- Page 1 Digital Camcorder User Manual RoHS COMPLIANT...
- Page 2 Introduction Congratulations on your purchase of this digital video camera. Before using the camera, please read this user manual carefully. With this digital video camera you can take both video clips and still photos. The illustrations in this user manual are to visually detail the operation of the digital video camera.
- Page 3 Maintenance and care: 1. To clean the lens, first blow away dust on its surface, then use cloth or tissue to wipe the lens. If necessary, use lens cleanser. 2. Avoid touching the lens with your fingers. 3. When left idle for long periods, remove the batteries from your digital video camera and store in a dry and dark place.
- Page 4 System requirements When operating and using this digital video camera, be sure the computer you are using meets some basic requirements. Doing so will allow you to operate the camera to its full functionality. Below are the requirements: Operation System Microsoft Windows 98, 2000,XP, Vista, Windows 7 Above Intel PIII667 or CPU of equal performance Memory...
- Page 5 Getting to know your camera 1. Appearance and Buttons...
- Page 6 9.LCD panel 1. Power Key 10.Set Key 2. SD/MMC SDHC Card Slot 11.Mode Key 3.Microphone 12. Right Key 4.Lens 13. Confirm/OK key 5.Busy indicator 14.UP key 6.Speaker 15.Down key 7. USB Switch 16.Left key 8.USB Connector 2. Basic operation 2.1 Installing the battery Slide down the back cover and insert three new AAA alkaline batteries.
- Page 7 - Note that the SD Card has a tiny LOCK switch on the side. Set the switch to the un-LOCK position to store recorded videos and still pictures. 2.3 Powering on/off In the power-off state, press and hold the power key to power on the camera.
- Page 8 Date and time setting Press the SET key to open the menu and then press the left and right key to enter setting menu. Press the down key to select “date and time” menu option and press OK key to enter setting window.
- Page 9 2.4 Change mode After power on, it will enter video record mode, press "Mode" key to change mode among video record, still camera and playback. 2.5 Video record Your camera will power on in the video record mode. To record a video press the Confirm/OK key to start video recording.
- Page 10 In the video record mode you can use the zoom feature by pressing the up or down key zooms in or out on the image before you record or while you are recording.While it is zooming, you can find the zoom rate on the bottom of the screen. 2.7 Still camera Press the Mode key to switch from video mode to still camera mode.
- Page 11 2.8 Playback videos or photos Press the mode key to change modes, from video mode to still photo mode, to playback mode. Once in playback mode, press the ◄ key or ► key to select the desired file. When playing a video file press the Confirm/OK key to begin playing, press and hold the up or down key to increase or decrease the volume.
- Page 12 2.9 Delete files In playback mode, press the Set key once to display “Delete File? (ALL/YES/NO)”, then press left or right key to select ALL, YES or NO, press the Confirm/OK key to confirm the action. 3. Connect to PC Turn the camcorder on.
- Page 13 4. Download files from the camera to PC 4.1 After connecting to a computer go to "My Computer” and open the "Removable Disk." The videos will be saved in the \DCIM\ 100MEDIA folder in the removable disk. Choose the folder desired video in the 100MEDIA and copy (drag with mouse) it into a folder of your choice in the computer.
- Page 14 Application of Attached ArcSoft MediaImpression: 1. Introduction interface for software installation Put the CD attached into the CD-ROM of the computer, and then the following menu will appear: If the CD driver does not automatically start, please double click the autorun.exe program under the root directory of the CD.
- Page 15 2. MediaImpression Installation and Use: Install MediaImpression: Click “Install MediaImpression” button and complete the installation as per the tips.
- Page 16 After installation, please restart the computer. Run MediaImpression : icon on the desktop or follow “Start → Programs” to open Double click the MediaImpression.
- Page 17 After starting MediaImpression, click “Import” to import the media.
- Page 18 Choose the video camera storage and choose the output location. Choose require file and click import. The selected file will be stored in the output location.
- Page 19 Click “Go to start page” to return to the main screen. Click “Video” or “All media” to use the “YouTube” function. Choose the file and click “Upload to YouTube”.
- Page 20 Enter your username and password to login to YouTube to execute your upload.
- Page 21 Product specifications: Image sensor 0.3 Mega Pixels Function mode Video Recorder, Still camera, Playback Lens F2.8, f=3.8mm Digital Zoom 4× Shutter Electronic LCD display 1.77 inch TFT Display Video: VGA (640x480) @30fps;QVGA(320x240)@30fps Resolution Still photo: default to 0.3M (640x480); interpolated to 1MP(1024x768) White balance Automatic...
- Page 22 FCC Warning: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
