- Page 1 MP54G3 (MS-6855A) Wireless 11g MiniPCI Card User’s Guide...
- Page 2 FCC STATEMEMT: This device is intended only for OEM integrators under the following conditions: 1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and 2) The transmitter module may not be co-located with any other transmitter or antenna.
-
Page 3: Fcc Caution
FCC Caution 1. The device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. -
Page 4: Important Safety Precautions
Important Safety Precautions Always read and follow these basic safety precautions carefully when handling any piece of electronic component. Keep this User’s Guide for future reference. Keep this equipment away from humidity. Lay this equipment on a reliable flat surface before setting it up. The openings on the enclosure are for air convection hence protects the equipment from overheating. - Page 5 MiniPCI Card Compliant with IEEE802.11g, the Wireless 11g MiniPCI Card MP54G3 (MS-6855A) is a high-efficiency wireless adapter for wireless networking at home, in office or in public places. The data rate can be up to 54 Mbps and auto-negotiated to 48, 36, 24, 18, 12, 9, 6Mbps (IEEE 802.11g), or 11, 5.5, 2, 1Mbps (IEEE802.
- Page 6 >>> 1.2 How Wireless LAN Adapter Works Ad-hoc Mode : An Ad-hoc network is a local area network or other small network, especially one with wireless or temporary plug-in connections, in which some of the network devices are part of the network only for the duration of a communications session.
- Page 7 Infrastructure Mode : The difference between Infrastructure network and Ad-hoc network is that the former one includes an Access Point. In an Infrastructure network, the Access Point can manage the bandwidth to maximize bandwidth utilization. Addi- tionally, the Access Point enables users on a wireless LAN to access an existing wired network, allowing wireless users to take advantage of the wired networks resources, such as Internet, email, file transfer, and printer sharing.
-
Page 8: Specifications
>>> 1.3 Specifications Form Factor 32-bit Type IIIB Operation voltage 3.3V Antenna Connector Two antenna connectors Standard - IEEE 802.11g/b - WECA Wi-Fi - WHQL (Windows XP/2000) Frequency Range 2.412GHz to 2.484GHz Data Rate and IEEE 802.11b (Auto-Fallback): Modulation Types - CCK @ 5.5 and 11 Mbps - DQPSK @ 2 Mbps - DBPSK @ 1 Mbps... - Page 9 Range Up to 400 m Transmitter Output Power Up to 15dBm Operating system Microsoft Windows 98SE/ ® ® ME/2000/XP Environmental - Operating Temperature: 0 ~ 55 - Operating Humidity: 10 ~ 90%, non-condensing Dimensions (WxDxH) 59.75 x 44.60 mm Weight 15 g...
-
Page 10: System Requirements
>>> 1.4 System Requirements Before installing the wireless LAN adapter, your PC should meet the following items: - One desktop/notebook PC with an available MiniPCI slot. - Windows 98SE/ME/2000/XP operating system. ® - Minimum 5MB free disk space for installing the driver and utilities. -
Page 11: Product View
>>> 1.6 Product View External antenna connectors Connect to external antennas for enhanced data transmission and reception. The external antennas are well designed on the desktop or notebook computers. Golden Finger... -
Page 12: Hardware Installation
Hardware Installation The following diagrams provide you a basic installation for your wireless LAN adapter, including how to install and remove the MiniPCI card. The instruction below is suitable for most com- puters with MiniPCI slot. For more information about the MiniPCI module, please refer to your computer’s manual. - Page 13 >>> 2.2 Removing the Wireless LAN Adapter Locate the MiniPCI slot with wireless LAN adapter installed. Press the retaining clips outwards, and the card should bound upwards slightly after being released from the slot. Remove the card from the MiniPCI slot carefully.
-
Page 14: Software Installation
Setup CD to copy files during the installation. Please NOTE that the MP54G3 should be installed into your computer before installing the driver and utility. Then, the operating system will detect a new device and start to configure the new device. - Page 15 1 1 1 1 1 Insert the software CD into your CD-ROM drive, and the Setup STEP program should launch automatically. If the Autorun program doesn’t launch automatically, click Start E:\setup.exe at the taskbar and select Run..Type (where your CD-drive) in the Open box and click OK to launch the Setup program manually.
- Page 16 Windows Setup CD during the installation. Please insert the Setup CD by the on-screen instruction to continue the installation. 4 4 4 4 4 Click Finish when the installation is completed. The MSI Wire- STEP less LAN icon will appear in the status area. MSI Wireless LAN icon...
