Page 1: User Manual
UHD LED/LCD TV LE43E5S1UHD LE49E5S1UHD LE55E5S1UHD LE65E5S1UHD USER MANUAL IMPORTANT ! WARRANTY INFORMATION INSIDE. PLEASE READ www.teac.com.au Trademark of TEAC Corporation JAPAN... - Page 2 Keep your purchase receipt to enable you to proceed quickly in the event of a Warranty Service. If you require Warranty Service, please contact the TEAC Warranty Service Hotline at 1300 553 315 for assistance. Please ensure that you have the model number, serial number and purchase receipt ready when you call.
- Page 3 Warranty, the customer shall be charged for the cost of the repair. No one is authorised to assume any liability on behalf of TEAC or impose any obligation on it, in connection with the sale of any equipment other than as stated in this warranty and outlined above.
-
Page 4: Table Of Contents
Contents TOPIC PAGE Safety Information ………………………………………………………………….……………2 Introduction ……..……………………………….……………………………………………….5 Unit Overview…...………………………………………………………………………………..6 Remote Control ………………………………………………………………………………….8 Initial Set Up ...…………………………………………………………………………………...9 Smart Features & Apps …..………………………………………….………………………...11 Watching TV …………..………………………………………………...……………………...14 PVR Recording …………………………………………………………….…………………...16 USB Media Playback……………..………………………………………………………..…...17 Menu System & Advanced Controls ..………………………………...……………………...19 Internet Connectivity ……………………………………………………………………….…...21 Troubleshooting ………………………………………………………………………….……...25 Specifications ………………………………………………………………….………………...26... -
Page 5: Safety Information
Safety Information CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. IMPORTANT - Please read these instructions fully before installing or operating In extreme weather (storms, lightning) and long inactivity periods (going on holiday) disconnect the TV set from the mains. - Page 6 Class II Equipment: This appliance is designed in such a way that it does not require a safety connection to electrical earth. Class II Equipment With Functional Earthing: This appliance is designed in such a way that it does not require a safety connection to electrical earth, the earth connection is used for functional purposes.
- Page 7 WARNING Large TVs are fall hazards. You should use furniture straps to fix the TV to the wall and/or the entertainment cabinet, to avoid risk of injury or death due to a falling TV. (Anti-tip TV/furniture straps sold separately) Environmental Information When the TV is not in use, please switch off or disconnect the TV from the mains plug.
-
Page 8: Introduction
Introduction What’s In The Box 1. TV set 2. Remote control and batteries 3. User manual 4. Quick Start Guide 5. Stand 6. Screws for the stand 7. Power cable Installing Remote Control Batteries 1. Open the battery cover. 2. Insert two AAA size batteries. Place the batteries with their terminals corresponding to the (+) and (-) indications in the battery compartment. -
Page 9: Unit Overview
Unit Overview Cable Connections 1. DIGITAL AUDIO out – high quality digital audio. Connect to compatible sound systems 2. USB2.0 – connect to USB hard drives/flash drives for recording and media playback 3. LAN – for wired network connection 4. HDMI 3 – high quality video/audio input 5. - Page 10 Control Panel Buttons VOL+ : Volume up / navigate right VOL- : Volume down / navigate left CH+: Next TV channel / navigate up CH - : Previous TV channel / navigate down / MENU: Press to turn the TV on / enter menu / return While the TV is on, press / MENU to bring up the menu shown below.
-
Page 11: Remote Control
Remote Control Buttons (POWER) Turns the TV on or standby Access TV Mode SOURCE Bring up the SOURCE menu for changing input 0 – 9 (Numeric buttons) Enters channel numbers SUBTITLE Select from available subtitle languages Go to the YouTube homepage VOL +/- (VOLUME UP/DOWN) Adjust the TV's volume (MUTE) Turn the volume off or on... -
Page 12: Initial Set Up
Initial Set Up CAUTION: Ensure that the power to the TV is turned off while making or changing connections. Power Connection To connect the TV to power: 1. Connect the power cord to its socket at back of the TV and then plug into a suitable power outlet. - Page 13 NOTE: Home Mode is tuned for best energy efficiency. Store Mode is suited only for shop displays and settings may reset periodically. Please use Home Mode when you set the TV for personal use. Step Three: Disclaimer Use the ▲/▼ buttons to read the complete disclaimer. Then select ‘I agree’ and press OK to go to the next step.
- Page 14 2. A list of available networks will be displayed on the screen. Highlight the desired network by using ▲ / ▼, then press OK to proceed. 3. Highlight “Password” and press OK to display the password prompt “Please enter password”. 4.
-
Page 15: Smart Features & Apps
Smart Features & Apps Homepage Press the button on the remote control. Here you can run the installed apps and access input sources and menu options. Press the / buttons to select these functions. To hide the Homepage, press the EXIT button. Smart TV Applications ▪... - Page 16 Wireless Display The Wireless Display feature enables you to mirror the display of a compatible device (such as a smart phone, tablet or PC) on the TV screen by connecting your device to the TV wirelessly. In order to use this feature, your device must support Wi-Fi Display technology. NOTE: Make sure your devices support the correct Wireless Display technology.
-
Page 17: Watching Tv
Watching TV Switching to DTV If you are not in DTV Mode, switch to DTV by pressing the TV button on the remote control. Alternatively, press the SOURCE button and select DTV, then press the OK button. If you are in USB Mode, press the EXIT button to return to DTV Mode. NOTE: ATV = Analogue TV. - Page 18 Time-Shift Recording and Playback (in DTV mode only) The time-shift function allows you to pause the live TV signal, then resume playback at your convenience. 1. First, insert your USB memory device into the USB port. 2. When watching a programme in DTV Mode, press the button on the remote control to initiate time-shift mode and pause the programme;...
-
Page 19: Pvr Recording
First, insert your USB memory device into the USB port. A USB flash drive or a hard disk drive with an external power source is recommended. CAUTION: Do not disconnect the USB storage device while recording is in progress. TEAC does not take responsibility for lost data. -
Page 20: Usb Media Playback
USB Media Playback Note: To use these features, a compatible data storage unit (like a flash drive or hard disk drive in FAT32 format) must be connected and running. NOT all USB devices, such as phones, MP3 players, cameras, and the like, are compatible. We recommend using USB Flash Drives, or external HDDs with a separate power supply. - Page 21 My Music 1. Select Multimedia > My Music, and press OK to confirm. Press ▲/▼/◄/► to select a disk and press OK. 2. Press ▲/▼/◄/► to highlight one piece of music and press OK to play it. The list of music is displayed on the left.
-
Page 22: Menu System & Advanced Controls
Menu System and Advanced Controls Using the Menu System This section explains the system settings menu of your TV. Each menu is outlined and detailed to help you get the most from your TV. Please note that some function might be unavailable in certain input source. - Page 23 1. Highlight the desired channel using the the ▲ / ▼ buttons. 2. Press the RED button to mark/unmark the channel as a favourite. 3. While watching DTV, you can press the FAV button to see the list of Favourite Channels. •...
-
Page 24: Internet Connectivity
Content Type Press OK to enter, then press ◄/► to select Video, PC and Game ECO Setting Press OK to select Off / On for power saving. Color Temperature Adjusts the color temperature of the picture. Press ▲/▼ to select the color settings: Cool for a cooler palette of picture colors;... - Page 25 SPDIF Mode This option is used to control the type of audio stream sent to the Digital Audio Output (SPDIF) socket. Press OK to select Auto, PCM or Off. Audio Delay This option is used to synchronize the sound with the picture. If the sound is slower/quicker than the action of the picture, you can press ◄/►...
- Page 26 Off Time Press OK to select in and then press toswitch between Off, Once and Every Day. Sleep Timer Use ◄/► to selevt: Off,10Min,20Min,30Min,60Min, 90Min,120Min,180Min and 240Min. This can also be done with the SLEEP button on the remote control outside of the menu. Time Zone Press ◄/►...
- Page 27 T-Link This enables the TV set and your CEC devices (e.g. DVD) to turn on/off. Press OK to enter. Software Upgrade Choose to upgrade the software by USB or network. Software version Display the currently installed software version by pressing OK. Netflix Setting In Netflix Setting menu,Netflix Deactivation can deactivate your device form Netflix Primary Subtitle Language...
-
Page 28: Troubleshooting
Troubleshooting If you experience technical difficulties with your TV, try the following solutions. If this does not solve your problem, contact TEAC at 1300 553 315. Tv will not turn on • Make sure the power cord is plugged in securely to the wall outlet. Check if the remote control batteries are exhausted. -
Page 29: Specifications
Specifications (LE43E5S1UHD) PAL BG/DK/II’ SECAM BG/DK TV Broadcasting Receiving Channels VHF (BAND I/III) - UHF (BAND U) - HYPERBAND Number of Preset Channels 1000 Channel Indicator On Screen Display RF Aerial Input 75 Ohm (unbalanced) Operating Voltage 110-240V AC, 50/60Hz. - Page 30 Specifications (LE49E5S1UHD) PAL BG/DK/II’ SECAM BG/DK TV Broadcasting Receiving Channels VHF (BAND I/III) - UHF (BAND U) - HYPERBAND Number of Preset Channels 1000 Channel Indicator On Screen Display RF Aerial Input 75 Ohm (unbalanced) Operating Voltage 110-240V AC, 50/60Hz. Audio German+Nicam Stereo Audio Output Power (WRMS.) (10% THD)
- Page 31 Specifications (LE55E5S1UHD) PAL BG/DK/II’ SECAM BG/DK TV Broadcasting Receiving Channels VHF (BAND I/III) - UHF (BAND U) - HYPERBAND Number of Preset Channels 1000 Channel Indicator On Screen Display RF Aerial Input 75 Ohm (unbalanced) Operating Voltage 110-240V AC, 50/60Hz. Audio German+Nicam Stereo Audio Output Power (WRMS.) (10% THD)
- Page 32 Specifications (LE65E5S1UHD) PAL BG/DK/II’ SECAM BG/DK TV Broadcasting Receiving Channels VHF (BAND I/III) - UHF (BAND U) - HYPERBAND Number of Preset Channels 1000 Channel Indicator On Screen Display RF Aerial Input 75 Ohm (unbalanced) Operating Voltage 110-240V AC, 50/60Hz. Audio German+Nicam Stereo Audio Output Power (WRMS.) (10% THD)
- Page 33 AV and HDMI Signal Compatibility Source Supported Signals Available Side AV SECAM NTSC4.43 NTSC3.58 HDMI 480i, 480p 60Hz 576i, 576p 50Hz 720p 50Hz,60Hz 1080i 50Hz,60Hz 1080p 24Hz, 25Hz, 30Hz, 50Hz, 60Hz (X: Not Available, O: Available) In some cases a signal on the TV may not be displayed properly. The problem may be an inconsistency with standards from the source equipment (DVD, Set top box, etc).
