- Page 1 HDMI 2.0 E XTEDER BCI reserves the right to make changes to the products described herein without prior notice or consent. No liability is assumed as a result of their use or application. All rights reserved. ©2015 Broadata Communications, Inc.
- Page 2 LBC-H2CS-T/R-Lite User Manual Link Bridge HDBaseT HDMI 2.0 Extender, 4 Play SAFETY INSTRUCTIONS AND COMPLIANCE DECLARATIONS PLEASE OBSERVE THE FOLLOWING SAFETY PRECAUTIONS SURGE PROTECTION DEVICE RECOMMENDED This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc.
-
Page 3: Table Of Contents
4.0 MAINTENANCE AND TROUBLESHOOTING ....9 4.1 MAINTENANCE ..............9 4.2 TROUBLESHOOTING .............9 5.0 SPECIFICATIONS ............10 6.0 SERVICE PROCEDURE ..........11 6.1 REPLACEMENT POLICY ..........11 6.2 RETURN AND REPAIR SERVICE ......... 11 7.0 LIMITED WARRANTY ............ 12 Broadata Technical Support, (800) 214-0222... -
Page 4: Product Description
LBC-H2CS-T/R-Lite User Manual Link Bridge HDBaseT HDMI 2.0 Extender, 4 Play 1.0 PRODUCT DESCRIPTION • Extend HDMI 2.0 Signals up to 40 meters Over One CAT 5e/6 Cable, based on chroma subsampling • Supports True DDC/EDID/HDCP Transmission Over One CAT 5e/6 Cable •... -
Page 5: Operation Controls And Functions
TX, RX, GND (from the left side to the right) 7. Dip Switch: for F/W update ([ON] F/W update Mode; [OFF] Normal Mode) 8. HDMI IN: Connects to a HDMI source with HDMI male-male cable Broadata Technical Support, (800) 214-0222... -
Page 6: Receiver Front And Rear Panels
LBC-H2CS-T/R-Lite User Manual Link Bridge HDBaseT HDMI 2.0 Extender, 4 Play 2.2 Receiver Front and Rear Panels Front LBC-H2CS-R-Lite Rear 1. LED: Power LED, Status LED, Link LED, HDCP LED (a) Power LED: This LED light always shine is meant that works fine. -
Page 7: Ir Blaster Cable Pin Assignment
Link Bridge HDBaseT HDMI 2.0 Extender, 4 Play 3.0 IR EXTENDERS 3.1 IR Blaster Cable Pin Assignment IR Blaster IR Blaster Signal [20-60KHz] Grounding 3.3 IR Receiver Cable Pin Assignment IR Receiver IR Signal Grounding Power Broadata Technical Support, (800) 214-0222... -
Page 8: Maintenance And Troubleshooting
LBC-H2CS-T/R-Lite User Manual Link Bridge HDBaseT HDMI 2.0 Extender, 4 Play 4.0 MAINTENANCE AND TROUBLESHOOTING 4.1 Maintenance There is no operator maintenance other then keeping the units clean. However, observe the following light indicators to make sure that the unit is working properly: 4.2 Troubleshooting... -
Page 9: Specifications
Data Rate 20 - 60KHz In/Out Connectors 3.5mm Stereo PHYSICAL Dimensions Standalone 4.7”(W) x 2.9”(D) x 0.8”(H) Power Consumption +12VDC @ 1.2 Amps (Max.) Operating Temperature 0 to +40 Humidity 20 to 90% RH, Non-Condensing Broadata Technical Support, (800) 214-0222... -
Page 10: Service Procedure
The LBC-H2CS-Lite System contains no user serviceable components. If you have a problem with your unit, please contact the Customer Service Department. To facilitate our return/repair processing please contact Broadata Communications, Inc. to obtain a Return Material Authorization (RMA). Please include the following information: •... -
Page 11: Limited Warranty
HDBaseT HDMI 2.0 Extender, 4 Play 7.0 LIMITED WARRANTY Broadata Communications, Inc. (BCI) warrants, for a period of one year from date of shipment, each product sold shall be free from defects in material and workmanship. BCI will correct, either by repair, or at BCI’s election, by replacement, any said products that in our sole... - Page 12 LBC-H2CS-T/R-Lite User Manual Link Bridge HDBaseT HDMI 2.0 Extender, 4 Play Broadata Technical Support, Sales@Broadatacom.com...
- Page 13 LBC-H2CS-T/R-Lite User Manual Link Bridge HDBaseT HDMI 2.0 Extender, 4 Play Broadata Technical Support, (800) 214-0222...
- Page 14 Broadata Communications, Inc. 2545 West 237th Street, Suite K Torrance, CA 90505 1-800-214-0222 (310) 530-1416 (310) 530-5958 (Facsimile) e-mail: CustomerService@Broadatacom.com Website: www.broadatacom.com 60000-LBCH2CST/RLite...
