Summary of Contents for Westinghouse TR15142
- Page 1 INSTRUCTION MANUAL GASOLINE BRUSH CUTTER TR15142 Note : Read and carefully before using this machine 0.70 L 42.7cc 1.3 kW...
- Page 2 MANUAL SAFETY SYMBOLS AND IMPORTANT INFORMATION This symbol accompanied by the words WARNING and DANGER calls attention to an act or condition that can lead to serious personal injury to operator and bystanders. IMPORTANT: The enclosed message NOTE This enclosed message provides tips provides information necessary for the for use, care and maintenance of the unit.
- Page 3 WARNING! DANGER! Read this Manual. Failure to do so can result in serious injury to the operator and/or bystanders. • Objects may be thrown or ricochet in all directions. ALWAYS WEAR EYE PROTECTION. • Keep bystanders at least 50 feet (15m) away. •...
-
Page 4: What Is What
WHAT IS WHAT? Harness Throttle trigger Left handle Switch Engine Throttle lock Clutch Safety trigger plug Belt hoop Spark plug Control handle Priming bulb Shaft pipe Chock lever Bush guard Muffler Gearbox Start Blade Fuel tank Trimmer kit Tank cap Mixing bottle Accessories: 1pc Spool &... -
Page 5: Assembly Procedures
ASSEMBLY PROCEDURES ASSEMBLE THE HANDLES (Fig. 1-1) • Loosen the 4 bolts on the upper shaft • Insert the handle • Push on the handles as desired • Tighten the 4 screws with the 5mm Allen Key. REPLACE THE CUTTING BLADE (Fig. 1-2, 3) •... -
Page 6: Operating Procedures
OPERATING PROCEDURES FUEL WARNING! DANGER! • The trimmer is equipped with a two -stroke engine. Always run the engine on fuel, which is mixed with oil. • Provide good ventilation, when fueling or handling fuel. • Always use branded 90 octane unleaded gasoline. •... - Page 7 STARTING (Fig 2-1A, 1B, 1C) CAUTION! Before starting, make sure the cutting attachment does not touch anything 1. Set ignition switch (14) to the ON position. (Fig. 2-1A). Push priming bulb (18) several times so that fuel flows through return pipe (Fig. 2-1B) 2.
-
Page 8: Maintenance
Fig. 2 - 2C Fig. 2- 1A Fig. 2-2B STOPPING • Decrease engine speed and run at an idle for a few minutes, then turn off ignition switch. WARNING! DANGER! A cutting attachment can injure while it continues to spin after the engine is stopped or power cont rol is released. - Page 9 NOTE! Standard Idle rpm is 2800-3200 rpm WARNING! DANGER! When the engine is idling the cutting attachment must under no circumstances rotate. AIR FILTER (Fig. 3-2) The air filter must be cleaned from dust and dirt in order to avoid: •...
- Page 10 MUFFLER Remove the muffler and clean excess carbon from the exhaust port or muffler inlet every 100 hours of operation. If you find corrosion on the muffler, replace it. CYLINDER (ENGINE COOLING) The engine is air cooled, and air must circulate freely around engine and over cooling fins on cylinder head to prevent overheating.
-
Page 11: Troubleshooting
TROUBLESHOOTING Problem Check Status Cause Remedy Fuel strainer dogged Clean or replace Fuel at No fuel at carburetor Fuel line clogged Clean or replace carburetor Carburetor See your Local dealer No fuel at cylinder Carburetor See your Local dealer Open choke Fuel at cylinder Engine Clean/replace...
