SERVICE MANUAL
6 S ERVICE MANUAL
2007
MA346
KW-XG700J, KW-XG701E, KW-XG701EX,
KW-XG701EY, KW-XG701EU, KW-XG704UI,
KW-XG705U, KW-XG705UN, KW-XG705UH,
KW-XG706U, KW-XG706UN, KW-XG706UH,
KW-XG707EE, KW-XG708UF
COPYRIGHT © 2007 Victor Company of Japan, Limited
* Please refer to the mechanism manual (model TN2007-1010
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)
1
PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
2
SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
3
DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
4
ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-15
5
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-16
CD RECEIVER
KW-XG700
KW-XG700

TABLE OF CONTENTS

COPYRIGHT © 2007 Victor Company of Japan, Limited
KW-XG701
KW-XG707
(No.MY005
and No.MY005B)) for the CD mechanism.
No.MA346
2007/6

Advertisement

Table of Contents
loading

Related Manuals for JVC KW-XG700J

Summary of Contents for JVC KW-XG700J

  • Page 1: Table Of Contents

    SERVICE MANUAL CD RECEIVER MA346 2007 6 S ERVICE MANUAL KW-XG700J, KW-XG701E, KW-XG701EX, KW-XG701EY, KW-XG701EU, KW-XG704UI, KW-XG705U, KW-XG705UN, KW-XG705UH, KW-XG706U, KW-XG706UN, KW-XG706UH, KW-XG707EE, KW-XG708UF KW-XG701 KW-XG700 KW-XG700 KW-XG707 COPYRIGHT © 2007 Victor Company of Japan, Limited * Please refer to the mechanism manual (model TN2007-1010 (No.MY005...
  • Page 2 SPECIFICATION KW-XG700 AUDIO AMPLIFIER SECTION 20 W RMS × 4 Channels at 4 Ω and [< or =] 1% THD+N Power Output 80 dBA (reference: 1 W into 4 Ω) Signal to Noise Ratio 4 Ω (4 Ω to 8 Ω allowance) Load Impedance Tone Control Range Bass...
  • Page 3 KW-XG701 AUDIO AMPLIFIER SECTION Maximum Power Output Front and rear 50 W per channel 19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total har- Continuous Power Output Front and rear (RMS) monic distortion.
  • Page 4 KW-XG704 AUDIO AMPLIFIER SECTION Maximum Power Output Front and rear 50 W per channel 19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total har- Continuous Power Output Front and rear (RMS) monic distortion.
  • Page 5 KW-XG705/KW-XG706/KW-XG708 AUDIO AMPLIFIER SECTION Maximum Power Output Front and rear 50 W per channel 19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total har- Continuous Power Output Front and rear (RMS) monic distortion.
  • Page 6 KW-XG707 AUDIO AMPLIFIER SECTION Maximum Power Output Front and rear 50 W per channel 19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total har- Continuous Power Output Front and rear (RMS) monic distortion.

  • Page 7: Precaution

    SECTION 1 PRECAUTION Safety Precautions Burrs formed during molding may be left over on some parts of the chassis. Therefore, pay attention to such burrs in the case of preforming repair of this system. Please use enough caution not to see the beam directly or touch it in case of an adjustment or operation check.
  • Page 8 Preventing static electricity Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs. 1.2.1 Grounding to prevent damage by static electricity Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as laser products.
  • Page 9 Important for laser products 1.CLASS 1 LASER PRODUCT 5.CAUTION : If safety switches malfunction, the laser is able to function. 2.CAUTION : (For U.S.A.) Visible and/or invisible class II laser radiation 6.CAUTION : Use of controls, adjustments or performance of when open.

  • Page 10: Specific Service Instructions

    SECTION 2 SPECIFIC SERVICE INSTRUCTIONS This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS. 1-10 (No.MA346)

  • Page 11: Disassembly

    SECTION 3 DISASSEMBLY Main body 3.1.1 Removing the FRONT PANEL assembly (See Fig.1) (1) From the bottom side of main body, remove the two screws A attaching the both side of the FRONT PANEL assembly. (2) Disengage two hooks a engaged CHASSIS assembly. hook hook Fig.1...
  • Page 12 3.1.3 Removing the REAR BRACKET (See Fig.3) (1) Remove the seven screws D, two screws E and one screw F attaching the REAR BRACKET. Fig.3 3.1.4 Removing the BOTTOM CHASSIS assembly (See Fig.4) (1) Remove the four screws G attaching the BOTTOM CHAS- SIS assembly.
  • Page 13 3.1.5 Removing the FUNC BOARD assembly (See Fig.5) (1) Remove the one screw H attaching the FUNC BOARD as- sembly. CN501 (2) Disconnect the connecter wire from MAIN BOARD assem- bly connected to connector CN322 of the FUNC BOARD assembly. (3) Straighten hook b attaching the FUNC BOARD assembly.
  • Page 14 3.1.8 Removing the CD MECHANISM assembly (See Fig.7) (1) Remove the three screws L attaching the CD MECHA- NISM assembly. Fig.7 3.1.9 Removing the SWITCH BOARD assembly (See Fig.8) (1) Remove the volume knob from the front side of the FRONT PANEL assembly.

  • Page 15: Adjustment

    Load impedance : 20K.(2 Speakers connection) (3) Digital tester Output Level : Line out 2.5V (Vol. MAX) (4) Tracking offset meter (5) Test Disc JVC :CTS-1000 4.1.3 Standard volume position (6) Extension cable for check Balance and Bass &Treble volume : lndication"0"...

  • Page 16: Troubleshooting

    SECTION 5 TROUBLESHOOTING 16 PIN CORD DIAGRAM (for KW-XG700) OR/WH Black Green BL/WH Violet Blue Gray WH/BK White Yellow GN/BK Brown Orange VI/BK GY/BK MEMORY 16 YL 8 BK 7 RD 15 OR/WH 13 BR REMOTE 5 BL/WH 3 GN 11 GN/BK 2 VI 10 VI/BK...

  • Page 17: Gn Gn/Bk

    16 PIN CORD DIAGRAM (for KW-XG701, KW-XG707) Black Green OR/WH Violet Gray Blue BL/WH White Yellow Orange Brown WH/BK GN/BK VI/BK GY/BK BL/WH OR/WH 7 RD RD 7 16 YL MEMORY YL 4 15 OR/WH 8 BK REMOTE 6 BL/WH 13 BR 3 GN 11 GN/BK...

  • Page 18: Vi/Bk

    16 PIN CORD DIAGRAM (for KW-XG-704, KW-XG705, KW-XG706) Black Green OR/WH Violet BL/WH Gray Blue WH White Yellow WH/BK Brown Orange GN/BK VI/BK GY/BK MEMORY 16 YL 8 BK 7 RD 15 OR/WH 13 BR 3 GN 11 GN/BK 2 VI 10 VI/BK 4 WH 12 WH/BK...
  • Page 19 16 PIN CORD DIAGRAM (for KW-XG708) Black Green Violet OR/WH Gray Blue BL/WH White Yellow Orange Brown WH/BK GN/BK VI/BK GY/BK OR/WH RD2 BK YL 2 OR/WH GN/BK VI/BK WH/BK GY/BK BL/WH VI/BK GY/BK WH/BK GN/BK (No.MA346)1-19...

  • Page 20: No.ma346)1

    Victor company of Japan, Limited Mobile Entertainment Business Group Mobile Entertainment Category 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan (No.MA346) Printed in Japan...
  • Page 21 SCHEMATIC DIAGRAMS CD RECEIVER KW-XG700J,KW-XG701E,KW-XG701EX KW-XG701EY,KW-XG701EU,KW-XG704UI KW-XG705U,KW-XG705UN,KW-XG705UH KW-XG706U,KW-XG706UN,KW-XG706UH KW-XG707EE,KW-XG708UF CD-ROM No.SML200706 KW-XG701 KW-XG700 KW-XG700 KW-XG707 * Please refer to the mechanism manual (model TN2007-1010, No.MY005, MY005B) for the CD mechanism. Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)

  • Page 22: Safety Precaution

    Safety precaution Burrs formed during molding may be left over on some parts of the chassis. Therefore, pay attention to such burrs in the case of preforming repair of this system. Please use enough caution not to see the beam directly or touch it in case of an adjustment or operation check.
  • Page 23 < M E M O >...

  • Page 24: Block Diagram

    Block diagram Main amplifier CD servo control section LOAD/FEED FEED+/- MOTOR IC502,X5001 CLOCK GEN. POSITION SET SWITCH IC503 LRCK 24BIt SPINDLE SPINDLE+/- DATA IC581 CD.L/R OUTL/R MOTOR CD L.P.F. IC541 DACMS DACMC, DACMD SW1, SW2 D.SERVO & DSP SFSY, SRAMSTB DBUS0 to 3 BUS0 to 3 DBUCK, /DCCE...
  • Page 25 DIMMER INPUT TELMUTE Q891 TELMUTE TEL MUTE CN702 STEERING STEERING REMOTE Used for KW-XG700,KW-XG701 SO, I/O SI/SO IC801 SI/SO, BUSCK INT, SCK JVC BUS JVC BUS IC181,Q181,Q182 USB/CDCH CH.L/R USB/CH SWITCH URST USB_L/R USB_TX, USB_RX IC652 681,IC682 L.P.F. IC641 IC642 LEVEL...
  • Page 26 Standard schematic diagrams Main section CN261 QGA2501C1-03 R262 Q262 KTD130 1/50 4.7u QNB0190-001 1/50 IC161 TDA7419N-X R161 2.2k R162 RDSDA 2.2k R178 1/50 C161 1/50 C171 CD.L C162 R179 CD.R C172 CH-USB.L CH-USB.R 0.0047 AUX_L C164 1/50 AUX_G C165 1/50 C166 AUX_R RT1N141C-X...
  • Page 27 SWREG D331 D321 MC2836-X MC2836-X 3.3V R262 R321 R322 USB_L R325 RT6N430C-X Q262 Q321 KTD1304-X USB_R R331 R332 USB_TX R335 Q331 USB_RX RT6N430C-X URST USBMUTE R345 Q341 RT6N430C-X Q933 2SA1365/F/-X IC301 R341 R342 TB2926HQ R355 Q351 RT6N430C-X R351 R352 R386 C364 R385 C315...
  • Page 28 CD section FEED- FEED- R504 R516 C520 8.2k 0.022 FEED+ FEED+ 8.2k R515 6.8k R512 7.5k VCC_3.3 R511 D501 1A3G-T1 R524 SPINDLE- SPINDLE- SPINDLE+ SPINDLE+ FOCUS- FOCUS- VREF VREF FOCUS+ FOCUS+ TRACKING+ TRACKING+ TRACKING- TRACKING- R522 1.5k R523 1.5k 1.5_V7 1.5_V8 C530 0.015...
  • Page 29 CD_8V CD.L C580 1A3G-T1 4.7/25 R581 R583 R585 R589 CD.R C582 1.5k R586 150p 8.2k VDD_5V C581 C584 CDON 100p 820p SW5V C591 C594 BUS0 100p 820p BUS1 R591 R593 BUS2 BUS3 BUCK L5002 Q5002 RT1N141C-X R580 DACMS R5006 DACMC 1.2K DACMD R596 C592...
  • Page 30 LCD and Key control section (for KW-XG700J) LCD1 QLD0484-001 IC603 IC602 PT6523LQ-L PT6523LQ-L S49B S32B S49A S32A S31B S31A S50B S51B S30B S30A R6400 R6401 S29B S29A 2.2K 2.2K COM1B S28B COM1A S28A COM2B S27B COM2A S27A COM3B S26B COM3A...
  • Page 31 R6003 Q6002 2SA1365/F/-X CN601 QGB1004J2-24X KEY0 KEY1 KEY2 VOL1 VOL2 DIMOUT LCDCE1 LCDCE2 LCDSCK LCDDATA REMOCON S32A S31A S30A S29A S28A S27A R6202 R6201 S26A R6304 R6303 R6302 R6301 R6300 KEY0 S25A 2.7K 1.8K 1.2K IC604 S24A C6202 C6201 NJL29H380A S23A PJ601 0.0047...
  • Page 32 LCD and Key control section (except KW-XG700J) LCD1 QLD0485-001 IC602 IC603 PT6523LQ-L PT6523LQ-L S49a S32a S49b S32b S31a S50b S31b S30a S51b S30b S29a S29b COM1a S28a COM1b S28b COM2a S27a COM2b S27b COM3a S26a COM3b S26b S25a S25b R6402...
  • Page 33 D6102 D6101 D6100 NSCM315C/Z/-W NSCM315C/Z/-W NSCM315C/Z/-W CN601 R6200 QGB1004J2-24X KEY0 Q6200 2SA1365/F/-X KEY1 KEY2 VOL1 VOL2 DIMOUT LCDCE1 LCDCE2 LCDSCK LCDDATA R6203 ACC5V 1.2K REMOCON R6204 1.2K COL1 R6127 100k COL2 R6128 100k S32b COL3 R6129 100k S31b S30b S29b S28b S27b R6350...
  • Page 34 USB section B601 C601 100P IC65 X602 AK4385 NAX0832-001X MCLK BCLK USBLRCK R612 DACPDN DACOCS DCLK DDATA C614 XA12 XA11 XA10 C612 C602 C605 0.0012 C620 C610 C611 330p IC601 C640 0.15 R621 4.7K TCC8600 IC641 C648 SA16D90TFI011B 22/6.3 R699 XA16 R698 XA15...
  • Page 35 CN691 QGB1004K1-06 IC691 BD6516F-X R696 R676 R672 R677 4.7K C671 4.7K USB_L 3300P R671 R675 IC651 R678 470P C673 AK4385ET-X 4.7K IC683 BD9781HFP-W C654 47/10 C655 IC652 0.1/16 NJM4565E-X L681 NQL71EM-330X C663 R661 R665 470P 4.7K R668 C661 R662 3300P USB_R 4.7K R667...
  • Page 36 Printed circuit boards Main board Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade) forward side IC901 C908 C911 C934 IC301 C306...
  • Page 37 reverse side CN901 C901 IC901 C912 IC301 C317 C914 J801 C908 C184 L901 C906 C186 C320 C910 C919 C315 C909 R901 C310 D901 C881 C904 C913 C933 C902 CN702 C903 C851 C907 C905 C262 C261 CN261 C365 C386 C177 C171 C385 C168 C165...
  • Page 38 Switch board Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade) for KW-XG700J forward side D6125 S6300 D6126 LCD1...
  • Page 39 Switch board Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade) except KW-XG700J D6224 forward side D6223 D6222 S6302...
  • Page 40 Function board Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade) Q331 J321 R325 D321 R345 R341 B331 Q351 R355 D331 CN322...
  • Page 41 < M E M O >...
  • Page 42 Victor Company of Japan, Limited Mobile Entertainment Business Group Mobile Entertainment Category 10-1,1chome,Ohwatari-machi,Maebashi-city,Gumma-ken,371-8543,Japan Printed in Japan (No.MA346SCH)

  • Page 43: Parts List

    PARTS LIST KW-XG700J,KW-XG701E,KW-XG701EX KW-XG701EY,KW-XG701EU,KW-XG704UI KW-XG705U,KW-XG705UN,KW-XG705UH KW-XG706U,KW-XG706UN,KW-XG706UH KW-XG707EE,KW-XG708UF * All printed circuit boards and its assemblies are not available as service parts. * Please refer to the mechanism manual (model TN2007-1010, No.MY005,MY005B) for the CD mechanism. - Contents - 3- 2 Exploded view of general assembly and parts list (Block No.M1)
  • Page 44 Exploded view of general assembly and parts list Block No. Main board S/M : MY005,MY005B model : TN2007-1010 Switch board...
  • Page 45 board Function board The parts without symbol number are not service.
  • Page 46 General Assembly Block No. [M][1][M][M]  Symbol No. Part No. Part Name Description Local GE10170-001A TOP CHASSIS LV10864-002A MIDDLE CHASSIS LV10865-002A BOTTOM CHASSIS GE31799-003A REAR BRACKET LV34655-002A HEAT SINK QYSDST2604ZA TAP SCREW M2.6 x 4mm(x3) GE40377-002A SCREW (x4) GE40218-074A SHEET QYSDST2606ZA TAP SCREW M2.6 x 6mm(x4)
  • Page 47  Symbol No. Part No. Part Name Description Local QNZ0932-001 RUBBER CONNECTO (x2) VYTA500-001 PIN CAP (x2) QAM0991-001 STEERING REMOTE 700J,701E,701EX,701EY,701EU QAM1008-001 S.WOOFER CABLE WJN0193-001A-E E-SH C WIRE C-C LV34650-001A IC BKT GE40364-001A REG IC BKT GE32742-001A NAME PLATE 700J GE32760-001A NAME PLATE 701E,701EX,701EY,701EU...

  • Page 48: Electrical Parts List

    Electrical parts list Main board  Symbol No. Part No. Part Name Description Local Block No. [0][1] Q977 2SA1530A/QR/-X TRANSISTOR  Symbol No. Part No. Part Name Description Local Q977 or 2SB709A/QR/-X TRANSISTOR Q5001 2SA1705/ST/-T TRANSISTOR Q5002 RT1N141C-X DIGI TRANSISTOR IC71 LC72725KM-X 701E,701...
  • Page 49  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local D852 or RB160M-30-X SB DIODE 704UI,70 C167 NCB31HK-472X C CAPACITOR 4700pF 50V K 5U,705U C168 QTE1A57-107Z E CAPACITOR 100uF 10V N,705UH, C171 QTE1H57-105Z E CAPACITOR 1uF 50V...
  • Page 50  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local C366 QEKJ1HM-475Z E CAPACITOR 4.7uF 25V M 700J,701 C525 QEKJ1AM-107Z E CAPACITOR 100uF 10V M 701EX,70 E,704UI, 1EY,701E 705U,705 UN,705U C526 QEKJ1CM-107Z E CAPACITOR 100uF 10V M 700J,701...
  • Page 51  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local C575 QEKJ1AM-107Z E CAPACITOR 100uF 10V M 701EX,70 C685 NCB31EK-104X C CAPACITOR 0.1uF 25V K 1EY,701E C686 NCB31HK-472X C CAPACITOR 4700pF 50V K C687 NBZ0009-127X E.
  • Page 52  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local C995 NDC31HJ-471X C CAPACITOR 470pF 50V J R302 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J C996 NDC31HJ-471X C CAPACITOR 470pF 50V J R303 NRSA63J-103X MG RESISTOR 10kΩ...
  • Page 53  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local R585 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J R682 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R586 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J R683 NRSA63J-103X MG RESISTOR 10kΩ...
  • Page 54 MG RESISTOR 47kΩ 1/16W J R932 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R971 NRS181J-222X MG RESISTOR 2.2kΩ 1/8W J Switch board (except KW-XG700J) R972 NRS181J-222X MG RESISTOR 2.2kΩ 1/8W J R976 NRSA02J-273X MG RESISTOR 27kΩ 1/10W J Block No. [0][2]...
  • Page 55  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local Q6107 or 2SD601A/QR/-X TRANSISTOR D6205 LSQ971/KL/-X 701E,701 EX,701EY, Q6108 2SC3928A/QR/-X TRANSISTOR 701EU,70 Q6108 or 2SD601A/QR/-X TRANSISTOR Q6109 2SC3928A/QR/-X TRANSISTOR D6205 LHQ974/LM/-X 704UI,705 Q6109 or 2SD601A/QR/-X TRANSISTOR U,705UN,...
  • Page 56  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local D6213 LHQ974/LM/-X 704UI,705 D6222 LSQ971/KL/-X 701E,701 U,705UN, EX,701EY, 705UH,70 701EU,70 6U,706UN ,706UH,70 D6222 LHQ974/LM/-X 704UI,705 U,705UN, D6214 LSQ971/KL/-X 701E,701 705UH,70 EX,701EY, 6U,706UN 701EU,70 ,706UH,70 D6214...
  • Page 57 MG RESISTOR 470Ω 1/16W J 701E,701 EX,701EY, S6340 NSW0206-001X TACT SWITCH 701EU,70 R6221 NRSA63J-431X MG RESISTOR 430Ω 1/16W J 704UI,705 Switch board (only KW-XG700J) U,705UN, 705UH,70 6U,706UN Block No. [0][3] ,706UH,70  Symbol No. Part No. Part Name Description Local...
  • Page 58  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local D6122 LHQ974/LM/-X R6314 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J D6123 LHQ974/LM/-X R6320 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J D6124 LHQ974/LM/-X R6360 NRSA63J-153X MG RESISTOR 15kΩ...
  • Page 59  Symbol No. Part No. Part Name Description Local CN322 QGA2001F1-07 CONNECTOR W-B (1-7) J321 QNN0740-001 PIN JACK 3-17...
  • Page 60 Packing materials and accessories parts list Block No. No additional / supplemental order of WARRANTY CARDs are available. A1,A2,A3,A4,A5,A9, A13,A14,A15,A16, A17,A18,A19 KW-XG701 Only The parts without symbol number are not service. 3-18...
  • Page 61 Packing and Accessories Block No. [M][3][M][M]  Symbol No. Part No. Part Name Description Local GET0457-001A INST BOOK ENG FRE SPA 700J GET0461-001A INST BOOK GER FRE ITA 701E GET0461-004A INST BOOK DUT DAN FIN SWE 701EX GET0461-006A INST BOOK ENG GER RUS 701EY GET0461-005A...
