- Page 1 ATTACHMENT J – USER’S MANUAL © 2000 PCTEST Lab...
- Page 2 StudioWorks 77ME/77M User’s Guide Benutzerhandbuch Manuel d’utilisation Guida Utente http://www.lge.com Guia del Usuario Manual do preprietário Handleiding Please read this manual carefully before operating your set. Retain it for future reference. Record model number and serial number of the set. See the label attached on the back cover and quote this information to your dealer when you require service.
- Page 3 Contents Controllo Regolazione On Screen Display (OSD) ...D6 ENGLISH Elementi di Selezione e Regolazione dell'OSD..D7 Introduction ............A1 Souno di Selezione e Regolazione .....D11 Connecting the Monitor........A2 Modalità di Memoria Video .......D12 Location and Function of Controls .......A3 In Caso di Problemi ..........D13 Control Panel Function .........A4 Specifiche............D14 On Screen Display (OSD) Control Adjustment ...A6...
- Page 5 Introduction Thank you for purchasing a high resolution monitor. It will give you high resolution performance and convenient reliable operation in a variety of video operating modes. Features The monitor is a 17 inches (15.9 inches viewable ) intelligent, microprocessor based monitor compatible with most analog RGB (Red, Green, Blue) display standards, including IBM PC , PS/2...
- Page 6 Connecting the Monitor On the back of the monitor are two plug-in connections; one for the AC power cord, and the other for the signal cable from the video card. Power off both the monitor and PC. Connect the 15 pin VGA connector of the supplied signal cable to the output VGA video connector on the PC.
- Page 7 Location and Function of Controls Front View Front Panel Controls Left Side Jacks Rear View ID Label M I C . A U D I O O U T Audio IN Mic Out AC Power Socket D-Sub Signal Cable...
-
Page 8: Front Panel Controls
Control Panel Function Front Panel Controls OSD Select /Adjustment Control Built-in Microphone Power (DPMS) Indicator Sound Mute Power Button Sound Menu Brightness OSD ON/OFF Enter Button Contrast Control Function OSD Select/ Use these buttons to choose or adjust items in Adjustment Control the on screen display. -
Page 9: Rear Panel Jacks
Control Panel Function Left Side Jacks Headphone Jack Headphone Jack that automatically mutes the speaker volume when headphone is attached. Microphone Jack An external microphone can be used instead of the built-in microphone. Rear Panel Jacks Mic. Out Connects microphone sound to PC via cable. - Page 10 On Screen Display (OSD) Control Adjustment Making adjustments to the image size, position and operating parameters of the monitor are quick and easy with the On Screen Display Control system. A quick example is given below to familiarize you with the use of the controls. Following section is an outline of the available adjustments and selections you can make using the OSD.
- Page 11 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selection and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the items that are shown on the Menu. OSD Adjust Description H POSITION...
- Page 12 On Screen Display(OSD) Selection and Adjustment OSD Adjust Description TRAPEZOID 6 8 . 7 k H z / 8 5 H z To correct geometric distortion. T R A P E Z O I D Makes the screen image narrower at the top.
- Page 13 On Screen Display(OSD) Selection and Adjustment OSD Adjust Description COLOR • 9300 : To appear the display’s color temperature. Slightly 6 8 . 7 k H z / 8 5 H z C O L O R bluish white. • 6500 : To appear the display’s color temperature.
- Page 14 On Screen Display(OSD) Selection and Adjustment OSD Adjust Description VIDEO LEVEL 6 8 . 7 H z / 8 5 H z This item is used to select the V I D E O L E V E L monitor's input signal level. The normal level used for most PC's is 0.7V.
- Page 15 Sound Selection and Adjustment You were introduced to the procedure of selection and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the items that are shown on the main Menu. To make adjustments in the On Screen Display, follow these steps: OSD Adjust Description...
-
Page 16: User Modes
Video Memory Modes The monitor has 36 memory locations for display modes, 11 of which are factory preset to popular video modes. Preset Modes (Resolution) Display Modes (Resolution) Horizontal Freq.(kHz) Vertical Freq.(Hz) 640 x 480 37.50 800 x 600 VESA 46.88 800 x 600 VESA... - Page 17 Troubleshooting Check the following before calling for service. SELF DIAGNOSTICS message. The signal cable is not connected, or is loose. Check and secure the connection. OUT OF FREQUENCY message appears. The frequency of the signal from the video card is outside the operating range of the monitor.
- Page 18 Specifications 17 inch (15.9 inches viewable) FST Picture Tube 90 degree deflection 0.27mm dot pitch ARAS(Anti-Reflective Anti-Static) coating Sync Input Horizontal Freq. 30 - 70kHz (Automatic) Vertical Freq. 50 - 160Hz (Automatic) Input Form Separate TTL, Positive/Negative Signal Input 15 pin D-Sub Connector Video Input Input Form Separate, RGB Analog, 0.7Vp-p/75 ohm, Positive...
