User Manual
Z9 USER GUIDE
Introduction
The BlueAnt Z9 Dual Microphone portable mono headset utilizes Bluetooth Wireless
Technology. Its dual microphones combined with the BlueAnt Voice Isolation Technology™
software, provide the BlueAnt Z9 with revolutionary clear and clean voice input enabling high
quality voice communications. Winner of the prestigious CES Design and Engineering award,
the BlueAnt Z9 is the next generation in Noise Suppression, Echo Cancellation and Wind
Noise Reduction for Bluetooth headsets.
There are two settings of Voice Isolation - STANDARD and MAX.
Voice Isolation Standard is for use in normal environments and gives you a natural
sounding voice removing mild noise.
Voice Isolation Max gives you superior voice clarity in a wide variety of high noise areas.
Advertisement
Table of Contents
Related Manuals for Blueant Z9
Summary of Contents for Blueant Z9
- Page 1 The BlueAnt Z9 Dual Microphone portable mono headset utilizes Bluetooth Wireless Technology. Its dual microphones combined with the BlueAnt Voice Isolation Technology™ software, provide the BlueAnt Z9 with revolutionary clear and clean voice input enabling high quality voice communications. Winner of the prestigious CES Design and Engineering award, the BlueAnt Z9 is the next generation in Noise Suppression, Echo Cancellation and Wind Noise Reduction for Bluetooth headsets.
- Page 2 Winner of the CES 2007 Innovations Design & Engineering Award • Two microphones for pure speech • Voice Isolation Technology ™ BlueAnt’s revolutionary Digital Signal Processor (DSP) software • During a call, users can switch between two Voice Isolation modes –...
-
Page 3: What Is Bluetooth Wireless Technology
Your headset is a Bluetooth V2.0 qualified product and supports both the Headset and Handsfree Bluetooth profiles. The Z9 can store information and wirelessly interact with up to three different Bluetooth V1.1, V1.2 or V2.0 compliant devices (backward and forward compatible), including mobile phones, PDA’s, PC’s / Mac’s or any Bluetooth enabled device... - Page 4 Overview...
-
Page 5: Getting Started
2. Pair your headset with a Bluetooth enabled device, e.g. Cell phone, PDA, Computer Charging Your Z9 comes with a built-in rechargeable battery. For first time use, you must fully charge your Z9. During charging, the indicator shows a steady Red light. When the battery is fully charged, the Red light will turn off. - Page 6 Charging the Z9 with the Wall Charger 1. Plug the AC Charger into a power socket and the cable into the charging port on the Z9. Make sure the USB plug matches up to the USB socket on the headset. Do not force the plug into the socket it should slide in easily.
- Page 7 Ensure that the headset is pointing towards your mouth. You can wear the Z9 on left or right ears. For optimal performance of the Z9 headset, angle the headset so that...
-
Page 8: Pairing Procedure
6 seconds. The LED will appear a solid Blue, and then will start flashing. The Z9 is now in Pairing mode and ready to be found in searches by other Bluetooth devices. Pairing mode will be active for 2 minutes. - Page 9 An additional security setting in your phone may be needed to allow the headset and phone to connect automatically without confirmation each time you connect your Z9. Generally in the options for the BlueAnt Z9, it will be referred to as "set as authorized", "add to trusted devices", ‘’allow connection’’ or similar.
- Page 10 If no phone has yet been Paired, the Z9 will enter into Pairing mode. If no Paired phone is in range, the Z9 will enter Idle mode. 2. Power OFF: Press and Hold the MFB for 3 seconds.
- Page 11 9. Volume level: Click Volume or Volume during a call to adjust the desired level. 10. Disconnect / Transfer: To disconnect the Z9 with the currently connect phone or transfer an ongoing call back to the phone, Click Volume and Volume...
- Page 12 Basic Headset Functions (continued) 11. Reconnect: To reconnect your phone to the Z9, simply turn the Z9 ON. Or with the Z9 ON simply press the MFB Alternatively, you can use the menu of your Bluetooth phone. 12. Mute/Unmute: the microphone. Press and Hold Volume for 3 seconds during a call.
- Page 13 OFF while a call is active. 16. Z9 Reset: If you have already Paired 3 devices to the Z9 it is not possible to pair another as the memory is full. If you want to pair with another phone you must reset the headset.
- Page 14 To switch between Standard and Max: Click the MFB while on a call • When switching between Standard and Max you will hear a confirmation voice tag played from the Z9 speaker. • When you first turn the headset ON, it will be in the Standard setting. •...
- Page 15 Reject Call 3 Seconds Ringing Redial Last Number 3 Seconds Standby Idle Mode Voice Dial Activate Click Standby means the Z9 is ON but not Transfer/Disconnect Z9 Click Connected & connected to any Call Conference 3 Seconds Active Call device...
-
Page 16: Led Indicator Chart
LED Indicator Chart Power ON Solid Blue for 5 Seconds Power OFF Red flash 3 times Pairing Mode Blue flashing Reset Blue flashing Charging Solid Red Charging with Power ON Solid Red with a Purple Flash Charging Complete Red indicator OFF Low Battery All LED’s change to Red Idle... - Page 17 Using your headset with multiple Bluetooth devices The Z9 will connect to only one device at a time but 3 devices can be paired to it. 1. Make sure the last phone used has Bluetooth switched off or is out of range.
-
Page 18: Firmware Upgrade
Firmware upgrade The BlueAnt Z9 is firmware upgradeable via the USB port and provided USB cable. Please see the support section at www.blueantwireless.com for information and downloads for any upgrades that are available. Further Information Setting up a Phone Profile (different to Bluetooth Profiles) In your phone, set up a Profile with appropriate ringing volumes and keypad tones and select and activate when using with the Z9. - Page 19 Phone/PDA/Computer Software Please make sure you have the latest firmware upgrade for your Phone especially if you are using a PDA Phone. Go to the support section of the manufacturers’ website to check that you have the latest version. Many new mobile phones, PDA’s and computer phones require a Bluetooth patch to improve Bluetooth functionality from the original released version.
-
Page 20: Specifications
Specifications General Bluetooth v2.0 Specification Up to 10 meters RF coverage CE,FCC,BQB, RoHS / WEEE Compliant Headset Profile, Hands-Free profile v1.0 RF Spec. Carrier Frequency 2.402 ~ 2.480GHz < 0.1% BER at -80 dBm 0 ± 4 dBm (Class 2) User Interface Blue color LED for operation indication. - Page 21 2. Check our website for more information, updated manuals and troubleshooting. www.blueantwireless.com 3. Call us and speak to one of the BlueAnt Wireless Customer Service Team We will clarify whether you have a hardware or connection issue. 4. If your unit is confirmed to be faulty, a Return Merchandise Authorization (RMA) will be issued .
- Page 22 All rights reserved. The Bluetooth word, mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by BlueAnt is under license. Other trademarks and trade names are those of their respective owners.
- Page 23 Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection) This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material...
-
Page 24: Federal Communication Commission Interference Statement
Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 25 FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
