Page 3
In this Guide This Getting Started Guide provides instructions for basic installation and configuration of the SonicWall™ Secure Mobile Access 6200/7200 appliances. For Quick Policy Setup Charts, refer to Quick Policy Setup on page 57. Contents Chapter 1 Sections included: In this Guide on page 3 Contents on page 3 Chapter 2 Sections included: Introduction to the SMA 6200/7200 on page 7 SMA 6200/7200 Package Contents on page 8 SMA 6200/7200 Front Panels on page 10 SMA 6200/7200 Back Panels on page 11 SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 4
Chapter 3 Sections included: Preparing to Deploy the SMA 6200/7200 on page 13 Network Architecture on page 14 Preparing for the Installation on page 16 About Installation and Deployment on page 19 Chapter 4 Sections included: Installation and Configuration on page 21 Connecting the Appliance on page 22 Starting the Appliance on page 22 Entering Network Settings Using the LCD on page 23 Running the Setup Wizard on page 23 Connecting to AMC on page 25 Configuring Basic WorkPlace Portal Access on page 26 Chapter 5 Sections included: Registering and Obtaining a License on page 31 Using MySonicWall on page 32 Creating a MySonicWall account on page 32 Registering your Appliance on page 33 Downloading your License File on page 33 Importing your Licenses on page 34 SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 5
Chapter 6 Sections included: Rack Mounting the Appliance on page 37 Attaching Inner Rails to the Appliance on page 40 Installing the Outer Rails on page 40 Installing the Appliance in the Rack on page 42 Removing the Appliance from the Rack on page 42 Chapter 7 Sections included: Safety and Regulatory Information on page 45 Safety Instructions on page 46 Sicherheitsanweisungen on page 48 安全說明 on page 51 Declaration of Conformity on page 53 Warranty Information on page 53 台灣 RoHS / 限用物質含有情況標示資訊 on page 54 For general support information, see SonicWall Support on page 55. SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 6
SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 7
Introduction to the SMA 6200/7200 This section describes the items shipped with the SonicWall Secure Mobile Access 6200/7200 appliances and provides front and rear illustrations of the appliances. • SMA 6200/7200 Package Contents on page 8 • SMA 6200/7200 Front Panels on page 10 • SMA 6200/7200 Back Panels on page 11 SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 8
1 One SMA 6200 or SMA 7200 appliance 2 One rack mounting kit 3 One RJ45 to DB9 console cable 4 One Ethernet cable 5 One power cord for SMA 6200 or two power cords for SMA 7200* 6 One SonicWall Secure Mobile Access 6200/7200 Getting Started Guide *The included power cord(s) are approved for use only in specific countries or regions. Before using a power cord, verify that it is rated and approved for use in your location. The power cords are for AC mains installation only. See Safety and Regulatory Information on page 45 for minimum power cord rating and additional safety information. 添付の電源 コ ー ド に関 し て 電気安全を確保する ために、 弊社製品にご使用いただ く 電源 コ ー ド は必ず製品同梱の電源 コ ー ド を ご使用 く だ さ い。...
Page 9
Package contents SonicWall™ Secure Mobile Access 6200/7200 Ge ng Started Guide Regulatory Model Numbers: 1RK31-0B0 – SMA 6200 1RK30-0AF – SMA 7200 If any items are missing from your package, contact Support at https://support.sonicwall.com. SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 10
Console port Diagnostics port (for future use) LED Indicators USB ports (top to bottom) Hard disk drive activity Alarm condition Test - Quick blinking: Initializing; Solid: Test mode Power 1/2 - Blue: operating correctly; Yellow: Unconnected power supply or failure SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 11
SMA 6200/7200 Back Panels SMA 6200: Hard drives (2) Power supply Fans (3) SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 12
SMA 7200: Hard drives (2) Power supplies (2) Fans (3) SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 13
Preparing to Deploy the SMA 6200/7200 This section provides an overview of single‐homed and dual‐homed network architecture and discusses firewall settings and other information you need about components of your network to successfully deploy the SMA 6200/7200. • Network Architecture on page 14 • Preparing for the Installation on page 16 • About Installation and Deployment on page 19 SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 14
Network Architecture All SMA 6200/7200 appliances can be set up in either a dual interface or single interface configuration, also known as dual‐ homed and single‐homed. In either configuration, appliance management with AMC is SMA appliance accomplished by accessing the internal (X0) interface. This guide steps you through a basic single‐homed interface Single‐Homed Interface Configuration configuration. For the highest level of security and performance, SonicWall recommends a dual‐homed (Internal Interface) configuration. Refer to the Deployment Planning Guide and SMA Administration Guide for further information. A single network interface is used for both internal and external traffic. In this configuration, the appliance is usually installed in the demilitarized zone (or DMZ, also known as a Dual‐Homed Configuration (Internal perimeter network). and External Interfaces) Corporate network One network interface is used for external traffic (that is, to and from the Internet), and the other interface is used for Internet internal traffic (to and from your corporate network). File Internal interface Server Application Server Server Firewall Firewall SMA appliance SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 15
7200 services—including HTTP/S traffic for the Web proxy service—are sent over port 80 (HTTP) and port 443 (HTTPS). and ease of use: Traffic from the OnDemand agent is always sent over port 443. • Network Time Protocol (NTP) server for synchronizing Because most networks are configured to enable traffic over the time on the appliance. these ports, you should not need to reconfigure firewalls on your network. • External server for storing syslog output. You should install the appliance in a location where it can • Administrator’s workstation for secure shell (SSH) connect to resources on your network, including: access. • Application servers and file servers, including Web You can configure the appliance to use a self‐signed server servers, client/server applications, and Windows file certificate, or, for enhanced security, you can obtain a servers. certificate from a commercial certificate authority (CA). For more information, refer to the SMA Administration Guide. • External authentication repositories (such as an LDAP, Microsoft Active Directory, or RADIUS server). • One or more Domain Name System (DNS) servers. • Optionally, a Windows Internet Name Service (WINS) server. This is required for browsing Windows networks using WorkPlace. CAUTION: The SMA 6200/7200 appliance does not provide full firewall capabilities and should be secured behind a firewall. Running without a firewall makes the appliance vulnerable to attacks that can compromise security and degrade performance. SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 16
• Verifying your Firewall Policies on page 17 and for any WorkPlace sites that use a unique name. These names should be added to your public DNS; they are also visible to users when they connect to Web‐ Gathering Information based resources. • A FQDN for the Appliance Management Console (AMC) Before configuring the appliance, you need to gather the server. The AMC server name is used to access AMC, following information. You are prompted for some of this which is a Web‐based tool for administering the information when running the Setup Wizard, but most of it will appliance. be used when you configure the appliance in the Appliance Management Console (AMC). Refer to the SMA Administration Name lookup information Guide. • Internal DNS domain name of the network to which the Settings required to start Appliance Management Console appliance is connected • The root password for administering the appliance • Primary internal DNS server address (additional DNS servers are optional) • The name for the appliance (because this name is used only in log files, you do not need to add it to DNS) • IP address for an internal WINS server and the name of your Windows domain (required to browse files on a • The internal IP address and, optionally, an external IP Windows network using WorkPlace, but are otherwise address optional) SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 17
External Firewall (Connect Tunnel or OnDemand Tunnel), you must allocate IP For secure access to the appliance from a Web browser or addresses for one or more address pools. For more OnDemand, you must make sure that ports 80 and 443 are information, refer to the SMA Administration Guide. open on firewalls at your site. Opening your firewall to permit Optional configuration information SSH access is optional, but can be useful for performing administrative tasks from a remote system. • To enable SSH access from a remote machine, you need to know the remote host’s IP address. External Firewall • To synchronize with an NTP server, you need to know Traffic Port/ the IP addresses for one or more NTP servers. Usage Required? Type protocol • To send data to a syslog server, you need to know the IP 4500/UDP ESP Tunnel address and port number for one or more syslog HTTP 80/tcp Unencrypted network servers. access HTTPS 443/tcp Encrypted network access 22/tcp Administrative access to the application SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 18
Traffic Type Port/protocol Usage 123/udp Synchronize the Microsoft 138/tcp and Used by WorkPlace to appliance clock with an networking 138/udp perform WINS name NTP server resolution, browse 137/tcp and Syslog 514/tcp Send system log requests, and access 137/udp information to a syslog file shares server 139/udp SNMP 161/udp Monitor the appliance 162/snmp from an SNMP 445/smb management tool LDAP 389/tcp Communicate with an (unencrypted) LDAP directory or Microsoft Active Directory SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 19
Settings Using the LCD on page 23. Installation and Deployment Process Run Setup Wizard. The wizard guides you through the process of initial setup for your SMA Installation Step Description appliance. See Running the Setup Make a note of your You’ll need this information when you Wizard on page 23. appliance serial register your product on Register your Register your appliance on number and MySonicWall. The serial number and appliance on MySonicWall. Product registration authentication code. authentication code are printed on MySonicWall. gives you access to essential your appliance label; they are also resources, such as your license file displayed on the General Settings and updates. To register, you need page in AMC. both the serial number for your Rack‐mount the See Rack Mounting the Appliance on appliance and its authentication appliance and page 37 and Connecting the code. connect the cables. Appliance on page 22. SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 20
SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 21
Installation and Configuration This section provides the steps to perform the initial installation and settings configuration of the SonicWall Secure Mobile Access 6200/7200. For more detailed information, the SMA Administration Guide has complete instructions for installing your SMA 6200/ 7200 appliance. • Connecting the Appliance on page 22 • Starting the Appliance on page 22 • Entering Network Settings Using the LCD on page 23 • Running the Setup Wizard on page 23 • Connecting to AMC on page 25 • Configuring Basic WorkPlace Portal Access on page 26 SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 22
Use the following instructions to connect the appliance to your network. To connect the power of the SMA 6200, plug in the power cord to the power supply socket on the back of the appliance, and For a diagram of the appliance, refer to SMA 6200/7200 Front then connect the cord to an AC outlet. Panels on page 10. For the SMA 7200, plug the power cords to the power supply For rack mounting instructions, refer to Rack Mounting the sockets on the appliance back and then connect the cords to Appliance on page 37. AC outlets. For best reliability, connect the two cords of the SMA 7200 to outlets on different circuits. To connect the SMA6200/7200 appliance: 1 Connect a network cable from your internal network to 隨附的電源線僅限於特定的國家或地區使用。 使用前, 請確認 the internal interface on the appliance (X0). 電源線的額定 且已被認可在你的地區上使用。 2 Optionally, connect a cable from your external network to the external interface on the appliance (X1). CAUTION: Remove any USB devices from the appliance before you reboot it. If a USB device is plugged in to your appliance when it is rebooted, the appliance tries Starting the Appliance to use it as a boot device. As a result, the boot information stored in the BIOS on the appliance is The SMA 6200 contains a single AC power supply and comes overwritten, and the device becomes unusable. with a single power cord. The SMA 7200 includes dual power supplies for redundant AC power and added reliability. Two power cords are included with the SMA 7200 appliance. Refer to Safety and Regulatory Information on page 45 for information. SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 23
Running the Setup Wizard To the right of the LCD screen on the front of your appliance are four buttons used to enter your settings. After the LCD configuration steps, the Setup Wizard continues the initial setup for your SMA 6200/7200 appliance. To configure settings using the LCD controls: 1 Press Up and Down to read the welcome screen, and To run the Setup Wizard: press Right to continue past it. 1 Configure your management computer with a static IP NOTE: SMA 7200 only: select either a 1GB or a 10 GB address on the same subnet as your internal (X0) port. interface. If you kept the default X0 IP address, set your computer to an IP address on the 192.168.0.0/24 2 Enter the IP address for your internal interface. subnet, such as 192.168.0.20, and set the subnet mask The default internal (X0) IP address is 192.168.0.10. To to 255.255.255.0 and the default gateway to change the IP address, use the Left and Right buttons to 192.168.0.1. position your cursor over the number you want to 2 Using an Ethernet cable, connect the appliance X0 change, and then use Up and Down to change the interface to your management computer. number. Press Right to continue to the next screen. 3 Access the wizard by starting a Web browser and 3 Enter your subnet mask. typing: https://<IP address>:8443 where SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 24
NOTE: Accept the certificate warning and continue. allows users access and is the least secure, but can always be changed later when more security 4 Follow the instructions in the wizard to enter your is needed. For the most secure, select Initially configuration settings: deny all access.) a Accept the license agreement. 5 When ready, click Finish to apply your settings. The appliance restarts, which causes you to lose your b Create an administrator password of at least 8 current connection. Wait a few minutes and then point characters. your browser to the X0 IP address and port 8443 to c Configure the time zone. connect to the Appliance Management Console (AMC). For example: d Enter a name for the appliance without spaces or underbars. https://<IP address>:8443 e Configure settings for either dual interfaces or a single interface. For routing, configure the internal (X0) gateway IP address and optionally select dual gateway and set the external (X1) gateway IP address. The default internal gateway address is 192.168.0.1. g For name resolution, enter the default domain for your network. SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 25
Connecting to AMC AMC login screen AMC is the Web‐based application used to administer the appliance. NOTE: Appliance management with AMC is accomplished by accessing the internal interface. The appliance cannot be managed by a direct connection to the external interface. To access the login page after the Setup Wizard finishes, point your browser to https://<IP address>:8443, where <IP address> matches the address you defined for the internal network interface. The default X0 IP address is Type admin in the Username field, and then enter the 192.168.0.10. password you created with the Setup Wizard. Both are case‐ sensitive. For Log in using, select the Management Console realm. Click Login to log into the Management Console. SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 26
Creating a Basic Realm This section describes how to configure a local authentication server and user on the appliance itself, and create a realm and A realm references an authentication server and determines access rule to go with them. This allows you to quickly create a which access agents are provisioned to your users and what portal while gathering the information needed for a full end point control restrictions are imposed. production deployment. This same sequence of steps also applies if you are configuring To create a basic realm that uses your local an external authentication server and more advanced settings authentication server: for your realm or access rules. 1 Navigate to the User Access > Realms page. Creating a Local Authentication Server 2 Select click here. 3 Click New realm on the Realms page. To create a local authentication server: 4 In the Name field, type in a name for the realm. 1 In AMC, navigate to the System Configuration > 5 In the Authentication server drop‐down list, select the Authentication Servers page. local authentication server you just configured. 2 In the Authentication servers section, click New. 6 Click Finish. 3 In the User Store section, under Local user storage, The Realms page displays your new realm and shows it select the Local users radio button. as associated with your local authentication server. SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 27
Creating a Local User Configuring the Default WorkPlace Site To create a local user: 1 Navigate to the Security Administration > Users & To configure the Default WorkPlace Site: Groups page. 1 Navigate to the User Access > WorkPlace page and click 2 Click the Local Accounts tab. on the WorkPlace Sites tab. 3 Click New and select User. 2 Click Default. 4 In the Username field, type in a name for the local user. 3 In the Custom FQDN field, type in the configured internal or external IP address of the appliance. 5 In the Password field, type in a password for the local user. 6 Clear the User must change password at next login checkbox. 7 Click Save. SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 28
Configuring an Access Rule This field should match the IP address or hostname of the appliance as the user would access it. The SMA 6200/7200 appliance uses a granular access policy to determine what backend resources a given user is allowed to access. To configure a default access rule to allow any user to access resources through the appliance: 1 Navigate to the Security Administration > Access Control page. 2 Click New. 3 Optionally type in a Description. 4 Click Finish. Applying the Pending Changes 4 Click Save. To apply all your changes: 1 Click Pending changes at the top right corner of the page. 2 In the pop‐up dialog box, click Apply changes. SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 29
Logging into the WorkPlace Portal After the appliance finishes applying the changes, you can log into the WorkPlace portal using the local user credentials. To log in as the local user: 1 Point your browser to https://<IP address> where <IP address> matches the address you defined for the internal or external network interface. The default internal IP address is 192.168.0.10. 2 In the portal login screen, enter the username and password for the local user. 3 Click Login. SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 30
SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 31
Registering and Obtaining a License This section describes how to register your SonicWall Secure Mobile Access 6200/7200 and then download the license file from MySonicWall. You can register your SMA 6200/7200 appliance before or after you initialize or deploy it. Registration provides access to essential resources, such as your license file, firmware updates, documentation, and technical support information. • Using MySonicWall on page 32 • Creating a MySonicWall account on page 32 • Registering your Appliance on page 33 • Downloading your License File on page 33 • Importing your Licenses on page 34 SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 32
Using MySonicWall Creating a MySonicWall account SonicWall requires a MySonicWall account prior to configuring A MySonicWall account is required in order to register the your appliance. If you already have a MySonicWall account, appliance. you can continue to the Registering your Appliance on page 33. To create a MySonicWall account from any computer: MySonicWall is used during registration of your SonicWall appliance and to activate or purchase licenses for security 1 In your Web browser, navigate to services, support, or software specific to your SonicWall https://www.mysonicwall.com. device. MySonicWall registration information is not sold or shared with any other company. SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 33
2 In the login screen, click the Register Now link. 3 Enter the appliance serial number into the Register A Product field and then click Next. 3 Complete the Registration form, and then click Register. 4 Verify that the information is correct, and then click Submit. 5 To confirm your account was created, click Continue. Registering your Appliance 4 Enter a friendly name for this appliance. 5 Click Register to continue, and follow the online To register your appliance on MySonicWall: prompts to fill out the survey and complete the registration process. 1 Locate your appliance serial number and authentication code, which is printed on your appliance label. The Continue with the next section to download the appliance serial number and authentication code are also license file from MySonicWall. displayed in the AMC on the General Settings page once you initialize and connect to your appliance. Downloading your License File 2 In your Web browser, navigate to https://www.mysonicwall.com and log in to your MySonicWall account with your username and You can download an initial user license from MySonicWall password. that is valid for one user (the administrator plus one end user) for an unlimited number of days. You can use this limited license until ready to deploy the appliance to production with full licensing. SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 34
2 Click My Products to view the list of your registered administrator plus one end user) for an unlimited appliances. number of days. To become familiar with the AMC and test it in your environment with additional users, either 3 Click the link for the appliance that requires a license. retrieve an appliance license, or request a lab license to 4 On the Service Management page, click the Click here add a few more users. for the License File link. • Appliance licenses: The number of concurrent users 5 In the View License dialog box, select 10.5 or later supported with the appliance license varies, depending (Base) in the drop‐down list, and then click the Click on the appliance model you have: here for the License File link. • SMA 7200: up to 10,000 users 6 Select the option to save the license file, or copy the • SMA 6200: up to 2,000 users license text to your clipboard and save it as an XML file (.xml) on your computer. You must import this license • Component licenses: If the license for an appliance file using AMC. component (such as OnDemand) has expired, users attempting to use that component see an error message in WorkPlace. In the case of a Spike License, the date on which it was activated and how many days still remain is displayed in AMC. SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 35
• If a license is about to expire, the AMC displays a license 7 Apply the change by clicking the Pending changes link warning message in the status area that links to the in the upper‐right corner and then clicking Apply Licensing page. changes. NOTE: When you upload a Spike License, the countdown When you are ready to move the appliance into production of the number of days it is valid begins once you activate after initial setup and testing, download your appliance license it and apply the pending change in the AMC. Do not click file from MySonicWall and then use the AMC to import it to the Activate link until you are ready to start using it. the appliance. The process for importing an appliance license file is described in detail in the online help for the AMC. To import an appliance license: 1 Log in as admin to the AMC. 2 Click General Settings. 3 Click the Edit link in the Licensing area. The Manage Licenses page appears. 4 Click Import License. 5 In the License file box, click Browse to locate the license file you retrieved from your MySonicWall account, and double‐click on it. 6 Click Upload to copy the license to the appliance. SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 36
SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 37
Rack Mounting the Appliance This section provides instructions and illustrations for rack mounting the SonicWall Secure Mobile Access 6200/7200. The SMA 6200/7200 appliance is designed to be mounted in a standard 19‐inch rack. The product packaging contains a slide rail kit for mounting the appliance in a four‐post cabinet. Before installing the appliance in an equipment rack, the rails must be attached to the appliance and to the rack posts. You will need the following tools and hardware for installation: • Phillips (cross head) screwdriver (#1 bit and #2 bit) • Anti‐static wrist strap and conductive foam pad (recommended) • Two outer rails • Four inner rails • Crosshead threaded screws CAUTION: Do not use slide/rail mounted equipment as a shelf or a work space. SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 38
Assemble the Slide Rail Fasten 4 screws to the rail. WASHERS*8 M4 SCREW*8 SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 39
Assemble the Slide Rail Fasten two-sided screws to the rail. M5 SCREW*8 M5 Nut*8 SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 40
Attaching Inner Rails to the Installing the Outer Rails Appliance To install the outer rail: 1 Attach the rail to the posts of the rack by using three To attach the inner rails to the appliance: rack screws. 1 Position the inner rail alongside the side of the 2 Extend the outer back rail to the back of the rack and appliance with the finger tab facing outward. firmly attach it with two rack screws. 2 Align the screw holes of the rail and the mounting holes 3 Repeat step 1 and 2 to install the other rail. of the appliance and then attach the inner rail to the appliance with crosshead threaded screws. 3 Repeat the above steps to attach another rail on the same side of the appliance. 4 Attach the front bracket to the system. 5 Repeat to attach the other inner rails and front bracket to the other side of the appliance. SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 41
Assemble Inner Rail to Chassis Fasten 6 screws to attach the inner channel onto the chassis. M4 SCREW*6 SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 42
Installing the Appliance in the Removing the Appliance from Rack the Rack 1 Holding the appliance with its front facing you, lift it 1 Pull the appliance half way out to the lock position. and carefully insert the inner rail into the outer rail. 2 Press the rail lock release tabs on both sides while 2 Push the appliance all the way in until the front pulling the appliance towards you until past the tabs. brackets contact the rack. Continue to pull the appliance until it is fully removed from the 3 Optionally attach the front brackets to the rack. outer rails. SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 43
Insert Chassis to Frame Slide inner channel into rails. Push hook down to separate. SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 44
SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 45
Safety and Regulatory Information This section provides safety and regulatory information. Regulatory Model/Type Product Name 1RK31‐0B0 SMA 6200 1RK30‐0AF SMA 7200 • Safety Instructions on page 46 • Sicherheitsanweisungen on page 48 安全說明 on page 51 • • Declaration of Conformity on page 53 • Warranty Information on page 53 • 台灣 RoHS / 限用物質含有情況標示資訊 on page 54 SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 46
6 Mount in a location away from direct sunlight and • Lithium Battery Warning on page 48 sources of heat. A maximum ambient temperature of • Cable Connections on page 48 104º F (40º C) is recommended. 7 If installed in a closed or multi‐rack assembly, the Installation Requirements operating ambient temperature of the rack environment may be greater than the room ambient. Therefore, consideration should be given to installing WARNNG: the equipment in an environment compatible with the The following conditions are required for proper installation: maximum recommended ambient temperature. 1 The SonicWall SMA appliance is designed to be 8 Mount the SonicWall appliances evenly in the rack in mounted in a standard 19‐inch rack mount cabinet. order to prevent a hazardous condition caused by uneven mechanical loading. 2 Use the mounting hardware recommended by the rack manufacturer and ensure that the rack is adequate for 9 Four mounting screws, compatible with the rack design, the application. must be used and hand‐tightened to ensure secure installation. Choose a mounting location where all four 3 Ensure that no water or excessive moisture can enter mounting holes line up with those of the mounting bars the unit. of the 19‐inch rack mount cabinet. 4 Allow unrestricted airflow around the unit and through ...
Page 47
18 Before replacing the fan unit, carefully read and follow power supply connections other than direct the instructions provided with the unit. connections to the branch circuits, such as power strips. 13 The included power cord is approved for use only in Warning of Potential Hazard from Fan specific countries or regions. Before using a power cord, verify that it is rated and approved for use in your location. 14 Minimum power cord rating for European Union (CE): 19 When using a Fiber Optic Small‐Form Pluggable (SFP) Certified power supply cord not lighter than light PVC module, ensure it is IEC 60825 certified. sheathed flexible cord according to IEC 60227, designation, or H05 VV‐F or H05 VVH2‐F2, and rated for For SMA 7200 only: at least 3G 0.75 mm². 1 As shipped from the factory this SonicWall product 15 The following statement applies only to rack‐installed includes two power supplies for redundant AC power products that are GS‐Marked: This equipment is not and added reliability. intended for use at workplaces with visual display units, 2 To disconnect AC power, both power cords must be in accordance with §2 of the German ordinance for removed. workplaces with visual display units. 16 This product is not intended to be installed and used in a home or public area accessible to the general SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 48
• Anforderungen an die Installation on page 48 • Hinweis zur Lithiumbatterie on page 50 Lithium Battery Warning • Kabelverbindungen on page 51 The Lithium Battery used in the SonicWall SMA Internet security appliance may not be replaced by the user. The Anforderungen an die Installation appliance must be returned to a SonicWall authorized service center for replacement with the same or equivalent type Verwarnung: recommended by the manufacturer. If, for any reason, the Für eine ordnungsgemäße Montage sollten die folgenden battery or SonicWall SMA Internet security appliance must be Hinweise beachtet werden: disposed of, do so following the battery manufacturer's instructions. 1 Das SonicWall SMA Modell ist für eine Montage in einem standardmäßigen 19‐Zoll‐Rack konzipiert. Cable Connections 2 Vergewissern Sie sich, dass das Rack für dieses Gerät geeignet ist und verwenden Sie das vom Rack‐Hersteller All Ethernet and RS232 (Console) cables are designed for intra‐ empfohlene Montagezubehör. building connection to other equipment. Do not connect these 3 Stellen Sie sicher, dass das Gerät vor Wasser und hoher ports directly to communication wiring or other wiring that Luftfeuchtigkeit geschützt ist. exits the building where the SonicWall SMA is located. 4 Stellen Sie sicher, dass die Luft um das Gerät herum zirkulieren kann und die Lüftungsschlitze an der Seite des Gehäuses frei sind. Hier ist ein Belüftungsabstand von mindestens 26 mm einzuhalten. SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 49
Überlastung der Stromversorgung beeinflusst werden. Nähe von Wärmequellen befindet. Die Prüfen Sie dabei sorgfältig die Angaben auf dem Umgebungstemperatur darf nicht mehr als 40 °C Aufkleber des Geräts. Überlasten Sie nicht den betragen. Stromkreis. 7 Wenn das Gerät in einem geschlossenen 19"‐Gehäuse 12 Eine sichere Erdung der Geräte im Rack muss oder mit mehreren anderen Geräten eingesetzt ist, wird gewährleistet sein. Insbesondere muss auf nicht direkte die Temperatur in der Gehäuse höher sein als die Anschlüsse an Stromquellen geachtet werden wie z. B. Umgebungstemperatur. Achten Sie darauf, daß die bei Verwendung von Mehrfachsteckdosen. Umgebungstemperatur nicht mehr als 40° C beträgt. 13 Das im Lieferumfang enthaltene bzw. die im 8 Bringen Sie die SonicWall SMA waagerecht im Rack an, Lieferumfang enthaltenen Netzkabel sind nur für die um mögliche Gefahren durch ungleiche mechanische Verwendung in bestimmten Ländern und Regionen Belastung zu vermeiden. zugelassen. Überprüfen Sie bitte vor der Verwendung eines Netzkabels, ob es für die Verwendung in Ihrem 9 Verwenden Sie für eine sichere Montage vier passende Land oder Ihrer Region zugelassen ist und den Befestigungsschrauben, und ziehen Sie diese mit der geforderten Normen entspricht. Hand an. Wählen Sie einen Ort im 19‐Zoll‐Rack, wo alle vier Befestigungen der Montageschien verwendet 14 Mindest Stromkabel Bewertung für die Europäische werden. Union (CE): Zertifizierte Netzkabel nicht leichter als leichte PVC‐Schlauchkabel nach IEC 60227, Bezeichnung ...
Page 50
1 Dieses Produkt wird mit zwei Wechselstrom‐Netzteilen 16 Dieses Produkt ist nicht dafür entwickelt, um in zur redundanten Stromversorgung fuer erhöhte Bereichen mit öffentlichem Zugang betrieben zu Verfu¨gbarkeit ausgeliefert. werden. Wenn es in Schulen betrieben wird, stellen Sie 2 Um den Wechselstrom (AC) zu unterbrechen muessen sicher, dass das Gerät in einem abgeschlossenen Raum beide Stromkabel entfernt werden. installiert wird, der nur von speziell ausgebildetem Personal betreten werden kann. 3 Wenn Sie das Netzteil wechseln, entfernen Sie unbedingt die Stromversorgung von dem zu 17 Vergewissern Sie sich, dass die Schrauben nach dem wechselnden Netzteil. Austausch mit entsprechendem Werkzeug fest angezogen werden. Hinweis zur Lithiumbatterie 18 Lesen Sie vor dem Austausch der Lüftereinheit die Anleitung, die mit dem Gerät geliefert wurde und Die in der Internet Security Appliance von SonicWall befolgen Sie die Anweisungen. verwendete Lithiumbatterie darf nicht vom Benutzer ausgetauscht werden. Zum Austauschen der Batterie muss die Achtung—Lüfter Potentielle SonicWall in ein von SonicWall autorisiertes Service‐Center Gefahrenquelle gebracht werden. Dort wird die Batterie durch denselben oder entsprechenden, vom Hersteller empfohlenen Batterietyp ersetzt. Beachten Sie bei einer Entsorgung der Batterie oder der SonicWall Internet Security Appliance die diesbezüglichen Anweisungen des Herstellers. SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 52
12 必須維護可靠的機架裝載設備接地。必須特別留意 僅適用於 SMA 7200: 電源供應器連線,而不是直接連接到電源板之類的 1 從工廠運出時,這個 SonicWall 產品包括為後備交流 分支電路。 電源和增加可靠性而附帶的兩個電源。 13 隨附的電源線僅限於特定的國家或地區使用。使用 2 要斷開交流電源,兩條電源線都必須被拔除。 前,請確認電源線的額定值且已被認可在你的地區 上使用。 3 切勿在交流電源線還連接著電源時移除或安裝電 源。 14 本產品的設計目的不是安裝並使用於住家或一般大 眾可接觸到的公共區域。如果是安裝在學校,本設 備只能安裝在受訓人員能接觸到的安全位置。 鋰電池警告 15 當安裝及後續接觸產品背面之後,必須用工具將指 旋螺釘鎖緊。 使用者不得自行更換 SMA 網際網路安全性裝置中使用的鋰 電池。必須將 SMA 送回 SMA 授權的服務中心,以更換相 16 更換風扇部件前,請仔細閱讀,並遵循所提供的指 同的鋰電池或製造商推薦的同類型鋰電池。若因任何原因 示。 必須丟棄電池或 SMA 網際網路安全性裝置,請嚴格遵守電 池製造商的指示。 風扇潛在危險警告 纜線連結...
Page 53
Declaration of Conformity Warranty Information A “Declaration of Conformity” in accordance with the All SonicWall appliances come with a 1‐year Limited Hardware directives and standards has been made and is on file at: Warranty which provides delivery of critical replacement parts SonicWall International Limited, City Gate Park, Mahon, Cork, for defective parts under warranty. Visit the Warranty Ireland. Information page details on your product’s warranty: https://support.sonicwall.com CE declarations can be found online at: https://support.sonicwall.com NOTE: Additional regulatory notifications and information for this product can be found online at: https://support.sonicwall.com. SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 55
SonicWall Support Technical support is available to customers who have purchased SonicWall products with a valid maintenance contract and to customers who have trial versions. The Support Portal provides self‐help tools you can use to solve problems quickly and independently, 24 hours a day, 365 days a year. To access the Support Portal, go to https://support.sonicwall.com/. The Support Portal enables you to: • View knowledge base articles and technical documentation • Download software • View video tutorials • Collaborate with peers and experts in user forums • Get licensing assistance • Access MySonicWall • Learn about SonicWall professional services • Register for training and certification To contact SonicWall Support, refer to https://support.sonicwall.com/contact‐support. SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 56
SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 57
Allow and Deny Zones. Windows® Firewall. IT-issued mobile device — You can create as many device profiles Device watermarked with a company-issued user certificate, encrypted text file Running Google® Desktop Search — Deny access. named “itpocketpc.txt”. as necessary. SonicWall Secure Mobile Access 6200/7200 Getting Started Guide...
Page 58
This setup guide assumes that basic network configuration has been completed. If you used the Setup Wizard for your initial evaluation, you can Reference modify the access control policy you have already created, or use this quick setup guide as an introduction to the SonicWall Appliance Management See these sections in the SonicWall SMA Deployment Console (AMC).
Page 59
SMA 6200/7200 Getting Started Guide Updated ‐ June 2017 232‐003431‐51 Rev B ...
