Phonic Powerpod 415RW Easy Manual

GETTING STARTED

1. Before turning on the power, set the Main output control to the
"0" position.
2. Always turn the power off before connecting or disconnecting
cables.
3. Cleck the AC Voltage before connecting the AC plug.
4. Do not obstruct the back panel at all for proper ventilation.
BLUETOOTH SETUP
1. Set the "Wireless Pairing" switch to the ON position.
2. Enter your smartphone or tablet's Bluetooth setup options to
find the "Phonic.BT" Bluetooth device.
3. If requested, the password for the POWERPOD's Bluetooth
function is 0000. Many modern smartphones will enter this as
the default password.
4. Audio signals received through the Bluetooth interface will be
controlled by the rotary control on the face of the mixer.
5. To reset the connection, turn your smartphone or tablet's
Bluetooth connection off and then on again.
6. When using cell phones and tablets, it may be an idea to turn
"Airplane Mode" or "Flight Mode" on to stop phone calls or push
notifications from interrupting your audio.
Note: Not all modern Bluetooth-enabled devices allow for use of external
audio playback. In the case of laptops in particular, Bluetooth may be used
for data transmission only - depending on the model. This is a limitation of
these devices and you will not be able to use the POWERPOD 415RW's
Bluetooth function with these devices.
USB MODULE (PLAYBACK)
1.
Power on the device.
2.
Insert an appropriately formatted (FAT32) USB flash drive.
3.
Press the PLAY button to play the current track, or the << and
>> buttons to skip forward and backwards between tracks.
4. The POWERPOD 415RW can playback MP3 and WMA files.
5. Use the TAPE IN/USB IN level control to adjust the USB
player's volume.
6. Push and hold the STOP/MENU button to return to the main
menu.
Repeat Mode – There 4 repeat modes available.
No Repeat – Play each file in the current folder or root once.
Repeat One – Continuously repeat selected song.
Repeat Folder – Continuously repeat all the song in the current
folder or root directory.
Random – Enables random playback of files in current folder
or root.
This user guide was designed to make immediate setup as simple as possible. For more detailed operating instructions on
the POWERPOD 415RW, please find the full manual here: http://www.phonic.com/mixers/powerpod-415rw/
POWERPOD 415RW EASY MANUAL
USB MODULE (RECORDING)
1. Insert a FAT-32 formatted USB flash drive to the USB player.
2. In the main menu, select "Recordings" and press the PLAY
button to enter the recording function.
3. Here you have three options: 'Start voice recording,' 'Recordings
library,' and 'Storage'. To select the recording destination, enter
the 'Storage' menu and choose either the USB flash drive or the
internal storage (70MB available).
4. Select "Start voice recording" to begin recording immediately.
The unit will save an audio file to the selected storage destination.
5. Push the PLAY button to pause recording. Pushing the PLAY
button again will resume recording from the position at which it
was paused.
6.
Press the STOP/MENU button at any time to stop the recording.
The device will then ask if you wish to save your recording.
Select "Yes" or "No".
7. Press and hold the STOP/MENU button to return to the main
menu.
Note: As the quality of the flash drive can affect recording performance,
Phonic recommends using Sandisk brand drives to help ensure stable
recording performance.
USB MODULE STORAGE
The POWERPOD
approximately 70MB of onboard storage to use for playback. That
may sound small but that could mean up to 60 minutes of music at
128 Kbps, or a few hours of speech at 40 Kbps. To upload files to the
onboard storage, you will need a USB-A to USB-A cable. Connect the
USB connector on the face of the POWERPOD to your computer and
it will be recognized as a USB storage device. Simply copy your files
to the POWERPOD 415RW.
http://www.phonic.com
415RW USB player module features
