Avanti Wine Cooler VM301W Parts List

Avanti products wine cooler parts list
Hide thumbs Also See for Wine Cooler VM301W:
1
2

Advertisement

Quick Links

Download this manual See also: Instruction Manual

Advertisement

loading

Related Manuals for Avanti Wine Cooler VM301W

Summary of Contents for Avanti Wine Cooler VM301W

  • Page 2 VM301W Spare Parts List No. Item Code 1 2.00.2TQ021-018 Foamed Cabinet 2 1.06.TQ6212-027 Hinge Hole Cover 3 1.11.01001TQ-01 Upper hinge 4 1.06.TQ3210-001 Upper Hinge Cover 5 1.13.G50130-104 Flange Screw 6 2.23.22TQ00-018 Evaporator 7 1.03.11TQ39-018 Drawer A 8 1.03.31TQ39-018 Drawer B 9 1.39.2TQ102-010 Door Gasket 10 1.06.TQ4310-001 Door hinge plug 11 2.01.F1TQ02-018 Foamed Door...
