Page 3 F o r e w o r d HOW TO USE THIS MANUAL We want to help you get the greatest You will find various WARNINGs, possible driving pleasure from your CAUTIONs, and NOTICEs in this vehicle. Your Owner’s Manual can manual.
Page 5: Table Of Contents
Introduction Your vehicle at a glance Safety features of your vehicle Features of your vehicle Audio system table of contents Driving your vehicle What to do in an emergency Maintenance Specifications & Consumer information Index...
Page 6 Hybrid System Overview HEV (HYBRID ELECTRIC VEHICLE) SYSTEM / H2 PHEV (PLUG-IN ELECTRIC VEHICLE) SYSTEM / H3 CHARGING THE PLUG-IN HYBRID VEHICLE / H4 DRIVING THE HYBRID/PLUG-IN HYBRID VEHICLE / H25 HYBRID ENERGY FLOW / H31 PLUG-IN HYBRID ENERGY FLOW / H33 STARTING THE HYBRID/PLUG-IN HYBRID VEHICLE (SMART KEY) / H37 COMPONENTS OF THE HYBRID/PLUG-IN HYBRID VEHICLE / H39...
Page 7 HEV (HYBRID ELECTRIC VEHICLE) SYSTEM The Kia Hybrid Electric Vehicle (HEV) uses both the gasoline engine and the electric motor for power. The electric motor is run by a 360V high-voltage HEV battery. Depending on the driving conditions, the HEV computer selectively operates between the engine and the electric motor or even both at the same time.
Page 8 PHEV (PLUG-IN ELECTRIC VEHICLE) SYSTEM The Kia Plug-in Hybrid Electric Vehicle (PHEV) shares the characteristics of both a conventional hybrid electric vehi- cle and an all-electric vehicle. When used as a conventional hybrid electric vehicle, the HEV computer selectively operates between the engine and the electric motor or even both at the same time.
Page 9 CHARGING THE PLUG-IN HYBRID VEHICLE Charging Information • Trickle Charger: The plug-in hybrid Charging Time vehicle can be charged by using • Normal Charger: The plug-in • Normal Charger: Takes about 2 household electricity. hybrid vehicle is charged by plug- hours 15 minutes at room tempera- The electrical outlet in your home ging into a normal charger installed...
Page 10 Charging Status Charging Connector Operation of AUTO/LOCK Mode Charging Indicator Charging Status Lamp (1) Charging in Turns on (Green) progress Not Charging or Turns off fully charged Slowly blinks Waiting for sched- (Green) and then uled charging turns off (repeat (turns off after 3 for 3 minutes) minutes)
Page 11 CHARGING THE PLUG-IN HYBRID VEHICLE (CONT.) ❈ ❈ Charging connector When the Charging Connector • AUTO mode (button indicator on) : AUTO/LOCK mode is Locked The connector locks when charg- ing starts. The connector unlocks When the charging connector is LOCK AUTO when charging is complete.
Page 12 ❈ Locking/unlocking the charging 2. Conditions for unlock : Scheduled Charging door − − When unlocking doors from out- (if equipped) The charging door lock/unlock func- side the vehicle with the charg- • You can set reserved charging tion works only when the following ing door closed.
Page 13 CHARGING THE PLUG-IN HYBRID VEHICLE (CONT.) • When scheduled charging is set, charging is not initiated immediate- ly when the normal charger or portable charging cable (ICCB: In- Cable Control Box) is connected. • If charging is required immediately, turn off the scheduled charge using the vehicle’s touchscreen or UVO eco smartphone application or press the vehicle's scheduled...
Page 14 Charging Precautions WARNING WARNING ■ Normal Charger Interference with electron- Touching the charging ic medical devices connector When using medical electric Do not to touch the charging devices such as an implantable connector, charging plug, and cardiac pacemaker, make sure to the charging inlet when con- ask the medical team and manu- necting the cable to the charger...
Page 15 CHARGING THE PLUG-IN HYBRID VEHICLE (CONT.) • Comply with the following in order • Always keep the charging connec- WARNING - Charging to prevent electrical shock when tor and charging plug in clean and charging: cable dry condition. Be sure to keep the charging cable in a condition where - Use a waterproof charger •...
Page 16 Normal Charge How to Connect Normal Charger ■ Normal Charger OJFHPQ016021L ODEPQ017026 ■ Normal charger cable 4. Remove any dust on the charging ODEPQ017025 connector and charging inlet. 1. Depress the brake pedal and 5. Hold the charging connector han- apply the parking brake.
Page 17 CHARGING THE PLUG-IN HYBRID VEHICLE (CONT.) ✽ ✽ NOTICE • Charging is in progress only when the shift lever is in P (Park). Charging the battery with the Engine Start/Stop button in the ACC position is possible. However, it may discharge the 12-V battery. Thus, if possible, charge the bat- tery with the Engine Start/Stop button in the OFF position.
Page 18: Hood
Unlock Connector in Emergency Charging Status Operation of Charging Indicator Charging Status Checking Charging Status Lamp (1) Charging in Turns on (Green) progress Not Charging or Turns off fully charged Slowly blinks Waiting for sched- (Green) and then uled charging turns off (repeat (turns off after 3 for 3 minutes)
Page 19 CHARGING THE PLUG-IN HYBRID VEHICLE (CONT.) How to Disconnect Normal For more details, refer to “Charging Charger Connector AUTO/ LOCK Mode” in this chapter. 1.The vehicle must be in the AUTO mode or the doors must be unlocked in order to be able to dis- CAUTION connect the charging connector.
Page 20 ✽ ✽ NOTICE Trickle Charger (Portable Charging Cable) • Keep the charging connector and the charging plug clean and dry. The charging cable should also be kept dry. • Use an air gun to blow any foreign substances from the charging con- nector and the charging plug.
Page 21 CHARGING THE PLUG-IN HYBRID VEHICLE (CONT.) How to Connect Portable Charging Cable (ICCB: In-Cable Control Box) ODEPQ017025 ODEPQ017047 3. After unlocking doors, open the 4. Connect the plug to a household charging door by pressing it. electric outlet. 5. Make sure that the power connec- OJFHPQ016015N tion indicator (green) lights in the 1.
Page 22 ■ Charge ODEPQ017049 ■ Vehicle connection ODEPQ017035 ODEPQ017027 8. Charging starts automatically and 9. Check if the charging cable con- the charging light blinks. nection indicator of the high volt- age battery in the instrument clus- ter is turned ON. Charging does not occur when the indicator is OFF.
Page 23 CHARGING THE PLUG-IN HYBRID VEHICLE (CONT.) ✽ ✽ NOTICE Unlock Connector in Emergency • The charging is in progress only with the shift lever is in P (Park). Charging the battery with the Engine Start/Stop button in the ACC position is possible. However, it may discharge the 12-V battery.
Page 24 Charging Status Charge cable storage Operation of Charging Indicator Charging Status Lamp (1) Charging in Turns on (Green) progress Not charged or Turns off fully charged Slowly blinks Waiting for sched- (Green) and then uled charging turns off (repeat (turns off after 3 for 3 minutes) minutes) Quickly...
Page 25 CHARGING THE PLUG-IN HYBRID VEHICLE (CONT.) Charging Status Indicator Lamp for Portable Charging Cable Control Box Indicator Details On : Power on Blink : Plug temperature sensor failure (Green) PLUG On : Plug high temperature protection Blink : Plug high temperature warning (Red) POWER On : Power on...
Page 26 - Before plugging charging connector into vehicle (Red blink) - While charging • Abnormal temperature • Charge indicator (Green blink) • ICCB (In-Cable Control Box) failure • Vehicle indicator (Blue ON) Have your vehicle inspected by an authorized Kia dealer.
Page 27 • Current leakage • Communication failure • Abnormal temperature Have your vehicle inspected by an Have your vehicle inspected by an authorized authorized Kia dealer. Kia dealer. • Plug temperature sensor failure (Green blink) • Plug high temperature protection - Power saving mode (Red blink) •...
Page 28 How to Disconnect PortableCharging Cable (ICCB: In-Cable Control Box) 1. Before disconnecting the charging connector, make sure the doors are unlocked. When the door is locked, the charging connector lock system will not allow disconnection. To pre- vent charging cable theft, the charging connector cannot be dis- con nected from the inlet when the ODEPQ017031...
Page 29 • Use the portable charging cable charging cable. electric outlet condition, have it that is certified by Kia. checked by a licensed electrician. • Do not let children operate or touch • Do not try to repair, disassemble, or the portable charging cable.
Page 30 DRIVING THE HYBRID/PLUG-IN HYBRID VEHICLE Changing plug-in hybrid mode Plug-in hybrid mode message (Plug-in hybrid vehicle) • CD (Charge Depleting, Electric) mode : The high-voltage (hybrid) battery is mainly used to drive the vehicle. ODEPQ017016L • CS (Charge Sustaining, Hybrid) mode : The high-voltage (hybrid) battery...
Page 31 This indicator illuminates : In this case, have your vehicle Charging Cable When the vehicle is ready to be driven. inspected by an authorized Kia deal- Connection Indicator - ON : Normal driving is possible. (Plug-in hybrid vehicle) - OFF : Normal driving is not possible, or a problem has occurred.
Page 32 ✽ ✽ NOTICE Coasting guide (if equipped) • User settings A chime will sound and the coasting Press the Engine Start/Stop button Coasting guide is only a supplemen- guide indicator will blink four times to and put the shift lever in P(Park). In tal system to assist with fuel-efficient inform the driver when to take the the User Settings Mode, select...
Page 33 In this case, have your vehicle inspect- the problem is solved. ing message is displayed. ed by an authorized Kia dealer. In this case, park the vehicle in a safe In this case, have your vehicle inspect- location and have your vehicle ed by an authorized Kia dealer.
Page 34 -14 °C (57 °F), and you In this case, have the system Maintaining Hybrid mode turn the climate control On for inspected by an authorized Kia deal- (Plug-in hybrid vehicle) heating, the above message will be This message is displayed when the displayed in the cluster.
Page 35 DRIVING THE HYBRID/PLUG-IN HYBRID VEHICLE (CONT.) Wait until fuel door opens Fuel door open Unplug vehicle to start (Plug-in hybrid vehicle) (Plug-in hybrid vehicle) (Plug-in hybrid vehicle) The message is displayed when you This message is displayed when the The message is displayed when you attempt to open the fuel filler lid with fuel filler lid is opened.
Page 36 HYBRID ENERGY FLOW Kia hybrid system notifies the drivers EV Propulsion Engine Only Propulsion of energy flow in various operating modes. Eleven Modes show drivers the current operating condition. ODE046121N ODE046123N Electric power is used to move the Engine power is used to move the vehicle.
Page 37 HYBRID ENERGY FLOW (CONT.) Regeneration Power Reserve Engine Generation/Regeneration ODE046121N ODE046127N ODE046128N Hybrid battery is being charged by Engine is both driving the vehicle The engine and regenerative braking and charging the hybrid battery. regenerative braking. system charge the hybrid battery (Engine ➞...
Page 38 PLUG-IN HYBRID ENERGY FLOW Kia hybrid system notifies the drivers EV Propulsion Engine Only Propulsion of energy flow in various operating modes. Eleven Modes show drivers the current operating condition. ODEP047202N ODEP047204N Electric power is used to move the Engine power is used to move the vehicle.
Page 39 PLUG-IN HYBRID ENERGY FLOW (CONT.) Regeneration Power Reserve Engine Generation/Regeneration ODEP047206N ODEP047207N ODEP047207N Hybrid battery is being charged by Engine is both driving the vehicle The engine and regenerative braking regenerative braking. and charging the hybrid battery. system charge the hybrid battery driving deceleration.
Page 40 ✽ ✽ NOTICE AUX. BATTERY SAVER+ (For Mode Plug-in Hybrid, if equipped) • Cycle Mode : The Aux. Battery Saver+ activates maximum of 20 minutes. If the Aux. The Aux. Battery Saver+ is a function When the vehicle is OFF with all Battery Saver+ function activates that monitors the charging status of doors, hood and liftgate closed, the...
Page 41 To reduce the risk of electrical up frequently, have your vehicle`s shock, do not touch any high auxiliary battery or electric/electronic voltage components (orange) or components serviced by an author- other electrical devices while ized Kia dealer. charging is occurring.
Page 42 STARTING THE HYBRID/PLUG-IN HYBRID VEHICLE (SMART KEY) Starting the Hybrid System • When the engine start/stop but- If the starting procedure is fol- lowed, the " " symbol on the ton is in the ACC or ON position, 1.Carry the smart key into the vehicle. instrument cluster will turn on.
Page 43 STARTING THE HYBRID/PLUG-IN HYBRID VEHICLE (SMART KEY) (CONT.) ✽ ✽ NOTICE ECONOMICAL and SAFE OPERATION of Hybrid system When the hybrid system is in ready mode, the engine will automatically • Drive smoothly. Accelerate at a start and stop as needed. moderate rate and maintain a The "...
Page 44 COMPONENTS OF THE HYBRID/PLUG-IN HYBRID VEHICLE 1. Engine : 1.6 L 5. HPCU (Hybrid Power Control Unit) 2. Motor : 32 kw (hybrid)/44.5 kw (plug-in hybrid) 6. High voltage battery system 3. Transmission : 6 DCT 7. Generative brake system 4.
Page 45 ODEQ016002 to some system components as addi- HEV Battery tional warnings. Have your vehicle serviced by an authorized Kia dealer. WARNING - Touching HPCU When replacing the fuses in the engine...
Page 46 Motor CAUTION - High Voltage WARNING - After market Battery Damage battery charger When loading your vehicle, be Do not use an after-market bat- careful of transporting items in tery charger to charge the a manner that could damage the Hybrid battery.
Page 47 COMPONENTS OF THE HYBRID/PLUG-IN HYBRID VEHICLE (CONT.) ✽ ✽ NOTICE - Prolonged parking CAUTION - Cleaning WARNING - Use of Water Prolonged parking might cause bat- Engine or Liquids tery discharge and operation failure When you clean the engine com- If water or liquids come into due to natural discharge.
Page 48 Safety plug Some Special Features of the WARNING - Safety Plug Hybrid Vehicle. ■ Hybrid Never touch the safety plug. Hybrid vehicles sound different than Safety plug is attached to high gasoline engine vehicles. When the voltage hybrid battery system. hybrid system operates, you may Touching safety plug will result hear a sound from the hybrid battery...
Page 49 COMPONENTS OF THE HYBRID/PLUG-IN HYBRID VEHICLE (CONT.) The HEV system may emit electro- Virtual Engine Sound System WARNING - Turning off magnetic waves which can affect the (VESS) performance of electronic devices HEV system The Virtual Engine Sound System appliances, such as laptop comput- When you leave the vehicle, you generates engine sound for pedestri- ers, which are not part of the vehicle...
Page 50 High Voltage Battery Air Intake If An Accident Occurs WARNING - Air Intake • Avoid the engine compartment. • Blocking the air intake behind • Avoid any orange or high voltage the rear seats may damage wires, cables, or components. the HEV battery.
Page 51 COMPONENTS OF THE HYBRID/PLUG-IN HYBRID VEHICLE (CONT.) ✽ ✽ NOTICE • After parking the vehicle, shift the If a vehicle accident occurs: transmission into "P" position. Turn 1.Stop the vehicle and shift the trans- • If a small scale fire occurs, use a off the hybrid system by pushing mission into "P"...
Page 52 2. Set the start button at OFF, and try towed to and inspected by an vehicle. If a fire occurs, evacu- to start the Hybrid system by authorized Kia dealer. ate the car immediately and applying the brake pedal and contact the fire department.
Page 53: Table Of Contents
Introduction Fuel requirements ......1-2 • Gasoline containing alcohol and methanol ..1-2 •...
Page 54: Gasoline Containing Alcohol And Methanol
Gasoline containing alcohol and what has been specified. (Consult an Discontinue using gasohol of any methanol authorized Kia dealer for details.) kind if drivability problems occur. Gasohol, a mixture of gasoline and • Tighten the cap until it clicks one...
Page 55 (Oxygen Content 2.7% weight) ance and damage to your vehicle's ing, clogging, abnormal corrosion, may reduce vehicle performance and engine and fuel system. Kia recom- life cycle reduction, etc. produce vapor lock or hard starting. mends that customers do not use...
Page 56 Gasoline containing MMT Fuel Additives Operation in foreign countries Some gasoline contains harmful man- Kia recommends that you use good If you are going to drive your vehicle ganese-based fuel additives Such as quality gasolines treated with deter- in another country, be sure to:...
Page 57 Introduction VEHICLE BREAK-IN HEV/PHEV POWERTRAIN PROCESS By following a few simple precautions for the first 1,000 km (600 miles) you No special break-in period is needed. may add to the performance, econo- By following a few simple precautions my and life of your vehicle. for the first 1,000 km (600 miles) you may add to the performance, econo- •...
Page 58 Introduction VEHICLE DATA COLLECTION AND EVENT DATA RECORDERS This vehicle is equipped with an These data can help provide a bet- To read data recorded by an EDR, event data recorder (EDR). The ter understanding of the circum- special equipment is required, and main purpose of an EDR is to stances in which crashes and access to the vehicle or the EDR is...
Page 59 Your vehicle at a glance Exterior overview ......2-2 Interior overview ......2-4 Instrument panel overview .
Page 60 Your vehicle at a glance EXTERIOR OVERVIEW ■ Front view 1. Hood............4-33 2. Head lamp (Features of your vehicle) ...4-117 Head lamp (Maintenance).....8-95 3. Day time running light (D.R.L) .....4-117 4. Fog lamp ........4-121, 8-95 5. Wheel and tire........8-52, 9-4 6.
Page 61 Your vehicle at a glance ■ Rear view 1. Door locks ..........4-21 2. Fuel filler lid........4-35, 4-36 3. Rear combination lamp (Maintenance) ........8-97 4. High mounted stop lamp (Maintenance) ........8-97 5. Liftgate...........4-26 6. Antenna ...........5-2 7. Rear wiper and Rearview camera ........4-124, 4-116 8.
Page 62: Table Of Contents
Your vehicle at a glance INTERIOR OVERVIEW 1. Inside door handle.........4-22 ■ ■ Plug-in Hybrid Hybrid 2. Power window switch ......4-28 3. Central door lock switch ......4-23 4. Power window lock button .....4-31 5. Outside rearview mirror control .....4-52 6. Outside rearview mirror folding .....4-53 7.
Page 63: Table Of Contents
Your vehicle at a glance INSTRUMENT PANEL OVERVIEW 1. Driver`s front air bag ......3-57 2. Horn.............4-48 3. Instrument cluster........4-54 4. Wiper and washer control lever (Right)..........4-122 Turn signal / headlamp control lever (Left) ..........4-118 5. Engine start/stop button ......6-9 6. Cruise control ........6-47 Smart cruise control ......6-51 7.
Page 64: Table Of Contents
Your vehicle at a glance ENGINE COMPARTMENT ■ ■ Hybrid (Kappa 1.6 GDI) 1. Engine coolant reservoir ....8-33 2. Engine oil filler cap ......8-30 3. Engine oil dipstick ......8-30 4. Brake fluid reservoir......8-37 5. Inverter coolant reservoir ....8-33 6. Fuse box ...........8-67 7.
Page 65 Your vehicle at a glance ■ ■ Plug-in Hybrid (Kappa 1.6 GDI) 1. Engine coolant reservoir ....8-33 2. Engine oil filler cap ......8-30 3. Engine oil dipstick ......8-30 4. Brake fluid reservoir......8-37 5. Inverter coolant reservoir ....8-33 6. Fuse box ...........8-67 7.
Page 66: Table Of Contents
Safety features of your vehicle Important safety precautions ....3-2 Air bag - advanced supplemental restraint system ........3-42 •...
Page 67: Important Safety Precautions
Safety features of your vehicle IMPORTANT SAFETY PRECAUTIONS You will find many safety precautions Restrain all children Driver distraction and recommendations throughout All children under age 13 should ride Driver distraction presents a serious this section, and throughout this man- in your vehicle properly restrained in and potentially deadly danger, espe- ual.
Page 68: Control Your Speed
Safety features of your vehicle • ONLY use your mobile device Control your speed Keep your vehicle in safe con- when allowed by laws and when dition Excessive speed is a major factor in conditions permit safe use. NEVER crash injuries and deaths. Generally, Having a tire blowout or a mechani- text or email while driving.
Page 69: Seat
Safety features of your vehicle SEAT Front seat (1) Forward and backward (2) Seatback angle (3) Seat cushion height (Driver`s seat) ■ Manual seat (4) Lumbar support (Driver’s seat)* (5) Head rest Rear seat (6) Seatback folding ■ Power seat (7) Headrest (8) Armrest* * : if equipped...
Page 70 Safety features of your vehicle WARNING WARNING WARNING - Loose - Driver respon- - Seat cushion objects sibility for passengers Occupants should never sit on Do not place anything in the dri- aftermarket seat cushions or sit- ver's foot well or under the front ting cushions.
Page 71 Safety features of your vehicle Feature of Seat Leather WARNING WARNING - Rear seatbacks - Seat • Leather is made from the outer adjustment Always lock the rear seatback skin of an animal, which goes before driving. Failure to do so •...
Page 72: Front Seat Adjustment - Manual
Safety features of your vehicle Front seat adjustment - manual Seatback angle (2) CAUTION To recline the seatback: • Belts with metallic acces- 1. Lean forward slightly and lift up the sories, zippers or keys inside seatback recline lever. the back pocket may damage 2.
Page 73: Front Seat Adjustment - Power
Safety features of your vehicle Seat belts must be snug against your Seat height (3) Front seat adjustment - power hips and chest to work properly. (if equipped) To change the height of the seat, push When the seatback is reclined, the the lever upwards or downwards.
Page 74: Outside Rearview Mirror
Safety features of your vehicle Forward and backward (1) Lumbar support (for driver’s seat, Driver position memory system if equipped) (4) (if equipped, for power seat) Push the control switch forward or backward to move the seat to the The lumbar support can be adjusted desired position.
Page 75 Safety features of your vehicle Storing positions into memory Recalling positions from memory WARNING - Driver using the buttons on the door 1. Shift the shift lever into P. Position Memory System Storing driver’s seat positions 2. To recall the position in the memo- Never attempt to operate the ry, press the desired memory but- 1.
Page 76: Headrest (For Front Seat)
Safety features of your vehicle Easy access function (if equipped) Headrest (for front seat) Also, adjust the headrest as close to your head as possible. For this rea- The system will move the driver's son, the use of a cushion that holds seat automatically as follows: the body away from the seatback is •...
Page 77 Safety features of your vehicle Adjusting the height up and down Removal and reinstallation ■ Type A OYFH034205 ✽ ✽ NOTICE ODE036009 ODEP037011N ■ Type B If you recline the seatback towards To raise the headrest, pull it up to the the front with the headrest and seat desired position (1).
Page 78 Safety features of your vehicle To remove the headrest: To reinstall the headrest : ■ Type A 1. Recline the seatback (2) with the 1. Put the headrest poles (2) into the recline lever or switch (1). holes while pressing the release button (1).
Page 79: Seatback Pocket
Safety features of your vehicle Seatback pocket Rear seat adjustment For maximum effectiveness in case of an accident, the headrest should Headrest be adjusted so the middle of the headrest is at the same height of the center of gravity of an occupant's head.
Page 80 Safety features of your vehicle Armrest (if equipped) ODE036016 ODE036017 Adjusting the height up and down Removal and reinstallation ODE036018 To raise the headrest, pull it up to the To remove the headrest, raise it as To use the armrest, pull it forward desired position (1).
Page 81 Safety features of your vehicle Folding the rear seat CAUTION The rear seatbacks may be folded to Blocked Hybrid battery facilitate carrying long items or to duct increase the luggage capacity of the vehicle. WARNING - Folded Seatback The purpose of the fold-down rear seatbacks is to allow you to carry longer objects than could ODE036019...
Page 82 Safety features of your vehicle ODE036029L ODE036021 ODE036022L 4. Pull on the seatback folding lever, 5. To use the rear seat, lift and pull the then fold the seat toward the front seatback backward by lifting up of the vehicle. When you return the seat back.
Page 83 Safety features of your vehicle CAUTION - WARNING - Damaging WARNING Rear - Cargo rear seat belt buckles Seatback Cargo should always When you fold the rear seat- To ensure maximum protection secured to prevent it from being back, insert the buckle between in the event of an accident or thrown about the vehicle in a the rear seatback and cushion.
Page 84: Seat Belts
Safety features of your vehicle SEAT BELTS Seat belt restraint system Seat belts are designed to bear upon WARNING - Shoulder Belt the bony structure of the body, and • For maximum restraint system pro- should be worn low across the front •...
Page 85 Safety features of your vehicle • No modifications or additions WARNING - Seat belt should be made by the user which would either prevent the seat belt buckle adjusting devices from operating to Do not allow foreign material remove slack, or prevent the seat (gum, crumbs, coins, liquids, belt assembly from being adjusted etc.) to obstruct the seat belt...
Page 86 Safety features of your vehicle ■ Type A ■ Type B ODE036084L ODE036083N Front seat belt warning Conditions Warning pattern Driving conditions Seat belt Vehicle speed Light Sound Buckled No sound While - Sounds parked Illuminates 0 km/h (0 mph) (for 6 seconds, driver`s seat) (Ignition (for 6 seconds)
Page 87 Safety features of your vehicle Seat belt - Driver's 3-point system Front seat with emergency locking retractor B200A02NF OJF035031 The seat belt automatically adjusts to Height adjustment You can adjust the height of the shoul- the proper length only after the lap B180A01NF-1 der belt anchor to one of the 4 posi- belt portion is adjusted manually so...
Page 88 Safety features of your vehicle Release the button to lock the Seat belts - Front passenger and It automatically adjusts to the proper anchor into position. Try sliding the rear seat 3-point system with length only after the lap belt portion height adjuster to make sure that it of the seat belt is adjusted manually combination locking retractor...
Page 89 Safety features of your vehicle CAUTION Do NOT fold down the left por- tion of the rear seat back when the rear center seat belt is buck- led. ALWAYS UNBUCKLE the rear center seat belt before fold- ing down the left portion of the rear seat back.
Page 90 Safety features of your vehicle Stowing the rear seat belt • The rear seat belt buckles can be stowed in the pocket between the ■ Outboard belt rear seatback and cushion when not in use. • Insert the seat belt into the two holes (A) located on both sides.
Page 91: Pre-Tensioner Seat Belt
Safety features of your vehicle Pre-tensioner seat belt (1) Retractor Pretensioner The purpose of the retractor pre- tensioner is to make sure that the shoulder belts fit in tightly against the occupant's upper body in cer- tain frontal collisions. (2) EFD (Emergency Fastening Device) The purpose of the EFD is to make sure that the pelvis belts fit in tightly against the occupant's...
Page 92 Kia burn you. dealer inspect the pre-tensioner seat belt and SRS air bag system as soon ✽...
Page 93: Seat Belt Precautions
Safety features of your vehicle Seat belt precautions Larger children If the shoulder belt portion slightly touches the child’s neck or face, try Children who are too large for child Infant or small child placing the child closer to the center of restraint systems should always Most countries have child restraint the vehicle.
Page 94 Safety features of your vehicle Restraint of pregnant women Injured person Do not lie down Pregnant women should wear A seat belt should be used when an To reduce the chance of injuries in lap/shoulder belt assemblies when- injured person is being transported. the event of an accident and to ever possible according to specific When this is necessary, you should...
Page 95: Care Of Seat Belts
Keep belts clean and dry ation should be directed to an Seat belts should be kept clean and authorized Kia dealer. WARNING dry. If belts become dirty, they can be - Pinched seat cleaned by using a mild soap solu- belt tion and warm water.
Page 96: Child Restraint System (Crs)
Safety features of your vehicle CHILD RESTRAINT SYSTEM (CRS) Children Always in the Rear Children under age 13 must always Child restraint systems must be ride in the rear seats and must always properly placed and installed in the be properly restrained to minimize the rear seat.
Page 97: Selecting A Child Restraint System (Crs)
✽ ✽ NOTICE • Always follow child restraint system. restraint system manufactur- After an accident, have a Kia dealer er’s instructions for installa- check the child restraint system, seat tion and use. belts, tether anchors and lower anchors. (Continued)
Page 98 Safety features of your vehicle Child restraint system types WARNING - WARNING - Holding Unattended There are three main types of child Children Children restraint systems: rear-facing seats, Never hold a child in your arms Never leave children unattended forward-facing seats, and booster or lap when riding in a vehicle.
Page 99 Safety features of your vehicle Convertible and 3-in-1 child seats typically have higher height and weight limits for the rear-facing posi- tion, allowing you to keep your child rear-facing for a longer period of time. Continue to use a rear-facing child seat for as long as your child will fit within the height and weight limits allowed by the child seat manufactur-...
Page 100: Installing A Child Restraint System (Crs)
Safety features of your vehicle Booster seats Installing a Child Restraint • Secure the child in the child restraint. Make sure the child is System (CRS) A booster seat is a restraint designed properly strapped in the child to improve the fit of the vehicle’s seat After selecting a proper child seat for restraint according to the manufac- belt system.
Page 101 Safety features of your vehicle Lower Anchors and Tether for WARNING - LATCH Lower Children (LATCH) System Anchors The LATCH system holds a child Never attempt to attach a LATCH restraint during driving and in an equipped seat in the center accident.
Page 102 Kia dealer after an acci- dent. An accident can damage ❈ (1) : Lower Anchor position indicator the LATCH system and may (2) : Lower Anchor not properly secure the child restraint.
Page 103 Safety features of your vehicle Securing a child restraint seat WARNING with "Tether Anchor" system Take the following precautions when installing the tether strap: • Read and follow all installation instructions provided with your child restraint system. • NEVER attach more than one child restraint to a single teth- er anchor.
Page 104 Safety features of your vehicle 3. Check that the child restraint is To install a child restraint system on securely attached to the seat by the rear seats, do the following: pushing and pulling the seat for- 1.Place the child restraint system on ward and from side-to-side.
Page 105 Safety features of your vehicle OEN036101 OEN036102 OEN036103 2. Fasten the lap/shoulder belt latch 3. Pull the shoulder portion of the 4. Slowly allow the shoulder portion into the buckle. Listen for the dis- seat belt all the way out. When the of the seat belt to retract and listen tinct “click”...
Page 106 Safety features of your vehicle ✽ ✽ NOTICE 5. Remove as much slack from the belt as possible by pushing down When the seat belt is allowed to on the child restraint system while retract to its fully stowed position, feeding the shoulder belt back into the retractor will automatically the retractor.
Page 107: System
Safety features of your vehicle AIR BAG - ADVANCED SUPPLEMENTAL RESTRAINT SYSTEM (1) Driver’s front air bag (2) Passenger’s front air bag (3) Side air bag (4) Curtain air bag (5) Driver’s knee air bag Even in vehicles with air bags, you and your passengers must always wear the safety belts provided in order to minimize the risk and sever-...
Page 108: How Does The Air Bag System Operate?
Safety features of your vehicle How does the air bag system • The front air bags will completely • In order to help provide protection, operate? inflate and deflate in an instant. the air bags must inflate rapidly. The speed of the air bag inflation is It is virtually impossible for you to •...
Page 109 Safety features of your vehicle Noise and smoke WARNING WARNING - Airbag infla- - Hot compo- When inflated, the air bags make a tion nents loud noise and leave smoke and Sit as far back as possible from powder in the air inside the vehicle. Do not touch the air bag storage the steering wheel while still This is normal and is a result of the...
Page 110: Air Bag Warning Light
Safety features of your vehicle Do not install a child restraint on Air bag warning light WARNING - Air bag the front passenger’s seat deployment When children are seated in the rear outboard seats of a vehicle equipped with side and/or cur- tain air bags, install the child restraint system as far away from the door side as possible.
Page 111: Srs Components And Functions
The SRS consists of the following properly and you should have your components: vehicle checked by an authorized Kia 1. Driver's front air bag module dealer. 2. Passenger's front air bag module 3. Side air bag modules 4.
Page 112 Driver’s front air bag (2) occur, this indicates a malfunction in the air bag system. Have an author- ized Kia dealer inspect the air bag system as soon as possible. • The light does not turn on briefly when you change engine start/stop button to ON.
Page 113 Safety features of your vehicle Driver’s front air bag (3) Passenger’s front air bag WARNING - Flying objects Do not place any objects (an umbrella, bag, etc.) between the front door and the front seat. Such objects may become dan- gerous projectiles if the side airbag inflates.
Page 114: Occupant Detection System (Ods)
SRS is not working properly. If this occurs, have your vehicle immediately inspected authorized Kia dealer. ✽ ✽ NOTICE ODE036039N Your vehicle is equipped with an Before you replace a fuse or discon- occupant detection system in the nect a battery terminal, change front passenger's seat.
Page 115 Safety features of your vehicle Main components of the occu- If the front passenger seat is occu- Always be sure that you and all vehicle pant detection system pied by a person that the system occupants are seated and restrained determines to be of appropriate size, properly (sitting upright with the seat in •...
Page 116 Safety features of your vehicle Condition and operation in the front passenger occupant detection CAUTION system • Do not install a child restraint seat in the passenger seat Indicator/Warning light Devices when the seat is heavily Condition detected by the “PASSENGER soaked with any type of liquid.
Page 117 ODS must be ket, front seat cover or after market done at Kia service center. seat heater to the front passenger • After the passenger seat has been seat.
Page 118 Safety features of your vehicle WARNING - ODS System Riding in an improper position adversely affects the Occupant Detection System and may result in the deactivation of the front passenger airbag. It is important for the driver to instruct the passenger as to the proper seating instructions as contained in this manual.
Page 119 Safety features of your vehicle (Continued) OJFA035107 OJFA035108 OJFA035109 - Never excessively recline the - Never place feet on the dash- - Never lean on the door or cen- ter console. front passenger seatback. board. - Never sit on one side of the front passenger seat.
Page 120 Safety features of your vehicle (Continued) OJFA035101 OJFA035102 OJFA035103 - Do not use car seat acces- - Do place electronic - Wet Passenger Seat sories such as thick blankets devices such as laptops, DVD Do not spill liquid in the pas- and cushions which cover up player, or conductive materi- senger seat.
Page 121 Safety features of your vehicle ✽ ✽ NOTICE If the PASSENGER AIR BAG “OFF” Proper position indicator is still on, ask the passen- The PASSENGER AIR BAG “OFF” ger to move to the rear seat. indicator illuminates for about 4 sec- onds after Engine Start/Stop button WARNING is turned to the ON position after the...
Page 122: Driver`s Front Air Bag
Safety features of your vehicle • Even though your vehicle is Any child age 12 and under should Driver's and passenger's front equipped with the occupant detec- ride in the rear seat. Children too air bag tion system, never install a child large for child restraints should use ■...
Page 123 Safety features of your vehicle ■ Passenger’s front air bag The SRS consists of air bags These sensors provide the ability to installed under the pad covers in the control the SRS deployment based on center of the steering wheel and the whether or not the seat belts are fas- passenger's side front panel above tened, and how severe the impact is.
Page 124 Kia dealer using original tain conditions. For more detail, see below the deployment threshold. Kia parts designed for this vehi- "Occupant detection system" in this cle and model. Any other such chapter. replacement or modification...
Page 125: Side Air Bag
Safety features of your vehicle Side air bag The purpose of the air bag is to pro- WARNING - No attaching vide the vehicle's driver and/or the objects front passenger with additional pro- tection than that offered by the seat No objects (such as crash pad belt alone.
Page 126 No attaching the driver's and the passenger's have the vehicle checked and seat belt systems and is not a sub- repaired by an authorized Kia deal- objects stitute for them. Therefore your er. Inform the dealer that your vehi- • Do not place any objects over...
Page 127: Curtain Air Bag
This should only be impact. However, when side deploy- done by an authorized Kia dealer. ment threshold is satisfied at front- impact, side air bags may deploy. WARNING - No attaching •...
Page 128 Safety features of your vehicle Why didn’t my air bag go off in a Air bag collision sensors collision? (Inflation and non-infla- tion conditions of the air bag) There are many types of accidents in which the air bag would not be expected to provide additional pro- tection.
Page 129 Have the vehicle checked and collisions if the front impact sensors repaired by an authorized Kia detect a sufficient frontal force in dealer. another type of impact. Side and cur- tain air bags are designed to inflate in certain side impact collisions.
Page 130 Safety features of your vehicle They may inflate in other types of Air bag non-inflation conditions • Just before impact, drivers often collisions where a side force is brake heavily. Such heavy braking • In certain low-speed collisions the detected by the sensors. Side air bag lowers the front portion of the vehi- air bags may not deploy.
Page 131: Srs Care
SRS precautions must be observed. An inoperative. Any work on the SRS system, such authorized Kia dealer knows these as removing, installing, repairing, or precautions and can give you the any work on the steering wheel, the necessary information.
Page 132: Air Bag-Equipped Vehicle
Safety features of your vehicle Adding equipment to or modi- Air bag warning label fying your air bag-equipped vehicle If you modify your vehicle by chang- ing your vehicle's frame, bumper sys- tem, front end or side sheet metal or ride height, this may affect the opera- tion of your vehicle's air bag system.
Page 133: Sunroof
Features of your vehicle Folding key ....... . 4-4 Windows ....... . . 4-28 •...
Page 134: Liftgate
Instrument cluster ......4-54 Parking assist system ..... . 4-111 •...
Page 135 Welcome system ......4-129 • Seat warmer ....... . 4-152 •...
Page 136 This may damage the key. attached to the key set. Should lose your keys, this number will enable an authorized Kia dealer to WARNING - Aftermarket duplicate the keys easily. Remove the key code tag and store it in a safe Use only Kia original parts for place.
Page 137 Features of your vehicle Door Unlock (2) WARNING - Ignition key 1. Press the unlock button(2). (smart key) 2. The driver's door will unlock. The Never leave the keys in your hazard warning lights will blink two vehicle with unsupervised chil- times.
Page 138 Features of your vehicle Liftgate unlock (3) Panic (4) Transmitter precautions The liftgate is unlocked if the button The horn sounds and hazard warn- • The transmitter will not work if any is pressed for more than 1 second. ing lights flash for about 27 seconds of following occur: if this button is pressed for more than Also, once the liftgate is opened and...
Page 139 If you have a Keep the transmitter away from problem with the transmitter, con- water or any liquid as it can tact an authorized Kia dealer. become damaged and not func- tion properly. • If the transmitter is in close proxim-...
Page 140 Features of your vehicle For replacement transmitters, see an Immobilizer system CAUTION - Transmitter authorized Kia dealer for transmitter Your vehicle is equipped with an damage reprogramming. electronic engine immobilizer system Do not drop, wet or expose the • The transmitter is designed to give...
Page 141 To deactivate the immobilizer Immobilizer your keys, contact an authorized system: alterations Kia dealer. Insert the ignition key into the key Do not change, alter or adjust the cylinder and turn it to the ON position. immobilizer system because it could...
Page 142 30 seconds. If you operation of the device. switch. Your password is only avail- attempt to start the engine after 30 able from an authorized Kia dealer- seconds, the engine will not start ✽ ✽ NOTICE ship. Contact an authorized dealer and you will have to input your for more information.
Page 143 WARNING - Smart key this number will enable an author- Never leave the keys in your ized Kia dealer to duplicate the keys vehicle with unsupervised chil- easily. Remove the bar code tag and dren. Leaving children unat- store it in a safe place. Also, record...
Page 144 Features of your vehicle Locking The hazard warning lights will blink Unlocking once to indicate that all doors (and Pressing the button of the front out- liftgate) are locked. The button will side door handles with all doors (and only operate when the smart key is liftgate) closed and locked, unlocks within 0.7 ~ 1 m (28 ~ 40 in.) from the all the doors (and liftgate).
Page 145 Features of your vehicle ✽ ✽ NOTICE Liftgate unlocking Engine start If you are within 0.7 ~ 1 m (28 ~ 40 in.) You can start the engine without You can activate or deactivate the from the outside liftgate handle, with inserting the key.
Page 146 Kia dealer (tow the vehi- smart key. calls, text messaging, and/or send- cle, if necessary) to protect it from - The smart key is near a mobile ing/receiving emails.
Page 147 (1) this replace the battery, contact an device may not cause interfer- authorized Kia dealer. ence, and (2) this device must • Using the wrong battery can cause accept any interference, includ- the smart key to malfunction.
Page 148 Keep each key separate in the engine from being started. order to avoid a starting malfunction. ✽ ✽ NOTICE If you need additional keys or lose your keys, contact an authorized Kia dealer.
Page 149 Features of your vehicle This device complies with Industry Canada licence-exempt RSS stan- dard(s). Operation is subject to the following two conditions: (1) This device may not cause inter- ference, and (2) This device must accept any interference, including interfer- ence that may cause undesired operation of the device.
Page 150 Disarmed Theft-alarm 3. Lock the doors by depressing the stage stage tivated by an authorized Kia dealer. door lock button on the smart key. If you want this feature, consult an After completion of the steps above, authorized Kia dealer.
Page 151 Features of your vehicle Do not arm the system until all Theft-alarm stage Disarmed stage passengers have left the vehicle. If The alarm will be activated if any of The system will be disarmed when the system is armed while a pas- the following occurs while the system •...
Page 152 Engine Start/Stop button with the smart key. • If you lose your keys, consult your authorized Kia dealer. CAUTION - Adjusting alarm system Do not change, alter or adjust the theft alarm system in your vehicle.
Page 153 Features of your vehicle DOOR LOCKS ✽ ✽ NOTICE Operating door locks from CAUTION outside the vehicle • In cold and wet climates, door lock Do not unnecessarily open and and door mechanisms may not close the door repeatedly or work properly due to freezing con- with excessive force.
Page 154 Features of your vehicle Operating door locks from • If the inner door handle of the dri- ver’s (or front passenger’s) door is inside the vehicle pulled when the door lock button is With the door lock button in the lock position, the button will unlock and the door will open.
Page 155 Features of your vehicle With central door lock switch • When pressing the left portion(2) WARNING for driver side or the lower por- ■ Driver side tion(2) for passenger side of the Do not pull the inner door han- switch, all vehicle doors will unlock. dle of driver’s(or passenger’s) door while the vehicle is mov- •...
Page 156 Features of your vehicle Impact sensing door unlock Child-protector rear door lock WARNING - Unattended system children/animals In the event of air bag deployment Never leave children or animals resulting from a vehicle impact, all unattended in your vehicle. An doors will automatically unlock.
Page 157 Features of your vehicle 3. Close the rear door. To open the rear door, pull the out- side door handle (2). Even though the doors may be unlocked, the rear door will not open by pulling the inner door handle until the rear door child safety lock is unlocked.
Page 158 Features of your vehicle LIFTGATE Opening the liftgate The liftgate swings upward. Make Closing the liftgate sure no objects or people are near the rear of the vehicle when opening the liftgate. ✽ ✽ NOTICE In cold and wet climates, door lock and door mechanisms may not work properly due to freezing conditions.
Page 159 Features of your vehicle Emergency liftgate safety WARNING WARNING - Exhaust release fumes • No one should be allowed to Driving with the liftgate open is occupy the cargo area of the advisable. Dangerous vehicle at any time. The cargo exhaust fumes can enter the area is a very dangerous loca- passenger compartment.
Page 160: Power Window Switch
Features of your vehicle WINDOWS ■ ■ Front (1) Driver’s door power window switch (2) Front passenger’s door power window switch (3) Rear door (left) power window switch (4) Rear door (right) power window switch (5) Window opening and closing* (6) Automatic power window up/down* (Driver's and Passenger's window)
Page 161: Power Window Lock Button
Features of your vehicle ✽ ✽ NOTICE Power windows Window opening and closing While driving with the rear windows The ignition switch or Engine down or with the sunroof (if Star/Stop button must be in the ON equipped) in an open (or partially position for power windows to oper- open) position, your vehicle may ate.
Page 162 Features of your vehicle Auto up/down window (if equipped) 1. Turn to the Engine Start/Stop but- ton ON position. 2. Close the driver's and passenger's window and continue pulling up the driver’s power window switch for at least 1 second after the win- dow is completely closed.
Page 163 Features of your vehicle If the power window switch is pulled Power window lock button WARNING up continuously again within 5 sec- onds after the window is lowered by The automatic reverse feature the automatic window reversal fea- doesn’t activate while resetting ture, the automatic window reversal power window system.
Page 164 Features of your vehicle • When the power window lock If the window cannot be close CAUTION - Opening /clos- button is pressed : because it is blocked by objects, ing Window remove the objects and close the - The driver's master control can window.
Page 165 Features of your vehicle HOOD Opening the hood ODE046015 ODE046016 2. Go to the front of the vehicle, raise 4. Pull out the stay rod. ODE046014 the hood slightly, push the second- 5. Hold the hood opened with the 1. Pull the release lever to unlatch ary latch (1) upward inside of the stay rod (1).
Page 166 Features of your vehicle Hood open warning Closing the hood WARNING Fire risk 1. Before closing the hood, check the Do not leave gloves, rags or any following: other combustible material in the • All filler caps in the engine com- engine compartment.
Page 167 Features of your vehicle FUEL FILLER LID (HYBRID) Opening the fuel filler lid Closing the fuel filler lid 1. To install the cap, turn it clockwise until it “clicks” once. This indicates that the cap is securely tightened. 2. Close the fuel filler lid and push it in lightly making sure that it is securely closed.
Page 168 Features of your vehicle FUEL FILLER LID (PLUG-IN HYBRID) ✽ ✽ NOTICE Opening the fuel filler lid • It may take up to 20 seconds to open fuel filler door. • When the fuel filler door is frozen and does not open after 20 seconds at freezing temperature, slightly tap the fuel filler door and then attempt to open it.
Page 169 Features of your vehicle ✽ ✽ NOTICE Closing the fuel filler lid 1. To install the cap, turn it clockwise • Add fuel into the fuel tank within until it “clicks”. This indicates that 20 minutes after opening the fuel the cap is securely tightened.
Page 170 Features of your vehicle WARNING WARNING WARNING - Refueling - Fire/explo- - Static sion risk electricity Always remove the fuel cap carefully and slowly. If the cap Read and follow all warnings • Before touching the fuel noz- is venting fuel or if you hear a posted at the gas station facili- zle, you should eliminate hissing sound, wait until the...
Page 171 If the fuel filler cap requires replace- portable fuel container, be sure leave a lit cigarette in your vehi- ment, use only a genuine Kia cap or to place the container on the cle while at a gas station espe- the equivalent specified for your vehi- ground prior to refueling.
Page 172 Features of your vehicle SUNROOF (IF EQUIPPED) CAUTION WARNING - Sunroof operation To prevent damage to the sun- roof, periodically remove any When closing the sunroof, make dirt that may accumulate on the sure there are no body parts in guide rail.
Page 173 Features of your vehicle Sunroof open warning Sliding the sunroof CAUTION (if equipped) Do not extend any luggage out- side the sunroof while driving. WARNING To avoid accidental injury, do not let children operate the sun- roof without adult supervision. WARNING - ODE046020 Roof cargo...
Page 174 Features of your vehicle To open the sunroof to the maximum Automatic reversal Tilting the sunroof slide open position, press the switch towards the rear of the vehicle once again and hold it until the sunroof slide all the way open. ✽...
Page 175 Features of your vehicle Sunshade Resetting the sunroof WARNING - Sunroof Whenever the vehicle battery is dis- Do not extend the face, neck, connected or discharged, or related arms or body outside through fuse is blown, you must reset your the sunroof opening while driv- sunroof system as follows: ing or operating the sunroof.
Page 176 (The sunroof system has been reset.) ❈ For more detailed information, contact an authorized Kia dealer. ✽ ✽ NOTICE If the sunroof is not reset when the vehicle battery is disconnected or discharged, or related fuse is blown,...
Page 177: Steering Wheel
Take your vehicle to • The steering gets heavy immedi- ing system becomes inoperative, the an authorized Kia dealer and have ately after turning the Engine vehicle may still be steered, but it will the vehicle checked as soon as Start/Stop button is ON position.
Page 178 Features of your vehicle (Continued) Tilt and telescopic steering • When the charging system warning Tilt and telescopic steering allows light comes on due to the low volt- you to adjust the steering wheel age (When the alternator or bat- before you drive.
Page 179 Features of your vehicle Heated steering wheel CAUTION WARNING (if equipped) • Do not install any type of grip If the steering wheel becomes cover for the steering wheel, it too warm, turn the system off. may impair the function of the The heated steering wheel may heated steering wheel system.
Page 180: Horn
Features of your vehicle Horn ODE046024 To sound the horn, press the horn symbols on your steering wheel. Check the horn regularly to be sure it operates properly. ✽ ✽ NOTICE To sound the horn, press the area indicated by the horn symbol on your steering wheel (see illustra- tion).
Page 181 Features of your vehicle MIRRORS Inside rearview mirror Day/night rearview mirror WARNING - Mirror adjust- (if equipped) Adjust the rearview mirror so that the ment center view through the rear window Do not adjust the rearview mir- is seen. Make this adjustment before ror while the vehicle is moving.
Page 182 Features of your vehicle Electric chromatic mirror (ECM) CAUTION - Cleaning (if equipped) mirror The electric rearview mirror automat- When cleaning the mirror, use a ically controls the glare from the paper towel or similar material headlights of the vehicles behind you dampened with glass cleaner.
Page 183 Features of your vehicle Electric chromatic mirror (ECM) And telematics buttons are on the Outside rearview mirror with UVO service (if equipped) mirror. Be sure to adjust the mirror angles 1) eService guide button before driving. 2) UVO(Voice local search) button Your vehicle is equipped with both left-hand and right-hand outside 3) Roadside assist button...
Page 184 Features of your vehicle Adjusting outside rearview mirror CAUTION - CAUTION - Rearview Outside mirror mirror • The mirrors stop moving when they reach the maximum Do not scrape ice off the mirror adjusting angles, but the face; this may damage the sur- motor continues to operate face of the glass.
Page 185 Features of your vehicle Folding the outside rearview mirror Center (AUTO) : (if equipped) The mirror will fold or unfold automat- ically as follows: • The mirror will fold or unfold when the door is locked or unlocked by the folding key or smart key. •...
Page 186: Instrument Cluster
Features of your vehicle INSTRUMENT CLUSTER ■ ■ For Hybrid 1. Hybrid system gauge 2. Fuel gauge 3. Speedometer 4. Warning and indicator lights 5. LCD display (including Trip computer) 6. Battery SOC (State of Charge) gauge 7. Distance to empty ❈...
Page 187 Features of your vehicle ■ ■ Type A for Plug-in Hybrid 1. Hybrid system gauge 2. Fuel gauge 3. Speedometer 4. Warning and indicator lights 5. LCD window ■ ■ Type B for Plug-in Hybrid 6. Battery SOC (State of Charge) gauge 7.
Page 188 Features of your vehicle ■ ■ Type B Sport mode for Plug-in Hybrid 1. Hybrid system gauge 2. Fuel gauge 3. Speedometer 4. Warning and indicator lights 5. LCD window 6. Battery SOC (State of Charge) gauge ❈ For more details, refer to the “Gauges” in this chapter.
Page 189 Features of your vehicle Instrument Cluster Control LCD window control Adjusting Instrument Cluster ■ Type A Illumination OQLE045233 ODE046103 • If you hold the illumination control ■ Type B button (“+” or “-”), the brightness will be changed continuously. ODE047102N •...
Page 190 Features of your vehicle : MODE button for change the Gauges Tachometer (if equipped) LCD MODES Speedometer ■ Type B Sport mode for Plug-in Hybrid : MOVE scroll switch for select the items (3) OK : SET/RESET button for set the items or reset the items ❈...
Page 191 Features of your vehicle Hybrid System Gauge • CHARGE : Shows that the energy CAUTION made by the vehicle is ■ Type A being converted Do not operate the engine with- electrical energy. in the tachometer's RED ZONE. (Regenerated energy) This may cause severe engine damage.
Page 192 Malfunction Indicator Lamp (MIL) ) turn on when the SOC gauge is near the “L (Low)” level, have your vehicle inspected by an authorized Kia dealer. ✽ ✽ NOTICE ODE046108 Never try to start the vehicle if the ■ Type B for Plug-in Hybrid ODE046107 fuel tank is empty.
Page 193 Features of your vehicle ✽ ✽ NOTICE ✽ ✽ NOTICE - Distance to empty Fuel gauge • The fuel tank capacity is given in Running out of fuel can expose vehi- ■ Hybrid chapter 9. cle occupants to danger. You must •...
Page 194 Features of your vehicle ✽ ✽ NOTICE Distance To Empty (1) - For plug-in hybrid • The distance to empty is the esti- • Electric range (1) • If the vehicle is not on level ground mated distance the vehicle can be or the battery power has been The distance to empty is the esti- driven with the remaining fuel.
Page 195 Features of your vehicle Odometer - Odometer range : 1,599,999 kilo- Outside Temperature Gauge meters or 0 ~ 999,999 miles. ■ ■ Type A Type A ODEP047214 OJF045135 ■ ■ Type B Type B ODEP047211 ODEP047194C This gauge indicates the current out- The odometer Indicates the total dis- side air temperatures by 1°C (1°F).
Page 196 Features of your vehicle The outside temperature on the dis- Dual clutch transmission shift indicator play may not change immediately ■ Type A-Drive mode ■ Type A-Sport mode like a general thermometer to pre- vent the driver from being distracted. To change the temperature unit (from °C to °F or from °F to °C) temperature...
Page 197 Features of your vehicle LCD WINDOWS (IF EQUIPPED) Over view Trip information (Trip computer, Trip Modes for Hybrid) ■ Type A FUEL ECONOMY The trip computer is a microcomput- er-controlled driver information sys- • Average Fuel Economy tem that displays information related •...
Page 198 Features of your vehicle Fuel Economy Manual reset Automatic reset To clear the average fuel economy To make the average fuel economy manually, press the OK button be reset automatically whenever (reset) on the steering wheel for refueling, select the “Fuel economy more than 1 second when the aver- auto reset”...
Page 199 Features of your vehicle Instant Fuel Economy (2) Trip A/B Average Vehicle Speed (2) • This mode displays the instant fuel • The average vehicle speed is cal- economy during the last few sec- culated by the total driving dis- onds when the vehicle speed is tance and driving time since the more than 10 km/h (6 mph).
Page 200 Features of your vehicle ✽ ✽ NOTICE Elapsed Time (3) Digital speedometer • The elapsed time is the total driv- • The average vehicle speed is not ing time since the last elapsed time displayed if the driving distance reset. has been less than 500 meters (0.03 miles) or the driving time has been - Time range (hh:mm): 00:00 ~...
Page 201 Features of your vehicle Driving style One time driving information mode ODEP047199L OJF045285L The driving style is displayed when you are driving in ECO mode. This display shows trip distance (1), average fuel economy (2) and the When you drive in SPORT mode, vehicle can be driven with the each driving category will be dis- remaining fuel (3).
Page 202 Features of your vehicle Energy flow EV Propulsion Engine Only Propulsion Kia hybrid system notifies the drivers of energy flow in various operating modes. Eleven Modes show drivers the current operating condition. ODE046121N ODE046123N Electric power is used to move the Engine power is used to move the vehicle.
Page 203 Features of your vehicle Regeneration Power Reserve Engine Generation/Regeneration ODE046121N ODE046127N ODE046128N Hybrid battery is being charged by Engine is both driving the vehicle The engine and regenerative braking regenerative braking. and charging the hybrid battery. system charge the hybrid battery driving deceleration.
Page 204 Features of your vehicle Trip information (Trip computer, Trip Modes Fuel Economy for Plug-in Hybrid) FUEL ECONOMY The trip computer is a microcomput- er-controlled driver information sys- • Average Fuel Economy tem that displays information related • Instant Fuel Economy to driving.
Page 205 Features of your vehicle Manual reset Automatic reset Instant Fuel Economy (2) • This mode displays the instant fuel To clear the average fuel economy To make the average fuel economy economy during the last few sec- manually, press the OK button be reset automatically whenever onds when the vehicle speed is (reset) on the steering wheel for...
Page 206 Features of your vehicle Accumulated driving information One time driving information mode - If the engine is running, even when mode the vehicle is not in motion, the infor- mation will be accumulated. ODEP047198L ODEP047197L The vehicle will display Driving Information once per one ignition cycle.
Page 207 Features of your vehicle Digital speedometer Driving style ODEP047218L ODEP047199L This mode displays the current The driving style is displayed when speed of the vehicle. you are driving in ECO mode. When you drive in SPORT mode, each driving category will be dis- played with “---”...
Page 208 Features of your vehicle Energy flow EV Propulsion Engine Only Propulsion Kia hybrid system notifies the drivers of energy flow in various operating modes. Eleven Modes show drivers the current operating condition. ODEP047202N ODEP047204N Electric power is used to move the Engine power is used to move the vehicle.
Page 209 Features of your vehicle Regeneration Power Reserve Engine Generation/Regeneration ODEP047206N ODEP047207N ODEP047207N Hybrid battery is being charged by Engine is both driving the vehicle The engine and regenerative braking regenerative braking. and charging the hybrid battery. system charge the hybrid battery (Wheel ➞...
Page 210 Features of your vehicle Engine coolant temperature LCD Modes (3) Assist mode(if equipped) This mode displays the state of the ■ For Hybrid Lane Keeping Assist System (LKAS), Driver Attention Alert (DAA) and Smart Cruise Control (SCC). (4) Audio mode (if equipped) This mode displays the state of the A/V system.
Page 211 Features of your vehicle (7) Door open mode ■ (3) Assist mode (if equipped) For Plug-in Hybrid When the any door is not closed This mode displays the state of the securely, this symbol illuminated. Lane Keeping Assist System (LKAS), Driver Attention Alert (DAA) and Smart Cruise Control (SCC).
Page 212 Features of your vehicle Tire Pressure Turn By Turn Mode (if equipped) A/V Mode (if equipped) OJF045223L OJF045142L ODE067054L This mode displays the state of the This mode displays the state of the This mode displays the pressure sta- navigation. A/V system.
Page 213 Features of your vehicle Service Mode OJF045294L ODE046169N Service required Service interval OFF ODEP047243C If you do not have your vehicle serv- If the service interval is not set, Service in iced according to the already “Service interval OFF” message is It calculates and displays when you inputted service interval, “Service displayed on the LCD window.
Page 214 Features of your vehicle User Settings Mode Edit settings after shifting to P Driving Assist (if equipped) This warning message appears if • Lane Keeping Assist System you try to adjust the User Settings (if equipped) while driving. - Lane Departure Warning : To acti- - Dual clutch transmission vate the lane departure warning function.
Page 215 Features of your vehicle • Smart Cruise Control Response (if • BSD (Blind Spot Detection) Sound Door equipped) : Choose the sensitivity (if equipped) : If this item checked, • Automatic Lock of the smart cruise control. the blind spot detection sound will - Enable on Speed : All doors will be activated.
Page 216 Features of your vehicle Lights Convenience Service interval • One Touch Turn Signal • Seat Easy Access (if equipped) • Service Interval - Off : The one touch turn signal - None : The seat easy access To activate or deactivate the serv- function will be deactivated.
Page 217 Features of your vehicle ✽ ✽ NOTICE Other Features • Fuel Economy Unit : Choose the fuel economy unit. (L/100 km, • Instrument Cluster layout If any of the following conditions km/L, US gallon, UK gallon) equipped) : Selecting the mode occur, the mileage and number of Simple/Normal/Detailed changes days to service may be incorrect.
Page 218 Features of your vehicle Coasting guide (if equipped) • User settings Warning messages A chime will sound and the coasting Press the Engine Start/Stop button Warning messages appear on the guide indicator will blink four times to and put the shift lever in P(Park). In LCD to warn the driver.
Page 219 Features of your vehicle ODE046116 ODE046117 ODE046118 Door Open Liftgate Open Hood Open • It means that any door is open. • It means that the liftgate is open. • It means that hood is open. 4 87...
Page 220 Features of your vehicle ODE046119 OJF045166L ODE046137L Sunroof Open (if equipped) Turn on FUSE SWITCH (if equipped) Engine has overheated • This warning is displayed if you • This warning message illuminates This warning message illuminates turn off the engine when the sun- if the fuse switch under the steer- when the engine coolant tempera- roof is open.
Page 221 Features of your vehicle Shift to P (for smart key system) Press START button while turn steer- Press brake pedal to start engine ing (for smart key system) (for smart key system) • This warning message illuminates if you try to turn off the engine with- •...
Page 222 - When the low fuel level warning Start/Stop Button, have your vehi- Shift to P or N to start engine light is illuminates. cle inspected by an authorized Kia (for smart key system) Add fuel as soon as possible. dealer.
Page 223 In this case, have your vehicle inspect- tion. And the instrument panel's one ed by an authorized Kia dealer. In this case, have your vehicle inspect- time driving information mode has ed by an authorized Kia dealer.
Page 224 Refill inverter coolant the nearest professional workshop the shift lever in R (Reverse), N This warning message illuminates and have the vehicle inspected. Kia (Neutral) or D (Drive). Move the shift when the inverter coolant is nearly recommends to visit an authorized lever to P (Park) and re-start the empty.
Page 225 Features of your vehicle EV/HEV modes (Plug-in hybrid) Low/High System Temp. Maintaining Charger Error! (Plug-in hybrid) Hybrid mode (Plug-in hybrid) A corresponding message is dis- This message is displayed when played when a mode is selected by This message is displayed when the there is a problem with the charger.
Page 226 Features of your vehicle Switching to Hybrid mode to allow heating (Plug-in hybrid) • When the coolant temperature is lower than -14°C (57°F), and you turn the climate control On for heating, the above message will be displayed in the cluster. Then, the vehicle will automatically switch to HEV mode.
Page 227 SRS. In this case, have your vehicle This warning light illuminates: inspected by an authorized Kia when there is a malfunction with the dealer. hybrid system. In this case, have the vehicle inspected by an authorized Kia deal- 4 95...
Page 228 In this case, have your vehicle al engine braking and stop the vehi- - If the warning light illuminates towed to an authorized Kia dealer cle as soon as it is safe to do so. with the parking brake released, it and inspected.
Page 229 In this case, have your vehicle sudden braking thereby • When there is a malfunction with inspected by an authorized Kia increasing the risk of a crash the ABS (The normal braking sys- dealer. and injury. In this case, avoid...
Page 230 • When there is a malfunction with In this case, have your vehicle inspect- Warning light (red) and Regenerative the EPS. ed by an authorized Kia dealer as Brake Warning Light (yellow) to illu- soon as possible. minate simultaneously. In this case, have your vehicle...
Page 231 - Catalytic either the alternator or electrical Converter Damage charging system. In this case, have your vehicle inspected by an authorized Kia If the Malfunction Indicator dealer. Lamp (MIL) illuminates, poten- If there is a malfunction with either tial catalytic converter damage...
Page 232 Kia dealer as soon as immediately. In this case, have possible. your vehicle inspected by an...
Page 233 In this case, have your vehicle - Blind Spot Detection failure ly move to a safe position off the inspected by an authorized Kia road. - Smart Cruise Control System fail- dealer as soon as possible.
Page 234 In this case, have the vehicle inspect- ed and may be damaged. - It illuminates for approximately 3 ed by an authorized Kia dealer. seconds and then goes off. If your vehicle is overheated, refer to “Overheating” in chapter 7.
Page 235 In this case, have your vehicle ❈For more details, refer This indicator light blinks: inspected by an authorized Kia “Electronic Stability Control (ESC)” • When there is a malfunction with dealer. in chapter 6. the immobilizer system. In this case, have your vehicle...
Page 236 Button is ON. • When the vehicle detects the In this case, have your vehicle smart key in the vehicle properly inspected by an authorized Kia while the Engine Start/Stop Button If any of the following occurs, there dealer. is ACC or ON.
Page 237 Features of your vehicle High Beam Indicator Light ON Indicator Light Cruise SET Indicator Light Light (if equipped) This indicator light illuminates: This indicator light illuminates: This indicator light illuminates: • When the headlights are on and in • When the cruise control speed is set. •...
Page 238 When the ready indicator goes OFF in chapter 6. or blinks, there is a problem with the This indicator illuminates when the system. In this case, have your vehi- vehicle is driven by the electric cle inspected by an authorized Kia motor. dealer.
Page 239 Features of your vehicle LKAS (Lane Keeping Assistant System) Indicator (if equipped) The LKAS indicator will illuminate when you turn the lane keeping assistant system on by pressing the LKAS button. If there is a problem with the system, the yellow LKAS indicator will illumi- nate.
Page 240 Features of your vehicle REAR PARKING ASSIST SYSTEM (IF EQUIPPED) Operation of the rear parking WARNING - Rear parking assist system assist system Operating condition Never rely solely on the rear • This system will activate when parking assist system. Always backing up with the ignition switch perform a visual inspection to make sure the vehicle is clear of...
Page 241 Features of your vehicle Types of warning sound Non-operational conditions of The detecting range may decrease when: rear parking assist system • When an object is 120 cm to 61 cm (47 in. to 24 in.) from the rear 1. The sensor is covered with foreign The rear parking assist system bumper: Buzzer beeps intermit- matter such as snow or water.
Page 242 Kia dealer as soon as possible. height or sensor installation has Always visually check behind the been modified or damaged. Any vehicle when backing up.
Page 243 Features of your vehicle PARKING ASSIST SYSTEM (IF EQUIPPED) ■ This system is a supplemental sys- Operation of the parking Rear tem and it is not intended to nor does assist system it replace the need for extreme care Operating condition and attention of the driver.
Page 244 Features of your vehicle • The sensing distance while backing Type of warning indicator and sound up is approximately 120 cm (47 in.) : with Warning sound when you are driving less than 10 km/h (6.2 mph). Warning indicator Distance •...
Page 245 Features of your vehicle ✽ ✽ NOTICE Non-operational conditions of There is a possibility of parking assist system malfunction when: parking assist system • This system can only sense objects 1. Driving on uneven road surfaces within the range and location of Parking assist system may not such as unpaved roads, gravel, the sensors;...
Page 246 Features of your vehicle ✽ ✽ NOTICE ✽ ✽ NOTICE Detecting range may decrease when: 1. The warning may not sound This system can only sense objects 1. Outside temperature sequentially depending on the speed within the range and location of the extremely hot or cold.
Page 247 (if equipped) (blinks) If this occurs, we recommend that the system be checked by an authorized Kia dealer. ✽ ✽ NOTICE Your new vehicle warranty does not cover any accidents or damage to the vehicle or injuries to its occu- pants related to a parking assist sys- tem.
Page 248 Features of your vehicle REARVIEW CAMERA • This system is a supplementary WARNING - Backing & function only. It is the responsibility of the driver to always check the using camera inside/outside rearview mirrors and Never rely solely on the rear view the area behind the vehicle before camera when backing.
Page 249 Features of your vehicle LIGHTING Battery saver function Headlight escort function Daytime running light (if equipped) • The purpose of this feature is to The Daytime Running Lights (DRL) prevent the battery from being dis- can make it easier for others to see the If you turn the ignition switch to the charged if the lights are left in the front of your vehicle during the day.
Page 250 Features of your vehicle Lighting control Headlight position ( Parking & Tail light ( ODE046457N ODE046406N ODE046407N When the light switch is in the park- The light switch has a Headlight and When the light switch is in the head- ing light position, the tail, license and light position, the head, tail, license a Parking light position.
Page 251 Features of your vehicle Auto light position High beam operation WARNING - High beams Do not use high beam when there are other vehicles. Using high beam could obstruct the other driver’s vision. ODE046408N ODE046460N When the light switch is in the AUTO To turn on the high beam headlamp, light position, the taillights and head- push the lever away from you.
Page 252 Features of your vehicle Turn signals and lane change If an indicator stays on and does not flash or if it flashes abnormally, one of signals the turn signal bulbs may be burned out and will require replacement. ✽ ✽ NOTICE If an indicator flash is abnormally quick or slow, a bulb may be burned out or have a poor electrical connec-...
Page 253 (1) is turned to the on position an authorized Kia dealer. after the headlight is turned on. To turn off the fog lights, turn the fog ✽...
Page 254 Features of your vehicle WIPERS AND WASHERS A : Wiper speed control (front) Windshield wipers Windshield wiper/washer · MIST – Single wipe Operates as follows when the igni- tion switch is turned ON. · OFF – Off MIST : For a single wiping cycle, ·...
Page 255 Features of your vehicle ✽ ✽ NOTICE Front windshield washers The reservoir filler neck is located in the front of the engine compartment If there is heavy accumulation of on the passenger side. snow or ice on the windshield, defrost the windshield for about 10 minutes, or until the snow and/or ice is CAUTION -...
Page 256 Features of your vehicle Rear window wiper and wash- CAUTION - WARNING - Wipers & Obscured er switch windshields visibility • To prevent possible damage Do not use the washer in freez- to the wipers or windshield, ing temperatures without first do not operate the wipers warming the windshield with when the windshield is dry.
Page 257 Features of your vehicle OQL045466 Push the lever away from you to spray rear washer fluid and to run the rear wipers 1 ~ 3 cycles. The spray and wiper operation will continue until you release the lever 4 125...
Page 258 Features of your vehicle INTERIOR LIGHTS Do not use the interior lights for Automatic turn off function Room lamp extended periods when the engine is (if equipped) ■ Type A not running. The interior lights automatically turn It may cause battery discharge. off approximately 20 minutes after the ignition switch is turned off, if the lights are in the ON position.
Page 259 Features of your vehicle ✽ ✽ NOTICE Map lamp • (2) : DOOR mode The DOOR mode and ROOM mode ■ Type A - The map lamp and room lamp can not be selected at the same time. come on when a door is opened. The lamps go out after approxi- Front Room Lamp: mately 30 seconds.
Page 260 Features of your vehicle Liftgate room lamp Vanity mirror lamp (if equipped) ODE046412L OQL045416 The liftgate room lamp comes on Push the switch to turn the light on or when the liftgate is opened. off. • : The lamp will turn on if this button is pressed.
Page 261 Features of your vehicle WELCOME SYSTEM (IF EQUIPPED) Headlight (Headlamp) escort Interior light Pocket lamp (if equipped) function When the interior light switch is in the When all doors are locked and DOOR position and all doors (and lift- closed, the pocket lamp will come on The headlights (and/or taillights) gate) are locked and closed, the for 15 seconds if any of the below is...
Page 262 Features of your vehicle DEFROSTER Rear window defroster activate rear window CAUTION - Conductors defroster, press the rear window defroster button located in the center To prevent damage to the con- facia switch panel. The indicator on ductors bonded to the inside the rear window defroster button illu- surface of the rear window, minates when the defroster is ON.
Page 263: Climate Control System
Features of your vehicle AUTOMATIC CLIMATE CONTROL SYSTEM ■ ■ Type A 1. Driver’s temperature control knob 2. AUTO (automatic control) button 3. Front windshield defroster button 4. Rear window defroster button 5. Air conditioning button 6. Air intake control button 7.
Page 264 Features of your vehicle ✽ ✽ NOTICE Automatic heating and air con- ■ ■ Driver’s side Passenger’s side ditioning • To turn the automatic operation off, select any button or switch of the following: - Mode selection button - Air conditioning button - Front windshield defroster button (Press the button one more time to deselect the front windshield...
Page 265 Features of your vehicle ODE046414 ✽ ✽ NOTICE Never place anything over the sensor located on the instrument panel to ensure better control of the heating and cooling system. 4 133...
Page 266 Features of your vehicle Manual heating and air condi- tioning The heating and cooling system can be controlled manually by pressing buttons or turning knob(s) other than the AUTO button. In this case, the system works sequentially according to the order of buttons or knob(s) selected.
Page 267 Features of your vehicle Mode selection Floor/Defrost-Level Face-Level (B, D) (A, C, D, E, F) Most of the air flow is directed to the Air flow is directed toward the upper floor and the windshield with a small body and face. Additionally, each amount directed to the side window outlet can be controlled to direct the defrosters.
Page 268 Features of your vehicle Temperature control ■ ■ Driver’s side Passenger’s side ODE046303 ODE046319 Defrost-Level (A, D) Instrument panel vents ODE046305 Most of the air flow is directed to the The outlet vents can be opened or The temperature will increase to the windshield with a small amount of air closed separately using the thumb- maximum (HI) by turning the knob to...
Page 269 Features of your vehicle Adjusting the driver and passenger Air intake control side temperature individually • Press the “SYNC” button again to adjust the driver and passenger side temperature individually. The illumination of button turns off. • Operate the driver side tempera- ture control knob to adjust the driv- er side temperature.
Page 270 Features of your vehicle Outside (fresh) air position Prolonged operation of the heater in Fan speed control the recirculated air position (without With the outside (fresh) air conditioning selected) may cause air position selected, air fogging of the windshield and side enters the vehicle from windows and the air within the pas- outside and is heated or...
Page 271 Features of your vehicle Air conditioning WARNING - WARNING - Reduced Sleeping with Visibility AC on Continuous use of the climate Do not sleep in a vehicle with control system in the recirculat- the air conditioning or heating ed air position may allow on as this may cause serious humidity to increase inside the harm or death due to a drop in...
Page 272 Features of your vehicle OFF mode Climate information screen Driver Only selection (if equipped) ODE046310 ODE046312 ODE046311 Press the front blower OFF button to If you press the DRIVER ONLY but- turn off the front air climate control ton( ) and the indicator light illumi- Press the climate information screen system.
Page 273 Features of your vehicle Sunroof inside air recircula- System operation Operation Tips tion • To keep dust or unpleasant fumes Ventilation from entering the vehicle through The outside (fresh) air position is 1.Set the mode to the position. the ventilation system, temporarily automatically selected, when the 2.Set the air intake control to the out- set the air intake control to the...
Page 274 Air conditioning system operation tips CAUTION - Excessive A/C • If the vehicle has been parked in All Kia Air Conditioning Systems are direct sunlight during hot weather, filled with R-1234yf refrigerant. When using the air conditioning open the windows for a short time 1.Start the engine.
Page 275 (fresh) air position is selected. If this hap- pens, have the climate control air fil- ter replaced by an authorized Kia dealer. 4 143...
Page 276 Therefore, if abnormal operation is by trained and certified techni- found, have the system inspected by cians. an authorized Kia dealer. WARNING The oil and refrigerant in your vehicle's air conditioning sys- tem is under very high pres- sure.
Page 277 Features of your vehicle WINDSHIELD DEFROSTING AND DEFOGGING • For maximum defrosting, set the Automatic climate control WARNING - Windshield temperature control to the extreme system heating right/hot position and the fan speed To defog inside windshield control to the highest speed. Do not use the posi- tion during cooling operation in...
Page 278 Features of your vehicle If the air conditioning and outside To defrost outside windshield Defogging logic (fresh) air position are not selected To reduce the possibility of fogging automatically, adjust the correspon- up the inside of the windshield, the ding button manually. If the posi- air intake or air conditioning is con- tion is selected, lower fan speed is...
Page 279 Features of your vehicle Automatic climate control system Auto defogging system This indicator illuminates (if equipped) when the auto defogging system senses the mois- ture on the inside of the windshield and operates. If more moisture is in the vehicle, higher steps operate as follow.
Page 280 Features of your vehicle CLEAN AIR (IF EQUIPPED) To cancel or reset the Auto Defogging Do not remove the sensor cover System located on the upper end of the pas- senger side windshield glass. Press the front windshield defroster Damage to the system parts could button for 3 seconds when the igni- occur and may not be covered by tion switch is in the ON position.
Page 281 Features of your vehicle STORAGE COMPARTMENTS These compartments can be used to Center console storage Glove box store small items required by the driver or passengers. • To avoid possible theft, do not leave valuables in the storage compartment. • Always keep the storage compart- ment covers closed while driving.
Page 282 Features of your vehicle Sunglass holder WARNING - WARNING Glove Box - Sunglass holder To reduce the risk of injury in an accident or sudden stop, always • Do not keep objects except keep the glove box door closed sunglasses inside the sun- while driving.
Page 283 Features of your vehicle Luggage box ODE046428N You can place tools, etc. in the box for easy access. Grasp the handle (1) on the edge of the cover and lift it. 4 151...
Page 284 Features of your vehicle INTERIOR FEATURES ■ Front seat Cup holder Seat warmer (if equipped) ■ Front seat WARNING Hot liquids Do not place uncovered cups with hot liquid in the cup holder while the vehicle is in motion. If the hot liquid spills, you may burn yourself.
Page 285 Features of your vehicle ✽ ✽ NOTICE During mild weather or under condi- Temperature control(Automatic) tions where the operation of the seat With the seat warmer switch in the The seat warmer starts to automati- warmer is not needed, keep the ON position, the heating system in cally control the seat temperature in switches in the “OFF”...
Page 286 Features of your vehicle Air ventilation seat (if equipped) • The seat warmer (with air ventila- WARNING - Seat warmer tion) defaults to the OFF position burns whenever the ignition switch is turned on. The seat warmer may cause burns, even at low tempera- tures, if used over a long period CAUTION - Seat damage...
Page 287: Power Outlet
Features of your vehicle Sunvisor * The actual sunvisor lamp in the vehi- Power outlet (if equipped) cle may differ from the illustration. CAUTION - Vanity mirror lamp If you use the vanity mirror lamp, turn off the lamp before returning the sunvisor to its original position, otherwise it could result in battery dis-...
Page 288: Usb Charger
Features of your vehicle • Only use 12V electric accessories USB charger (if equipped) WARNING - Electric shock which are less than 10A in electric capacity. Do not put a finger or a foreign • Adjust the air-conditioner or heater element (pen, etc.) into a power to the lowest operating level when outlet and do not touch with a...
Page 289 Features of your vehicle ✽ ✽ NOTICE • Some devices are not supported AC inverter (if equipped) for fast charging but will be • Rated voltage : AC 115V charged with normal speed. • Maximum electric power : 150W • Use the USB charger when the •...
Page 290 Features of your vehicle • To prevent the battery from being dis- • While the power consumption of Wireless smart phone charg- charged, do not use the AC inverter some electrical devices/appliances ing system (if equipped) while the engine is not running. may be within the AC inverter’s electric power range, it may mal- •...
Page 291 Features of your vehicle For best wireless charging results, Wireless smart phone charging If the wireless charging is not func- place the smart phone on the center tioning properly, the orange light will 1. Remove any object on the smart of the charging pad.
Page 292 Features of your vehicle ✽ ✽ NOTICE CAUTION WARNING - - Liquid in Distracted • When the interior temperature of Wireless Smart Phone driving the wireless charging system rises Charger Driving while distracted can above a set temperature, the wire- To prevent liquid from damag- result in a loss of vehicle con- less charging will cease to func-...
Page 293 Features of your vehicle (Continued) (Continued) Clothes hanger (if equipped) • The wireless charging will stop • Smart phones of some manufac- when the vehicle is turned OFF. turers may display messages on • The wireless charging will stop weak current. This is due to the when the smart phone is not in particular characteristic of the complete contact with the wireless...
Page 294 WARNING - After market injury. interference with pedal operation, floor mat Kia recommends that only the Kia Do not install aftermarket floor floor mat designed for use in your mats that are not capable of vehicle be installed. being securely attached to the vehicle's floor mat anchors.
Page 295 If necessary, we recommend that the edges into the slots. you contact an authorized Kia dealer. CAUTION To prevent damage to the vehi- cle, care should be taken when carrying fragile or bulky objects in the luggage compartment.
Page 296 Features of your vehicle WARNING - Cargo Security Screen Do not place objects on the cargo security screen. Such objects may be thrown about inside the vehicle and possibly injure vehicle occupants during an accident or when braking. CAUTION Do not place luggage on the cargo security screen.
Page 297 (if equipped). load cargo on top of your vehicle. This can damage the sunroof. Crossbars and fixing components needed to install the roof rack on your vehicle may be obtained from an authorized Kia dealer or other qualified shop. 4 165...
Page 298 Features of your vehicle • The following specification is the • Always drive slowly and turn corners maximum weight that can be loaded carefully when carrying items on the onto the roof rack. Distribute the roof rack. Severe wind updrafts, load as evenly as possible across caused by passing vehicles or natu- the crossbars (if equipped) and roof...
Page 299: Audio System
Audio system Audio System ......5-2 • Antenna ........5-2 •...
Page 300 Audio system AUDIO SYSTEM (IF EQUIPPED) ✽ ✽ NOTICE Antenna Shark fin antenna (if equipped) The shark fin antenna will receive the If you install an after market HID ■ Type A transmit data. head lamp, your vehicle’s audio and electronic device may malfunction.
Page 301 Audio system AUX, USB port ODE046439L If your vehicle has an AUX and/or USB(universal serial bus) port, you can use the AUX port to connect audio devices and the USB port to ®. plug in a USB device or iPod ✽...
Page 302: Driving Your Vehicle
Driving your vehicle Before driving ......6-4 Autonomous Emergency Braking (AEB)..6-36 •...
Page 303 Blind Spot Detection system (BSD) ... 6-66 • Driving off-road......6-93 •...
Page 304 1. Close all windows. exhaust system checked as soon as 2. Open side vents. possible by an authorized Kia dealer. 3. Set the air intake control at “Fresh”, the air flow control WARNING - Engine at “Floor”...
Page 305 Driving your vehicle BEFORE DRIVING Before entering vehicle Necessary inspections Before starting • Be sure that all windows, outside Fluid levels, such as engine oil, • Close and lock all doors. mirror(s), and outside lights are engine coolant, brake fluid, and •...
Page 306 Driving your vehicle WARNING WARNING WARNING - Fire risk - Loose - Driving while objects intoxicated When you intend to park or stop the vehicle with the engine on, Securely store items in your Do not drive while intoxicated. be careful not to depress the vehicle.
Page 307 Driving your vehicle KEY POSITIONS (IF EQUIPPED) Illuminated ignition switch Ignition switch position (if equipped) The warning lights can be checked LOCK before the engine is started. This is the normal running position after the engine is started. Do not leave the ignition switch ON if the engine is not running to prevent battery discharge.
Page 308 Driving your vehicle Starting the hybrid system WARNING WARNING - Ignition switch - Leaving the Vehicle Never turn the ignition switch to WARNING - Proper LOCK or ACC while the vehicle To avoid unexpected or sudden footwear is moving. This would result in vehicle movement, never leave Always wear appropriate shoes loss of directional control and...
Page 309 Driving your vehicle ✽ ✽ NOTICE ✽ ✽ NOTICE 3. Turn the ignition switch to START. If the hybrid system starts, the • Do not wait for the engine to warm To prevent damage to the vehicle: “ ” indicator will come on. up while the vehicle remains sta- •...
Page 310 Driving your vehicle ENGINE START/STOP BUTTON Illuminated ENGINE ENGINE START/STOP button In an emergency situation while the vehicle is in motion, you are able to START/STOP button position turn the engine off and to the ACC position by pressing the ENGINE START/STOP button for more than 2 seconds or 3 times successively within 3 seconds.
Page 311: Engine Start/Stop Button
Driving your vehicle ACC(Accessory) START/RUN Amber Not illuminated Press the ENGINE START/STOP Press the ENGINE START/STOP To start the engine, depress the button while it is in the OFF position button while it is in the ACC position brake pedal and press the ENGINE without depressing the brake pedal.
Page 312 Driving your vehicle ✽ ✽ NOTICE ✽ ✽ NOTICE Starting the hybrid system If you leave the ENGINE START/ • The hybrid system will start by STOP button in the ACC or ON WARNING pressing the Engine Start/Stop position for a long time, the battery button, only when the smart key is •...
Page 313 Driving your vehicle ✽ ✽ NOTICE ✽ ✽ NOTICE 1. Always carry the smart key with you. • Do not wait for the engine to warm To prevent damage to the vehicle: 2. Make sure the parking brake is up while the vehicle remains sta- •...
Page 314 Driving your vehicle • When the stop lamp fuse is blown, WARNING - Unintended you can't start the engine normally. vehicle movement Replace the fuse with a new one. If it is not possible, you can start the Never leave the smart key in the engine by pressing the ENGINE vehicle with children or vehicle START/STOP button for 10 sec-...
Page 315 Driving your vehicle DUAL CLUTCH TRANSMISSION (DCT) Dual clutch transmission oper- ation The dual clutch transmission has six forward speeds and one reverse speed. The individual speeds are selected automatically in the D (Drive) posi- tion. Depress the brake pedal and press the shift button while moving the shift lever. Press the shift button while moving the shift lever.
Page 316 Driving your vehicle • The dual Clutch Transmission • When rapidly accelerating at low WARNING gives the driving feel of a manual vehicle speed, engine could rev at transmission, yet provides the high rpm depending on vehicle To reduce the risk of serious ease of a fully automatic transmis- drive condition.
Page 317 Kia dealer. transmission. This is a normal accelerator pedal on a hill the characteristic of this type of dual •...
Page 318 Driving your vehicle The indicator in the instrument clus- R (Reverse) WARNING ter displays the shift lever position Use this position to drive the vehicle when the ignition switch is in the ON backward. • Shifting into P (Park) while the position.
Page 319 Driving your vehicle N (Neutral) - Parking in N (Neutral) gear WARNING - Parking In The wheels and transmission are not Follow below steps when parking Neutral engaged. and you want the vehicle to move when pushed. • With the exception of parking in neutral gear, always park 1.After parking your vehicle, step on WARNING...
Page 320 Driving your vehicle ✽ ✽ NOTICE D (Drive) This is the normal driving position. • Only the six forward gears can be The transmission will automatically selected. To reverse or park the shift through a six-gear sequence, vehicle, move the shift lever to the providing the best fuel economy and R (Reverse) or P (Park) position as power.
Page 321 Driving your vehicle SPORT Mode / ECO Mode Shift lock system When you drive after changing the For your safety, the dual clutch trans- gear shift lever to manual mode, the mission has a shift lock system which vehicle will automatically shift to prevents shifting the transaxle from P SPORT mode.
Page 322 • Exercise extreme caution when depressed. 7. We recommend that the system driving on a slippery surface. Be be inspected by an authorized Kia • Never move the shift lever into P especially careful when braking, dealer. (Park) when the vehicle is in motion.
Page 323 Driving your vehicle WARNING If your vehicle becomes stuck in snow, mud, sand, etc., then you may attempt to rock the vehicle free by moving it forward and backward. Do not attempt this procedure if people or objects are anywhere near the vehicle. During the rocking operation the vehicle may suddenly move for- ward of backward as it becomes...
Page 324 Driving your vehicle BRAKE SYSTEM Power brakes CAUTION - Brake Pedal WARNING - HEV driving Your vehicle has power-assisted down hill Do not drive with your foot rest- brakes that adjust automatically ing on the brake pedal. This will Do not turn off the Hybrid sys- through normal usage.
Page 325: Brake Pedal
Driving your vehicle Wet brakes may impair the vehicle’s In the event of brake failure Disc brakes wear indicator ability to safely slow down; the vehi- If service brakes fail to operate while When your brake pads are worn and cle may also pull to one side when the vehicle is in motion, you can new pads are required, you will hear...
Page 326 Driving your vehicle Parking brake – Foot type Releasing the parking brake WARNING - Brake wear (if equipped) Do not ignore high pitched wear Applying the parking brake sounds from your brakes. If you ignore this audible warning, you will eventually lose braking per- formance, which could lead to a serious accident.
Page 327 Driving your vehicle If at all possible, cease driving the WARNING - Parking brake vehicle immediately. If that is not pos- sible, use extreme caution while operating the vehicle and only contin- • Never allow a passenger to ue to drive the vehicle until you can touch the parking brake.
Page 328 Driving your vehicle Anti-lock brake system (ABS) The ABS continuously senses the • Even with the anti-lock brake sys- speed of the wheels. If the wheels tem, your vehicle still requires suf- ABS (or ESC) will not prevent acci- are going to lock, the ABS system ficient stopping distance.
Page 329 During that time, the ABS will go through self-diagnosis and the light will go off if everything is normal. If the light stays on, you may have a problem with your ABS. Contact an authorized Kia dealer as soon as possible.
Page 330 Driving your vehicle Electronic stability control Electronic stability control (ESC) will The Electronic Stability Control (ESC) not prevent accidents. Excessive system is an electronic system (ESC) speed in turns, abrupt maneuvers designed to help the driver maintain and hydroplaning on wet surfaces vehicle control under adverse condi- can still result in serious accidents.
Page 331: Esc Off Button
Driving your vehicle ESC operation When operating ESC operation off When the ESC is in opera- ESC ON condition ESC OFF state tion, the ESC indicator light • When the engine start/stop This car has 2 kinds of ESC blinks. button is turned ON, ESC off states.
Page 332 Driving your vehicle “Traction Control disabled” Indicator light WARNING - Electronic sta- • ESC off state 1 bility control ■ ESC indicator light To cancel ESC operation, press the Drive carefully even though your ESC OFF button (ESC OFF ) short- vehicle has Electronic Stability ly (ESC OFF indicator light (ESC OFF Control.
Page 333 Driving your vehicle ✽ ✽ NOTICE ESC OFF usage Vehicle stability management (VSM) When driving • When operating the vehicle on a dynamometer, ensure that the • ESC should be turned on for daily This system provides further ESC is turned off (ESC OFF light driving whenever possible.
Page 334 ) or EPS warning light This is only the effect of brake and remains on, take your vehicle to an EPS control and indicates nothing authorized Kia dealer and have the unusual. system checked. The VSM does not operate when: ✽...
Page 335 No system, no to apply brakes while stopped on ized Kia dealer for assistance. matter how advanced, can compen- an incline. While stopped, make sate for all driver error and/or driv- •...
Page 336 Driving your vehicle • Don't "ride" the brake pedal. If your vehicle is facing uphill, turn Resting your foot on the brake the front wheels away from the pedal while driving can be danger- curb to help keep the vehicle from ous because the brakes might rolling.
Page 337 Driving your vehicle AUTONOMOUS EMERGENCY BRAKING (AEB) (IF EQUIPPED) ✽ ✽ NOTICE The AEB system is to reduce or to System setting and activation avoid accident risk. It recognizes the Take the following precautions when System setting distance from the vehicle ahead or using the Autonomous Emergency The driver can activate the AEB by the pedestrian through the sensors...
Page 338 Kia dealer. the initial warning occurs. occurs. The driver can use it The driver feels it is too when the traffic is not busy...
Page 339 Driving your vehicle Prerequisite for activation • The AEB automatically activates WARNING when you turn the vehicle on. The AEB will activate activated when the AEB is selected on the LCD dis- To avoid driver distractions, do The driver can deactivate the AEB play, and when the following prereq- not attempt to set or cancel the by canceling the in the system set-...
Page 340 Driving your vehicle AEB warning message and Forward Warning (1st warning) Collision Warning (2nd warning) system control The AEB produces warning mes- sages, warning alarms, and emer- gency braking based on the level of risk of a frontal collision, such as when a vehicle ahead suddenly brakes, when there is no following dis- tance from the vehicle in front, or...
Page 341 Driving your vehicle Emergency braking (3 warning) Brake operation WARNING • In an urgent situation, the braking The AEB cannot avoid all colli- system enters into the ready status sions. The AEB might not com- for prompt reaction against the dri- pletely stop the vehicle before ver’s depressing the brake pedal.
Page 342 Kia dealer. sensing performance. It may even • Use only the genuine Kia sensor temporarily cancel the AEB. Always This is not a malfunction with the cover. Do not arbitrarily apply keep the sensor lens clean.
Page 343 Due to the sensing lim- minate. In this case, have your vehi- tem may not be activated. itation, the AEB may not produce cle inspected by an authorized Kia warning messages or warning dealer. alarm at all. • When there is a malfunction with...
Page 344 Driving your vehicle Limitation of the system Recognizing vehicles - The outside brightness is greatly changed, such as entering/exiting - The radar or the camera is contam- The AEB is an assistant system for a the tunnel. inated with foreign substances. driver in a certain risky driving condi- - The vehicle driving is unstable.
Page 345 Driving your vehicle OQL055053 OQL055054 ODE056060 - Driving on a curve While driving on a curve, the AEB - Driving on a slope may recognize the vehicle in front in The AEB performance decreases The AEB performance decreases the next lane. Exercise caution, and, if while driving on a curve.
Page 346 Driving your vehicle OQL055056 OQL055057 ODE056061 - Changing lanes When the stopped vehicle in front - Recognizing the vehicle gets out of the lane, it may not be Even though the vehicle in the next When the vehicle in front has heavy recognized by your AEB.
Page 347 Driving your vehicle Recognizing pedestrians • Pay great caution to the vehicle in WARNING - Testing the front, when it has heavy loading - The pedestrian is not fully captured extended rearward, or when it has by the camera sensor, or the higher ground clearance.
Page 348 Driving your vehicle CRUISE CONTROL SYSTEM ✽ ✽ NOTICE Use the cruise control system only when traveling on open highways in • During normal cruise control oper- good weather. ation, when the SET switch is acti- Do not use the cruise control when vated or reactivated after applying driving in heavy or varying traffic, or the brakes, the cruise control will...
Page 349: Cruise Control
Driving your vehicle To set cruise control speed: To increase cruise control set speed: OJF055039 3. Move the lever down (to SET-), OJF055038 and release it at the desired OJF055040 1. Press the CRUISE button on the speed. The SET indicator light in steering wheel to turn the system Follow either of these procedures: the instrument cluster will illumi-...
Page 350 Driving your vehicle To decrease the cruising To temporarily accelerate with To cancel cruise control, do speed: the cruise control on: one of the following: If you want to speed up temporarily when the cruise control is on, depress the accelerator pedal. Increased speed will not interfere with the cruise control operation or change the set speed.
Page 351 Driving your vehicle Each of these actions will cancel To resume cruising speed at To turn cruise control off, do cruise control operation (the SET more than approximately one of the following: indicator light in the instrument clus- 30 km/h (20 mph): ter will go off), but it will not turn the system off.
Page 352 Driving your vehicle SMART CRUISE CONTROL SYSTEM (SCC) (IF EQUIPPED) • Use the SCC only when traveling WARNING on open highways in good weather. • Limited visibility (rain, snow, smog, Smart Cruise Control etc) System (SCC) is deactivated when driving under the speed •...
Page 353: Smart Cruise Control
Driving your vehicle Speed setting (SCC) (Continued) WARNING To set cruise control speed: • The smart cruise control sys- - Smart Cruise Control cannot recognize Limitations stopped vehicle, pedestrians • The smart cruise control is a oncoming vehicle. supplemental system and is Always look ahead cautiously not a substitute for safe driv- to prevent unexpected and...
Page 354 Driving your vehicle To increase cruise control set • SCC will operate to a maximum speed: setting of 180 km/h (110 mph). However all local speed limit laws must be followed. ODE056040CN 3. Move the lever down (to SET-), and release it at the desired ODE056041CN speed.
Page 355 Driving your vehicle To decrease the cruise control To temporarily accelerate with the SCC will be temporarily canceled set speed: cruise control on: when: If you want to speed up temporarily when the cruise control is on, depress the accelerator pedal. Increased speed will not interfere with cruise control operation or change the set speed.
Page 356 3 sec- not mentioned, have the system onds after the vehicle is stopped by checked by an authorized Kia dealer. the Smart Cruise Control System with no other vehicle ahead or a vehicle stopped far away in front.
Page 357 Driving your vehicle To resume cruise control set To turn cruise control off: WARNING - Following speed: Distance • To avoid collisions, always be aware of the selected speed and vehicle to vehicle dis- tance settings when activat- ing your smart cruise control system.
Page 358 Driving your vehicle Vehicle to vehicle distance The vehicle to vehicle distance will For example, if you drive at 90 km/h automatically activate when the SCC (56 mph), the distance is maintained setting (SCC) is on. as follows; To set vehicle to vehicle distance: Select the appropriate distance according to road conditions and Distance 4 - approximately 52.5 m...
Page 359 Driving your vehicle • The vehicle will maintain the set speed, when the lane ahead is clear. • The vehicle will slow down or speed up within selected speed to maintain the selected distance, when there is a vehicle ahead of you in the lane.
Page 360 Take your vehicle to an authorized Always keep the sensor clean. Kia dealer and have the system checked. 6 59...
Page 361 To convert to cruise control bumper clean. Smart Cruise Control mode: • Use only a genuine Kia sensor The sensitivity of vehicle speed when The driver may choose to only use cover for your vehicle. following the front vehicle to maintain the cruise control mode (speed con- •...
Page 362 Driving your vehicle Limitations of the system On curves • On curves, the SCC may not detect a moving vehicle in your lane, and then your vehicle could accelerate to the set speed. Also, the vehicle speed will rapidly slow down when the vehicle ahead is recognized suddenly.
Page 363 Driving your vehicle On inclines Lane changing OJF055049 • Your vehicle may accelerate when ODE056060 OJF055028 a vehicle ahead of you disappears. • During uphill or downhill driving, the • A vehicle which moves into your • When you are warned that the SCC may not detect a moving vehi- lane from an adjacent lane cannot vehicle ahead of you is not detect-...
Page 364 Driving your vehicle Vehicle recognition A vehicle ahead cannot be recog- nized correctly by the sensor if any of following occurs: - When the vehicle is pointing upwards due to overloading in the liftgate - While making turns by steering - When driving to one side of the lane - When driving on narrow lanes or on curves...
Page 365 Driving your vehicle WARNING - Safe Use of The SCC can provide you with an additional level of safety and fatigue reduction. However you must maintain careful observa- tion of the roadway in front and around you and maintain control of your vehicle and spacing around other vehicles as you normally would.
Page 366 Driving your vehicle - After an engine start, please stop This device complies with for several seconds. If system ini- Industry Canada licence-exempt tialization is not completed, the RSS standard(s). SCC does not normally operate. Operation is subject to the following - After an engine start, if any objects conditions: are not detected or the sensor...
Page 367 Driving your vehicle BLIND SPOT DETECTION SYSTEM (BSD) (IF EQUIPPED) (1) BSD (Blind Spot Detection) WARNING - BSD The warning range depends on Limitations your vehicle speed. However, if your vehicle is about 10 km/h (6 • The Blind Spot Detection mph) faster than the other vehi- System (BSD) is a supplemen- cle, the system will not warn you.
Page 368 Driving your vehicle BSD (Blind Spot Detection) / When the system is not used turn the Warning type system off by turning off the switch. LCA (Lane Change Assist) The system will activate when: When the system is turned on the 1.
Page 369 Driving your vehicle - The second stage alarm may be 1st stage 2nd stage deactivated. • To activate the alarm: Go to the User Settings Mode → Sound and select “BSD” on the LCD display. • To deactivate the alarm: Go to the User Settings Mode →...
Page 370 “Blind Spot Detection disabled tem- removed, take your vehicle to an porarily” authorized Kia dealer and have the The message will appear to notify system checked. the driver with one of followings. The If the system does not work properly, light on the switch and the system a warning message (“Check BSD...
Page 371 Driving your vehicle RCTA (Rear Cross Traffic Alert) Operating conditions • The RCTA (Rear Cross Traffic Alert) detecting range is 0.5 m (1.6 • Go to the User Settings Mode ➝ feet) ~ 20 m(65 feet ) based on the ➝...
Page 372 Driving your vehicle Warning type • If the vehicle detected by sensors WARNING approaches your vehicle, the warn- ing chime will sound and the warn- Blind Spot Detection ing light will blink on the outside System with Lane Change rearview mirror. Assist and Rear Cross Traffic •...
Page 373 Driving your vehicle Limitations condition - A fixed object is near such as a - When the temperature of the rear guardrail, etc. bumper is very high or low. Driver's Attention - A substantial amount of metallic - When bike racks, etc. cover the The driver must be cautious in the objects such as a construction sensor.
Page 374 Driving your vehicle Outside rearview mirror may not This device complies with alert the driver when: Industry Canada licence-exempt RSS standard(s). - The outside rearview mirror hous- Operation is subject to the following ing is very dirty. two conditions: - The window is very dirty. 1.
Page 375 Driving your vehicle LANE KEEPING ASSIST SYSTEM (LKAS) (IF EQUIPPED) ✽ ✽ NOTICE WARNING - LKAS • Driver is responsible for being Limitations aware of surroundings and steer- The LKAS is a supplemental ing the vehicle for safe driving system and should not be sole- practices.
Page 376 • You may not hear warning sound of authorized Kia dealer and have the LKAS because of the excessive system checked to need a calibra- audio sound.
Page 377 Driving your vehicle The color of indicator will change LKAS activation WARNING depend on the condition of LKAS. - White : Sensor does not detect the Lane Keeping Assist lane marker or vehicle System is a system to help pre- speed is less than 64 km/h vent the driver from leaving the (40 mph).
Page 378 Driving your vehicle When the conditions below are met, Warning ■ Lane undetected ■ Lane detected LKAS will be enable to assist steer- ■ ■ Left lane Right lane ing. • Vehicle speed is above 64 km/h (40 mph). • Both lane markers are detected by LKAS.
Page 379 Take your vehicle to an However, if the driver has their hands authorized Kia dealer and have the on the steering wheel again, the sys- system checked. tem will start controlling the steering...
Page 380 Driving your vehicle The system will be cancelled when: • The steering will not be assisted WARNING when you brake suddenly. • You change lanes with the turn sig- nal. • The driver is responsible for • The steering will not be assisted accurate steering.
Page 381 Driving your vehicle DRIVER’S ATTENTION - The lane marker is very thick or When external condition is inter- thin. vened The driver must be cautious in the - The lane marker is not visible - The brightness outside below situations may not work due to snow, rain, stain, a puddle changes suddenly when enter- properly when recognition of the...
Page 382 Driving your vehicle LKAS Function Change Active LKA When front visibility is poor The active LKA mode provides more - The lens or windshield is cov- The driver can change LKA to Lane frequent steering wheel control in ered by strange materials. Departure Warning System (LDWS) comparison with the Standard LKA or change the LKAS mode between...
Page 383 Driving your vehicle DRIVER ATTENTION ALERT SYSTEM (DAA) (IF EQUIPPED) The Driver Attention Alert (DAA) sys- System setting and activation • The Driver can select mode of the tem displays the condition of the dri- Driver Attention Alert System. System setting ver's fatigue level and inattention.
Page 384 Driving your vehicle Drivers’ Attention level • The driver can monitor their driving Take a break conditions on the LCD display. ■ System off The DAA screen will appear when you select the Assist mode tab ) on the LCD display if the system is activated.
Page 385 In this restarts driving. situations. case, have the vehicle inspected by an authorized Kia dealer. - The camera sensor keeps failing to detect the lanes. - Driving speed remains under 64 km/h (40 mph) or over 177 km/h...
Page 386 Kia • The driver, who feels fatigued, dealer and have the system should take a break, even checked to need a calibration.
Page 387 Driving your vehicle ✽ ✽ NOTICE The Driver Attention Alert system may not properly operate with limit- ed alerting in the following situa- tions: • Not properly recognize lane (For more information, refer to “Lane Keeping Assist System (LKAS)” in this chapter.) •...
Page 388 Driving your vehicle ECONOMICAL OPERATION Your vehicle's fuel economy depends • Don't "ride" the brake pedal. This • Keep your vehicle in good condi- mainly on your style of driving, where can increase fuel consumption and tion. For better fuel economy and you drive and when you drive.
Page 389 Driving your vehicle • Remember, your vehicle does not • Use your air conditioning sparingly. WARNING - Engine off require extended warm-up. After The air conditioning system is the engine has started, allow the operated by engine power so your during motion engine to run for 10 to 20 seconds fuel economy is reduced when you...
Page 390 Driving your vehicle SPECIAL DRIVING CONDITIONS Hazardous driving conditions • If stalled in snow, mud, or sand, Reducing the risk of a rollover use the second gear. Accelerate When hazardous driving conditions This multi-purpose passenger vehi- slowly to avoid spinning the drive are encountered such as water, cle is defined as a Sports Utility wheels.
Page 391 • A SUV is not designed for cor- by Kia for off road driving, you nering at the same speeds as should not use these tires for conventional vehicles.
Page 392 Driving your vehicle Rocking the vehicle Smooth cornering CAUTION - Vehicle rocking If it is necessary to rock the vehicle Avoid braking or gear changing in Prolonged rocking may cause to free it from snow, sand, or mud, corners, especially when roads are engine overheating, transaxle first turn the steering wheel right and wet.
Page 393 Driving your vehicle Driving at night Driving in the rain • A heavy rainfall will make it harder to see and will increase the dis- Because night driving presents more Rain and wet roads can make driving tance needed to stop your vehicle, hazards than driving in the daylight, dangerous, especially if you’re not so slow down.
Page 394 Driving your vehicle Driving in flooded areas Highway driving WARNING - Tire tread Avoid driving through flooded areas Tires Always check the tire tread unless you are sure the water is no Adjust the tire inflation pressures to before driving your vehicle. higher than the bottom of the wheel specification.
Page 395 Driving your vehicle WINTER DRIVING Severe weather conditions in the Snowy or icy conditions Snow tires winter result in greater wear and If you mount snow tires on your vehi- To drive your vehicle in deep snow, it other problems. To minimize the cle, make sure they are radial tires of may be necessary to use snow tires problems of winter driving, you...
Page 396 Window wash- damaged in any way. er anti-freeze is available from an Winter puts additional burdens on authorized Kia dealer and most auto the battery system. Visually inspect parts outlets. Do not use engine the battery and cables as described coolant or other types of anti-freeze in chapter 8.
Page 397 Driving your vehicle Don’t let your parking brake Carry emergency equipment freeze Depending on the severity of the weather, you should carry appropri- Under some conditions your parking ate emergency equipment. Some of brake can freeze in the engaged the items you may want to carry position.
Page 398 Driving your vehicle VEHICLE LOAD LIMIT Tire and loading information label Vehicle capacity weight: 385 kg (849 lbs.) Vehicle capacity weight is the maxi- mum combined weight of occupants and cargo. If your vehicle is equipped with a trailer, the combined weight includes the tongue load.
Page 399 Driving your vehicle Towing capacity: Steps For Determining Correct 5. Determine the combined weight of Load Limit - luggage and cargo being loaded We do not recommend using this on the vehicle. That weight may vehicle for trailer towing. 1. Locate the statement "The com- not safely exceed the available bined weight of occupants and cargo and luggage load capacity...
Page 400 Driving your vehicle Example 1 Example 2 Example 3 C190F01JM C190F02JM C190F03JM Item Description Total Item Description Total Item Description Total Vehicle Capacity 385 kg Vehicle Capacity 385 kg Vehicle Capacity 385 kg Weight (849 lbs) Weight (849 lbs) Weight (849 lbs) Subtract Occupant Subtract Occupant...
Page 401 Driving your vehicle ✽ ✽ NOTICE Certification label The label will help you decide how much cargo and installed equipment The certification label is located on Overloading your vehicle may cause your vehicle can carry. the driver's door sill at the center pillar. damage.
Page 402 Driving your vehicle VEHICLE WEIGHT This chapter will guide you in the Base curb weight GAWR proper loading of your vehicle and/or (Gross axle weight rating) This is the weight of the vehicle trailer, to keep your loaded vehicle including a full tank of fuel and all This is the maximum allowable weight within its design rating capa- standard equipment.
Page 403: What To Do In An Emergency
What to do in an emergency Road warning ......7-2 If you have a flat tire (with Tire Mobility Kit) . . 7-18 •...
Page 404 What to do in an emergency ROAD WARNING Hazard warning flasher Depress the flasher switch with the ignition switch in any position. The flasher switch is located in the center facia panel. All turn signal lights will flash simultaneously. • The hazard warning flasher oper- ates whether your vehicle is run- ning or not.
Page 405 If you have a flat tire while again. If your vehicle will not start, 4. When changing a flat tire, follow driving contact an authorized Kia dealer the instruction provided later in or seek other qualified assistance. this section. If a tire goes flat while you are driv- ing: ✽...
Page 406 4. If the engine still does not start, 4. Check the starter connections to call an authorized Kia dealer or be sure they are securely tight- seek other qualified assistance. ened. 5. Do not push or pull the vehicle to start it.
Page 407 What to do in an emergency EMERGENCY STARTING Before Jump Starting • To charge 12V battery, keep driving Once the 12V battery is fully dis- or idling the car more than 30 min- charged and reconnected, the 12V (For Hybrid) utes.
Page 408 What to do in an emergency Charging method for 12V battery External power source using 12V CAUTION battery (A) It is recommended to charge the • The use of an improper charg- (Except the use of dash cameras) 12V battery by starting and run- er with a voltage and current ning the vehicle (HEV Ready The use of external power acces-...
Page 409: Maintenance
What to do in an emergency Method to disconnect the (-) When the vehicle is under regular Jump starting maintenance, make sure to separate cable for regular maintenance the (-) cable inside the luggage room (For Hybrid) before maintenance. Procedures to separate the (-) cable is as below : •...
Page 410 What to do in an emergency CAUTION - Push/pull start WARNING WARNING - Electrolyte - Battery to 12 Volt Battery cables • Do not charge or discharge Use only a 12-volt jumper sys- arbitrarily. It may lead to fault, Do not connect the jumper cable tem.
Page 411 When the engine starts, the your vehicle checked by an author- jumper cable to the positive termi- vehicle can suddenly surge for- ized Kia dealer. nal of the discharged battery (1), ward and could cause a colli- then connect the other end to the sion with the tow vehicle.
Page 412 If this happens, you should: the engine immediately. Then, call check connecting parts the nearest authorized Kia dealer between the radiator hose, heater for assistance. If the “Engine hose, and water pump for any 1. Turn on the emergency warning Warning”...
Page 413 This possible by an authorized Kia dealer. can allow coolant to blow out of the open- CAUTION ing and cause seri- ous burns.
Page 414 What to do in an emergency TIRE PRESSURE MONITORING SYSTEM (TPMS) ✽ ✽ NOTICE Check tire pressure • You can check the tire pressure in • The tire pressure may change due the information mode on the clus- to factors such as parking condi- ter.
Page 415 What to do in an emergency Each tire, including the spare (if pro- Please note that the TPMS is not a Always check the TPMS malfunction vided), should be checked monthly substitute for proper tire maintenance, telltale after replacing one or more when cold and inflated to the inflation and it is the driver’s responsibility to tires or wheels on your vehicle to...
Page 416 3 seconds, take your vehicle Then the TPMS malfunction indicator to your nearest authorized Kia deal- and the Low Tire Pressure telltale er and have the system checked. may turn on and illuminate after...
Page 417 Tire tire pressure position telltales may Pressure Monitoring System illuminate together with the TPMS (TPMS). malfunction indicator. Have the system checked by an authorized Kia dealer as soon as possible to determine the cause of the problem. 7 15...
Page 418 Kia dealer as soon as possible or deactivated. If the TPMS sensor on After you replace the low pressure replace the flat tire with the spare...
Page 419 What to do in an emergency You may not be able to identify a low • The TPMS cannot alert you to This device complies with tire by simply looking at it. Always severe and sudden tire damage Industry Canada licence-exempt use a good quality tire pressure caused by external factors such as RSS standard(s).
Page 420 ■ for 18 inch tire inspected by an authorized Kia deal- er as soon as possible. When two or more tires are flat, do not use the tire mobility kit because...
Page 421 What to do in an emergency With the Tire Mobility Kit you stay This instruction shows you step by Notes on the safe use of the mobile even after experiencing a tire step procedure to temporarily seal Tire Mobility Kit puncture.
Page 422 6 mm (0.24 in). When repairing a flat tire with wash it with a large amount of the Tire Mobility Kit (TMK), Please contact the nearest Kia water. If skin irritation continues, quickly remove the sealant on dealership if the tire cannot be visit a doctor for examination.
Page 423 What to do in an emergency Components of the Tire Mobility Kit ■ ■ for 18 inch tire for 16 inch tire ODE067044 ODE066039L 1. Speed restriction label 7. On/off switch 2. Sealant bottle and label with speed restriction 8. Pressure gauge for displaying the tire inflation pres- sure 3.
Page 424 What to do in an emergency Using the Tire Mobility Kit WARNING Before using the Tire Mobility Kit, follow the instructions on the sealant bottle. Remove the label with the speed restriction from sealant bottle and apply it to the steering wheel.
Page 425 What to do in an emergency ■ for 18 inch tire OKIA067011 ■ for 16 inch tire ODE066007 ODE066041N ✽ ✽ NOTICE 4. Unscrew the valve cap from the valve of the defective wheel and If the sealant is injected when the screw filling hose (3) of the sealant tire air pressure injection valve and bottle onto the valve.
Page 426 What to do in an emergency Distributing the sealant WARNING - Tire pressure Do not attempt to drive your vehicle if the tire pressure is below 200 kPa (29 psi). This could result in an accident due to sudden tire failure. 9.
Page 427 2. Connect the filling hose (3) of the your vehicle inspected by an author- compressor (clip mounted side) ized Kia dealer. directly and then connect the fill ing hose (3) (opposite side) to the tire valve.
Page 428 - Tire pressure sensor When you use the Tire Mobility including sealant approved by Kia, the tire pres- sure sensors may be damaged by sealant. The sealant on the tire pressure sensor and wheel should be removed when you replace the tire with a new one and inspect the tire pressure sensors at an authorized dealer.
Page 429 What to do in an emergency Technical Data 18 inch tire 16 inch tire System Voltage DC 12 V DC 12 V Working Voltage DC 10 – 15 V DC 10 – 15 V MAX. 15 ± 1 A MAX. 10 ± 1 A Amperage rating (at DC 12V operation) (at DC 12V operation)
Page 430 ODE066010L If emergency towing is necessary, we recommend having it done by an authorized Kia dealer or a commer- cial tow-truck service. Proper lifting and towing procedures are neces- sary to prevent damage to the vehi- cle. The use of wheel dollies (1) or...
Page 431 What to do in an emergency When towing your vehicle in an Removable towing hook emergency without wheel dollies : (if equipped) 1. Set the ignition switch in the ACC ■ Front position. 2. Place the transaxle shift lever in N (Neutral).
Page 432 • Avoid towing a vehicle heavier than the vehicle doing the towing. ODE066017 • The drivers of both vehicles should If towing is necessary, have it communicate with each other fre- done by an authorized Kia dealer quently. or a commercial tow truck service.
Page 433 • Fasten the towing cable or chain easy visibility. We recommend that you con- securely to the hook. tact an authorized Kia dealer • Drive carefully so that the towing or a commercial tow truck strap is not loosened during tow- •...
Page 434 What to do in an emergency Emergency towing precautions • If the car is being towed with all four wheels on the ground, it can • Turn the ignition switch to ACC so be towed only from the front. Be the steering wheel isn’t locked.
Page 435 Upon witness- ing one of those, open the windows, and remain a safe distance from the vehicle out of the road. Immediately contact an authorized Kia dealer and advise them that a hybrid vehi- cle is involved. 7 33...
Page 436 Maintenance Engine compartment ......8-3 Washer fluid ......8-40 •...
Page 437 • Tire maintenance......8-57 • Back-up lamp bulb replacement ....8-104 •...
Page 438: Engine Coolant Reservoir
Maintenance ENGINE COMPARTMENT ■ ■ Hybrid (Kappa 1.6 GDI) 1. Engine coolant reservoir 2. Engine oil filler cap 3. Engine oil dipstick 4. Brake fluid reservoir 5. Inverter coolant reservoir 6. Fuse box 7. Engine clutch actuator reservoir tank 8. Air cleaner 9.
Page 439: Brake Fluid Reservoir
Maintenance ■ ■ Plug-in Hybrid (Kappa 1.6 GDI) 1. Engine coolant reservoir 2. Engine oil filler cap 3. Engine oil dipstick 4. Brake fluid reservoir 5. Inverter coolant reservoir 6. Fuse box 7. Engine clutch actuator reservoir tank 8. Air cleaner 9.
Page 440 Kia dealer perform this work. nical support from Kia in order to pro- dance with the scheduled mainte- vide you with a high level of service An authorized Kia dealer has factory- nance service charts shown on the satisfaction.
Page 441 As explained earlier in this section, become entangled in moving several procedures can be done only parts, if you must run the by an authorized Kia dealer with spe- engine while working under the cial tools. hood, make certain that you remove all jewelry (especially ✽...
Page 442 • Check the engine oil level. ized Kia dealer at the frequencies exhaust fumes in the vehicle. indicated to help ensure safe, • Check the coolant level in coolant •...
Page 443 Maintenance At least monthly: At least twice a year At least once a year : (i.e., every Spring and Fall) : • Check the coolant level in the • Clean the body and door drain engine coolant reservoir. holes. • Check the radiator, heater and air conditioning hoses for leaks or •...
Page 444 Maintenance SCHEDULED MAINTENANCE SERVICE Follow the Normal Maintenance • Driving on uphill, downhill, or If your vehicle is operated under the Schedule if the vehicle is usually mountain roads repeatedly. above conditions, should operated where none of the following inspect, replace or refill more fre- •...
Page 445: Normal Maintenance Schedule
If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ommended. Additives are available from your authorized Kia dealer along with information on how to use them. Do not mix other additives. ❈ Inspect : Inspect and if necessary, adjust, correct, clean or replace.
Page 446 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ❑ Inspect steering gear box, linkage & boots/lower arm ball joint, ommended. Additives are available from your authorized Kia dealer along with information on how to use them. Do not mix other additives.
Page 447 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ommended. Additives are available from your authorized Kia dealer along with information on how to use them. Do not mix other additives. ❈ Inspect : Inspect and if necessary, adjust, correct, clean or replace.
Page 448 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ommended. Additives are available from your authorized Kia dealer along with information on how to use them. Do not mix other additives. ❈ Inspect : Inspect and if necessary, adjust, correct, clean or replace.
Page 449 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- (Every 24,000 km (15,000 mile) or 12months) ommended. Additives are available from your authorized Kia dealer along with ❑ Replace climate control air filter (for evaporator and blower unit) information on how to use them.
Page 450 ❑ Inspect suspension mounting bolts If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ommended. Additives are available from your authorized Kia dealer along with ❑ Inspect brake fluid information on how to use them. Do not mix other additives.
Page 451 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ommended. Additives are available from your authorized Kia dealer along with information on how to use them. Do not mix other additives. ❈ Inspect : Inspect and if necessary, adjust, correct, clean or replace.
Page 452 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- (Every 24,000 km (15,000 mile) or 12months) ommended. Additives are available from your authorized Kia dealer along with ❑ Inspect dual clutch transmission fluid information on how to use them. Do not mix other additives.
Page 453 ❑ Inspect fuel tank air filter (if equipped) * If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ommended. Additives are available from your authorized Kia dealer along with ❑ Inspect parking brake information on how to use them. Do not mix other additives.
Page 454 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ommended. Additives are available from your authorized Kia dealer along with information on how to use them. Do not mix other additives. ❈ Inspect : Inspect and if necessary, adjust, correct, clean or replace.
Page 455 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ❑ Replace engine oil and filter ommended. Additives are available from your authorized Kia dealer along with (168,000 km (105,000 miles) or 168 months) information on how to use them. Do not mix other additives.
Page 456 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ❑ Inspect parking brake ommended. Additives are available from your authorized Kia dealer along with ❑ Inspect vapor hose and fuel filler cap information on how to use them. Do not mix other additives.
Page 457 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ommended. Additives are available from your authorized Kia dealer along with information on how to use them. Do not mix other additives. ❈ Inspect : Inspect and if necessary, adjust, correct, clean or replace.
Page 458 (Every 24,000 km (15,000 mile) or 12months) If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ommended. Additives are available from your authorized Kia dealer along with ❑ Replace climate control air filter (for evaporator and blower unit) information on how to use them.
Page 459 If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec- ❑ Inspect vapor hose and fuel filler cap ommended. Additives are available from your authorized Kia dealer along with information on how to use them. Do not mix other additives.
Page 460: Maintenance Under Severe Usage Conditions
Maintenance Maintenance Under Severe Usage Conditions The following items must be serviced more frequently on cars normally used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary MAINTENANCE MAINTENANCE ITEM MAINTENANCE INTERVALS...
Page 461 Fuel filter (for gasoline) Fuel lines, fuel hoses and con- nections The engine oil and filter should be Kia gasoline vehicle is equipped a changed at the intervals specified in lifetime fuel filter that integrated with Check the fuel lines, fuel hoses and the maintenance schedule.
Page 462 Vacuum crankcase ventilation Air cleaner filter Coolant (Engine / Inverter) hoses A Genuine Kia air cleaner filter is The coolant should be changed at recommended when the filter is the intervals specified in the mainte- Inspect the surface of hoses for evi- replaced.
Page 463 Maintenance Brake fluid Exhaust pipe and muffler Steering gear box, linkage & boots/lower arm ball joint Check the brake fluid level in the Visually inspect the exhaust pipes, brake fluid reservoir. The level should muffler and hangers for cracks, dete- With the vehicle stopped and engine be between “MIN”...
Page 464 Maintenance CHECKING FLUID LEVELS When checking engine oil, engine coolant, brake fluid, and washer fluid, always be sure to clean the area around any filler plug, drain plug, or dipstick before checking or draining any lubricant or fluid. This is espe- cially important in dusty or sandy areas and when the vehicle is used on unpaved roads.
Page 465 Maintenance ENGINE OIL Checking the engine oil level ■ Gasoline Engine (Kappa 1.6L-GDI) WARNING - Radiator hose ■ Gasoline Engine (Kappa 1.6L-GDI) Be very careful not to touch the radiator hose when checking or adding the engine oil as it may be hot enough to burn you.
Page 466 Maintenance Changing the engine oil and filter Have engine oil and filter changed by an authorized Kia dealer according to the Maintenance Schedule at the beginning of this chapter. WARNING Used engine oil may cause irrita- tion or cancer of the skin if left in contact with the skin for pro- longed periods of time.
Page 467 Maintenance COOLANT The high-pressure cooling system Checking the coolant level • Turn the engine off and wait until it has a reservoir filled with year round cools down. Use extreme care antifreeze coolant. The reservoir is when removing the radiator cap. WARNING filled at the factory.
Page 468 The coolant level should be filled overfill. If frequent additions are between MAX and MIN marks on the required, see an authorized Kia deal- side of the coolant reservoir when er for a cooling system inspection. the engine is cool.
Page 469 Ambient (volume) overfill. If frequent additions are water in the coolant filled at the fac- Temperature required, see an authorized Kia deal- Antifreeze Water tory. An improper coolant mixture er for a cooling system inspection. -15°C (5°F) can result in serious malfunction or -25°C (-13°F)
Page 470 Maintenance ✽ ✽ NOTICE ■ Engine coolant reservoir cap WARNING Make sure the coolant cap is proper- Radiator cap ly closed after refill of coolant. Otherwise the engine could be over- heated while driving. ■ Engine room front view Do not remove the radiator cap when the engine and radiator ODE076006 are hot.
Page 471 Maintenance ■ Engine room rear view Changing the coolant Have the coolant changed by an authorized Kia dealer according to the Maintenance Schedule at the beginning of this chapter. CAUTION Put a thick cloth or fabric around the radiator cap before...
Page 472 In the event the brake system CAUTION - Proper fluid requires frequent additions of fluid, the vehicle should be inspected by Only use brake fluid in brake an authorized Kia dealer. system. Small amounts improper fluids (such as engine When changing and adding brake oil) can cause damage to the fluid, handle it carefully.
Page 473 If the fluid level is excessively low, we WARNING - Engine clutch recommend that the system be actuator fluid level checked by an authorized Kia dealer. actuator fluid When changing and adding engine clutch actuator fluid, Use only the specified engine clutch handle it carefully.
Page 474 Maintenance CAUTION Do not allow engine clutch actu- ator fluid to contact the vehi- cle's body paint, as paint dam- age will result. The engine clutch actuator fluid, which has been exposed to open air for an extended time should never be used as its quality cannot be guaranteed.
Page 475 Maintenance WASHER FLUID Checking the washer fluid WARNING WARNING - Flammable - Windshield level fluid fluid Do not allow the washer fluid to Do not drink the windshield come in contact with open washer fluid. The windshield flames or sparks.The windshield washer fluid is poisonous to washer fluid reservoir is flamma- humans and animals.
Page 476 (30 kg) of force. Also, the parking brake alone should securely hold the vehicle on a fairly steep grade. If the stroke is more or less than specified, have the parking brake adjusted by an authorized Kia dealer. Stroke : 6~7 notch 8 41...
Page 477 Maintenance AIR CLEANER Filter replacement ODE076012L ODE076013 1. Loosen the air cleaner cover 2. Wipe the inside of the air cleaner. ODE076011 attaching clips and open the cover. 3. Replace the air cleaner filter. It must be replaced when necessary, 4.
Page 478 • Use a Kia genuine part. Use of a non-genuine part could damage the air flow sensor. 8 43...
Page 479 Maintenance CLIMATE CONTROL AIR FILTER (IF EQUIPPED) Filter inspection The climate control air filter should replaced according Maintenance Schedule. If the vehicle is operated in severely air-polluted cities or on dusty rough roads for a long period, it should be inspected more frequently and replaced earlier.
Page 480 Maintenance ODE076054 OQL075021 3. Remove the climate control air fil- 4. Replace the climate control air fil- ter cover while pressing the lock ter. on both sides of the cover. 5. Reassemble in the reverse order of disassembly. When replacing the climate control air filter install it properly.
Page 481 Maintenance WIPER BLADES Blade inspection Contamination of either the wind- Blade replacement shield or the wiper blades with for- When the wipers no longer clean eign matter can reduce the effective- adequately, the blades may be worn ness of the windshield wipers. or cracked, and require replacement.
Page 482 Maintenance Front windshield wiper blade 1JBA7037 OHM078060 1LDA5023 Type A 1. Raise the wiper arm and turn the wiper blade assembly to expose the plastic locking clip. CAUTION - Wiper arms 1JBA7038 OHM078061 Do not allow the wiper arm to 2.
Page 483 3. Make sure the blade assembly is installed firmly by trying to pull it slightly. To prevent damage to the wiper arms or other components, have an authorized Kia dealer replace the wiper blade.
Page 484 Wear protection Please return the battery to solution of water and baking soda. when charging or work- an authorized Kia dealer to • If the vehicle is not going to be near battery. be recycled. used for an extended time, discon-...
Page 485 Maintenance Recharging the battery When recharging battery, WARNING - Risk of elec- observe the following precautions: Your vehicle has a maintenance-free, trocution • The battery must be removed from calcium-based battery. Never touch the electrical igni- the vehicle and placed in an area •...
Page 486 Maintenance • Before performing maintenance or Reset items recharging the battery, turn off all Items should be reset after the bat- accessories and stop the engine. tery has been discharged or the bat- • The negative battery cable must be tery has been disconnected.
Page 487 Maintenance TIRES AND WHEELS Tire care WARNING - Tire underin- For proper maintenance, safety, and flation maximum fuel economy, you must Inflate your tires consistent with always maintain recommended tire the instructions provided in this inflation pressures and stay within manual.
Page 488 1.6 spare tire. refilling, have it checked by an km (one mile) since startup.) authorized Kia dealer. • Check the pressure of your spare • Overinflation produces a harsh How to check tire each time you check the pres-...
Page 489 • Remember to check the pressure Replace the tire if you find either of the valve stems. They help prevent of your spare tire. Kia recommends these conditions. Replace the tire if leaks by keeping out dirt and mois- that you check the spare every fabric or cord is visible.
Page 490 Maintenance Disc brake pads should be inspected Wheel alignment and tire bal- Without a spare tire for wear whenever tires are rotated. ance Rotate radial tires that have an The wheels on your vehicle were asymmetric tread pattern only from aligned and balanced carefully at the front to rear and not from right to left.
Page 491 Maintenance Tire replacement The ABS works by comparing the Wheel replacement speed of the wheels. The tire size When replacing the metal wheels for affects wheel speed. When replacing any reason, make sure the new tires, all 4 tires must use the same wheels are equivalent to the original size originally supplied with the vehi- factory units in diameter, rim width...
Page 492 Tire sidewall labeling CAUTION - Wheel Tire traction can be reduced if you Wheels that do not meet Kia's drive on worn tires, tires that are specifications may fit poorly improperly inflated or on slippery and result in damage to the road surfaces.
Page 493 Maintenance 2. Tire size designation 89 - Load Index, a numerical code Tire speed ratings associated with the maximum A tire’s sidewall is marked with a tire The chart below lists many of the dif- load the tire can carry. size designation.
Page 494 Maintenance 3. Checking tire life (TIN : Tire 5. Maximum permissible inflation WARNING - Tire age Identification Number) pressure Replace tires within the recom- Any tires that are over 6 years old, This number is the greatest amount of mended time frame. Failure to based on the manufacturing date, air pressure that should be put in the replace tires as recommended...
Page 495 Maintenance Tread wear Tires degrade over time, even when Traction - AA, A, B & C they are not being used. Regardless The tread wear grade is a compara- The traction grades, from highest to of the remaining tread, we recom- tive rating based on the wear rate of lowest, are AA, A, B and C.
Page 496 Maintenance Temperature -A, B & C Tire terminology and defini- Cold Tire Pressure: The amount of air pressure in a tire, measured in tions The temperature grades are A (the kilopascals (kPa) or pounds per highest), B and C representing the Air Pressure: The amount of air square inch (psi) before a tire has tire’s resistance to the generation of...
Page 497 Maintenance GVWR: Gross Vehicle Weight Rating Maximum Inflation Pressure: The Occupant Distribution: Designated maximum air pressure to which a seating positions. GAWR FRT: Gross Axle Weight cold tire may be inflated. The maxi- Rating for the Front Axle. Outward Facing Sidewall: The side mum air pressure is molded onto the of a asymmetrical tire that has a par- GAWR RR: Gross Axle Weight...
Page 498 Maintenance Production options weight: The Speed Rating: An alphanumeric Vehicle Maximum Load on the combined weight of installed regular code assigned to a tire indicating the Tire: Load on an individual tire due production options weighing over 5 maximum speed at which a tire can to curb and accessory weight plus lb.(2.3 kg) in excess of the standard operate.
Page 499 Maintenance All season tires Snow tires Radial-ply tires Kia specifies all season tires on If you equip your car with snow tires, Radial-ply tires provide improved some models to provide good per- they should be the same size and tread life, road hazard resistance and...
Page 500 • If the tire is impacted, we rec- ommend that you inspect the tire condition or contact an authorized Kia dealer. • To prevent damage to the tire, inspect the tire condition and pressure every 3,000 (1,900 miles).
Page 501 Maintenance • It is not easy to recognize the tire damage with your own eyes. But if there is the slightest hint of tire damage, even though you cannot see it, have the tire checked or replaced because the tire damage may cause air leakage from the tire.
Page 502 ■ BFT indicates an electrical problem. Avoid using the system involved and imme- CAUTION diately consult an authorized Kia dealer. Do not use a screwdriver or any Three kinds of fuses are used: blade other metal object to remove...
Page 503 Maintenance ✽ ✽ NOTICE Inner panel fuse replacement CAUTION • When replacing fuse, turn the • When replacing a blown fuse ignition “OFF” and turn off or relay, make sure the new switches of all electrical devices fuse or relay fits tightly into then remove battery (-) terminal.
Page 504 4. Check the removed fuse; replace it lamps, have the vehicle checked by if it is blown. an authorized Kia dealer for assis- tance. Spare fuses are provided in the engine compartment fuse panel.
Page 505: Fuse Box.
4. Push in a new fuse of the same rating, and make sure it fits tightly in the clips. If it fits loosely, consult an authorized Kia dealer. CAUTION After checking the fuse panel in engine...
Page 506 Incorrect or partial assembly torque may cause a fire. Have the vehicle checked by an authorized Kia dealer. ODE076022 ODE076023 If the multi fuse is blown, it must be If the multi fuse is blown, it must be...
Page 507 Kia dealer. cause fire. CAUTION ✽ ✽ NOTICE - Remodeling Visually inspect the battery cap Prohibited to ensure it is securely closed.
Page 508 Maintenance ■ Driver’s side fuse panel (Hybrid) Fuse/relay panel description Driver’s side fuse panel ODE076024 Inside the fuse/relay panel covers, you can find the fuse/relay label describing fuse/relay name and capacity. ✽ ✽ NOTICE ODE076066N Not all fuse panel descriptions in this manual may be applicable to your vehicle.
Page 509 Maintenance ■ Driver’s side fuse panel (Plug-in Hybrid) Driver’s side fuse panel ODE076024 Inside the fuse/relay panel covers, you can find the fuse/relay label describing fuse/relay name and capacity. ✽ ✽ NOTICE ODEP077072N Not all fuse panel descriptions in this manual may be applicable to your vehicle.
Page 510 Maintenance Instrument panel (Driver’s side fuse panel) (Hybrid) Fuse Name Fuse rating Circuit Protected Electro Chromic Mirror, Audio/Video & Navigation Head Unit, Audio, Driver IMS (Integrated memory system) Module, VESS (Virtual Engine Sound System) Unit, Shift Lever Indicator, Air Conditioner Control Module, MODULE 5 Rear Seat Warmer Control Module, Front Air Ventilation Seat Control Module, Front Seat Warmer Control Module, Head Lamp LH/RH...
Page 511 Maintenance Fuse Name Fuse rating Circuit Protected Engine Room Junction Block (Power Outlet Relay), Wireless Charger, BCM (Body Control Module), USB MODULE 2 Charger, Smart Key Control Module, Audio, BMS (Battery Management System) Control Module, Audio/Video & Navigation Head Unit, Driver Power Outside Mirror Switch, AMP (Amplifier) [Without Smart Key] Immobilizer Module PDM 3 7.5A...
Page 512 Maintenance Fuse Name Fuse rating Circuit Protected P/WINDOW RH Power Window (RH) Relay, Passenger Safety Power Window Module P/WINDOW LH Power Window (LH) Relay, Driver Safety Power Window Module [Without Smart Key] Immobilizer Module PDM 2 7.5A [With Smart Key] Smart Key Control Module, Start/Stop Button Switch BRAKE SWITCH 7.5A Stop Lamp Switch, Smart Key Control Module...
Page 513 Maintenance Fuse Name Fuse rating Circuit Protected DOOR LOCK Door Lock/Unlock Relay, ICM Relay Box (Two Turn Unlock Relay) Wiper Motor, Engine Room Junction Block (Front Wiper (Low) Relay), ECM (Engine Control Module), WIPER 2 (FRT) BCM (Body Control Module) MODULE 6 7.5A BCM (Body Control Module), Smart Key Control Module...
Page 514 Maintenance Instrument panel (Driver’s side fuse panel) (Plug-in Hybrid) Fuse Name Fuse rating Circuit Protected Electro Chromic Mirror, Audio/Video & Navigation Head Unit, Audio, Driver IMS (Integrated memory system) Module, VESS (Virtual Engine Sound System) Unit, Shift Lever Indicator, Air Conditioner Control Module, MODULE 5 Rear Seat Warmer Control Module, Front Air Ventilation Seat Control Module, Front Seat Warmer Control Module...
Page 515 Maintenance Fuse Name Fuse rating Circuit Protected START 7.5A Transaxle Range Switch Engine Room Junction Block (Power Outlet Relay), Wireless Charger, BCM (Body Control Module), USB MODULE 2 Charger, Smart Key Control Module, Audio, Audio / Video & Navigation Head Unit, Power Outside Mirror Switch, AMP (Amplifier) PDM3 7.5A...
Page 516 Maintenance Fuse Name Fuse rating Circuit Protected Front Seat Warmer Control Module, AC Inverter (220V), Front Air Ventilation Seat Control Module, Rear MODULE 7 7.5A Seat Warmer Module, AC Inverter Module WIPER (REAR) Engine Room Junction Block (Wiper RR Relay), Rear Wiper Motor HEATED BCM (Body Control Module) STEERING...
Page 517 Maintenance Fuse Name Fuse rating Circuit Protected BATTERY BMS (Battery Management System) Control Module MANAGEMENT P/SEAT (DRV) Driver Seat Manual Switch, Driver IMS (Integrated memory system) Module AMP (Amplifier) Battery Sensor Data Link Connector, AEB Module, Hazard Switch, Driver/Passenger Door Module, Driver/Passenger Smart MODULE 1 Key Outside Handle DOOR LOCK...
Page 518 Maintenance Engine compartment fuse panel ODE076027N ODE076067N 8 83...
Page 519 Maintenance Engine room compartment fuse panel (Hybrid) Fuse Name Fuse rating Circuit Protected B+ 5 Fuse - BATTERY C/FAN, HORN, B/ALARM HORN, ECU2, Engine Control Relay B+ 2 Instrument Panel Junction Block (Fuse - S/HEATER (REAR)) B+ 3 Instrument Panel Junction Block Instrument Panel Junction Block (Fuse - BATTERY MANAGEMENT, P/WINDOW (LH), P/WIN- B+ 4 DOW (RH), TAIL GATE OPEN, SUNROOF, AMP, S/HEATER (FRT), P/SEAT (DRV))
Page 520 Maintenance Fuse Name Fuse rating Circuit Protected POWER Power Outlet #2 OUTLET 3 POWER Power Outlet #1 OUTLET 2 DCT 3 TCM (Transmission Control Module) HPCU 1 HPCU (Hybrid Power Control Unit) Electric Water Pump (Engine) FUEL PUMP Fuel Pump Relay Instrument Panel Junction Block (Fuse - BRAKE SWITCH, PDM1, PDM2, MODULE1, DOOR FUSE B + 1...
Page 521 Maintenance Fuse Name Fuse rating Circuit Protected ACTIVE HYDRAULIC Integrated Brake Actuation Unit BOOTER 2 INVERTER AC Inverter Module POWER Power Outlet Relay OUTLET 1 B/UP LAMP Electro Chromic Mirror, Back-Up Lamp LH/RH ECU 3 ECM (Engine Control Module) HPCU 2 HPCU (Hybrid Power Control Unit), Clutch Actuator (HEV) ACTIVE FUSE...
Page 522 Maintenance Fuse Name Fuse rating Circuit Protected SENSOR 1 Oxygen Sensor (Up), Oxygen Sensor (Down) IGN COIL Ignition Coil #1/#2/#3/#4 FUSE ECU 2 ECM (Engine Control Module) B/ALARM HORN Burglar Alarm Horn Relay 8 87...
Page 523 Maintenance Engine room compartment fuse panel (Plug-in Hybrid) Fuse Name Fuse rating Circuit Protected B+ 5 Fuse - BATTERY C/FAN, HORN, B/ALARM HORN, ECU2, Engine Control Relay B+ 2 Instrument Panel Junction Block (Fuse - S/HEATER (REAR)) B+ 3 Instrument Panel Junction Block Instrument Panel Junction Block (Fuse - BATTERY MANAGEMENT, P/WINDOW (LH), P/WIN- B+ 4 DOW (RH), TAIL GATE OPEN, SUNROOF, AMP, S/HEATER (FRT), P/SEAT (DRV), IG3 1,...
Page 524 Maintenance Fuse Name Fuse rating Circuit Protected POWER Power Outlet #2 OUTLET 3 POWER Power Outlet #1 OUTLET 2 DCT 3 TCM (Transmission Control Module) HPCU 1 HPCU (Hybrid Power Control Unit) Electric Water Pump (Engine) FUEL PUMP Fuel Pump Relay Instrument Panel Junction Block (Fuse - BRAKE SWITCH, PDM1, PDM2, MODULE1, DOOR FUSE B + 1...
Page 525 Maintenance Fuse Name Fuse rating Circuit Protected ACTIVE HYDRAULIC Integrated Brake Actuation Unit BOOTER 2 INVERTER AC Inverter Module POWER Power Outlet Relay OUTLET 1 B/UP LAMP Electro Chromic Mirror, Back-Up Lamp LH/RH ECU 3 ECM (Engine Control Module) HPCU 2 HPCU (Hybrid Power Control Unit), Clutch Actuator (PHEV) ACTIVE FUSE...
Page 526 Maintenance Fuse Name Fuse rating Circuit Protected SENSOR 1 Oxygen Sensor (Up), Oxygen Sensor (Down) IGN COIL Ignition Coil #1/#2/#3/#4 FUSE ECU 2 ECM (Engine Control Module) B/ALARM HORN Burglar Alarm Horn Relay 8 91...
Page 527 Maintenance Relay (Hybrid) Relay Name Type PTC Heater #2 Relay MICRO PTC Heater #1 Relay MICRO PDM2 (IG1) Relay MICRO Battery C/FAN Relay MICRO Rear Wiper Relay MICRO PDM3 (IG2) Relay MICRO Fuel Pump Relay MICRO PDM1 (ACC) Relay MICRO Cooling Fan Relay MINI Rear Heated Relay...
Page 528 Maintenance Relay (Plug-in Hybrid) Relay Name Type PTC Heater #2 Relay MICRO PTC Heater #1 Relay MICRO PDM2 (IG1) Relay MICRO Battery C/FAN Relay MICRO Rear Wiper Relay MICRO PDM3 (IG2) Relay MICRO Fuel Pump Relay MICRO PDM1 (ACC) Relay MICRO Cooling Fan Relay MINI...
Page 529 Maintenance Battery terminal cover OJFH075172 ✽ ✽ NOTICE Not all fuse panel descriptions in this manual may be applicable to your vehicle. It is accurate at the time of printing. When you inspect the fuse panel in your vehicle, refer to the fuse panel label.
Page 530 Please have the vehicle or receiving an electric shock. checked by an authorized Kia dealer immediately. 8 95...
Page 531 (2) Front turn signal lamp (Bulb type) ■ Head lamp - Type A consult an authorized Kia dealer. In (3) Position lamp (LED type) many cases, it is difficult to replace (4) Side marker (Bulb type)
Page 532 Maintenance Light bulb position (Rear) ■ Light bulb position (Side) License plate lamp ■ Rear combination lamp - Type A ODE076056L ■ High mounted stop lamp ODE076031N ■ Rear combination lamp - Type B ODE076034 (1) Side repeater lamp (LED type) ODEP077055N (1) Stop/tail lamp (Bulb type) ODEP077032N...
Page 533 So if you need to have your last twice as long or longer than halo- authorized Kia dealer. vehicle disposed, you should remove gen bulbs depending on their fre- the HID headlamps before disposal.
Page 534 Side marke by turning it counterclockwise. r(4) does not operate, have the vehi- 3. Disconnect the headlamp bulb cle checked by an authorized Kia socket-connector. dealer. 4. Remove the bulb-socket from the The LED lamps cannot be replaced...
Page 535 Maintenance Headlamp bulb • Always handle them carefully, and Front turn signal lamp bulb avoid scratches and abrasions. If replacement the bulbs are lit, avoid contact with liquids. Never touch the glass with bare hands. Residual oil may cause the bulb to overheat and burst when lit.
Page 536 2. Open the service cover. bulb(LED) does not operate, have the vehicle checked by an authorized 3. Loosen the light assembly retain- Kia dealer. ing screws with a cross-tip screw- driver. The LED lamps cannot be replaced as a single unit because it is an inte- grated unit.
Page 537 Maintenance 9. Install the socket in the assembly by aligning the tabs on the socket with the slots in the assembly. Push the socket into the assembly and turn the socket clockwise. 10. Install the rear combination lamp assembly to the body of the vehi- cle.
Page 538 Maintenance Tail lamp (inside) bulb replace- 6. Install the socket in the assembly by aligning the tabs on the socket ment with the slots in the assembly. Push the socket into the assembly and turn the socket clockwise. 7. Install the service cover by putting it into the service hole.
Page 539 Kia dealer. checked by an authorized Kia dealer. checked by an authorized Kia dealer. The LED lamps cannot be replaced The LED lamps cannot be replaced...
Page 540 Kia dealer. The LED lamps cannot be replaced as a single unit because it is an inte- grated unit. The LED lamps has to be replaced with the unit.
Page 541 WARNING - Interior lamps lamp housing. authorized Kia dealer. Prior to working on the Interior 2. Remove the bulb by pulling it The LED lamps cannot be replaced lamps, ensure that the “OFF”...
Page 542 Maintenance 1. Using a flat-blade screwdriver, Room lamp (Bulb type) bulb 1. Using a flat-blade screwdriver, gently pry the lamp assembly from gently pry the lens cover from replacement interior. lamp housing. 2. Remove the bulb by pulling it 2. Remove the bulb by pulling it straight out.
Page 543 If the Liftgate room lamp (LED) does not operate, have the vehicle replacement replacement checked by an authorized Kia dealer. The LED lamps cannot be replaced as a single unit because it is an inte- grated unit. The LED lamps has to be replaced with the unit.
Page 544 Maintenance APPEARANCE CARE Exterior care Finish maintenance After washing the vehicle, test the brakes while driving slowly to see if Washing Exterior general caution they have been affected by water. If To help protect your vehicle’s finish It is very important to follow the label braking performance is impaired, dry from rust and deterioration, wash it directions when using any chemical...
Page 545 Maintenance High-pressure washing Waxing • When using high-pressure wash- Wax the vehicle when water will no ers, make sure to maintain suffi- longer bead on the paint. cient distance from the vehicle. Always wash and dry the vehicle Insufficient clearance or excessive before waxing.
Page 546 Maintenance Bright-metal maintenance • Wash the undercarriage of your CAUTION - Drying vehicle vehicle regularly during the winter • To remove road tar and insects, and whenever your vehicle has • Wiping dust or dirt off the use a tar remover, not a scraper or been exposed to such salts or body with a dry cloth will other sharp object.
Page 547 Maintenance Aluminum wheel maintenance Corrosion protection High-corrosion areas The aluminum wheels are coated with If you live in an area where your vehi- Protecting your vehicle from corrosion a clear protective finish. cle is regularly exposed to corrosive By using the most advanced design materials, corrosion protection is •...
Page 548 Maintenance High temperatures can also acceler- Keep your vehicle clean • When cleaning lower door panels, ate corrosion of parts that are not rocker panels and frame members, The best way to prevent corrosion is properly ventilated so the moisture be sure that drain holes are kept to keep your vehicle clean and free can be dispersed.
Page 549 Maintenance Keep paint and trim in good con- Interior care CAUTION - Leather dition Interior general precautions When cleaning leather products Scratches or chips in the finish Prevent chemicals such as perfume, (steering wheel, seats etc.), use should be covered with "touch-up" cosmetic oil, sun cream, hand clean- neutral detergents or low alco- paint as soon as possible to reduce...
Page 550 Maintenance Taking care of leather seats Cleaning the leather seats Fabric seat cover using precau- tions (If equipped) • Vacuum the seat periodically to • Remove all contaminations instant- remove dust and sand on the seat. ly. Refer to instructions below for Please clean the fabric seats regu- It will prevent abrasion or damage of removal of each contaminant.
Page 551 Maintenance Cleaning the upholstery and inte- Cleaning the lap/shoulder belt Window tinting precaution rior trim webbing Window tint(especially metallic film) might cause communication disorder Clean the belt webbing with any mild Vinyl or poor radio reception, and malfunc- soap solution recommended for Remove dust and loose dirt from tion of the automatic lighting system cleaning upholstery or carpet.
Page 552 (The ORVR system is designed to an authorized Kia dealer in accor- allow the vapors from the fuel tank to dance with the maintenance sched- be loaded into a canister while refu- ule in this manual.
Page 553 Maintenance Canister 3. Exhaust emission control Engine exhaust gas precautions (carbon monoxide) system Fuel vapors generated inside the fuel tank are absorbed and stored in the • Carbon monoxide can be present Exhaust Emission Control onboard canister. When the engine is with other exhaust...
Page 554 Maintenance • Do not operate the engine in con- Operating precautions for catalyt- WARNING - Fire fined or closed areas (such as ic converters (if equipped) garages) any more than what is • Do not park, idle or drive the necessary to move the vehicle in or vehicle over or near flamma- WARNING...
Page 555 All inspections and adjustments must be made by an authorized Kia dealer. • Avoid driving with an extremely low fuel level. Running out of fuel could cause the engine to misfire, dam- aging the catalytic converter.
Page 556: Specifications & Consumer Information
Specifications & Consumer information Dimensions ....... . 9-2 Engine ........9-2 Bulb wattage .
Page 557 Specifications & Consumer information DIMENSIONS Item Unit : in (mm) Overall length 4,355 (171.4) Overall width 1,805 (71.0) Without Roof rack 1,535 (60.4) Overall height With Roof rack 1,545 (60.8) 205/60R16 1,565 (61.6) Front 225/45R18 * 1,555 (61.2) Tread 205/60R16 1,579 (62.1) Rear 225/45R18 *...
Page 558: Bulb Wattage
Specifications & Consumer information BULB WATTAGE Light Bulb Wattage (W) Bulb type Headlamps (Low/High) HB3 HL+ Headlamps (Low/High) - HID type* Headlamps (Low/High) - LED type* Front turn signal lamps PY21W Front position lamps LED type Front Bulb type P21 L/L Daytime running light LED type * Front fog lamps...
Page 559 Specifications & Consumer information TIRES AND WHEELS Inflation pressure [bar(psi, kPa)] Wheel lug Load Speed nut torque Capacity capacity Item Tire size Wheel size Normal load Maximum load [Kgf·m (lbf·ft, N·m)] LI * SS * Km/h Front Rear Front Rear 205/60 R16 6.5J X 16 2.5 (36, 250)
Page 560 Specifications & Consumer information GROSS VEHICLE WEIGHT For HEV Gasoline 1.6 L Item NIRO FE NIRO NIRO Touring 1,850 kg 1,900 kg 1,930 kg (4,078 lb.) (4,189 lb.) (4,255 lb.) For PHEV Gasoline Item 1.6 L 2,000kg (4,409lb)
Page 561 Min : Behind rear seat to upper edge of the seat back. Max : Behind front seat to roof. AIR CONDITIONING SYSTEM Item Weight of volume Classification 550 ± 10g R-1234yf Refrigerant 550 ± 10g R-134a Compressor lubricant 130 ± 10g Have your vehicle inspected by an authorized Kia dealer.
Page 562: Recommended Lubricants And Capacities
Specifications & Consumer information RECOMMENDED LUBRICANTS AND CAPACITIES To help achieve proper engine and powertrain performance and durability, use only lubricants of the proper quality. The correct lubricants also help promote engine efficiency that results in improved fuel economy. These lubricants and fluids are recommended for use in your vehicle. Lubricant Volume Classification...
Page 563 Specifications & Consumer information Recommended SAE viscosity Temperature Range for SAE Viscosity Numbers number °C Temperature Engine oil viscosity (thickness) has an (°F) effect on fuel economy and cold 10W-30 weather operating (engine start and 1.6L GDI 0/5W-20, 5W-30 engine oil flowability). Lower viscosity engine oils can provide better fuel An engine oil displaying this API Certification Mark conforms economy and cold weather perform-...
Page 564 Specifications & Consumer information VEHICLE IDENTIFICATION NUMBER (VIN) VEHICLE CERTIFICATION LABEL ■ Frame number ■ VIN label ODE086001 OUM084005 The vehicle identification number The VIN is also on a plate attached ODE086002 (VIN) is the number used in register- to the top of the dashboard. The vehicle certification label...
Page 565 Specifications & Consumer information TIRE SPECIFICATION AND ENGINE NUMBER AIR CONDITIONER PRESSURE LABEL COMPRESSOR LABEL ODE086003 ODE086006L ODE086005L The engine number is stamped on the The tires supplied on your new vehi- engine block as shown in the drawing. A compressor label informs you the cle are chosen to provide the best type of compressor your vehicle is performance for normal driving.
Page 566 Index...
Page 567: Air Cleaner
Index Climate control air filter..... 4-143 Manual heating and air conditioning ... 4-134 Air bag - advanced supplemental restraint system.
Page 568 Index Brake fluid ........8-37 Inverter coolant......8-33 Checking the brake fluid level .
Page 569: Do Not Use Methanol
Index Dual Clutch Transmission (DCT)....6-14 Engine start/stop button ......6-9 Dual clutch transmission operation .
Page 570: Hev/Phev Powertrain
Index Fuses ........8-67 If you have a flat tire (with Tire Mobility Kit).
Page 571: Interior Overview
Index Interior features......4-152 AC inverter ....... 4-157 Lane Keeping Assist System (LKAS) .
Page 572 Index Headlamp (LED type) replacement ... . . 8-99 High mounted stop lamp bulb replacement ..8-104 Maintenance services ......8-5 License plate lamp bulb replacement.
Page 573 Index Seat belts........3-19 Care of seat belts ......3-30 Rear parking assist system .
Page 574 Index Starting the hybrid/plug-in hybrid vehicle (Smart key) H37 Low tire pressure position telltale ....7-14 Steering wheel ....... 4-45 Low tire pressure telltale .
Page 575: Vehicle Break-In Process
Index Welcome system ......4-129 Headlight (Headlamp) escort function..4-129 Vehicle break-in process .

Kia Niro 2018 Owner's Manual

Quick Links

Related Manuals for Kia Niro 2018

Summary of Contents for Kia Niro 2018

Table of Contents
