Plateau
Outdoor Decorative Gas Appliance
WARNING: FOR OUTDOOR USE ONLY
WARNING:
If the information in these instructions
are not followed exactly, a fire
or explosion may result causing
property damage, personal injury or
loss of life.
WARNING:
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property damage.
Read the installation, operating and
maintenance instructions thoroughly
before installing or servicing this
equipment.
Installation and service must be
performed by a qualified installer,
service agency or the gas supplier
Tested by:
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
919-326
PTO28 City Table
®
WARNING - FOR YOUR SAFETY
What to do if you smell gas:
•Shut off gas to the appliance.
•Do not try to light any appliance.
•Extinguish any open flame.
•If odor continues, keep away from the appliance and im-
mediately call your gas supplier or fire department.
•Do not touch any electrical switch: do not use any phone
in your building.
•Immediately call your gas supplier from a neighbour's
phone.
•Follow the gas supplier's instructions.
•If you cannot reach your gas supplier, call the fire
department.
WARNING:
Do not store or use gasoline or other flammable vapours
and liquids in the vicinity of this or any other appliance.
A LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Owners &
Installation Manual
MODELS: PTO28CIT - NG1
PTO28CIT - LP1
www.regency-fire.com
09.17.15
Advertisement
Table of Contents
Summary of Contents for Regency Plateau
- Page 1 Owners & Plateau PTO28 City Table ® Installation Manual Outdoor Decorative Gas Appliance MODELS: PTO28CIT - NG1 PTO28CIT - LP1 WARNING: FOR OUTDOOR USE ONLY www.regency-fire.com WARNING: WARNING - FOR YOUR SAFETY If the information in these instructions What to do if you smell gas: are not followed exactly, a fire •Shut off gas to the appliance.
- Page 2 To the New Owner: Congratulations! You are the owner of a state-of-the-art Outdoor Decorative Gas Appliance by REGENCY . The City ® Table Outdoor Decorative Gas Appliance has been designed to provide you with all the warmth and charm of a fire at the flick of a switch. The City Table Outdoor Decorative Gas Appliance has been approved by Warnock Hersey/Intertek for both safety and efficiency.
-
Page 3: Table Of Contents
Operating Instructions ..........21 Lighting Procedure ............21 Shutdown Procedure ...........21 First Fire ..............21 Copy of Lighting Plate Instructions ......22 Maintenance Instructions..........23 Thermocouple replacement .........23 Valve assembly replacement ........24 Main assembly.............25 Burner assembly............26 Limited Warranty: ............27 Regency PTO28-1 City Table Outdoor Gas Fireplace... -
Page 4: Copy Of Safety Decal
Created draft for approval - Do not print Jan. 15/14: Added ànd CGA 2.17 as per R/D Feb.20/14: Updated Standard wording as per R/D For the State of Massachusetts, the appliances individual manual shut-off must be a t-handle type valve. Regency PTO28-1 City Table Outdoor Gas Fireplace... -
Page 5: Unit Dimensions - City Table
UNIT DIMENSIONS - CITY TABLE NOTE: Optional glass surround shown Regency PTO28-1 City Table Outdoor Gas Fireplace... -
Page 6: Important Message
California to cause cancer, birth defects or USED IN A BUILDING, GARAGE OR ANY other reproductive harm. OTHER ENCLOSED AREA. 4. Inspect the burner before each use of the appliance for blockage and any signs of deterioration. Regency PTO28-1 City Table Outdoor Gas Fireplace... -
Page 7: Installation Checklist
At least 30% of the remaining wall area is open and unrestricted 30% or more in total of the remaining wall area is open and unrestricted. Open side at least 25% of total wall area *SEE IMPORTANT INSTALLATION NOTES NEXT PAGE Regency PTO28-1 City Table Outdoor Gas Fireplace... -
Page 8: Outdoor Appliance Installation Summary
This will create a pressure zone • Only Regency approved media should be used in the firebox (i.e. at the firebox and will prevent the unit from venting stones/glass) •... -
Page 9: Minimum Clearances To Combustibles
When using supplied leveling legs. 1"(25mm) Unit Base to Floor : Floor E: Alcove Width 84"(2134mm) Wall to Wall (Minimum) F: Alcove Depth 72" (1829mm) Front to Back Wall (Maximum) Notes: 0" No Hearth Required Alcove Regency PTO28-1 City Table Outdoor Gas Fireplace... -
Page 10: High Elevation
Do not use open flame for leak testing. NOTE: This is a low pressure system. Pressure in excess of 14" will require a pressure regulator to reduce gas flow to appliance. 10 | Regency PTO28-1 City Table Outdoor Gas Fireplace... -
Page 11: Lp Tank Gas Connection
NOTE: If soap bubbles, this would indicate a gas leak. 5. Reverse step 1. Average LP Tank Burn Times High 20lb Tank 13 Hrs NOTE: Inspect hose before each use of appliance. Diagram 2 Butterfly Bolt Tank Holder Regency PTO28-1 City Table Outdoor Gas Fireplace... -
Page 12: Lp Hard Line Conversion(For Use In Place Of Lp Tank)
4. Secure regulator in position with top bracket - secure with 2 screws. NOTE: Top bracket to sit over top of lower bracket. Attach supplied "MAX. 0.5 PSI" sticker to top bracket. LP hose Bracket Diagram 2 Diagram 5 12 | Regency PTO28-1 City Table Outdoor Gas Fireplace 919-334 12/17/13... - Page 13 8. Check all gas connections (at valve, regulator, and LP outlet) under normal operating pressure, for leaks, with soapy water. NOTE: If soap bubbles, this would indicate a gas leak. 9. Check inlet and outlet pressures. 10. Reinstall panels. Regency PTO28-1 City Table Outdoor Gas Fireplace 919-334 12/17/13...
-
Page 14: Conversion From Lp To Ng
2. Remove outer tray by removing 8 screws in locations shown below in Diagram 2. 5. Remove LP orifi ce #50—replace with NG orifi ce #32. Diagram 2 Orifi ce Diagram 5 14 | Regency PTO28-1 City Table Outdoor Gas Fireplace 919-328 04/16/14... - Page 15 Attach supplied "MAX. 0.5 PSI" sticker to top bracket. NOTE: If soap bubbles, this would indicate a gas leak. 16. Check inlet and outlet pressures. 17. Reinstall panels. Bracket Diagram 9 919-328 Regency PTO28-1 City Table Outdoor Gas Fireplace 04/16/14...
-
Page 16: Table Top Installation
OPTIONAL THERMOCOUPLE SHIELD INSTALLATION For areas with high wind velocity - the supplied thermocouple shield should be installed, to prevent nuisance outages. 1. Install shield over thermocouple with one screw as shown. Thermocouple shield 16 | Regency PTO28-1 City Table Outdoor Gas Fireplace... -
Page 17: Glass Crystal / Basalt Volcanic Stones Installation
Note: shown w/ optional shield installed. NOTE: Basalt Volcanic Stones are NOT to be placed anywhere on the Pilot assembly area. Glass Crystals to be installed on the burner prior to installing stones. Regency PTO28-1 City Table Outdoor Gas Fireplace... -
Page 18: Log Set Installation
1. Install glass crystals on burner (see instructions in manual). 2. Install Log A on burner in the position shown below. 3. Install Log B in position shown below. Final Install 18 | Regency PTO28-1 City Table Outdoor Gas Fireplace 919-231a 06/10/13... -
Page 19: Optional Glass Surround Installation
Repeat process on other end. Press down fi rmly from to secure glass surround in position. Use care not to scratch surfaces. Regency PTO28-1 City Table Outdoor Gas Fireplace 919-214 12/06/12... -
Page 20: City Table Cover Installation
1. Place the weather cover over the entire table - when not in use. Diagram 1 Diagram 3 CAUTION: Never start the unit with the cover on. Let the unit cool before installing the cover. Turn off gas supply to unit before installing cover. 20 | Regency PTO28-1 City Table Outdoor Gas Fireplace... -
Page 21: Operating Instructions
« OFF » position. b) Wait 5 minutes - allow unit to cool. c) Clear any obstructions around the thermocouple. d) Repeat steps 3-6. DO NOT place hand over burner when lighting. Regency PTO28-1 City Table Outdoor Gas Fireplace... -
Page 22: Copy Of Lighting Plate Instructions
1. Shut off gas supply to appliance. 2. Laisser l'appareil refroidir à la température ambiante. 2. Allow unit to cool to room temperature 3. Reinstall cover. 3. Remettre le couvercle. DO NOT REMOVE THIS INSTRUCTION PLATE 919-329 22 | Regency PTO28-1 City Table Outdoor Gas Fireplace... -
Page 23: Maintenance Instructions
Maneuver thermocouple up out of slot, then push down into the unit. 1/4" Thermocouple Remove nut Diagram 4 - correct thermocouple position 5. Reverse steps 3 and 1 to reassemble unit. Diagram 2 Regency PTO28-1 City Table Outdoor Gas Fireplace... -
Page 24: Valve Assembly Replacement
9. Maneuver valve assembly up and out. 3. Slide burner away from orifice and remove as shown below in Diagram 3. Diagram 6 Diagram 3 10. Replace with new valve assembly. 11. Reverse steps 8 -1 24 | Regency PTO28-1 City Table Outdoor Gas Fireplace... -
Page 25: Main Assembly
Side Panel (4 slots) 286-028/G Side Panel (no slots) 286-025/G City Table Leaf Cover (Grey) 286-037 City Table Leaf Cover (Stainless) 286-938 Seasonal weather cover 948-054 Rubber legs (each) 919-326 Manual Not shown Supplied by others Regency PTO28-1 City Table Outdoor Gas Fireplace... -
Page 26: Parts List
Burner bracket 2 286-012 Burner bracket 3 911-151 Valve (Copreci) 286-017 Valve Bracket (Copreci) 286-016 Valve Holder 911-152 Knob 286-031 Thermocouple mount 911-150 Thermocouple 286-032 Burner Bracket 286-033 Valve Tray Heat Shield 26 | Regency PTO28-1 City Table Outdoor Gas Fireplace... -
Page 27: Limited Warranty
It is the general practice of FPI to charge for larger, higher priced replacement parts and issue credit once the replaced component has been returned to FPI and evaluated for manufacturer defect. The authorized selling dealer is responsible for all in-field service work carried out on your Regency product. FPI will not be liable for results or costs of ®... - Page 28 Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ Regency, Regency Plateau are registered trademarks of FPI Fireplace Products International Ltd. Printed in Canada © Copyright 2015, FPI Fireplace Products International Ltd. All rights reserved.
