Overview
Welcome to the Intel® PRO/Wireless 5000 LAN Access Point User's Guide. This guide covers
software installation, configuration, and troubleshooting.
To select a topic, click a link in the contents column to the left.
After installing the access point register your access point online. Go to the
Registration Web
site.
Copyright © 2002 Intel Corporation.
Introduction
The 802.11a and 802.11b Intel® PRO/Wireless 5000 LAN Dual Access Point operates in the both
5 GHz and 2.4 GHz environment at speeds up to 54 Mbps (802.11a) and 11 Mbps (802.11b). It
features a software configurable antenna and will supports IEEE 802.3af Power over Ethernet.
Each access point uses eight non-overlapping transmission channels for support of up to 64
active users per access point. Placement can be on a desk or table, mounting on a wall or ceiling.
The PRO/Wireless 5000 LAN Access Point is compatible with other products supporting the IEEE
802.11a standard and 802.11b standard.
Security features include support for 128, 64, and 0-bit Wired Equivalent Privacy (WEP)
encryption and Virtual Private Network (VPN) compatibility.
A browser-based user interface is provided for configuration of the access point. See the
installation
instructions for information on how to set up and configure one or more access points.
For information on how to set up a wireless LAN, see the
Administrator's Guide is intended for use by network administrators.
802.1x Authentication
The 802.11a Intel® PRO/Wireless 5000 LAN Dual Access Point supports 802.1x authentication
for Windows operating systems.
802.1x authentication for wireless LANs has three main components: The supplicant (usually the
client software); the authenticator (the access point); and the authentication server (usually a
Remote Authentication Dial-In User Service or RADIUS server).
802.1x is a standards-based solution for port-level authentication for a wired or wireless Ethernet
client systems.
Copyright © 2002 Intel Corporation.
Legal Information
Legal Information
1
Intel Product
Administrator's
Guide. The

Advertisement

Table of Contents
loading

Related Manuals for Intel PRO/Wireless 5000

Summary of Contents for Intel PRO/Wireless 5000

  • Page 1 Legal Information Introduction The 802.11a and 802.11b Intel® PRO/Wireless 5000 LAN Dual Access Point operates in the both 5 GHz and 2.4 GHz environment at speeds up to 54 Mbps (802.11a) and 11 Mbps (802.11b). It features a software configurable antenna and will supports IEEE 802.3af Power over Ethernet.

  • Page 2: Installation

    Access Point Configuration Introduction Your Intel® PRO/Wireless 5000 LAN Access Point, when used with Intel PRO/Wireless 5000 LAN Adapters or other 802.11a and 802.11b-compliant wireless LAN adapters, offers an easy and economical way to add secure wireless connectivity to a wired local area network (LAN) within a building or office.

  • Page 3: Led Indicators

    The Intel® PRO/Wireless 5000 LAN Access Point can be mounted "right side up" on a desk or table or "upside down" on a wall or ceiling. The LED discussion that follows is based on a wall- or ceiling-mounted configuration in which the access point is "upside down."...

  • Page 4: Configuring The Access Point For The First Time

    6. To access the Express Setup pages, type a user name and a password. The default for both user name and password is Intel (upper case I, lower case ntel) 7. Use Express Setup to configure the access point with a new IP address, subnet, and other settings suitable for the network to which it will be permanently connected.

  • Page 5: Using Dhcp

    LAN network in question. Using DHCP The Intel PRO/Wireless 5000 LAN Access Point can be configured to use DHCP to get its IP address, subnet mask, and default gateway: 1. Access the Express Setup page in the browser-based Configuration Management...

  • Page 6: The Mac Address

    DHCP "lease table." • You can also use the Intel Access Point Administration Tool AP Discovery to find the access point and display its IP address. See the Administrator's Guide for information.

  • Page 7: Restore Factory Defaults

    WEP key, if used. • Use the Site Survey utility supplied on the Intel CD-ROM to analyze positioning and test signal strength at various locations. Modify the positioning of the access points and client stations as required for optimum performance. See the Administrator's Guide information on this utility.

  • Page 8: The Access Point Online Help File

    1. Create a directory for the Help file. For example: D:/Intel/Wireless/Ap/Help. 2. Create an alias for the Help path. For example: HelpPath. 3. Copy the file WAP50HLP.HTM from the directory GUIDES/APHelp/5000 on the Intel CD- ROM to the directory created in Step 1.

  • Page 9: Installing The Access Point Administration Tools

    Troubleshooting Tips Use the Latest Release of Your Intel Installation CD-ROM If you have more than one Intel Installation CD-ROM for your Intel PRO/Wireless 5000 LAN products, always use the CD-ROM with the highest version number. Access Point LED Functions The front panel of the Access Point uses seven LEDs to indicate the current state of activity.

  • Page 10: Additional Sources Of Information

    Intel® PRO/Wireless 5000 LAN Products Specifications Specifications by Model Models Intel® PRO/Wireless 5000 LAN Dual Access Point model WDAP5000 Intel® PRO/Wireless 5000 LAN Access Point model WSAP5000 Intel® PRO/Wireless 5000 LAN CardBus Adapter model WCB5000 Intel® PRO/Wireless 5000 Mini-PCI Adapter model WM3A5000 Intel®...

  • Page 11: General Specifications

    Wired Standard 10/100BTx Architecture Infrastructure, ad-hoc (peer-to-peer) Roaming 802.11a compliant for seamless roaming between access points Wired-to-wireless switching Intel® PROSet II software Security Encryption 64-bit and 128-bit WEP 802.11i (802.1x, Radius, EAP): Pending IEEE ratification in 2002 enhanced wireless authentication security...

  • Page 12: Intel® Pro/Wireless 2011B Lan Products Specifications

    Singapore Japan A-tick Intel® PRO/Wireless 2011B LAN Products Specifications Specifications by Model Models Intel® PRO/Wireless 2011B LAN Access Point model xxx Intel® PRO/Wireless 2011B LAN Adapter model xxx Access Point Form Factor Access Point Physical Dimensions 1.75” x 6” x 8.5” (4.4 cm x 15.2 cm x 21.6 cm)
  • Page 13 Architecture Infrastructure, ad-hoc (peer-to-peer) Roaming • 802.11b compliant for seamless roaming between access points • International roaming (802.11d) Wired-to-wireless Intel® PROSet II software switching Security Encryption 64-bit and 128-bit WEP Range and Data Rates 11 Mbps - Optional Throughput 5.5 Mbps - Optional...

  • Page 14: Intel® Pro/Wireless Lan Products Safety And Regulatory Notices

    (RF) electromagnetic energy emitted by FCC certified equipment. The Intel PRO/Wireless 5000 LAN products meet the Human Exposure limits found in OET Bulletin 65, 2001, and ANSI/IEEE C95.1, 1992. Proper operation of this radio according to the instructions found in this manual will result in exposure substantially below the FCC’s recommended limits.

  • Page 15: Fcc Regulations

    FCC Regulations FCC Regulations Part 15 Declaration of Conformity (DoC) Intel Corporation declares that the equipment described in this document is within the requirements of the Code of Federal Regulations listed below: Title 47 Part 15, Subpart B, Class B for a digital device.
  • Page 16 This declaration is based upon the compliance of the Intel® PRO/Wireless 5000 LAN Access Point model WSAP5000, the Intel® PRO/Wireless 5000 LAN Dual Access Point model WDAP5000, the Intel PRO/Wireless CardBus Adapter model WCB5000, the Intel PRO/Wireless PCI Adapter model WPCI5000 and the Intel® PRO/Wireless 5000 Mini-PCI Adapter model WM3A5000 to the above standards.

  • Page 17: Canadian Department Of Communications Industry Canada (Ic) Notice

    CAUTION: The Part 15 radio device operates on a non-interference basis with other devices operating at this frequency. Any changes or modification to said product not expressly approved by Intel could void the user's authority to operate this device. Canadian Department of Communications Industry Canada (IC) Notice...

  • Page 18: Intel® Pro/Wireless 2011B Lan Products

    Intel® PRO/Wireless 2011B LAN Products Radio Frequency Interference Requirements – USA This device uses, generates and radiates radio frequency energy. The radio frequency energy produced by this device is well below the maximum exposure allowed by the Federal Communications Commission (FCC).
  • Page 19 CE Marking & European Union Compliance Products intended for sale within the European Union are marked with the Conformite Europeene (CE) Marking, which indicates compliance with the applicable Directives and European Normes, and amendments, identified below. This equipment also carries the Class 2 identifier. English This product follows the provisions of the European Directive 1999/5/EC.
  • Page 20 EN61000-4-11 – Voltage Dips, Short Interruptions and Voltage Variations EN 300 328-2 V1.1.1 (2000-07) – Radio Equipment and Systems (RES); Wideband transmission systems; Technical characteristics and test conditions for data transmission equipment operating in the 2.4 GHz ISM band and using spread spectrum modulation techniques ETS 300 826:1997 –...
  • Page 21 Intel Radio Frequency (RF) products are designed to be compliant with the rules and regulations in the locations where they are sold and are locally labeled as required. The majority of Intel RF devices are type-approved and do not require the user to obtain license or authorization before using the equipment.
  • Page 22 If the hardware product is found to be otherwise defective, Intel, at its option, will replace or repair the hardware product at no charge except as set forth below, provided that you deliver the hardware product along with a Return Material Authorization (RMA) number (see below), either to the company from whom you purchased it or to Intel (North America only).

  • Page 23: Critical Control Applications

    You agree to defend, indemnify, and hold Intel harmless from and against any and all claims arising out of use of the hardware product in such applications by you or your customers.

  • Page 24: Intel® Pro/Wireless Lan Access Point - Limited Hardware Warranty (3 Years)

    If the hardware product is found to be otherwise defective, Intel, at its option, will replace or repair the hardware product at no charge except as set forth below, provided that you deliver the hardware product along with a Return Material Authorization (RMA) number (see below), either to the company from whom you purchased it or to Intel (North America only).

  • Page 25: Limitation Of Liability And Remedies

    You agree to defend, indemnify, and hold Intel harmless from and against any and all claims arising out of use of the hardware product in such applications by you or your customers.

  • Page 26: Intel® Pro/Wireless Lan Products Software License Agreement

    LIMITED MEDIA WARRANTY. If the Software has been delivered by Intel on physical media, Intel warrants the media to be free from material physical defects for a period of ninety (90) days after delivery by Intel. If such a defect is found, return the media to Intel for replacement or alternate delivery of the Software as Intel may select.
  • Page 27 Contracts for the Sale of Goods. You may not export the Software in violation of applicable export laws and regulations. Intel is not obligated under any other agreements unless they are in writing and signed by an authorized representative of Intel.
