6. If there are two screws (E) preattached inside
each Handrail (84), remove and discard the
screws.
Attach a Handrail (84) to the Right Upright (90)
with two 5/16" x 3" Screws (28) and two 5/16"
Star Washers (11); start both Screws, and
then tighten them. Make sure not to pinch the
Upright Wire (81).
Attach the other Handrail (not shown) to the
Left Upright (89) in the same way. Note: There
are no wires on the left side.
7. Set the Console Base (64) face down on a soft

surface to avoid scratching the Console Base.

Remove and discard the two indicated screws
(F). Then, remove the Pulse Crossbar (31).
6
84
89
7
F
10
28
11
E
81
90
31
F
64
