INSTRUCTIONS. La sección en español empieza en la página 16. Avanti has a policy of continuous improvement on its products and reserves the right to change materials and specifications without notice. Avanti Products, A Division of The Mackle Co., Inc.
Care and Maintenance Cleaning Your Appliance Maintenance of Your Appliance Energy Saving Tips Troubleshooting Guide Service for Your Appliance Wiring Diagram Your Avanti Products Warranty Instrucciones en Español Registration Information and Registration Card TABLE OF CONTENTS 12 – 13 18-22...
All safety messages will alert you to what the potential hazard is, tell you how to reduce the chance of injury, and let you know what can happen if the instructions are not followed. CHEST FREEZER SAFETY Danger means that failure to heed this safety statement may result in severe personal injury or death.
• Do not attempt to repair or replace any part of your chest freezer unless it is specifically recommended in this material. All other servicing should be referred to a qualified technician. • Use two or more people to move and install the chest freezer. Failure to do so can result in back or other injury.
Keep it handy to answer your questions. If you don't understand something or you need more help, please call: Avanti Customer Service 800-220-5570 Keep proof of original purchase date (such as your sales slip) with this guide to establish the warranty period.
INCLUDED WITH ACCESSORIES IS A CLEAR CONTROL PANEL COVER , SLIDE COVER OVER CONTROL PANEL TO INSTALL AND SLIDE UP TO REMOVE SLIDE UP TO REMOVE PARTS AND FEATURES SLIDING GLASS LIDS DRAIN PLUG(not shown) ROLLERS LID LOCK CONTROL PANEL COVER THERMOSTAT CONTROL KNOB FAST FREEZE SWITCH POWER INDICATOR...
1 Plastic Control Panel Cover · Before connecting the freezer to the power source, let it stand upright for approximately 2 hours. This will reduce the possibility of a malfunction in the cooling system from handling during transportation. ·...
Never unplug the freezer by pulling the power cord. Always grip the plug firmly and pull straight out from the receptacle. Do not use an extension cord with this freezer. If the power cord is too short, have a qualified electrician or service technician install an outlet near the freezer.
• This switch is used to freeze unfrozen food in appreciable quantities. • When loading the freezer, freeze only three pounds of fresh food per cubic foot of freezer space at one time. • Distribute packages to be frozen evenly throughout the freezer.
We recommend using the plastic scraper provided with your unit. • Remove the frozen food from the freezer and place it in a cooler to protect the food. • Turn the thermostat knob to “OFF”.
Foods that freeze too slowly may lose quality, or spoil. • Be sure to wrap foods properly, and wipe containers dry before placing them in the freezer. This cuts down on frost build-up inside the freezer.
PROBLEMS WITH YOUR FREEZER ? You can solve many common freezer problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. PROBLEM Freezer does not operate.
Page 13
Moisture forms on inside freezer walls. Moisture forms on outside of freezer. The door will not close properly. Check to assure that the freezer is not on a level surface. Floor is uneven or weak. Freezer rocks on the floor when it is moved slightly. Be sure floor can adequately support freezer.
We are proud of our customer service organization and the network of professional service technicians that provide service on your Avanti appliances. With the purchase of your Avanti freezer, you can have the confidence that if you ever need additional information or assistance the Avanti Products Customer Service team will be here for you.
Cualquier consulta con respecto a la energía y/o cable de tierra debe ser dirigida a un electricista certificado o autorizado por el Servicio Técnico de Avanti Products. Conexión eléctrica Este electrodoméstico debe ser conectado a tierra. En el caso que ocurra un corto circuito, la conexión a tierra reduce el riesgo de recibir un choque eléctrico ya que cuenta con un alambre...
Page 17
El uso inapropiado del enchufe a tierra puede desencadenar un choque eléctrico. Consulte a personal autorizado por Avanti Productos si tiene alguna duda sobre las instrucciones o si tiene alguna consulta si el electrodoméstico está correctamente instalado a la corriente eléctrica y a tierra.
Page 18
Descongelando • Cuando descongelar? Para el mejor funcionamiento y consumo mínimo de energía de su congelador, descongele cuando las paredes internas estén llenas de escarcha o tengan un espesor de ¼ a ½ pulgada. • Escoja un momento cuando no tenga muchos alimentos en el congelador. •...
Page 19
CUIDADO Y MANTENIMIENTO Limpiando su Congelador • Después de instalar su congelador, se le recomienda que este sea limpiado a fondo. • Gire el control de temperatura a “0”, desconecte el congelador y retire los alimentos y la canasta de almacenaje.
Page 20
PROBLEMAS CON SU CONGELADOR Usted puede resolver muchos problemas comunes de su electrodoméstico fácilmente, ahorrándole el gasto de una posible visita del servicio técnico. Pruebe las siguientes sugerencias para verificar si usted puede resolver el problema antes de llamar al servicio técnico.
Page 21
Departamento de Servicio al Cliente de Avanti Products, estará con usted para responder cualquier consulta o inquietud que usted tenga. Sólo llámenos gratis a los siguientes números telefónicos.
Protect your product: We will keep the model number and date of purchase of your new Avanti product on file to help you refer to this information in the event of an insurance claim such as fire or theft.
