- Page 1 O W N E R ’ S M A N U A L RM7200 RM3300 RM3600 RM7600 RM4300 RM4600 S Y S T E M S AT E L L I T E S C E N T E R C H A N N E L...
- Page 2 9am-6pm EST, Monday through Friday, or email: polkcs@polkaudio.com. The integrated brackets on the RM7000 Series satellites make them easy to mount. They also sound great on stands (available at your Polk Audio dealer, or online at http://polkaudio.tranguard.com/), bookshelves, or in entertainment centers. Place the small front satellites about as far apart as the distance you are sitting from them (Figure 2).
- Page 3 Note that one of the terminals on the rear of each speaker is red (+) and the other is black (–). Make certain that you connect the wire from the red (+) terminal of your amplifier or receiver to the red (+) terminal on your speaker and the wire from the black (–) terminal of your amplifier or receiver to the black (–) terminal on your...
- Page 4 Tug gently on the speaker to make certain that the screws and bracket are properly aligned and that the wall anchors are secure. If the bracket is not held snug against the wall by the screw heads, remove the speaker from the wall, drive the screws in a little further and then remount the speaker.
- Page 5 “off” position) the power light will glow RED. In the “Auto” position, the amplifier will automatically turn on as soon as the speaker senses a signal coming from your electronics. The power light will change from RED to GREEN upon sensing a signal. The subwoofer will turn off approximately 15 minutes after input signal ceases, and the power light will return to RED.
- Page 6 Outside the US: These adjustments are specific to the Polk Audio PSW650 Model Subwoofer. If you are using a subwoofer other than the PSW650, please refer to that subwoofer’s owner’s manual for correct, model-specific adjustment instructions You’ll find an informative article on “Subwoofer Positioning and Adjustment”...
- Page 7 If, after following these hook up directions, you experience difficulty, please double-check all wire connections. Should you isolate the problem to the speaker, contact the authorized Polk Audio dealer where you made your purchase, or call Polk Audio’s friendly Customer Service Department at 1-800-377-7655 (calls from US or CAN only), 410-764-5266 9am to 6pm EST, Monday through Friday.
- Page 8 RM7000 tienen blindaje magnético para poder ubicarlos con seguridad cerca de televisores o monitores de video. Si nota que hay distorsión o descoloración del video, aleje inmediatamente los altavoces de la fuente de video y llame al Servicio al Cliente de Polk Audio al 800.377.7655 (EE.UU. y Canadá) o escriba a polkcs@polkaudio.com.
- Page 9 Figure 3a Placement options for rear/surround speakers. Opciones de ubicación de los altavoces surround o de atrás. Options de disposition des enceintes arrière- ambiophoniques. Platzierungsoptionen für hintere Lautsprecher bzw. Surround-Lautsprecher. Figure 4 6" (15cm) Allow at least 6" (15cm) between sub driver and wall or obstruction.
- Page 10 Banana Plug holes. Insert Banana Plugs. (This is for US owners only.) Figure 8 CENTER CHANNEL SUBWOOFER Contact Polk Audio Customer Service 1-800-377-7655 (Outside US: 410-764-5266), polkcs@polkaudio.com Tighten hex nut. Do not insert insulated section of speaker wire.
- Page 11 Verwenden Sie die Schablone zur Markierung der Befestigungsstelle. Figure 12 Slide the speaker down on the screw heads to catch the keyhole slots. Deslice el altavoz sobre las cabezas de los tornillos para que encajen en las ranuras en forma de cerradura.
- Page 12 Arrière et contrôles du subwoofer amplifié RM7200. Rückseite des Subwoofers (mit RM7200) mit Steuerungen. Contact Polk Audio Customer Service 1-800-377-7655 (Outside US: 410-764-5266), polkcs@polkaudio.com Figure 14 t h e s p e a k e r s p e c i a l i s t s Rear of PSW650 Subwoofer used with RM7600, showing controls.
- Page 13 Figure 15a Figure 15b Recommended Variable Recommended Variable Crossover Crossover Setting for wall Setting for satellites on stands. mounted satellites. Ajuste recomendado del crossover Ajuste recomendado del crossover variable para satélites montados variable para satélites montados sobre pedestales. en la pared. Réglage recommandé...
- Page 14 Contact Polk Audio Customer Service 1-800-377-7655 (Outside US: 410-764-5266), polkcs@polkaudio.com...
- Page 15 Product is defective in materials or workmanship as warranted above, your sole remedy shall be repair or replacement as provided above. In no event will Polk Audio, Inc. be liable to you for any incidental or consequential damages arising out of the use or inability to use the Product, even if Polk Audio, Inc.
- Page 16 Polk Audio 5601 Metro Drive Baltimore, Maryland 21215 800-377-7655 RM7208-1...
