HP StorageWorks NAS 9000s
Quick Reference and Rack Installation Instructions
First Edition(September 2003)
Part Number: 352401–001
Quick
Reference
and Rack
Installation
Instructions
[bar code goes here in
text box, if applicable]
352401- 001
Thank you for purchasing your new HP
StorageWorks NAS 9000s
The NAS 9000s two-way server is housed in a modular, 4U
(7" high) rack-mount chassis that combines expandability with
efficient and space-saving design. The server combines enhanced
performance and optimal rack density with maximum availability
and manageability.
Important Safety Information
Before installing this product, read the Important Safety
Information document provided.
WARNING: This product contains energy levels that are
considered hazardous. To reduce the risk of personal injury
from electric shock and hazardous energy, individuals who
are knowledgeable of the procedures, precautions, and
hazards associated with equipment containing hazardous
energy circuits must perform the installation and servicing of
this product.
WARNING: To reduce the risk of personal injury or damage
to the equipment:
Observe local occupational health and safety
requirements and guidelines for manual material
handling.
Obtain adequate assistance to lift and stabilize the chassis
during installation or removal.
Be aware that the product becomes unstable when it is not
fastened to the rails.
Before removing the server from the rack remove all
hot-plug power supplies, power modules, and drives to
reduce the overall weight of the product.
Before removing the server from the rack remove all
hot-plug power supplies, power modules, and drives to
reduce the overall weight of the product.
Rack Stability
WARNING: To reduce the risk of personal injury or damage
to the equipment, be sure that:
The leveling jacks are fully extended to the floor.
The full weight of the rack rests on the leveling jacks.
The stabilizing feet are connected to the rack if it is a
single-rack installation.
The racks are coupled together in multiple-rack
installations.
The components are extended one at a time only. A rack
may become unstable if more than one component is
extended.
Audience Assumptions
This poster provides a quick way for customers experienced in
server installations to setup and configure the NAS 9000s server.
The following instructions are written for persons who are
qualified in installing and servicing computer equipment and are
trained in recognizing hazards in products with high-energy
levels, such as the power supplies, System Power Modules, and
redundant line cord switches in this computer system. For
detailed instructions, refer to the setup and installation guide.
