SERVICE MANUAL
DVD/CD PLAYER Hi-Fi STEREO VIDEO CASSETTE RECORDER

SPECIFICATIONS

GENERAL
Power supply:
110-220 V, 50/60 Hz
Power consumption:
Operation: 18 W
Stand by: 3 W
Weight:
7.9 lbs (3.6 kg)
Dimensions:
Width : 16-15/16 inches (430 mm)
Height : 3-7/8 inches (99 mm)
Depth : 9-13/16 inches (249 mm)
Inputs/Outputs:
Video:
In: 1 Vp-p/75 ohm
Out: 1 Vp-p/75 ohm
In: - 8 dBm/50 k ohm
Audio:
Out: - 8 dBm/1 k ohm
Antenna:
UHF/VHF IN/OUT: 75 ohm coaxial
Hi-Fi Frequency Response:
20 Hz to 20,000 Hz
Hi-Fi Dynamic Range:
More than 90 dB
VCR section
Video Head:
4 Rotary Heads
Audio Track:
Hi-Fi Sound - 2 Tracks / MONO Sound - 1 Track
Tuner:
181 Channel Freq. Synthesized
VHF
UHF
CATV
RF Channel Output:
Channel 3 or 4, Switchable
F.FWD/REW Time:
Approx. 1 minute 48 seconds (with T-120 Cassette Tape) (at + 25°C)
HR-XVC21UJ
2-13
14-69
14-36 (A)-(W)
37-59 (AA)-(WW)
60-85 (AAA)-(ZZZ)
86-94 (86)-(94)
95-99 (A-5)-(A-1)
100-125 (100)-(125)
01 (5A)
COPYRIGHT © 2003 VICTOR COMPANY OF JAPAN, LIMITED
DVD section
Signal system:
NTSC
Applicable disc:
DVD (12 cm, 8 cm), CD (12 cm, 8 cm)
Audio characteristics
Frequency response:
DVD: 4 Hz - 22 kHz
CD: 4 Hz - 20 kHz
S/N Ratio:
90 dB
Harmonic distortion
0.02%
Wow and flutter:
Less than 0.01% Wrms
Dynamic range:
More than 90 dB
Output:
Video :
Audio :
Digital Audio : 0.5 Vp-p 75 ohm
Pickup:
CD :
DVD : Wavelength: 640 - 660 nm
ACCESSORIES:
Remote control x 1
Batteries (2 x AA)
75 ohm Coaxial Cable x 1
AUDIO/VIDEO Cable x 1
Conversion plug x 1
(RCA) 1 Vp-p/75 ohm
(RCA) - 12 dBm/1k ohm
Wavelength: 775 - 805 nm
Maximum output power: 0.5 mW
Maximum output power: 1.0 mW
HR-XVC21UJ D2VP11
No.82990
2003/08
