CONTENTS SAFETY PRECAUTIONS................................2 SERVICE HINTS ..................................3 ADJUSTMENT PROCEDURE AND FACTORY SETTINGS .....................4 WAVEFORM PATTERN TABLE ...............................5 ALIGNMENT SETTINGS................................6 BLOCK DIAGRAMS ..................................7 PARTS LOCATION .................................13 REPLACEMENT PARTS LIST ..............................14 SCHEMATIC DIAGRAMS ...............................29 CONDUCTOR VIEWS................................37 SAFETY PRECAUTIONS GENERAL GUIDE LINES It is advisable to insert an isolation transformer in the the receiver should be repaired and rechecked before a.c.
SERVICE HINTS How to remove the rear cover 1. Remove the 10 screws as shown in Fig.2. SCREWS SCREWS Fig.2. LOCATION OF CONTROLS DG-Board L-Board Focus D-Board H-Board Screen U-Board G-Board A-Board DF-Board Fig.3.
To get into Self-Check mode press the down (-/v) button on the customer controls at the front of the TV set, at the same time pressing the STATUS button on the remote control, and the screen will show: - Factory use only O.K. Sum : **** O.K. TX-36PL30 OPTION 1 : O.K. OPTION 2 : O.K. OPTION 3 : O.K.
WAVEFORM PATTERN TABLE Note: All waveforms have been taken using a standard colour bar pattern. Video Out Luminance In Vert Drive IC3001 Pin 56 IC1315 Pin 37 A44 Pin 24 10mS 64µS 32µS VFLB H - Drive Vert Out IC451 Pin 6 A3 Pin 10 IC451 Pin 3 32µS...
ALIGNMENT SETTINGS (The figures below are nominal and used for representative purposes only.) Set the Bass to maximum position, set the Treble to minimum position, press the down button (- / v) on the customer controls at the front of the TV and at the same time press the INDEX button on the remote control, this will place the TV into the Service Mode.
SCHEMATIC DIAGRAMS FOR MODELS TX-36PL30 (EURO-7 CHASSIS) IMPORTANT SAFETY NOTICE Components identified by mark have special characteristics important for safety. When replacing any of these components, use only manufacturer's specified parts. NOTE RESISTOR All resistors are carbon ¼W resistor, unless marked otherwise.
