wheels are properly adjusted when they are slightly off the ground when mower is at the desired cutting height in operating position. Gauge wheels then keep the deck in proper position to help prevent scalping in most terrain conditions.

  • Page 13: Before Starting The Engine

    BEFORE STARTING THE ENGINE CHECK ENGINE OIL LEVEL • The engine in your tractor has been shipped, from the factory, already filled with summer weight oil. • Check engine oil with tractor on level ground. • Remove oil fill cap/dipstick and wipe clean, reinsert the dipstick and screw cap tight, wait for a few seconds, remove and read oil level.

  • Page 14: Mowing Tips

    MOWING TIPS • Mower should be properly leveled for best mowing performance. See “TO LEVEL MOWER HOUSING” in the Service and Adjustments section of this manual. • The left hand side of mower should be used for trimming. • Drive so that clippings are discharged onto the area that has been cut.

  • Page 15: Maintenance Schedule

    CUSTOMER RESPONSIBILITIES MAINTENANCE SCHEDULE FILL IN DATES AS YOU COMPLETE REGULAR SERVICE Check Brake Operation Check Tire Pressure Check Operator Presence and Interlock Systems Check for Loose Fasteners Sharpen/Replace Mower Blades Lubrication Chart Check Battery Level Clean Battery and Terminals Check Transaxle Cooling Check V-Belts Check Engine Oil Level...

  • Page 16: Operator Presence System

    CUSTOMER RESPONSIBILITIES TRACTOR Always observe safety rules when performing any mainte- nance. BRAKE OPERATION If tractor requires more than six (6) feet stopping distance at high speed in highest gear, then brake must be adjusted. (See “TO ADJUST BRAKE” in the Service and Adjustments section of this manual).

  • Page 17: Clean Air Screen

    CUSTOMER RESPONSIBILITIES NOTE: The original equipment battery on your tractor is maintenance free. Do not attempt to open or remove caps or covers. Adding or checking level of electrolyte is not necessary. TO CLEAN BATTERY AND TERMINALS Corrosion and dirt on the battery and terminals can cause the battery to “leak”...
  • Page 18 CUSTOMER RESPONSIBILITIES AIR FILTER (See Fig. 14) Your engine will not run properly using a dirty air filter. Clean the foam pre-cleaner after every 25 hours of operation or every season. Service paper cartridge every 100 hours of operation or every season, whichever occurs first. Service air cleaner more often under dusty conditions.

  • Page 19: Service And Adjustments

    SERVICE AND ADJUSTMENTS WARNING: TO AVOID SERIOUS INJURY, BEFORE PERFORMING ANY SERVICE OR ADJUSTMENTS: • Depress clutch/brake pedal fully and set parking brake. • Place gearshift lever in neutral (N) position. • Place attachment clutch in “DISENGAGED” position. • Turn ignition key to “STOP” and remove key. •...

  • Page 20: To Level Mower Housing

    SERVICE AND ADJUSTMENTS TO LEVEL MOWER HOUSING Adjust the mower while tractor is parked on level ground or driveway. Make sure tires are properly inflated (See “PROD- UCT SPECIFICATIONS” section of this manual). If tires are over or underinflated, you will not properly adjust your mower.
  • Page 21 SERVICE AND ADJUSTMENTS MANDREL IDLER PULLEYS PULLEY MANDREL PULLEY FIG. 21 TO ADJUST BRAKE (See Fig. 22) Your tractor is equipped with an adjustable brake system which is mounted on the right side of the transaxle. If tractor requires more than six (6) feet stopping distance at high speed in highest gear on a level dry concrete or paved surface, then brake must be adjusted.
  • Page 22 SERVICE AND ADJUSTMENTS TO REMOVE WHEEL FOR REPAIRS (See Fig. • Block up axle securely. • Remove axle cover, retaining ring and washers to allow wheel removal (rear wheel contains a square key - Do not lose). • Repair tire and reassemble. •...
  • Page 23 SERVICE AND ADJUSTMENTS TO REPLACE HEADLIGHT BULB • Raise hood. • Pull bulb holder out of the hole in the backside of the grill. • Replace bulb in holder and push bulb holder securely back into the hole in the backside of the grill. •...

  • Page 24: Storage

    Immediately prepare your tractor for storage at the end of the season or if the tractor will not be used for 30 days or more. CAUTION: Never store the tractor with gasoline in the tank inside a building where fumes may reach an open flame or spark.

  • Page 25: Troubleshooting Points

    TROUBLESHOOTING POINTS PROBLEM CAUSE Will not start Out of fuel. Engine not “CHOKED” properly. Engine flooded. Bad spark plug. Dirty air filter. Dirty fuel filter. Water in fuel. Loose or damaged wiring. Carburetor out of adjustment. Engine valves out of adjustment. Hard to start Dirty air filter.
  • Page 26 TROUBLESHOOTING POINTS PROBLEM CAUSE Engine continues to run Faulty operator-safety presence control system. when operator leaves seat with attachment clutch engaged Poor cut - uneven Worn, bent or loose blade. Mower deck not level. Buildup of grass, leaves, and trash under mower. Bent blade mandrel.

  • Page 27: Schematic

    TRACTOR - - MODEL NUMBER PPR2042STA SCHEMATIC AMMETER (OPTIONAL) WHITE IGNITION SWITCH IGNITION SWITCH POSITION CIRCUIT “MAKE” M+G+A1 NONE RUN/LIGHT B+A1 A2+L B+A1 NONE START B + S + A1 NONE BATTERY FUSE CLUTCH / BRAKE (PEDAL UP) WHITE BLACK BLACK ATT'MENT CLUTCH BLACK...

  • Page 28: Repair Parts

    REPAIR PARTS TRACTOR - - MODEL NUMBER PPR2042STA ELECTRICAL D .C...
  • Page 29 REPAIR PARTS TRACTOR - - MODEL NUMBER PPR2042STA ELECTRICAL PART DESCRIPTION 163465 Battery 74760412 Bolt Hex Hd 1/4-20unc X 3/4 176689 Box Battery Fender 176138 Switch Interlock 175685 Harness Socket Light with 415J 4152J Bulb, Light # 1156 4799J Cable Battery 146147 Cable Battery 6 Ga Red w/16 wire 175158...

  • Page 30: Repair Parts

    REPAIR PARTS TRACTOR - - MODEL NUMBER PPR2042STA CHASSIS...
  • Page 31 REPAIR PARTS TRACTOR - - MODEL NUMBER PPR2042STA CHASSIS PART DESCRIPTION 174619 Chassis 176554 Drawbar 17060612 Screw 3/8-16 X .75 155272 Bumper Hood/Dash 168337X012 Dash P/L 72140608 Bolt Carriage 3/8-16 x 1 174996 Panel Dash Lh 145660 Clip Tinnerman 172105X010 Panel Dash Rh 17490608 Screw Thdrol 3/8 x 16 x 1/2 159639X428 Hood LT/PL...
  • Page 32 REPAIR PARTS TRACTOR - - MODEL NUMBER PPR2042STA DRIVE...
  • Page 33 REPAIR PARTS TRACTOR - - MODEL NUMBER PPR2042STA DRIVE PART DESCRIPTION – – – – Transaxle (See Breakdown) Peerless 206-545C 146682 Spring Return Brake T/a Zinc 123666X Pulley Transaxle 18/20" tires 12000028 Ring Retainer # 5100-62 121520X Strap Torque 30 Degrees 17060512 Screw 5/16-18 x 3/4 165619...

  • Page 34: Steering Assembly

    REPAIR PARTS TRACTOR - - MODEL NUMBER PPR2042STA STEERING ASSEMBLY...
  • Page 35 REPAIR PARTS TRACTOR - - MODEL NUMBER PPR2042STA STEERING ASSEMBLY PART DESCRIPTION 159944X428 Wheel Steering 172393 Axle Asm Cast Iron LT 169840 Spindle Asm LH 169839 Spindle Asm RH 6266H Bearing Race Thrust Harden 121748X Washer 25/32 X 1-5/8 X 16 Ga 12000029 Ring Klip #t5304-75 175121...
  • Page 36 REPAIR PARTS TRACTOR - - MODEL NUMBER PPR2042STA SEAT ASSEMBLY PART DESCRIPTION 171683 Seat 140551 Bracket Pivot Seat 8 720 71110616 Bolt Fin Hex 3/8-16unc X 1 19131610 Washer 13/32 X 1 X 10 Ga 145006 Clip Push-In 73800600 Nut Hex w/Ins. 3/8-16 Unc 124181X Spring Seat Cprsn 2 250 Blk Zi 17000616...
  • Page 37 WHEELS AND TIRES 4,10 PART 172743 160396 176307 145005 179769X428 Pad Footrest Rh 179768X428 Pad Footrest Lh 138311 173587 173589 181377 181378 PART 59192 65139 170455 59904 106732X421 Rim Asm 6"front Service 278H 9040H 106108X421 Rim Asm 8"rear Service 170456...
  • Page 38 REPAIR PARTS TRACTOR - - MODEL NUMBER PPR2042STA ENGINE OPTIONAL EQUIPMENT Spark Arrester...
  • Page 39 REPAIR PARTS TRACTOR - - MODEL NUMBER PPR2042STA ENGINE PART DESCRIPTION 170771 Control Throt 17720408 Screw Hex Thd Cut 1/4-20x5/8 T - - - - - - - - Engine B&S Model No. 407777 (Order parts from engine manufacturer) 149723 Muffler Exhaust 159955 Exhaust Asm.
  • Page 40 REPAIR PARTS TRACTOR - - MODEL NUMBER PPR2042STA MOWER DECK 153 154 132 91...
  • Page 41 REPAIR PARTS TRACTOR - - MODEL NUMBER PPR2042STA MOWER DECK PART DESCRIPTION 165892X421 Mower Deck Assembly, 42" 72140506 Bolt 138017 Bracket Asm Fr. Sway Bar 3/42 165460 Bracket Asm Deck 42" Sway Bar 4939M Retainer Spring 178024 Bar Sway Deck 850857 Bolt 3/8-24 x 25 Gr.
  • Page 42 REPAIR PARTS TRACTOR - - MODEL NUMBER PPR2042STA MOWER LIFT 17 18 20...
  • Page 43 REPAIR PARTS TRACTOR - - MODEL NUMBER PPR2042STA MOWER LIFT PART DESCRIPTION 159460 Wire Asm Inner/Sprg W/plunger LT 159471 Shaft Asm Lift RH w/Inf 105767X Pin Groove 1 500 Zinc 12000002 E Ring #5133-62 19211621 Washer 21/32 X 1 X 21 Ga 120183X Bearing Nylon Blk 629 Id 125631X...
  • Page 44 SERVICE NOTES...
  • Page 45 ® Issued January 1980 Revised January 1991 NEW PEERLESS GEAR POWER TRAIN COMPONENTS Peerless Gear and Machine Division of Tecumseh Products Company (“Tecumseh”), subject to the limitations contained below, will, at its option, repair or replace, without charge for parts or labor only, any part of a new Power Train Component (which as used herein means and includes the transaxle, gear box, transmission, differential and right angle drives, and any part of the Power Train Component), EXCEPT any new Power Train Component incorporated in equipment used for commercial or rental purposes, which is found upon examination by any Tecumseh Authorized Service Outlet or...

  • Page 46: Warranty

    The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in materials and workmanship. For a period of two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we find to be defective due to materials or workmanship.
  • Page 47 SUGGESTED GUIDE FOR SIGHTING SLOPES FOR SAFE OPERATION WARNING: To avoid serious injury, operate your tractor up and down the face of slopes, never across the face. Do not mow slopes greater than 15 degrees. Make turns gradually to prevent tipping or loss of control.
