Page 2 Fiat Service authorised workshops you can find technicians who are trained by us, offering quality and professionalism for all your service requirements. Fiat workshops are always close to you for your servicing operations, repairs and seasonal checks and our experts will offer practical recommendations for keeping your car in the best possible condition.
Page 4 All our Genuine Parts undergo rigorous testing, both in design and build stages, by specialists who check the use of cutting-edge materials and test their reliability. This guarantees performance and safety in the long term for both you and the passengers in your automobile. Always insist on a Genuine Part and check that it has been used.
Page 5 • the Warranty Certificate with terms and conditions for maintaining its validity • the range of additional services available to Fiat customers. Enjoy the read. Happy motoring! This Owner Handbook describes all versions of the Fiat Freemont; please consider only the information relevant to your version, engine and configuration.
Page 7: Knowing Your Vehicle
Operating this vehicle at excessive speeds or while VEHICLE intoxicated may result in loss of control, collision with Congratulations on selecting your new FIAT vehicle. Be other vehicles or objects, going off the road, or over- assured that it represents precision workmanship, dis- turning;...
Page 8 IMPORTANT NOTICE The Owner's Manual illustrates and describes the fea- KNOWING tures that are standard or available as extra cost op- ALL MATERIAL CONTAINED IN THIS PUBLICA- YOUR tions. Therefore, some of the equipment and accesso- VEHICLE TION IS BASED ON THE LATEST INFORMATION ries in this publication may not appear on your vehicle.
Page 10 HOW TO USE THIS MANUAL The detailed index at the back of this Owner's Manual KNOWING contains a complete listing of all subjects. Consult the Table of Contents to determine which YOUR VEHICLE section contains the information you desire. Consult the following table for a description of the symbols that may be used on your vehicle or through- Since the specification of your vehicle depends on the out this Owner's Manual:...
Page 11: Vehicle Modifications
VEHICLE MODIFICATIONS/ KNOWING ALTERATIONS YOUR VEHICLE WARNING! Any modifications or alterations to this SAFETY vehicle could seriously affect its road- worthiness and safety and may lead to a collision resulting in serious injury or death. STARTING DRIVING WARNING LIGHTS MESSAGES IN AN EMERGENCY SERVICING...
Page 12: Instrument Panel Features
INSTRUMENT PANEL FEATURES KNOWING (fig. 2) YOUR VEHICLE SAFETY STARTING DRIVING WARNING LIGHTS MESSAGES IN AN EMERGENCY SERVICING AND CARE TECHNICAL (fig. 2) SPECIFICATIONS 1 — Side Window Demist Outlet 6 — Switch Bank 11 — Engine Start/Stop Button 2 — Air Outlet 7 —...
Page 13 INSTRUMENTS KNOWING (fig. 3) YOUR VEHICLE 1. Tachometer 2. Speedometer This gauge measures engine revolutions per minute Shows the vehicle speed. SAFETY (RPM x 1000). Before the pointer reaches the red area, 3. Fuel Gauge ease up on the accelerator to prevent engine damage. The fuel gauge shows the level of fuel in the tank when STARTING ignition switch is in the ON/RUN position.
Page 14 A WORD ABOUT YOUR KEYS 4. Coolant Temperature Gauge KNOWING The temperature gauge indicates engine coolant tem- Your vehicle uses a keyless ignition system. This system YOUR perature. Any reading within the normal range indi- VEHICLE consists of a Key Fob with Remote Keyless Entry (RKE) cates that the cooling system is operating satisfactorily.
Page 15 Key Fob To remove the emergency key, slide the mechanical KNOWING latch on the side of the Key Fob sideways with your The Key Fob also contains the Remote Keyless Entry YOUR thumb and then pull the key out with your other hand. (RKE) transmitter and an emergency key, which stores VEHICLE (fig.
Page 16 NOTE: With the Uconnect® system, the power win- (Continued) KNOWING dow switches, radio, power sunroof (for versions/ • Do not leave the Key Fob in or near the vehicle YOUR markets, where provided), and power outlets will re- VEHICLE or in a location accessible to children, and do not main active for up to 10 minutes after the ignition is leave the ignition in the ACC or ON/RUN posi- cycled to the OFF position.
Page 17: Sentry Key
SENTRY KEY® All of the Key Fobs provided with your new vehicle KNOWING have been programmed to the vehicle electronics. The Sentry Key® Immobilizer system prevents unau- YOUR VEHICLE thorized vehicle operation by disabling the engine. The Replacement Keys system does not need to be armed or activated. Op- NOTE: Only Key Fobs that are programmed to the eration is automatic, regardless of whether the vehicle SAFETY...
Page 18 REMOTE KEYLESS ENTRY (RKE) CUSTOMER KEY PROGRAMMING KNOWING Programming Key Fobs or RKE transmitters may be The RKE system allows you to lock or unlock the YOUR VEHICLE performed at an authorized dealer. doors and liftgate from distances up to approximately 20 m using a hand-held Key Fob with RKE transmitter.
Page 19 turn signal lights will flash to acknowledge the unlock Turn Headlights On With Remote Key Unlock KNOWING signal. The illuminated entry system will also turn on. This feature activates the headlights for up to 90 sec- YOUR onds when the doors are unlocked with the RKE VEHICLE If the vehicle is equipped with Passive Entry, refer to transmitter.
Page 20 NOTE: 3. Remove the battery by turning the back cover over KNOWING (battery facing downward) and tapping it lightly on a • Perchlorate Material — special handling may apply. YOUR solid surface such as a table or similar, then replace VEHICLE Batteries could contain dangerous materials.
Page 21: Vehicle Security Alarm
VEHICLE SECURITY ALARM GENERAL INFORMATION KNOWING Transmitter and receivers operate on a carrier fre- The Vehicle Security Alarm (VSA) system monitors the YOUR quency of 434 MHz as required by EEC regulations. VEHICLE vehicle doors, hood, and liftgate for unauthorized en- These devices must be certified to conform to specific try and the ignition switch for unauthorized operation.
Page 22 • Press the LOCK button on the exterior Passive • The Vehicle Security Alarm remains armed during KNOWING Entry Door Handle with a valid Key Fob available in power liftgate entry. Pressing the liftgate button will YOUR the same exterior zone (refer to "Keyless Enter-N- not disarm the Vehicle Security Alarm.
Page 23 PREMIUM SECURITY SYSTEM TO ARM THE SYSTEM KNOWING (for versions/markets, where Follow these steps to arm the theft alarm: YOUR provided) VEHICLE 1. Make sure the vehicle ignition system is "OFF". (refer to "Starting Procedures" in "Starting And The Premium Security system monitors the doors, Driving"...
Page 24 • The ultrasonic intrusion sensor (motion detector) NOTE: KNOWING actively monitors your vehicle every time you arm • The driver's door key cylinder and the trunk button YOUR the security system. If you prefer, you can turn OFF VEHICLE on the RKE transmitter cannot arm or disarm the the ultrasonic intrusion sensor and vehicle tilt sensor Vehicle Security Alarm.
Page 25: Steering Wheel Lock
STEERING WHEEL LOCK ELECTRONIC VEHICLE KNOWING (for versions/markets, where INFORMATION CENTER (EVIC) YOUR provided) VEHICLE The Electronic Vehicle Information Center (EVIC) fea- tures a driver-interactive display that is located in the Your vehicle may be equipped with a passive electronic instrument cluster.
Page 26 • Tire Pressure • DOWN Button KNOWING YOUR • Vehicle Information Press and release the DOWN button to VEHICLE scroll downward through the main menus • Warning Message Displays and sub-menus. • Turn Menu OFF • SELECT Button SAFETY The system allows the driver to select information by Press and release the SELECT button for pressing the following buttons mounted on the steer- access to main menus or sub-menus.
Page 27 The main display area will normally display the main • Five Second Unstored Messages KNOWING menu or the screens of a selected feature of the main When the appropriate conditions occur, this type of YOUR menu. The main display area also displays "pop up" message takes control of the main display area for five VEHICLE messages that consist of approximately 60 possible...
Page 28 • Oil Change Required (with a single chime) • Left/Right Front Door Ajar (one or more doors KNOWING open, with a single chime if speed is above 1.6 km/h) YOUR • Check Gascap (refer to “Adding Fuel” in “Knowing VEHICLE •...
Page 29 EVIC WHITE TELLTALE LIGHTS EVIC AMBER TELLTALE LIGHTS KNOWING This area will show reconfigurable white caution tell- This area will show reconfigurable amber caution tell- YOUR tales. These telltales include: tales. These telltales include: VEHICLE • Shift Lever Status — Automatic Transmission •...
Page 30 EVIC RED TELLTALE LIGHTS If jump starting is required, refer to “Jump Starting KNOWING Procedures” in “In An Emergency”. This area will show reconfigurable red telltales. These YOUR VEHICLE telltales include: • Electronic Throttle Control (ETC) Light This light informs you of a problem with the •...
Page 31 single chime will sound after reaching a set threshold. WARNING! KNOWING Further overheating will cause the temperature gauge YOUR If you continue operating the vehicle to pass H, a continuous chime will occur until the VEHICLE when the Transmission Temperature engine is allowed to cool.
Page 32 KNOWING YOUR VEHICLE SAFETY STARTING DRIVING WARNING LIGHTS MESSAGES (fig. 10) (fig. 12) GSI Shift Up (+) Indicator — Automatic Transmission GSI Shift Down (-) Indicator — Automatic Transmission IN AN EMERGENCY SERVICING AND CARE TECHNICAL SPECIFICATIONS CONTENTS (fig. 11) (fig.
Page 33 NOTE: Significant changes in driving style or vehicle the BACK button. To reset the oil change indicator MESSAGES loading will greatly affect the actual drivable distance of system please refer to a Fiat Dealership. the vehicle, regardless of the DTE displayed value. IN AN FUEL ECONOMY EMERGENCY Press and release the UP or DOWN button until “Fuel...
Page 34 When the DTE value is less than 48 km estimated VEHICLE SPEED KNOWING driving distance, the DTE display will change to a Press and release the UP or DOWN button until YOUR “LOW FUEL” message. This display will continue until VEHICLE “Vehicle Speed”...
Page 35 The Trip Functions mode displays the following infor- VEHICLE INFO (CUSTOMER KNOWING mation: INFORMATION FEATURES) YOUR (for versions/markets, where provided) VEHICLE Trip A Press and release the UP or DOWN button until Shows the total distance traveled for Trip A since the “Vehicle Info”...
Page 36 Uconnect® SETTINGS MESSAGES KNOWING In the Main Menu, press and release the UP or DOWN YOUR HARD-KEYS VEHICLE button until “Messages: XX” displays highlighted in the Hard-Keys are located on the left and right side of the EVIC. If there is more than one message, pressing the Uconnect®...
Page 37 Press the "Settings" hard-key to access the Settings • Mode (for versions/markets, where provided) KNOWING screen, use the Page Up/Down soft-keys to scroll Press the Mode soft-key to change this display. When in YOUR through the following settings. Touch the desired set- this display you may select one of the auto display VEHICLE ting soft key to change the setting using the description...
Page 38 Then, as you continue, the information will display in Clock KNOWING the selected language. • Set Time YOUR VEHICLE Press the Set Time soft-key to change this display. • Units When in this display you may select the time display Press the Units soft-key to change this display.
Page 39 Safety / Assistance or 90 seconds when exiting the vehicle. To change the KNOWING Headlight Off Delay status press the 0, 30, 60 or 90 • Park Assist (for versions/markets, where provided) YOUR soft-key followed by pressing the arrow back soft-key. VEHICLE Press the Park Assist soft-key to change this display.
Page 40 • Auto High Beams “SmartBeam™” (for versions/ the Auto Unlock on Exit soft-key, select On or Off KNOWING markets, where provided) followed by pressing the arrow back soft-key. YOUR Press the Auto High Beams soft-key to change this VEHICLE • Flash Lights with Lock (for versions/markets, display.
Page 41 grasped. If Driver Door 1st Press is programmed, only Engine Off Options KNOWING the driver’s door will unlock when the driver’s door is • Headlight Off Delay YOUR grasped. With Passive Entry, if Driver Door 1st Press is VEHICLE Press the Headlight Off Delay soft-key to change this programmed touching the handle more than once will display.
Page 42 Compass Settings sate for the differences, and provide the most accurate KNOWING compass heading. • Variance (for versions/markets, where provided) YOUR VEHICLE Press the Variance soft-key to change this display. NOTE: Keep magnetic materials away from the top Compass Variance is the difference between Magnetic of the instrument panel, such as iPod's, Mobile Phones, North and Geographic North.
Page 43 • Calibration (for versions/markets, where provided) • Balance / Fade (for versions/markets, where KNOWING Press the Calibration key to change this setting. This provided) YOUR compass is self-calibrating, which eliminates the need Press the Balance / Fade soft-key to change this display. VEHICLE to manually reset the compass.
Page 44 CUSTOMER PROGRAMMABLE FEATURES — selecting any point on the scale in between the + and – KNOWING Uconnect® 8.4 SETTINGS soft-keys followed by pressing the arrow back soft-key. YOUR VEHICLE In this mode the Uconnect® system allows you to • Display Brightness with Headlights OFF access programmable features that may be equipped (for versions/markets, where provided) such as Display, Clock, Safety/Assistance, Lights, Doors...
Page 45 • Voice Response Length (for versions/markets, press and release the On or Off soft-key followed by KNOWING where provided) pressing the arrow back soft-key. YOUR When in this display you may change the Voice Re- VEHICLE • Set Time Hours sponse Length settings.
Page 46 Safety / Assistance • Hill Start Assist (for versions/markets, where KNOWING provided) • Park Assist (for versions/markets, where provided) YOUR When this feature is selected, the Hill Start Assist VEHICLE The Rear Park Assist system will scan for objects (HSA) system is active. Refer to “Electronic Brake behind the vehicle when the transmission shift lever is Control System”...
Page 47 • Headlights with Wipers (for versions/markets, • Flash Headlights With Lock (for versions/ KNOWING where provided) markets, where provided) YOUR When this feature is selected, and the headlight switch When this feature is selected, the front and rear turn VEHICLE is in the AUTO position, the headlights will turn on signals will flash when the doors are locked or unlocked approximately 10 seconds after the wipers are turned...
Page 48 • 1st Press of Key Fob Unlocks (for versions/ the Passive Entry soft-key, select ON or OFF followed KNOWING markets, where provided) by pressing the arrow back soft-key. Refer to “Keyless YOUR When Unlock Driver Door Only On 1st Press is Enter-N-Go™”...
Page 49 Compass Settings NOTE: Keep magnetic materials away from the top KNOWING of the instrument panel, such as iPod's, Mobile Phones, • Variance (for versions/markets, where provided) YOUR Laptops and Radar Detectors. This is where the com- VEHICLE Compass Variance is the difference between Magnetic pass module is located, and it can cause interference North and Geographic North.
Page 50 • Perform Compass Calibration (for versions/ NOTE: Bass/mid/treble allow the you to simply slide KNOWING markets, where provided) your finger up/down to change the setting as well as YOUR Press the Calibration key to change this setting. This press directly on the desired setting. VEHICLE compass is self-calibrating, which eliminates the need •...
Page 51 SEATS Adjusting The Seat Up Or Down KNOWING The height of the seats can be adjusted up or down. Pull Seats are a part of the Occupant Restraint System of YOUR upward or push downward on the seat switch, the seat VEHICLE the vehicle.
Page 52 POWER LUMBAR (for versions/markets, WARNING! KNOWING where provided) YOUR • Adjusting a seat while driving may be VEHICLE The Power Lumbar switch is located on the outboard dangerous. Moving a seat while driving side of the driver's seat. Push the switch forward to could result in loss of control which could cause a increase the lumbar support.
Page 53 When the HI-level setting is selected, the heater will WARNING! KNOWING provide a boosted heat level during the first four YOUR • Persons who are unable to feel pain to minutes of operation. Then, the heat output will drop VEHICLE the skin because of advanced age, to the normal HI-level.
Page 54 Touch the “Driver” or “Passenger” seat soft- MANUAL FRONT SEAT ADJUSTMENTS KNOWING key once to select HI-level heating. Touch the For models equipped with manual seats, the driver and YOUR soft-key a second time to select LO-level VEHICLE passenger seats can be adjusted forward or rearward heating.
Page 55 WARNING! WARNING! KNOWING YOUR • Adjusting a seat while driving may be • Adjusting a seat while the vehicle is VEHICLE dangerous. Moving a seat while driving moving is dangerous.The sudden move- could result in loss of control which could cause a ment of the seat could cause you to lose control.
Page 56 DRIVER'S SEAT HEIGHT ADJUSTMENT Pull upward on the recline lever to fold or unfold the KNOWING seat. The seat height control lever is located on the out- YOUR VEHICLE board side of the seat. Raise the lever to raise the seat. WARNING! Lower the lever to lower the seat.
Page 57 When AHRs deploy during a rear impact, the front half WARNING! KNOWING of the head restraint extends forward to minimize the YOUR The head restraints for all occupants gap between the back of the occupant’s head and the VEHICLE must be properly adjusted prior to oper- AHR.
Page 58 For comfort, the Active Head Restraints can be tilted NOTE: KNOWING forward and backward. To tilt the head restraint closer • The head restraints should only be removed by YOUR to the back of your head, pull forward on the bottom of VEHICLE qualified technicians, for service purposes only.
Page 59 NOTE: WARNING! KNOWING • The head restraints should only be removed by qualified YOUR • Do not place items over the top of the VEHICLE technicians, for service purposes only. If any of the head Active Head Restraint, such as coats, restraints require removal, see your authorized dealer.
Page 60 THIRD ROW PASSENGER SEATS WARNING! KNOWING (Seven Passenger Models) YOUR • It is extremely dangerous to ride in a VEHICLE These head restraints are non-adjustable and non- cargo area, inside or outside of a vehicle. removable. However, you can fold them forward when In a collision, people riding in these areas are they are not in use by passengers.
Page 61 3. Lift the control lever with the other hand, allow the WARNING! KNOWING seatback to move forward slightly, and then release YOUR Be certain that the seatback is locked the lever. VEHICLE securely into position. Otherwise, the seat will not provide the proper stability for child WARNING! seats and/or passengers.
Page 62 WARNING! WARNING! KNOWING YOUR Adjusting a seat while the vehicle is mov- • Adjusting a seat while the vehicle is VEHICLE ing is dangerous.The sudden movement moving is dangerous.The sudden move- of the seat could cause you to lose control. The ment of the seat could cause you to lose control.
Page 63 To Move The Second-Row Passenger Seat WARNING! KNOWING Forward YOUR Keep the latch clean and free of objects VEHICLE NOTE: Raise the seatback/armrest before moving the and be certain that the seatback/ seat to allow for full seat travel. armrest is locked securely into position. Other- wise, the seat will not provide the proper stability Move the control lever on the upper outboard side of SAFETY...
Page 64 Adjust the seat track position as desired. Using body WARNING! KNOWING pressure, move forward and rearward on the seat to be YOUR Do not drive the vehicle with the seat in sure that the seat adjusters have latched. VEHICLE this position, as it is only intended for entering and exiting the third row seats.
Page 65 To Fold The Seatback To Unfold The Seatback KNOWING Pull the latch release-loop located at the top of the Grasp the assist strap loop on the seatback and pull it YOUR seatback upward, push the seatback forward slightly, toward you to raise the seatback. Continue to raise the VEHICLE and release the release-loop.
Page 66 TILT/TELESCOPING STEERING WARNING! KNOWING COLUMN YOUR • Be certain that the seatback is locked VEHICLE This feature allows you to tilt the steering column securely into position. Otherwise, the upward or downward. It also allows you to lengthen or seat will not provide the proper stability for shorten the steering column.
Page 67: Heated Steering Wheel
HEATED STEERING WHEEL WARNING! KNOWING (for versions/markets, where YOUR Do not adjust the steering column while provided) VEHICLE driving. Adjusting the steering column The steering wheel contains a heating element that while driving or driving with the steering column unlocked could cause the driver to lose control of helps warm your hands in cold weather.
Page 68 WARNING! KNOWING YOUR • Persons who are unable to feel pain to VEHICLE the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medi- cation, alcohol use, exhaustion or other physical SAFETY condition must exercise care when using the seat heater.
Page 69 MIRRORS AUTOMATIC DIMMING MIRROR KNOWING (for versions/markets, where provided) YOUR INSIDE DAY/NIGHT MIRROR This mirror automatically adjusts for headlight glare VEHICLE A two-point pivot system allows for horizontal and from vehicles behind you. This feature will be defaulted vertical adjustment of the mirror. Adjust the mirror to on, and only be disabled when the vehicle is moving in center on the view through the rear window.
Page 70 OUTSIDE MIRRORS Models Without Express Window Feature KNOWING To receive maximum benefit, adjust the outside mir- Press the mirror select button marked L (left) or YOUR VEHICLE ror(s) to center on the adjacent lane of traffic and a R (right) and then press one of the four arrow buttons slight overlap of the view obtained from the inside to move the mirror in the direction the arrow is mirror.
Page 71 POWER FOLDING MIRRORS (for ILLUMINATED VANITY MIRRORS KNOWING versions/markets, where provided) (for versions/markets, where provided) YOUR The switch for the power folding mirrors is located An illuminated vanity mirror is on each sun visor. To use VEHICLE between the power mirror switches L (left) and R (right). the mirror, rotate the sun visor downward and swing the Press the switch once and the mirrors will fold in, mirror cover upward.
Page 72: Climate Controls
CLIMATE CONTROLS KNOWING The air conditioning and heating system is designed to YOUR VEHICLE make you comfortable in all types of weather. This system can be operated through either the instrument panel or through the Uconnect® system display. SAFETY When the Uconnect® system is in different modes (Radio, Player, Settings, More, etc.) the driver and STARTING passenger temperature settings will be indicated at the...
Page 73 Button Descriptions KNOWING (Applies To Both Hard-keys And Soft-keys) YOUR VEHICLE 1. MAX A/C Button Press and release to change the current setting, the indicator illuminates when MAX A/C is ON. Perform- SAFETY ing this function again will cause the MAX A/C opera- tion to switch into manual mode and the MAX A/C indicator will turn off.
Page 74 5. Rear Defrost Button 7. Passenger Temperature Control Up Button KNOWING Press and release this button to turn on the rear (Uconnect® 8.4 Only) YOUR window defroster and the heated outside mirrors (for Provides the passenger with independent temperature VEHICLE versions/markets, where provided).
Page 75 The speeds can be selected using either hard-keys or • Bi-Level Mode KNOWING soft-keys as follows: Air comes from the instrument panel outlets and YOUR floor outlets. A slight amount of air is directed VEHICLE Hard-key through the defrost and side window demister outlets. The blower speed increases as you turn the control NOTE: BI-LEVEL mode is designed under comfort clockwise from the lowest blower setting.
Page 76 14. Driver Temperature Control Up Button NOTE: KNOWING (Uconnect® 8.4 Only) • For Manual Climate Controls, if the system is in Mix, YOUR Provides the driver with independent temperature con- VEHICLE Floor or Defrost Mode, the A/C can be turned off, trol.
Page 77 Rear Manual Temperature Control Recirculation Control KNOWING (MTC) (for versions/markets, YOUR When outside air contains smoke, odors, or where provided) VEHICLE high humidity, or if rapid cooling is desired, The rear MTC system has floor air outlets at the rear you may wish to recirculate interior air by right side of the 3rd Row seats and overhead outlets at SAFETY...
Page 78 To change the rear system settings: the rear display. The rear temperature and air source KNOWING are controlled from the front Uconnect® system. • Press "REAR" button to change control to rear YOUR VEHICLE control mode, Rear display (below) will appear. Con- •...
Page 79 Rear Lock Rear Blower Control KNOWING The rear blower control knob can be manually set to • Pressing the Rear Temperature Lock soft-key on the YOUR off, or any fixed blower speed, by rotating the knob VEHICLE Uconnect® touch-screen, illuminates a lock symbol in from low to high.
Page 80 Automatic Temperature Control Rear Mode Control KNOWING (ATC) With Touchscreen (for • Headliner Mode YOUR VEHICLE versions/markets, where provided) Air comes from the outlets in the headliner. Each of these outlets can be individually adjusted Hard-Keys to direct the flow of air. Moving the air vanes of the SAFETY Hard-keys are located on the left and right side of the outlets to one side will shut off the airflow.
Page 81 Button Descriptions KNOWING (Applies To Both Hard-keys And Soft-keys) YOUR VEHICLE 1. MAX A/C Button Press and release to change the current setting, the indicator illuminates when MAX A/C is ON. Perform- SAFETY ing this function again will cause the MAX A/C opera- tion to switch into manual mode and the MAX A/C indicator will turn off.
Page 82 3. Recirculation Button Failure to follow these cautions can KNOWING Press and release to change the current setting, the YOUR cause damage to the heating elements: indicator illuminates when ON. VEHICLE • Use care when washing the inside of 4. AUTO Operation Button the rear window.
Page 83 9. Passenger Temperature Control Down Button Soft-key KNOWING Provides the passenger with independent temperature Use the small blower icon to reduce the blower setting YOUR control. Push the button for cooler temperature set- VEHICLE and the large blower icon to increase the blower tings.
Page 84 • Floor Mode 15. Driver Temperature Control Up Button KNOWING Air comes from the floor outlets. A slight Provides the driver with independent temperature YOUR amount of air is directed through the defrost control. Push the button for warmer temperature VEHICLE and side window demister outlets.
Page 85 NOTE: Recirculation Control KNOWING • If fog or mist appears on the windshield or side glass, YOUR When outside air contains smoke, odors, or VEHICLE select Defrost mode and increase blower speed. high humidity, or if rapid cooling is desired, •...
Page 86 Automatic Temperature Control (ATC) To provide you with maximum comfort in the Auto- KNOWING matic mode, during cold start-ups the blower fan will YOUR Automatic Operation remain on low until the engine warms up. The blower VEHICLE 1. Press the AUTO hard-key or soft-key button (4) on will increase in speed and transition into Auto mode.
Page 87 Rear Automatic Temperature To change the rear system settings: KNOWING Control (ATC) (for versions/ • Press "REAR" button to change control to rear YOUR markets, where provided) VEHICLE control mode, Rear display (below) will appear. Con- trol functions now operate rear system. The rear ATC system has floor air outlets at the rear right side of the 3rd Row seats and overhead outlets at •...
Page 88 Rear Lock The rear ATC is located in the headliner, near the KNOWING center of the vehicle. (fig. 60) Pressing the Rear Temperature Lock soft-key on the YOUR • Press the Rear Temperature Lock button on the VEHICLE Uconnect® touch-screen, illuminates a lock symbol in Uconnect®...
Page 89 Once the desired temperature is displayed, the ATC Rear Temperature Control KNOWING System will automatically achieve and maintain that To change the temperature in the rear of the vehicle, YOUR comfort level. When the system is set up for your rotate the temperature knob counterclockwise to VEHICLE comfort level, it is not necessary to change the settings.
Page 90 A solution of 50% OAT (Organic Additive mild but rainy or humid weather. Technology) coolant that meets the requirements of NOTE: Fiat Classification 9.55522 and 50% water is recom- SERVICING • Recirculation mode without A/C should not be used mended. Refer to “Maintenance Procedures” in “Ser- AND CARE for long periods, as fogging may occur.
Page 91 Outside Air Intake A/C Air Filter KNOWING Make sure the air intake, located directly in front of the The climate control system filters outside air contain- YOUR windshield, is free of obstructions such as leaves. ing dust, pollen and some odors. Strong odors cannot VEHICLE Leaves collected in the air intake may reduce airflow, be totally filtered out.
Page 92 LIGHTS AUTOMATIC HEADLIGHTS KNOWING (for versions/markets, where provided) YOUR HEADLIGHT SWITCH VEHICLE This system automatically turns the headlights on or off according to ambient light levels. To turn the system The headlight switch is located on the left side of on, rotate the headlight switch counterclockwise to the instrument panel.
Page 93 HEADLIGHT TIME DELAY The front and rear fog lights may be operated as KNOWING desired when visibility is poor due to fog. The fog This feature provides the safety of headlight illumina- YOUR lights will activate in the following order: Press tion for up to 90 seconds when leaving your vehicle in VEHICLE the headlight switch once and the front fog lights...
Page 94 MULTIFUNCTION LEVER NOTE: KNOWING The multifunction lever controls the operation of the • If either light remains on and does not flash, or there YOUR VEHICLE turn signals, headlight beam selection and passing lights. is a very fast flash rate, check for a defective outside The multifunction lever is located on the left side of the light bulb.
Page 95 FLASH-TO-PASS DIMMER CONTROLS KNOWING You can signal another vehicle with your headlights by The dimmer control is part of the headlight switch and YOUR lightly pulling the multifunction lever toward you. This is located on the left side of the instrument panel. VEHICLE will turn on the high beams headlights until the lever is (fig.
Page 96 DOME LIGHT POSITION To operate, rotate the headlight leveling switch until KNOWING the appropriate number, which corresponds to the Rotate the dimmer control completely upward to the YOUR load listed on the following chart, illuminates on the VEHICLE second detent to turn on the interior lights. The switch.
Page 97: Illuminated Entry
ILLUMINATED ENTRY WINDSHIELD WIPERS AND KNOWING WASHERS The courtesy lights will turn on when you use the YOUR VEHICLE Remote Keyless Entry (RKE) transmitter to unlock the The windshield wiper/washer control lever is located doors or open any door or liftgate. on the left side of the steering column.
Page 98 INTERMITTENT WIPER SYSTEM NOTE: The wiper delay times depend on vehicle KNOWING speed. If the vehicle is moving less than 16 km/h, delay Use the intermittent wiper system when weather con- YOUR times will be doubled. VEHICLE ditions make a single wiping cycle, with a variable pause between cycles, desirable.
Page 99 If you activate the washer while the wiper control is in • Turn the windshield wipers OFF when KNOWING the OFF position, the wipers will operate for two or driving through an automatic car wash. YOUR three wipe cycles and then turn OFF. VEHICLE Damage to the windshield wipers may result if the wiper control is left in any position...
Page 100 HEADLIGHT WASHERS REAR WINDOW FEATURES KNOWING (for versions/markets, where YOUR REAR WINDOW WIPER/WASHER VEHICLE provided) The rear window wiper/washer control is located on The Headlight Washers are recessed into the top of the right side of the steering column. (fig. 69) the fascia, centrally located below each headlight.
Page 101 Rotate the switch upward past the first detent • Turn the rear wiper off when driving KNOWING position to activate the rear washer. The washer through an automatic car wash. Damage YOUR VEHICLE pump will continue to operate as long as the switch is to the rear wiper may result if the rear held.
Page 102 ELECTRONIC SPEED CONTROL REAR WINDOW DEFROSTER KNOWING When engaged, the Electronic Speed Control takes YOUR The rear window defroster button is located on VEHICLE over accelerator operations at speeds greater than the climate control panel. Press this button to 40 km/h. (fig.
Page 103 TO ACTIVATE vehicle will deactivate Electronic Speed Control with- KNOWING out erasing the set speed memory. Pressing the ON/ Push the ON/OFF button. The Cruise Indicator Light YOUR OFF button or turning the ignition switch OFF erases in the instrument cluster will illuminate. To turn the VEHICLE the set speed memory.
Page 104 OVERHEAD CONSOLE TO ACCELERATE FOR PASSING KNOWING Press the accelerator as you would normally. When the The overhead console contains courtesy/reading lights, YOUR VEHICLE pedal is released, the vehicle will return to the set storage for sunglasses, an interior observation mirror speed.
Page 105 COURTESY/READING LIGHTS SUNGLASSES STORAGE KNOWING The overhead console has two courtesy lights. The To access the storage compartment, press on the YOUR lights turn on when a door or the liftgate is opened. raised bars on the compartment door in the center of VEHICLE If your vehicle is equipped with Remote Keyless Entry the console and release and the door will swing down-...
Page 106 INTERIOR OBSERVATION MIRROR POWER SUNROOF SWITCH KNOWING (for versions/markets, where provided) The convex interior observation mirror provides the YOUR VEHICLE driver and front seat passenger a wide field of view to Refer to “Power Sunroof” for further information. conveniently view passengers sitting in the rear passen- ger seats.
Page 107: Hazard Warning Flashers
HAZARD WARNING FLASHERS STORAGE KNOWING The Hazard Warning flasher switch is located in the YOUR GLOVEBOX STORAGE VEHICLE instrument panel switch bank, above the climate The glovebox storage compartment is located on the controls. passenger side of the instrument panel. Pull on the Press the switch to turn on the Hazard Warning release handle to open the glovebox storage compart- SAFETY...
Page 108 FLOOR CONSOLE STORAGE KNOWING An open storage area, or cubby bin, is located in the YOUR VEHICLE floor console. (fig. 77) CENTER CONSOLE STORAGE There is a storage compartment located under the SAFETY center console armrest. (fig. 78) Pull upward on the release handle, located on the front STARTING of the lid, to open the storage compartment.
Page 109 FLIP 'N STOW™ FRONT PASSENGER SEAT WARNING! KNOWING STORAGE (for versions/markets, where YOUR Do not operate this vehicle with a con- provided) VEHICLE sole compartment lid in the open posi- The seat latch release-loop is located in the center of tion.
Page 110 SECOND-ROW PASSENGER SEAT WARNING! KNOWING TEMPORARY STORAGE BIN YOUR Be certain that the seat cushion is VEHICLE This is a temporary storage bin designed for use when locked securely into position before us- the seatback/armrest is down. Be sure to remove all ing the seat.
Page 111 IN-FLOOR STORAGE BIN WITH The liner can be removed for easy cleaning by lifting on KNOWING REMOVABLE LINER the notches as shown. (fig. 84) YOUR VEHICLE NOTE: Position the front seat to at least a mid-track position to provide easier access to the storage bin. An in-floor storage bin is located behind each front SAFETY seat.
Page 112 ELECTRICAL POWER OUTLETS This power outlet will also operate a conventional cigar KNOWING lighter unit. To preserve the heating element, do A 12 Volt (13 Amp) power outlet is located in the YOUR not hold the lighter in the heating position. VEHICLE center console below the radio.
Page 113 A third fused 12 Volt power outlet is located on the A fourth fused 12 Volt power outlet is located on the KNOWING back of the center console. This power outlet has left quarter trim panel in the cargo area. This power YOUR power available when the ignition switch is in the outlet has power available when the ignition switch is in...
Page 114 • Do not exceed the maximum power WARNING! KNOWING YOUR of 160 Watts (13 Amps) at 12 Volts. If the To avoid serious injury or death: VEHICLE 160 Watt (13 Amp) power rating is ex- Only devices designed for use in this •...
Page 115 CUPHOLDERS • Many accessories that can be plugged in KNOWING There are two cupholders, located in the center floor draw power from the vehicle's battery, YOUR VEHICLE console, for the front passengers. (fig. 90) even when not in use (i.e., cellular phones, etc.).
Page 116 When the armrest is folded flat the cupholders are in In addition to cupholders, vehicles may also be KNOWING the back of the Head Restraint. The Head Restraint can equipped with bottle holders. The bottle holders are YOUR be adjusted to better position the cupholders. located on the door trim panels.
Page 117 POWER SUNROOF (for versions/ WARNING! KNOWING markets, where provided) YOUR • Never leave children unattended in a VEHICLE The power sunroof switch is located between the sun vehicle, and do not leave the key fob in visors on the overhead console. (fig.
Page 118 OPENING SUNROOF — MANUAL MODE VENTING SUNROOF — EXPRESS KNOWING To open the sunroof, press and hold the switch rear- Press and release the “Vent” button, and the sunroof YOUR VEHICLE ward to full open. Any release of the switch will stop will open to the vent position.
Page 119: Door Locks
DOOR LOCKS SUNROOF MAINTENANCE KNOWING Use only a nonabrasive cleaner and a soft cloth to clean YOUR MANUAL DOOR LOCKS the glass panel. VEHICLE To lock each door, push the door lock knob on each IGNITION OFF OPERATION door trim panel downward. To unlock the front doors, For versions/markets, where provided without pull the inside door handle to the first detent.
Page 120 POWER DOOR LOCKS WARNING! KNOWING A power door lock switch is on each front door trim YOUR • For personal security and safety in the VEHICLE panel. Use this switch to lock or unlock the doors and event of a collision, lock the vehicle liftgate.
Page 121 Automatic Door Locks Automatic Unlock Doors On Exit KNOWING Programming The auto door lock feature default condition is dis- YOUR abled. When enabled, the door locks will lock auto- The Automatic Unlock Doors On Exit feature can be VEHICLE matically when the vehicle's speed exceeds 24 km/h. enabled or disabled as follows: The auto door lock feature can be enabled or disabled •...
Page 122 CHILD-PROTECTION DOOR LOCK 3. Repeat Steps 1 and 2 for the opposite rear door. KNOWING SYSTEM — REAR DOORS YOUR NOTE: When the Child-Protection Door Lock sys- VEHICLE To provide a safer environment for small children riding tem is engaged, the door can be opened only by using in the rear seats, the rear doors are equipped with a the outside door handle even though the inside door Child-Protection Door Lock system.
Page 123 NOTE: To Disengage The Child-Protection Door Lock KNOWING System • After engaging the Child-Protection Door Lock sys- YOUR VEHICLE tem, always test the door from the inside to make 1. Open the rear door. certain it is in the desired position. 2.
Page 124 KEYLESS ENTER-N-GO™ To Unlock From The Driver's Side: KNOWING The Passive Entry system is an enhancement to the With a valid Passive Entry RKE transmitter within YOUR VEHICLE vehicle’s Remote Keyless Entry (RKE) system and a 1.5 m of the driver's door handle, grab the driver's feature of Keyless Enter-N-Go™.
Page 125 To Unlock From The Passenger Side: To Enter The Liftgate KNOWING With a valid Passive Entry RKE transmitter within With a valid Passive Entry RKE transmitter within YOUR VEHICLE 1.5 m of the passenger door handle, grab the front 1.0 m of the liftgate, press the button underneath the passenger door handle to unlock all four doors and the left side of the accent bar, which is located on the liftgate automatically.
Page 126 Preventing Inadvertent Locking Of Passive To Lock The Vehicle’s Doors KNOWING Entry RKE Transmitter In Vehicle With one of the vehicle’s Passive Entry RKE transmit- YOUR VEHICLE To minimize the possibility of unintentionally locking a ters within 1.5 m of the driver or passenger front door Passive Entry RKE transmitter inside your vehicle, the handle, press the door handle LOCK button to lock all Passive Entry system is equipped with an automatic...
Page 127 Do NOT grab the door handle, when pressing the door NOTE: KNOWING handle lock button. This could unlock the door(s). • After pressing the door handle LOCK button, you YOUR (fig. 102) VEHICLE must wait two seconds before you can lock or unlock the doors, using either Passive Entry door handle.
Page 128 WINDOWS NOTE: For vehicles equipped with the Uconnect®, KNOWING the power window switches will remain active for up to YOUR Power Windows 10 minutes after the ignition is cycled to the LOCK/ VEHICLE The window controls on the driver's door trim panel OFF position.
Page 129 Auto-Down Feature • Any impact due to rough road conditions may trigger KNOWING the auto-reverse function unexpectedly during auto- The driver's power window switch has an Auto-down YOUR closure. If this happens, pull the switch lightly to the feature. Press the window switch past the first detent, VEHICLE first detent and hold to close window manually.
Page 130 Window Lockout Switch WIND BUFFETING KNOWING The window lockout switch on the driver's door trim Wind buffeting can be described as the perception of YOUR VEHICLE panel allows you to disable the window control on the pressure on the ears or a helicopter-type sound in the rear doors.
Page 131 LIFTGATE NOTE: Because the gas pressure drops with tempera- KNOWING ture, it may be necessary to assist the props when The liftgate can be unlocked or locked with the Re- YOUR opening the liftgate in cold weather. VEHICLE mote Keyless Entry (RKE) transmitter, the Keyless Enter-N-Go™...
Page 132 CARGO AREA FEATURES To operate the flashlight, press the switch once for KNOWING high, twice for low, and a third time to return to off. YOUR RECHARGEABLE FLASHLIGHT (fig. 107) VEHICLE (for versions/markets, where provided) NOTE: Be sure to return the flashlight to its charging The rechargeable LED flashlight stores in its charging station when not in use to ensure it is ready for station in the left rear quarter trim panel.
Page 133 CARGO MANAGEMENT SYSTEM SEVEN PASSENGER SYSTEM FEATURES KNOWING • A large built-in storage bin with a hinged hardcover YOUR FIVE PASSENGER SYSTEM FEATURES VEHICLE located in the floor behind the third-row passenger • A raised load floor that sits on top of a large built-in seats.
Page 134 CARGO TIE-DOWNS WARNING! KNOWING YOUR The weight and position of cargo and WARNING! VEHICLE passengers can change the vehicle cen- Cargo tie-downs are not safe anchors for ter of gravity and vehicle handling.To avoid loss of a child seat tether strap.In a sudden stop control resulting in personal injury, follow these SAFETY or collision, a tie-down could pull loose and allow...
Page 135 RETRACTABLE CARGO AREA COVER To install the cover, position it in the vehicle so that the KNOWING (for versions/markets, where provided) — flat side of the housing faces upward. Then, insert YOUR FIVE PASSENGER MODELS either the left or the right spring-loaded post (located VEHICLE on the ends of the cover housing) into the left attach- NOTE: The purpose of this cover is for privacy, not to...
Page 136 Insert the spring-loaded post on the opposite end of WARNING! KNOWING the cover housing into the attachment point on the YOUR A cargo cover that is unsecured in the opposite side of the vehicle. VEHICLE vehicle could cause injury in a collision.It Grab the cover handle and pull it toward you.
Page 137: To Open And Close The Hood
TO OPEN AND CLOSE THE HOOD KNOWING Two latches must be released to open the hood. YOUR VEHICLE 1. Pull the hood release lever located under the left side of the instrument panel. (fig. 111) SAFETY 2. Outside of the vehicle, locate the safety latch lever near the center of the grille between the grille and hood opening.
Page 138 Metal Crossbars can be purchased from your hood to ensure that both latches engage. Never FIAT dealer to provide a functional roof rack system. drive your vehicle unless the hood is fully closed, STARTING External racks do not increase the total load carrying with both latches engaged.
Page 139: Brake System
BRAKE SYSTEM • To prevent damage to the roof of your KNOWING vehicle, DO NOT carry any loads on the YOUR VEHICLE Your vehicle is equipped with dual hydraulic roof rack without the crossbars installed. brake systems. If either of the two hydraulic The load should be secured and placed on top of systems loses normal capability, the remaining system the crossbars, not directly on the roof.
Page 140 ANTI-LOCK BRAKE SYSTEM (ABS) WARNING! KNOWING This system aids the driver in maintaining vehicle con- YOUR • Riding the brakes can lead to brake VEHICLE trol under adverse braking conditions. The system failure and possibly a collision. Driving controls hydraulic brake pressure to prevent wheel with your foot resting or riding on the brake lock-up to help avoid skidding on slippery surfaces pedal can result in abnormally high brake tem-...
Page 141: Electronic Brake Control System
ELECTRONIC BRAKE CONTROL ABS is activated during braking under certain road or KNOWING stopping conditions. ABS-inducing conditions can in- SYSTEM YOUR clude ice, snow, gravel, bumps, railroad tracks, loose VEHICLE Your vehicle is equipped with an advanced electronic debris, or panic stops. brake control system commonly referred to as ESC.
Page 142 (Continued) Anti-Lock Brake Light KNOWING • Pumping of the Anti-Lock Brakes will diminish YOUR The Anti-Lock Brake Light monitors the ABS. VEHICLE their effectiveness and may lead to an accident. The light will turn on when the ignition Pumping makes the stopping distance longer. Just switch is turned to the ON position and may press firmly on your brake pedal when you need SAFETY...
Page 143 BRAKE ASSIST SYSTEM (BAS) TRACTION CONTROL SYSTEM (TCS) KNOWING The BAS is designed to optimize the vehicle’s braking This system monitors the amount of wheel spin of each YOUR capability during emergency braking maneuvers. The of the driven wheels. If wheel spin is detected, brake VEHICLE pressure is applied to the slipping wheel(s) and engine system detects an emergency braking situation by sens-...
Page 144 • Over-steer - when the vehicle is turning more than WARNING! KNOWING appropriate for the steering wheel position. YOUR Many factors, such as vehicle loading, VEHICLE • Under-steer - when the vehicle is turning less than road conditions, and driving conditions, appropriate for the steering wheel position.
Page 145 ESC Operating Modes WARNING! KNOWING The ESC system has two available operating modes. YOUR • When in “Partial Off ” mode, the TCS VEHICLE Full On functionality of ESC (except for the lim- ited slip feature described in theTCS section) has This is the normal operating mode for ESC.
Page 146 ESC ACTIVATION/MALFUNCTION NOTE: KNOWING INDICATOR LIGHT AND ESC OFF • The “ESC Activation/Malfunction Indicator Light” YOUR INDICATOR LIGHT VEHICLE and the “ESC OFF Indicator Light” come on momen- tarily each time the ignition switch is turned ON. The “ESC Activation/Malfunction Indicator •...
Page 147 HSA Activation Criteria Towing With HSA KNOWING The following criteria must be met in order for HSA to HSA will provide assistance when starting on a grade YOUR VEHICLE activate: when pulling a trailer. • Vehicle must be stopped. WARNING! SAFETY •...
Page 148 HSA Off NOTE: The TSC is disabled when the ESC system is in KNOWING the “Partial Off” mode. If you wish to turn off the HSA system, it can be done YOUR VEHICLE using the Customer Programmable Features in the WARNING! Electronic Vehicle Information Center (EVIC).
Page 149: Onboard Diagnostic System
ONBOARD DIAGNOSTIC SYSTEM — • Prolonged driving with the MIL on KNOWING OBD II could cause further damage to the emis- YOUR VEHICLE sion control system. It could also affect Your vehicle is equipped with a sophisticated onboard fuel economy and driveability.The vehicle must be diagnostic system called OBD II.
Page 150: Power Steering
POWER STEERING WARNING! KNOWING The standard power steering system will give you good YOUR Continued operation with reduced VEHICLE vehicle response and increased ease of maneuverability power steering assist could pose a safety in tight spaces. The system will provide mechanical risk to yourself and others.
Page 151: Tire Pressure Monitor System
TIRE PRESSURE MONITOR SYSTEM Do not use chemical flushes in your KNOWING (TPMS) power steering system as the chemicals YOUR VEHICLE can damage your power steering compo- The Tire Pressure Monitor System (TPMS) will warn nents. Such damage is not covered by the New the driver of a low tire pressure based on the vehicle Vehicle Limited Warranty.
Page 152 The TPMS will warn the driver of a low tire pressure if • The TPMS has been optimized for the KNOWING the tire pressure falls below the low-pressure warning YOUR original equipment tires and wheels. limit for any reason, including low temperature effects VEHICLE TPMS pressures and warning have been and natural pressure loss through the tire.
Page 153 NOTE: NOTE: It is particularly important for you to check KNOWING the tire pressure in all of the tires on your vehicle • The TPMS is not intended to replace normal tire care YOUR monthly and to maintain the proper pressure. VEHICLE and maintenance, or to provide warning of a tire failure or condition.
Page 154 Service TPMS Warning NOTE: KNOWING When a system fault is detected, the Tire Pressure 1. The compact spare tire does not have a tire pres- YOUR VEHICLE Monitoring Telltale Light will flash on and off for 75 sec- sure monitoring sensor. Therefore, the TPMS will onds and then remain on solid.
Page 155 TPMS Deactivation And Reactivation — PREMIUM SYSTEM (for versions/markets, KNOWING (for versions/markets, where provided) where provided) YOUR The TPMS can be deactivated if replacing all four wheel The Tire Pressure Monitor System (TPMS) uses wire- VEHICLE and tire assemblies (road tires) with wheel and tire less technology with wheel rim mounted electronic assemblies that do not have TPMS Sensors, such as sensors to monitor tire pressure levels.
Page 156 Tire Pressure Monitoring Low Pressure ServiceTPMS Warning KNOWING Warnings When a system fault is detected, the Tire Pressure YOUR VEHICLE Monitoring Telltale Light will flash on and off for 75 sec- The Tire Pressure Monitoring Telltale Light will onds and then remain on solid. The system fault will illuminate in the instrument cluster and a chime also sound a chime.
Page 157 4. Using tire chains on the vehicle. 3. After driving the vehicle for up to 20 minutes above KNOWING 25 km/h, the TPMS Telltale Light will flash on and off 5. Using wheels/tires not equipped with TPMS sen- YOUR for 75 seconds and then remain on solid. In addition, VEHICLE sors.
Page 158 TPMS Deactivation And Reactivation — Pressure Monitoring Telltale Light will flash on and off KNOWING (for versions/markets, where provided) for 75 seconds, the EVIC will display a “SERVICE TPM YOUR SYSTEM” text message, and the graphic will display tire VEHICLE The TPMS can be deactivated if replacing all four wheel pressure values to show that the TPMS is receiving and tire assemblies (road tires) with wheel and tire...
Page 159 REAR PARK ASSIST (for versions/ PARK ASSIST SENSORS KNOWING markets, where provided) The four Park Assist sensors, located in the rear YOUR fascia/bumper, monitor the area behind the vehicle that VEHICLE The Rear Park Assist system provides visual and audible is within the sensors’...
Page 160 PARK ASSIST DISPLAY KNOWING When the vehicle is in REVERSE, the warning display will YOUR VEHICLE turn ON indicating the system status. (fig. 115) (fig. 116) SAFETY STARTING DRIVING WARNING LIGHTS MESSAGES IN AN EMERGENCY SERVICING AND CARE TECHNICAL SPECIFICATIONS CONTENTS (fig.
Page 161 The system will indicate a detected obstacle by show- KNOWING ing three solid arcs and will produce a one-half second YOUR tone. As the vehicle moves closer to the object, the VEHICLE EVIC display will show fewer arcs and the sound tone will change from slow, to fast, to continuous.
Page 162 The vehicle is close to the obstacle when the warning KNOWING display shows one flashing arc and sounds a continuous YOUR tone. The following chart shows the warning alert VEHICLE operation when the system is detecting an obstacle: SAFETY WARNING ALERTS Rear Distance Greater than 200-100 cm...
Page 163 If “CLEAN PARK ASSIST” appears in the Electronic • When you turn Park Assist off, the EVIC will display KNOWING Vehicle Information Center (EVIC) make sure the “PARK ASSIST SYSTEM OFF.” Furthermore, once YOUR outer surface and the underside of the rear fascia/ you turn Park Assist off, it remains off until you turn VEHICLE bumper is clean and clear of snow, ice, mud, dirt or...
Page 164 (Continued) • Park Assist is only a parking aid and it is KNOWING • Before using Park Assist, it is strongly recom- YOUR unable to recognize every obstacle, in- VEHICLE mended that the ball mount and hitch ball as- cluding small obstacles. Parking curbs sembly is disconnected from the vehicle when the might be temporarily detected or not detected at vehicle is not used for towing.
Page 165 PARKVIEW® REAR BACK UP When the vehicle is shifted out of REVERSE, the rear KNOWING camera mode is exited and the navigation or audio CAMERA (for versions/markets, YOUR screen appears again. where provided) VEHICLE When displayed, static grid lines will illustrate the Your vehicle may be equipped with the ParkView®...
Page 166 NAVIGATION SYSTEM • To avoid vehicle damage, ParkView® KNOWING (for versions/markets, where YOUR should only be used as a parking aid.The VEHICLE provided) ParkView® camera is unable to view ev- ery obstacle or object in your drive path. Refer to your Uconnect® User Manual. •...
Page 167: Sound Systems
SOUND SYSTEMS STEERING WHEEL AUDIO KNOWING CONTROLS Refer to your Uconnect® User Manual. YOUR VEHICLE The remote sound system controls are located on the rear surface of the steering wheel. The left and right- hand controls are rocker-type switches with a pushbut- SAFETY ton in the center of each switch.
Page 168 RIGHT -HAND SWITCH FUNCTIONS LEFT -HAND SWITCH FUNCTIONS FOR KNOWING MEDIA (I.E., CD) OPERATION • Press the top of the switch to increase the volume. YOUR VEHICLE • Press the top of the switch once to listen to the next •...
Page 169 UCONNECT® MULTIMEDIA VIDEO Getting Started KNOWING ENTERTAINMENT SYSTEM (VES™) • Screen located in the overhead console: Unfold YOUR (for versions/markets, where VEHICLE the overhead LCD screen by pushing the button on provided) the overhead console behind the screen. (fig. 121) •...
Page 170 Video Screen NOTE: Certain high-end video games, such as Playsta- KNOWING tion3 and XBox360 will exceed the power limit of the YOUR NOTE: Typically there are two different ways to vehicle's Power Inverter. Refer to the Power Inverter VEHICLE operate the features of the Video Entertainment Sys- section in your vehicle's Owner's Manual for more tem (VES™).
Page 171 Listen To An Audio Source On Channel 2 Important Notes For Single Video Screen KNOWING While A Video Is Playing On Channel 1 System YOUR Ensure the Remote Control and Headphone switch is VEHICLE • VES™ is able to transmit two channels of stereo on Channel 2.
Page 172 Using The Remote Control Using The Touch-Screen Radio Controls KNOWING 1. Press the MODE button on the Remote Control. 1. Touch the “MORE” soft-key. YOUR VEHICLE 2. While looking at the Video Screen, highlight DISC 2. Touch the “Rear Entertainment” soft-key to display by either pressing Up/Down/Left/Right buttons or the Rear Entertainment Controls.
Page 173 Remote Control Operation NOTE: KNOWING Quick Reference Chart • Ensure the remote control channel/screen selector YOUR VEHICLE switch is set to the screen or channel to be con- This chart provides a quick reference of the remote trolled. control button functions for the different radio modes and menu screens.
Page 174 Standard Screens Menu Screens KNOWING Remote AM/FM/ DISC Mode YOUR Screen VEHICLE Control Button MW/LW AUX/AUX1/AUX2 Select Setup Menu Audio: Fast Rewind SAFETY Fast Video Play: Fast Rewind Not Avail- Selection Selection Left Arrow RW Tune Down* Rewind able Left Left Video Menu: Selection Left...
Page 175 Standard Screens Menu Screens KNOWING Remote AM/FM/ DISC Mode YOUR Screen VEHICLE Control Button MW/LW AUX/AUX1/AUX2 Select Setup Menu Audio: Disc Options Show Disc SAFETY Menu Not Avail- Not Avail- Not Avail- Menu Not Available Options able able able Video Play: Show Menu Disc Menu STARTING...
Page 176 Standard Screens Menu Screens KNOWING Remote AM/FM/ DISC Mode YOUR Screen VEHICLE Control Button MW/LW AUX/AUX1/AUX2 Select Setup Menu Audio: SAFETY Audio: Not Available Not Avail- able Not Avail- Not Avail- Not Avail- Status Not Available able able able Video: STARTING Video Play: Show Mode Show...
Page 177 Ensure remote control selector switch is set to Screen 3. Light – Turns the remote control backlighting on or KNOWING or Channel to be controlled: 1 OR 2. Ensure head- off. The remote backlighting turns off automatically YOUR phone selector switch is set to Screen or Channel to be after five seconds.
Page 178 10. PROG Up/Down – When listening to a radio menu, select the menu button on the radio. When KNOWING mode, pressing PROG Up selects the next preset a disc is loaded in the DVD player (for versions/ YOUR and pressing PROG Down selects the previous markets, where provided) and the VES™...
Page 179 Remote Control Storage Locking The Remote Control KNOWING The video screen(s) come with a built in storage All remote control functionality can be disabled as a YOUR compartment for the remote control which is acces- parental control feature. VEHICLE sible when the screen is opened. To remove the re- •...
Page 180 Headphones Operation Controls KNOWING The headphones receive two separate channels of The headphone power indicator and controls are lo- YOUR VEHICLE audio using an infrared transmitter from the video cated on the right ear cup. screen. NOTE: The rear video system must be turned on If no audio is heard after increasing the volume control, before sound can be heard from the headphones.
Page 181 3. If the video screen is displaying a video source (such Unwired® Stereo Headphone Lifetime KNOWING as a DVD Video), pressing STATUS shows the status Limited Warranty YOUR on a popup banner at the bottom of the screen. Who Does This Warranty Cover? This warranty VEHICLE Pressing the MODE button will advance to the next covers the initial user or purchaser ("you"...
Page 182 exclusion or limitation of incidental or consequential Only Channel 1 displays video images. When in video KNOWING damages, so the above limitation may not apply to you. mode the image is displayed on the full screen, however YOUR This warranty gives you specific legal rights. You may Channel 2’s functionality is still available.
Page 183 In a two-screen system, the video for Channel 1 is • Channel 1 Mode – Displays the current source for KNOWING displayed on the first rear seat screen and the video for Channel 1. YOUR Channel 2 is displayed on the second rear seat screen. VEHICLE •...
Page 184 • Clock — Displays the time. 2. When the digit is highlighted, press the remote KNOWING control’s ENTER button to select the digit. Repeat YOUR • Channel 1 Shared Status — When the icon is dis- these steps until all digits are entered. VEHICLE played, the audio for Channel 1 is also shared with the radio and playing through the cabin speakers.
Page 185 Options Menu Display Settings KNOWING (fig. 127) When watching a video source (DVD Video with the YOUR When watching a video source (DVD Video with the disc in Play mode, Aux Video, etc.), pressing the re- VEHICLE disc in Play mode, Aux Video, etc.), pressing the “Op- mote control’s SETUP button activates the Display tions”...
Page 186 Listening To Audio With The Screen Closed DVD Region Codes KNOWING To listen to only audio portion of the channel with the The DVD player and many DVD discs are coded by YOUR VEHICLE screen closed: geographic region. These region codes must match in order for the disc to play.
Page 187 compatible format and is playable on other players. To Compressed Audio Files (MP3,WMA AND KNOWING help avoid playback problems, use the following guide- ACC) YOUR lines when recording discs. VEHICLE The DVD player is capable of playing MP3 (MPEG-1 • Open sessions are ignored. Only sessions that are Audio Layer 3 with data bitrates from 32 to 320 kbit/s, closed are playable.
Page 188 • If you are creating your own files, the recommended Disc Errors KNOWING fixed bit rate for MP3 files is between 96 and If the DVD player is unable to read the disc, a "Disc YOUR 192Kbps and the recommended fixed bit rate for VEHICLE Error"...
Page 189 iPod®/USB/MP3 CONTROL Product Agreement KNOWING (for versions/markets, where This product incorporates copyright protection tech- YOUR nology that is protected by U.S. patents and other provided) VEHICLE intellectual property rights. Use of this copyright pro- This feature allows an iPod® or external USB device to tection technology must be authorized by Macrovision, be plugged into the USB port.
Page 190 CD/DVD DISC MAINTENANCE RADIO OPERATION AND MOBILE KNOWING PHONES To keep a CD/DVD in good condition, take the follow- YOUR VEHICLE ing precautions: Under certain conditions, the mobile phone being on in your vehicle can cause erratic or noisy performance 1.
Page 191: Adding Fuel
ADDING FUEL Locking Fuel Filler Cap (for versions/markets, KNOWING where provided) YOUR FUEL FILLER CAP (GAS CAP) VEHICLE Your vehicle may be equipped with a locking fuel cap. (for versions/markets, where provided) Use the specific blade key to lock/unlock this fuel cap. The gas cap is located behind the fuel filler door on the left side of the vehicle.
Page 192 (Continued) LOOSE FUEL FILLER CAP MESSAGE KNOWING (for versions/markets, where provided) • Never add fuel to the vehicle when the engine is YOUR VEHICLE If the vehicle diagnostic system determines that the running. fuel filler cap is loose, improperly installed, or damaged, •...
Page 193: Occupant Restraints
SAFETY KNOWING YOUR OCCUPANT RESTRAINTS For more information, refer to ISOFIX — Child Seat VEHICLE Anchorage System. Some of the most important safety features in your vehicle are the restraint systems: NOTE: The Advanced Front Air Bags have a multi- SAFETY stage inflator design.
Page 194 Research has shown that seat belts save lives, and they (Continued) KNOWING can reduce the seriousness of injuries in a collision. • Be sure everyone in your vehicle is in a seat and YOUR Some of the worst injuries happen when people are VEHICLE using a seat belt properly.
Page 195 Lap/Shoulder Belt Operating Instructions 3. When the belt is long enough to fit, insert the latch KNOWING plate into the buckle until you hear a “click.” 1. Enter the vehicle and close the door. Sit back and YOUR (fig. 130) VEHICLE adjust the front seat.
Page 196 4. Position the lap belt across your thighs, below your WARNING! KNOWING abdomen. To remove slack in the lap belt portion, YOUR • A belt that is buckled into the wrong pull up a bit on the shoulder belt. To loosen the lap VEHICLE buckle will not protect you properly.The belt if it is too tight, tilt the latch plate and pull on...
Page 197 (Continued) WARNING! KNOWING must be replaced immediately. Do not disas- YOUR • A lap belt worn too high can increase VEHICLE semble or modify the system. Seat belt assem- the risk of internal injury in a collision. blies must be replaced after a collision if they The belt forces won't be at the strong hip and have been damaged (bent retractor, torn web- pelvic bones, but across your abdomen.
Page 198 As a guide, if you are shorter than average you will of the seat belt by assuring that the belt is tight about KNOWING prefer a lower position and if you are taller than the occupant early in a collision. Pretensioners work YOUR average you will prefer a higher position.
Page 199 AHR. This system is designed to help prevent or All occupants, including the driver, should KNOWING reduce the extent of injuries to the driver and front not operate a vehicle or sit in a vehicle's YOUR passenger in certain types of rear impacts. VEHICLE seat until the head restraints are placed in their proper positions in order to minimize the...
Page 200 Resetting Active Head Restraints (AHR) 3. Pull down then rearward towards the rear of the KNOWING vehicle then down to engage the locking mecha- If the Active Head Restraints are triggered in a collision, YOUR nism. (fig. 135) (fig. 136) VEHICLE you must reset the head restraint on the driver’s and front passenger seat.
Page 201 4. The AHR front soft foam and trim half should lock ACTIVE HOOD SYSTEM (for versions/ KNOWING into the back decorative plastic half. (fig. 137) markets, where provided) YOUR The Active Hood system is intended to enhance pe- VEHICLE NOTE: destrian protection by elevating the vehicle’s hood •...
Page 202 The impact sensors are located within the front bum- In the event of an Active Hood deployment, the vehicle KNOWING per area. should be serviced by an authorized dealer. The hood YOUR hinges must be serviced and the actuator assemblies VEHICLE The EPPM monitors the readiness of the electronic replaced to restore system functionality.
Page 203 The front bumper assembly may affect proper opera- (Continued) KNOWING tion of the Active Hood system. The front bumper • Modifications to any part of the Active Hood YOUR components should be inspected for damage and re- VEHICLE system could cause it to fail when you need it. Do placed if necessary in the event of a frontal impact, even not modify the components or wiring.
Page 204 Enhanced Seat Belt Use Reminder System front passenger seat or when the seat is folded flat (for KNOWING (BeltAlert®) versions/markets, where provided). It is recommended YOUR that pets be restrained in the rear seat in pet harnesses VEHICLE BeltAlert® is a feature intended to remind the driver or pet carriers that are secured by seat belts, and cargo and front passenger (for versions/markets, where pro- is properly stowed.
Page 205 Child Restraints Before buying any restraint system, make sure that it KNOWING has a label certifying that it meets all applicable Safety (fig. 139) YOUR Standards. You should also make sure that you can Everyone in your vehicle needs to be buckled up at all VEHICLE install it in the vehicle where you will use it.
Page 206 Seating Position (or other site) KNOWING Mass Group YOUR Intermediate Intermediate Front Passenger Rear Outboard Rear Center VEHICLE Outboard Center Group — up to 10 kg SAFETY Group 0+ — up to 13 kg Group 1 – STARTING 9 to 18 kg DRIVING Group II –...
Page 207 Vehicle ISOFIX Positions Chart KNOWING Interme- YOUR VEHICLE diate Front Rear Interme- Mass Size Rear Out- Other Fixture Passen- Out- diate Group Class Center board Sites board Center SAFETY Right / Left ISO/L1 **IUF / X **IUF STARTING Carrycot ISO/L2 X / **IUF DRIVING *IUF /...
Page 208 Vehicle ISOFIX Positions Chart KNOWING Interme- YOUR VEHICLE diate Front Rear Interme- Mass Size Rear Out- Other Fixture Passen- Out- diate Group Class Center board Sites board Center SAFETY Right / Left *IUF / STARTING ISO/R2 *IUF *IUF *IUF / DRIVING ISO/R3 *IUF...
Page 209 • X = ISOFIX position not suitable for ISOFIX child There are different sizes and types of restraints for KNOWING restraint systems in this mass group and / or this size children from newborn size to the child almost large YOUR class.
Page 210 Infants And Child Restraints WARNING! KNOWING Safety experts recommend that children ride YOUR • Never place a rear facing infant seat in VEHICLE rearward-facing in the vehicle until they are two years front of an air bag. A deploying Passen- old or until they reach either the height or weight limit ger Advanced Front Air Bag can cause death or of their rear facing child safety seat.
Page 211 belts fit properly. If the child cannot sit with knees bent To position a child into the Integrated Child Booster KNOWING over the vehicle’s seat cushion while the child’s back is Seat follow these steps: YOUR against the seatback, they should use a belt-positioning VEHICLE 1.
Page 212 3. Lift the seat cushion up and push back to lock it in NOTE: The lap portion of the seat belt should be low KNOWING the booster seat position. (fig. 141) on the hips and as snug as possible. YOUR VEHICLE 4.
Page 213 2. Do the child’s knees bend comfortably over the WARNING! KNOWING front of the vehicle seat – while they are still sitting YOUR Securely lock the seat cushion into posi- all the way back? VEHICLE tion before using the seat. Otherwise, 3.
Page 214 Recommendations For Attaching Child Restraints KNOWING YOUR Use any attachment method shown with an “X” Below VEHICLE Combined ISOFIX – Weight of the ISOFIX – Restraint Type Lower Seat Belt + Top Child + Child Lower Seat Belt Only Anchors + Top Tether Anchor SAFETY Restraint...
Page 215 Locating The ISOFIX Anchorages Locating The ISOFIX Anchorages KNOWING (Second Row Seating) YOUR The lower anchorages are round bars that are VEHICLE found at the rear of the seat cushion where it In addition, there are tether strap anchors meets the seatback. They are just visible located behind each rear seatback, near to SAFETY when you lean into the rear seat to install the...
Page 216 Center Seat ISOFIX Options for installing two child seats using the ISOFIX KNOWING anchorages in this vehicle: This vehicle has 5 lower ISOFIX anchorages in the rear YOUR VEHICLE seat. Anchorages A and B are used for the right out- 1.
Page 217 To Install An ISOFIX Child Restraint: WARNING! KNOWING 1. If the selected seating position has a Switchable YOUR • Use anchorages B and C to install a VEHICLE Automatic Locking Retractor (ALR) seat belt, stow ISOFIX child restraint in the center seat- the seat belt, following the instructions below.
Page 218 5. If the child restraint has a tether strap, connect it to WARNING! KNOWING the top tether anchorage. See the section “Installing YOUR • Improper installation of a child re- Child Restraints Using the Top Tether Anchorage” VEHICLE straint to the ISOFIX anchorages can for directions to attach a tether anchor.
Page 219 Mode” description under “Occupant Restraints.” The webbing retracts, you will hear a clicking sound. This KNOWING cinching latch plate is designed to hold the lap portion means the seat belt is now in the Automatic Locking YOUR of the seatbelt tight when webbing is pulled tight and mode.
Page 220 Installing A Child Restraint With A Cinching Using The Top Tether Anchorage” for directions to KNOWING Latch Plate (CINCH) — for versions/markets, attach a tether anchor. YOUR where provided VEHICLE 6. Test that the child restraint is installed tightly by 1.
Page 221 Installing Child Restraints Using The Top 2. Route the tether strap to provide the most direct KNOWING Tether Anchorage path for the strap between the anchor and the child YOUR seat. If your vehicle is equipped with adjustable rear VEHICLE 1.
Page 222 4. Remove slack in the tether strap according to the NOTE: The Driver and Front Passenger Advanced KNOWING child restraint manufacturer’s instructions. Front Air Bags are certified to the regulations for YOUR Advanced Air Bags. VEHICLE WARNING! The Advanced Front Air Bags have a multistage inflator •...
Page 223 This vehicle is equipped with Supplemental Side Air Bag • Instrument Panel KNOWING Inflatable Curtains (SABIC) to protect the driver, front, • Knee Impact Bolsters YOUR and rear passengers sitting next to a window. The VEHICLE • Driver Advanced Front Air Bag SABIC air bags are located above the side windows and their covers are also labeled: SRS AIRBAG.
Page 224 The first stage inflator is triggered immediately during Supplemental Seat-Mounted Side Air Bags KNOWING an impact that requires air bag deployment. This low (SAB) YOUR output is used in less severe collisions. A higher energy VEHICLE SAB may provide enhanced protection to help protect output is used for more severe collisions.
Page 225 Supplemental Side Air Bag Inflatable Curtain NOTE: KNOWING (SABIC) • Should a vehicle rollover occur, the pretensioners YOUR SABIC air bags may offer side-impact and vehicle roll- VEHICLE and/or SAB and SABIC air bags on both sides of the over protection to front and rear seat outboard occu- vehicle may deploy.
Page 226 (Continued) Along with seat belts and pretensioners, Advanced KNOWING Front Air Bags and the Supplemental Driver Side Knee • Your vehicle is equipped with SABIC air bags, YOUR Air Bag work with the knee impact bolsters to provide VEHICLE do not have any accessory items installed which improved protection for the driver and front passenger.
Page 227 of impact, Advanced Front Air Bags may deploy in ORC detects a malfunction in any part of the system, it KNOWING crashes with little vehicle front-end damage but that turns on the Air Bag Warning Light, either momentarily YOUR produce a severe initial deceleration. or continuously.
Page 228 Air Bags. Different air bag inflation rates are possible, or if items are positioned in the area where the side air KNOWING based on several factors, including the collision type and bag inflates. This especially applies to children. YOUR severity. The steering wheel hub trim cover and the VEHICLE Supplemental Side Air Bag Inflatable Curtain upper right side of the instrument panel separate and...
Page 229 Front And Side Impact Sensors NOTE: Front and/or side air bags will not deploy in all KNOWING collisions. This does not mean something is wrong with In front and side impacts, impact sensors can aid the ORC YOUR the air bag system. in determining appropriate response to impact events.
Page 230 Do not drive your vehicle after the air bags have • The Air Bag Warning Light remains on after the four KNOWING deployed. If you are involved in another collision, the to eight-second interval. YOUR air bags will not be in place to protect you. VEHICLE •...
Page 231: Safety Tips
SAFETY TIPS • How far (if at all) the driver was depressing the KNOWING accelerator and/or brake pedal; and, YOUR Transporting Passengers VEHICLE • How fast the vehicle was traveling. NEVER TRANSPORT PASSENGERS IN THE CARGO These data can help provide a better understanding of AREA.
Page 232 (Continued) The best protection against carbon monoxide entry KNOWING into the vehicle body is a properly maintained engine • On seven passenger models, do not allow a YOUR exhaust system. VEHICLE passenger to sit in a third row seat with the second row seatback(s) folded flat.
Page 233 Air Bag Warning Light WARNING! KNOWING YOUR Pedals that cannot move freely can The light should turn on and remain on for VEHICLE cause loss of vehicle control and increase four to six seconds as a bulb check when the the risk of serious personal injury.
Page 234 (Continued) Lights KNOWING Have someone observe the operation of brake lights Failure to properly follow floor mat installation YOUR VEHICLE and exterior lights while you work the controls. Check or mounting can cause interference with the turn signal and high beam indicator lights on the instru- brake pedal and accelerator pedal operation ment panel.
Page 235: Starting And Driving
STARTING AND DRIVING KNOWING YOUR ENGINE BREAK-IN STARTING PROCEDURES VEHICLE RECOMMENDATIONS Before starting your vehicle, adjust your seat, adjust the inside and outside mirrors, fasten your seat belt, and if A long break-in period is not required for the engine SAFETY present, instruct all other occupants to buckle their and drivetrain (transmission and axle) in your vehicle.
Page 236 (Continued) 3. The system takes over and attempts to start the KNOWING vehicle. If the vehicle fails to start, the starter will • Do not leave the key fob in or near the vehicle YOUR disengage automatically after 10 seconds. VEHICLE (or in a location accessible to children), and do not leave the ignition of a vehicle equipped with...
Page 237 NOTE: If the ignition switch is left in the ACC or RUN EXTREME COLD WEATHER (BELOW −29°C) KNOWING (engine not running) position and the transmission is in To ensure reliable starting at these temperatures, use YOUR PARK, the system will automatically time out after of an externally powered electric engine block heater is VEHICLE 30 minutes of inactivity and the ignition will switch to...
Page 238 Clearing A Flooded Engine (Using ENGINE 2. Watch the “Wait To Start Indicator Light” in the KNOWING START/STOP Button) instrument cluster. Refer to “Instrument Cluster” in YOUR “Warning Lights And Messages” for further infor- VEHICLE If the engine fails to start after you have followed the mation.
Page 239 To Turn Off The Engine Using ENGINE Turbocharger “Cool Down” KNOWING START/STOP Button YOUR NOTE: Letting the engine idle after extended opera- VEHICLE 1. With the vehicle stopped, place the shift lever in tion allows the turbine housing to cool to normal NEUTRAL/PARK, then press and release the EN- operating temperature.
Page 240: Parking Brake
PARKING BRAKE TurboCharger “Cool Down” Chart KNOWING Idle Time Before leaving the vehicle, make sure that the parking YOUR Turbo- VEHICLE Driving (In Min- brake is fully applied. Also, be certain to leave an charger Condi- Load utes) automatic transmission in PARK, or manual transmis- Tempera- tions Before...
Page 241 Automatic Transmission NOTE: KNOWING The foot operated parking brake is located below the • When the parking brake is applied and the automatic YOUR VEHICLE lower left corner of the instrument panel. To apply the transmission is placed in gear, the “Brake Warning park brake, firmly push the park brake pedal fully.
Page 242 (Continued) (Continued) KNOWING • Before exiting a vehicle,always apply the park- • Always fully apply the parking brake when YOUR VEHICLE ing brake, shift the automatic transmission into leaving your vehicle or it may roll and cause PARK and first gear or REVERSE for a manual damage or injury.
Page 243: Manual Transmission
MANUAL TRANSMISSION Use each gear in numerical order, do not skip a gear. Be KNOWING sure the transmission is in first gear, (not third), when (for versions/markets, where YOUR starting from a standing position. Damage to the clutch provided) VEHICLE can result from starting in third.
Page 244 AUTOMATIC TRANSMISSION DOWNSHIFTING KNOWING (for versions/markets, where Proper downshifting will improve fuel economy and YOUR VEHICLE prolong engine life. provided) If you skip a gear while downshifting or Damage to the transmission may occur if SAFETY downshift at too high of a vehicle speed, the following precautions are not ob- these conditions may cause the engine to served:...
Page 245 (Continued) WARNING! KNOWING • Allowing children to be in a vehicle unattended YOUR • It is dangerous to shift out of PARK or VEHICLE is dangerous for a number of reasons. A child or NEUTRAL if the engine speed is higher others could be seriously or fatally injured.
Page 246 Brake/Transmission Shift Interlock System Only shift from DRIVE to PARK or REVERSE when the KNOWING accelerator pedal is released and the vehicle is stopped. This vehicle is equipped with a Brake Transmission Shift YOUR Be sure to keep your foot on the brake pedal when VEHICLE Interlock System (BTSI) that holds the shift lever in shifting between these gears.
Page 247 Gear Ranges WARNING! KNOWING DO NOT race the engine when shifting from PARK or YOUR • Never use the PARK position as a sub- NEUTRAL into another gear range. VEHICLE stitute for the parking brake.Always ap- NOTE: After selecting any gear range, wait a moment ply the parking brake fully when parked to guard to allow the selected gear to engage before accelerat- against vehicle movement and possible injury or...
Page 248 (Continued) • Before moving the shift lever out of KNOWING • Unintended movement of a vehicle could injure YOUR PARK, you must turn the ignition switch VEHICLE those in or near the vehicle. As with all vehicles, from the LOCK/OFF position to the ON/ you should never exit a vehicle while the engine is RUN position, and also press the brake pedal.
Page 249 REVERSE (R) DRIVE (D) KNOWING This range is for moving the vehicle backward. Shift into This range should be used for most city and highway YOUR REVERSE only after the vehicle has come to a complete driving. It provides the smoothest upshifts and down- VEHICLE stop.
Page 250 During cold temperatures, transmission operation may In the event of a momentary problem, the transmission KNOWING be modified depending on engine and transmission can be reset to regain all forward gears by performing YOUR temperature as well as vehicle speed. This feature the following steps: VEHICLE improves warm up time of the engine and transmission...
Page 251 AUTOSTICK® (for versions/ • The transmission fluid has reached an adequate tem- KNOWING perature. markets, where provided) YOUR VEHICLE • The engine coolant has reached an adequate tem- AutoStick® is a driver-interactive transmission feature perature. providing manual shift control, giving you more control of the vehicle.
Page 252 In AutoStick® mode, the transmission will shift up or • If a requested downshift would cause the engine to KNOWING down when the driver moves the shift lever to the right over-speed, that shift will not occur. YOUR (+) or left (-), unless an engine lugging or overspeed VEHICLE •...
Page 253: Driving On Slippery Surfaces
ALL WHEEL DRIVE (AWD) DRIVING ON SLIPPERY SURFACES KNOWING (for versions/markets, where YOUR ACCELERATION provided) VEHICLE Rapid acceleration on snow covered, wet, or other This feature provides on-demand All-Wheel Drive slippery surfaces may cause the driving wheels to pull (AWD). The system is automatic with no driver inputs erratically to the right or left.
Page 254: Driving Through Water
DRIVING THROUGH WATER TRACTION KNOWING When driving on wet or slushy roads, it is possible for Driving through water more than a few centimeters YOUR VEHICLE a wedge of water to build up between the tire and road deep will require extra caution to ensure safety and surface.
Page 255 • Always check the depth of the standing WARNING! KNOWING water before driving through it. Never YOUR • Driving through standing water limits VEHICLE drive through standing water that is your vehicle’s traction capabilities. Do deeper than the bottom of the tire rims mounted not exceed 8 km/h when driving through standing on the vehicle.
Page 256 TRAILER TOWING Gross Combination Weight Rating (GCWR) KNOWING The GCWR is the total permissible weight of your In this section you will find safety tips and information YOUR VEHICLE vehicle and trailer when weighed in combination. on limits to the type of towing you can reasonably do with your vehicle.
Page 257 Tongue Weight (TW) BREAKAWAY CABLE ATTACHMENT KNOWING The tongue weight is the downward force exerted on European braking regulations for braked trailers up to YOUR the hitch ball by the trailer. In most cases, it should not 3,500 kg require trailers to be fitted with either a VEHICLE be less than 7% or more than 10% of the trailer load.
Page 258 • For fixed ball tow bar, attach the clip directly to the KNOWING designated point. This alternative must be specifically YOUR permitted by the trailer manufacturer since the clip VEHICLE may not be sufficiently strong for use in the way. (fig.
Page 259 TRAILER TOWING WEIGHTS (MAXIMUM TRAILER WEIGHT RATINGS) KNOWING The following chart provides the maximum trailer weight ratings towable for your given drivetrain. YOUR VEHICLE Max.Tongue Wt. ♦ Engine/Transmission Frontal Area Max. GTW (Gross Trailer Wt.) (5 and 7 Passenger (5 and 7 Passenger Model) SAFETY Model...
Page 260 TOWING REQUIREMENTS WARNING! KNOWING To promote proper break-in of your new vehicle drive- YOUR Improper towing can lead to an injury VEHICLE train components the following guidelines are recom- accident. Follow these guidelines to mended: make your trailer towing as safe as possible: Make certain that the load is secured in the •...
Page 261 (Continued) – Check for signs of tire wear or visible tire damage KNOWING before towing a trailer. Refer to “Tires – General • Vehicles with trailers should not be parked on a YOUR Information” in “Technical Specifications” for the VEHICLE grade.When parking, apply the parking brake on proper tire inspection procedures.
Page 262 Towing Requirements – Trailer Lights And WARNING! KNOWING Wiring YOUR • Do not connect trailer brakes to your VEHICLE Whenever you pull a trailer, regardless of the trailer vehicle's hydraulic brake lines. It can size, stoplights and turn signals on the trailer are overload your brake system and cause it to fail.
Page 263 Pin Number Function Wire Color Pin Number Function Wire Color KNOWING Left Turn Signal Yellow Stoplights YOUR VEHICLE Rear Fog Light Blue Left Rear Black Position, Side Ground/ White Marker Lights, Common SAFETY and Rear Regis- Return tration Plate Right Turn Signal Green Illumination Right Rear...
Page 264 Pin Number Function Wire Color Pin Number Function Wire Color KNOWING YOUR Left Turn Signal Yellow Reverse lights Red/Black VEHICLE Rear Fog Light Blue Permanent Brown/White Power Supply Ground/ White (+12V) Common SAFETY Return for Power Supply Contacts (Pins) Controlled by 1 and 2 and Ignition Switch STARTING...
Page 265 TOWING TIPS NOTE: Check the transmission fluid level (four-speed KNOWING transmission only) before towing. The six-speed trans- Before setting out on a trip, practice turning, stopping, YOUR mission does not require a fluid level check before and backing up the trailer in an area located away from VEHICLE towing.
Page 266 Cooling System Trailer Tow Hitch Attaching Points And Overhang KNOWING To reduce potential for engine and transmission over- Dimensions YOUR VEHICLE heating, take the following actions: 366.71 mm City Driving 501.62 mm When stopped for short periods, shift the transmission SAFETY 628.69 mm into NEUTRAL and increase engine idle speed.
Page 267 RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) KNOWING YOUR TOWING THIS VEHICLE BEHIND ANOTHER VEHICLE VEHICLE FWD MODELS Towing Wheels OFF FWD MODELS MANUAL AUTOMATIC AWD MODELS Condition the Ground TRANSMISSION SAFETY TRANSMISSION • Transmission in NEUTRAL STARTING Flat Tow NONE NOT ALLOWED NOT ALLOWED •...
Page 268 NOTE: This vehicle may be towed on a flatbed or Failure to follow these towing methods KNOWING vehicle trailer provided all four wheels are OFF the YOUR can cause severe engine and/or transmis- ground. VEHICLE sion damage. Damage from improper This vehicle may also be towed using a tow dolly (with towing is not covered under the New Vehicle Lim- the front wheels OFF the ground).
Page 269: Warning Lights And Messages
WARNING LIGHTS AND MESSAGES KNOWING YOUR INSTRUMENT CLUSTER VEHICLE (fig. 162) SAFETY STARTING DRIVING WARNING LIGHTS MESSAGES IN AN EMERGENCY SERVICING AND CARE TECHNICAL SPECIFICATIONS CONTENTS (fig. 162)
Page 270 INSTRUMENT CLUSTER Certain conditions, such as a loose or missing gas cap, KNOWING poor fuel quality, etc., may illuminate the MIL after DESCRIPTIONS YOUR engine start. The vehicle should be serviced if the MIL VEHICLE 1. Air Bag Warning Light stays on through several of your typical driving cycles.
Page 271 3. Electronic Stability Control (ESC) Activation/ 4. Turn Signal Indicator Light KNOWING Malfunction Indicator Light (for versions/markets, The left or right arrow will flash in unison YOUR where provided) with the corresponding front and rear turn VEHICLE The “ESC Activation/Malfunction Indicator signal lights when the turn signal switch is Light”...
Page 272 7. Odometer Display / Electronic Vehicle 9. Tire Pressure Monitoring Telltale Light KNOWING Information Center (EVIC) Display Each tire, including the spare (if provided), YOUR should be checked monthly when cold and VEHICLE Odometer inflated to the inflation pressure recom- The odometer display shows the total distance the mended by the vehicle manufacturer on the vehicle has been driven.
Page 273 Please note that the TPMS is not a substitute for The TPMS has been optimized for the KNOWING proper tire maintenance, and it is the driver’s respon- original equipment tires and wheels. YOUR sibility to maintain correct tire pressure, even if under- VEHICLE TPMS pressures and warning have been inflation has not reached the level to trigger illumina-...
Page 274 11. Brake Warning Light NOTE: The light may flash momentarily during sharp KNOWING This light monitors various brake functions, cornering maneuvers, which change fluid level condi- YOUR including brake fluid level and parking brake tions. The vehicle should have service performed, and VEHICLE application.
Page 275 The light also will turn on when the parking brake is 13. Fuel Cap Indicator KNOWING applied with the ignition switch in the ON/RUN position. This symbol indicates the side of the vehicle YOUR where the fuel filler cap is located. VEHICLE NOTE: This light shows only that the parking brake is applied.
Page 276 IN AN EMERGENCY KNOWING JUMP-STARTING YOUR PREPARATIONS FOR JUMP-START VEHICLE The battery in your vehicle is located between the left If your vehicle has a discharged battery it can be front headlight assembly and the left front wheel splash jump-started using a set of jumper cables and a battery shield.
Page 277 WARNING! WARNING! KNOWING YOUR • Take care to avoid the radiator cooling Do not allow vehicles to touch each VEHICLE fan whenever the hood is raised. It can other as this could establish a ground start anytime the ignition switch is ON.You can connection and personal injury could result.
Page 278 4. Connect the opposite end of the negative (-) 7. Disconnect the negative end (-) of the jumper cable KNOWING jumper cable to the remote negative (-) post of the from the negative (-) post of the booster battery. YOUR vehicle with the discharged battery.
Page 279: Specifications
135 N·m M12 x 1.25 19 mm MESSAGES (fig. 164) **Use only FIAT recommended lug nuts/bolts and clean Wheel Mounting Surface IN AN or remove any dirt or oil before tightening. EMERGENCY Inspect the wheel mounting surface prior to mounting the tire and remove any corrosion or loose particles.
Page 280 JACKING AND TIRE CHANGING (for After 40 km check the lug nut/bolt torque to be sure KNOWING that all the lug nuts/bolts are properly seated against versions/markets, where provided) YOUR the wheel. VEHICLE WARNING! WARNING! • Do not attempt to change a tire on the SAFETY To avoid the risk of forcing the vehicle side of the vehicle close to moving traf-...
Page 281 Jack Location Preparations For Jacking KNOWING The jack and jack-handle are stowed underneath a 1. Park the vehicle on a firm, level surface as far from YOUR cover in the rear storage bin in the cargo area. VEHICLE (fig. 166) the edge of the roadway as possible.
Page 282 Spare Tire Removal NOTE: Assemble components 2 and 3 by seating the KNOWING small ball at the end of component 2 in the small hole at YOUR NOTE: On seven-passenger models, fold the third- the end of component 3. This will lock these compo- VEHICLE row passenger seats flat.
Page 283 Spare Tire Stowage The winch mechanism is designed for use KNOWING with the jack-handle only. Use of an air YOUR NOTE: Refer to “Spare Tire Removal” for information VEHICLE wrench or other power tools is not rec- on assembling the winch tools. ommended and it can damage the winch.
Page 284 JACKING INSTRUCTIONS (Continued) KNOWING • If working on or near a roadway, be extremely YOUR WARNING! VEHICLE careful of motor traffic. Carefully follow these tire changing • To assure that spare tires, flat or inflated, are warnings to help prevent personal injury securely stowed, spares must be stowed with the SAFETY or damage to your vehicle:...
Page 285 3. Place the jack underneath the lift area that is closest Do not attempt to raise the vehicle by KNOWING to the flat tire. Center the jack saddle between the jacking on locations other than those YOUR drain flute formations on the sill flange. Turn the jack VEHICLE indicated in the Jacking Instructions for screw clockwise to firmly engage the jack saddle with...
Page 286 WARNING! KNOWING YOUR Raising the vehicle higher than neces- VEHICLE sary can make the vehicle less stable. It could slip off the jack and hurt someone near it. Raise the vehicle only enough to remove the tire. SAFETY 5. Remove the wheel nuts. For vehicles so equipped, remove the wheel cover from the wheel by hand.
Page 287 NOTE: WARNING! KNOWING • For vehicles so equipped, do not attempt to install a YOUR To avoid possible personal injury, handle VEHICLE center cap or wheel cover on the compact spare. the wheel covers with care to avoid con- • Refer to “Compact Spare Tire” and to “Limited-Use tact with any sharp edges.
Page 288 10. Lower the jack to its fully closed position. WARNING! KNOWING YOUR 11. Place the deflated (flat) tire in the cargo area. Do To avoid the risk of forcing the vehicle VEHICLE not stow the deflated tire in the spare tire off the jack, do not tighten the lug nuts stowage location.
Page 289 4. Install the remaining lug nuts with the cone shaped Vehicles Without Wheel Covers KNOWING end of the nut toward the wheel. Lightly tighten the 1. Mount the road tire on the axle. YOUR lug nuts. VEHICLE 2. Install the remaining lug nuts with the cone shaped end of the nut toward the wheel.
Page 290 TIREFIT KIT (for versions/markets, TIREFIT KIT COMPONENTS AND KNOWING OPERATION where provided) YOUR (fig. 177) VEHICLE Small punctures up to 6 mm in the tire tread can be 1. Sealant Bottle sealed with TIREFIT. Foreign objects (e.g., screws or nails) should not be removed from the tire. TIREFIT 2.
Page 291 Using The Mode Select Knob And Hoses TIREFIT Usage Precautions KNOWING Your TIREFIT kit is equipped with the following sym- • Replace the TIREFIT Sealant Bottle (1) and Sealant YOUR bols to indicate the air or sealant mode. VEHICLE Hose (6) prior to the expiration date (printed on the bottle label) to assure optimum operation of the •...
Page 292 avoid injecting sealant into them. The TIREFIT Seal- (Continued) KNOWING ant is only intended to seal punctures less than 6 mm • A loose TIREFIT kit thrown forward in a colli- YOUR diameter in the tread of your vehicle. VEHICLE sion or hard stop could endanger the occupants of the vehicle.Always stow the TIREFIT kit in the •...
Page 293 SEALING A TIRE WITH TIREFIT 4. Remove the cap from the valve stem and then screw KNOWING the fitting at the end of the Sealant Hose (6) onto YOUR (A) Whenever You Stop To Use TIREFIT: the valve stem. VEHICLE 1.
Page 294 Check that the Mode Select Knob (5) is in the to the pressure indicated on the tire pressure label KNOWING Sealant Mode position and not Air Mode. Press the on the driver-side latch pillar (recommended pres- YOUR Power Button (4) to turn On the TIREFIT kit. sure).
Page 295 (E) After Driving: • The metal end fitting from Power Plug KNOWING Pull over to a safe location. Refer to “Whenever You (8) may get hot after use, so it should be YOUR Stop to Use TIREFIT” before continuing. VEHICLE handled carefully.
Page 296 2. Disconnect the TIREFIT kit from the valve stem, (F) Sealant Bottle And Hose Replacement: KNOWING reinstall the cap on the valve stem and unplug from 1. Uncoil the Sealant Hose (6) (clear in color). YOUR 12 Volt outlet. VEHICLE 2.
Page 297: Replacement Bulbs
REPLACEMENT BULBS LIGHTS BULBS – Outside Bulb Number KNOWING All the inside bulbs are brass or glass wedge base. Low Beam Headlamp ....H11 YOUR VEHICLE High Beam Headlamp .
Page 298 ¼ turn clockwise to STARTING Where possible, it is advisable to have lock it in place. bulbs changed at a FIAT Dealership. DRIVING Proper operation and orientation of the external lights are essential for driving safety and...
Page 299 FRONT FOG LAMP 4. Pull the bulb straight out from the keyed opening in KNOWING the housing. YOUR NOTE: Turn the steering wheel to the right if replac- VEHICLE 5. Align the index tabs of the replacement front fog ing the left front fog lamp or to the left if replacing the lamp bulb with the slots in the collar of the bulb right front fog lamp to allow for easier access to the opening on the back of the front fog lamp housing.
Page 300 REAR FOG LAMP 6. Remove the bulb from the connector socket and KNOWING install the replacement bulb. 1. Reach behind the bumper above the bumper rein- YOUR VEHICLE forcement and press the release tabs on the fog lamp 7. Align the index tabs of the replacement rear fog housing.
Page 301 SIDE REPEATER LAMP REAR TURN SIGNAL AND BACKUP LAMP KNOWING The side repeater lamps are located in both front The taillamps are a two-piece design. The tail/stop/rear YOUR fender panels. turn signal lamps are located in the rear corner body VEHICLE panels.
Page 302 3. Carefully insert a trim stick (plastic flat-blade tool) KNOWING between the body panel and the outboard side of YOUR the taillamp housing with one hand and grasp the VEHICLE flange on the inboard side of the taillamp housing with the other hand. Use the trim stick and hand SAFETY pressure together to disengage the taillamp housing from the vehicle.
Page 303 4. Rotate the applicable bulb's electrical connector 3. Hold the lens with one hand and rotate the bulb's KNOWING ¼ turn counterclockwise and remove it from the electrical connector ¼ turn counterclockwise with YOUR housing. the other hand and then separate the bulb and VEHICLE connector assembly from the lens.
Page 304 FUSES INTERIOR FUSES KNOWING The interior fuse panel is located on the passenger side YOUR VEHICLE under the instrument panel. WARNING! • When replacing a blown fuse, always Car- use an appropriate replacement fuse Mini- SAFETY Cavity tridge Description with the same amp rating as the original fuse. Fuse Fuse Never replace a fuse with another fuse of higher...
Page 305 Car- Car- KNOWING Mini- Mini- Cavity tridge Description Cavity tridge Description YOUR Fuse Fuse Fuse Fuse VEHICLE Rear Camera – For All Wheel Drive – 10 Amp F107 Versions/Markets, 10 Amp For Versions/ F120 SAFETY Where Provided Markets, Where Provided 15 Amp Instrument Panel F108...
Page 306 UNDERHOOD FUSES (POWER Car- KNOWING Mini- DISTRIBUTION CENTER) Cavity tridge Description YOUR Fuse VEHICLE Fuse The power distribution center is located in the engine compartment. 15 Amp Climate Control/ (fig. 186) F130 Blue Instrument Panel SAFETY Passenger Assistance/Hands 10 Amp F131 Free System –...
Page 307 Car- Car- KNOWING Mini- Mini- Cavity tridge Description Cavity tridge Description YOUR Fuse Fuse Fuse Fuse VEHICLE 60 Amp Interior Power Dis- 40 Amp Exterior Lights 2 F101 F144 Yellow tribution Center Rail Green SAFETY 60 Amp Interior Power Dis- 30 Amp To Body F102...
Page 308 Car- Car- KNOWING Mini- Mini- Cavity tridge Description Cavity tridge Description YOUR Fuse Fuse VEHICLE Fuse Fuse Brake/Electronic 25 Amp Powertrain Auto 10 Amp F164 F156 Stability Control Natural Shutdown SAFETY Module 20 Amp Powertrain F165 Transfer Case Mod- Yellow Shutdown 10 Amp ule –...
Page 309 SHIFT LEVER OVERRIDE Car- KNOWING Mini- Cavity tridge Description If a malfunction occurs and the shift lever cannot be YOUR Fuse Fuse VEHICLE moved out of the PARK position, you can use the 10 Amp Powertrain Control following procedure to temporarily move the shift F176 Modules lever:...
Page 310: Freeing A Stuck Vehicle
FREEING A STUCK VEHICLE 4. Press and maintain firm pressure on the brake pedal. KNOWING If your vehicle becomes stuck in mud, sand, or snow, it YOUR 5. Insert a screwdriver or similar small tool into the VEHICLE can often be moved using a rocking motion. Turn the access port, and push and hold the override release steering wheel right and left to clear the area around lever forward.
Page 311 • Racing the engine or spinning the WARNING! KNOWING wheels may lead to transmission over- YOUR Fast spinning tires can be dangerous. VEHICLE heating and failure. Allow the engine to Forces generated by excessive wheel idle with the shift lever in NEUTRAL for at least speeds may cause damage, or even failure, of the one minute after every five rocking-motion axle and tires.
Page 312 TOW EYE Tow eyes are for emergency use only, to KNOWING Your vehicle is equipped with a tow eye that can be YOUR rescue a vehicle stranded off road.Do not VEHICLE used to tow a disabled vehicle. (fig. 188) use tow eyes for tow truck hookup or highway towing.You could damage your vehicle.
Page 313 FRONT TOW EYE USAGE REAR TOW EYE USAGE KNOWING The front tow eye receptacle is located on the lower The rear tow eye receptacle is located behind a door, YOUR right side of the front fascia. located on the left rear bumper fascia. VEHICLE To install the tow eye, remove the rubber plug and To install the tow eye, open the door using the vehicle...
Page 314: Towing A Disabled Vehicle
TOWING A DISABLED VEHICLE KNOWING This section describes procedures for towing a disabled vehicle using a commercial towing service. YOUR VEHICLE FWD MODELS FWD MODELS Wheels OFF Towing Condition MANUAL AUTOMATIC AWD MODELS the Ground SAFETY TRANSMISSION TRANSMISSION If tranmission is operable: •...
Page 315 Proper towing or lifting equipment is required to pre- WITHOUT THE KEY FOB KNOWING vent damage to your vehicle. Use only tow bars and Special care must be taken when the vehicle is towed YOUR other equipment designed for this purpose, following with the ignition in the OFF position.
Page 316 FRONT WHEEL DRIVE (FWD) MODELS — FRONT WHEEL DRIVE (FWD) MODELS — KNOWING MANUAL TRANSMISSION AUTOMATIC TRANSMISSION YOUR VEHICLE The manufacturer recommends towing your vehicle The manufacturer recommends towing your vehicle with all four wheels OFF the ground using a flatbed. with all four wheels OFF the ground using a flatbed.
Page 317: Maintenance Schedule
SERVICING AND CARE KNOWING YOUR MAINTENANCE SCHEDULE NOTE: VEHICLE • The oil change indicator message will not moni- MAINTENANCE SCHEDULE – tor the time since the last oil change. Change GASOLINE ENGINE SAFETY your vehicles oil if it has been 12 months since The Scheduled Maintenance services listed in this your last oil change even if the oil change indica- manual must be done at the times or mileages specified...
Page 318 Thousands Of Kilometers KNOWING YOUR Months VEHICLE Check battery charge status and possibly recharge. • • • • • • • • Check tire condition/wear and adjust pressure, if SAFETY • • • • • • • • necessary. Check operation of lighting system (headlamps, direction STARTING indicators, hazard warning lights, luggage compartment, •...
Page 319 Thousands Of Kilometers KNOWING YOUR Months VEHICLE Check exhaust gas emissions. • • • • • • • • Check engine management system operation (via SAFETY • • • • • • • • diagnostic socket). Change the automatic transmission fluid and filter (**). •...
Page 320 Periodic Checks Heavy-Duty Use Of The Car KNOWING Every 1,000 km or before long journeys, check and, if If the car is used mainly under one of the following YOUR VEHICLE necessary, restore: conditions: • engine coolant; • towing a trailer or caravan; SAFETY •...
Page 321 The tech- STARTING nicians at your dealership know your vehicle best, and NOTE: DRIVING have access to factory trained information, genuine FIAT • Under no circumstances should oil change intervals parts, and specially designed electronic and mechanical WARNING exceed 24 months.
Page 322 Thousands Of Kilometers KNOWING YOUR Months VEHICLE Check lighting system operation (headlights, direction indicators, hazard • • • • • • SAFETY lights, passenger compartment lights, instrument panel warning lights, etc.). Check the position/wear of the • • • • •...
Page 323 Thousands Of Kilometers KNOWING YOUR Months VEHICLE Check battery charge status and possibly • • • • • • recharge. SAFETY Check engine control system operation • • • • • • (via diagnostic socket). Visually inspect the condition of the STARTING •...
Page 324 Thousands Of Kilometers KNOWING YOUR Months VEHICLE Change the automatic transmission fluid and filter (for versions/markets, where • SAFETY provided) (#). (*) If the car is used for less than 10,000 km per year, it Periodic Checks STARTING is necessary to replace engine oil and cartridge every Every 1,000 km or before long journeys, check and, if 12 months.
Page 325 Heavy-Duty Use Of The Car • visually inspect conditions of: engine, transmission, KNOWING pipes and hoses (exhaust - fuel system - brakes) and If the car is used mainly under one of the following YOUR rubber elements (boots - sleeves - bushes - etc.); conditions: VEHICLE •...
Page 326 ENGINE COMPARTMENT — 2.4L KNOWING (fig. 191) YOUR VEHICLE SAFETY STARTING DRIVING WARNING LIGHTS MESSAGES IN AN EMERGENCY SERVICING AND CARE (fig. 191) TECHNICAL SPECIFICATIONS 1 — Engine Coolant Reservoir 7 — Power Distribution Center (Fuses) 2 — Power Steering Fluid Reservoir 8 —...
Page 327 ENGINE COMPARTMENT — 3.6L KNOWING (fig. 192) YOUR VEHICLE SAFETY STARTING DRIVING WARNING LIGHTS MESSAGES IN AN EMERGENCY SERVICING AND CARE TECHNICAL SPECIFICATIONS (fig. 192) 1 — Engine Coolant Reservoir 5 — Air Cleaner Filter 2 — Power Steering Fluid Reservoir 6 —...
Page 328 ENGINE COMPARTMENT — 2.0L DIESEL KNOWING (fig. 193) YOUR VEHICLE SAFETY STARTING DRIVING WARNING LIGHTS MESSAGES IN AN EMERGENCY SERVICING AND CARE TECHNICAL SPECIFICATIONS (fig. 193) 1 — Engine Coolant Reservoir 5 — Brake Fluid Reservoir 2 — Power Steering Fluid Reservoir 6 —...
Page 329: Maintenance Procedures
• Car maintenance should be done at a FIAT STARTING future. Dealership. For routine and minor maintenance...
Page 330 ENGINE OIL Do not overfill the engine. Overfilling the KNOWING YOUR engine will cause oil aeration, which can Checking Oil Level – Gasoline Engine VEHICLE lead to loss of oil pressure and an in- To assure proper engine lubrication, the engine oil crease in oil temperature.This could damage your must be maintained at the correct level.
Page 331 9.55535-CR1 API SN, ILSAC GF-5 may be used when VEHICLE maintenance operations you wish to SAE 5W-20 engine oil meeting Fiat 9.55535-CR1 is not carry out yourself, we do recommend you have available. the proper equipment, genuine FIAT spare parts SAFETY and the necessary fluids;do not however carry out...
Page 332 Disposing Of Used Engine Oil And Oil Filters Engine Air Cleaner Filter Selection KNOWING Care should be taken in disposing of used engine oil and The quality of replacement engine air cleaner filters YOUR VEHICLE oil filters from your vehicle. Used oil and oil filters, varies considerably.
Page 333 (Continued) AIR CONDITIONER MAINTENANCE KNOWING For best possible performance, your air conditioner • Battery gas is flammable and explosive. Keep YOUR should be checked and serviced by an authorized VEHICLE flame or sparks away from the battery. Do not dealer at the start of each warm season. This service use a booster battery or any other booster source should include cleaning of the condenser fins and a with an output greater than 12 Volts.
Page 334 SERVICING AND CARE the proper equipment, genuine FIAT spare parts and the necessary fluids;do not however carry out these operations if you have no experience. TECHNICAL SPECIFICATIONS CONTENTS (fig.
Page 335 3. Pivot the glove box downward. The A/C air filter is identified with an arrow KNOWING 4. Disengage the two retaining tabs that secure the to indicate airflow direction through the YOUR VEHICLE filter cover to the HVAC housing and remove the filter.
Page 336 If any of these condi- carry out yourself, we do recommend you have tions are present, clean the wiper blades or replace as the proper equipment, genuine FIAT spare parts SAFETY necessary. and the necessary fluids;do not however carry out these operations if you have no experience.
Page 337 2. Lift the rear wiper arm upward to raise the wiper ADDING WASHER FLUID KNOWING blade off of the liftgate glass. The windshield washer and the rear window washer YOUR share the same fluid reservoir. The fluid reservoir is VEHICLE 3.
Page 338 FIAT spare parts Whenever a change is noticed in the sound of the SAFETY and the necessary fluids;do not however carry out exhaust system, when exhaust fumes can be detected these operations if you have no experience.
Page 339 AND CARE carry out yourself, we do recommend you have motion. the proper equipment, genuine FIAT spare parts • Do not try to start the engine by pushing or towing and the necessary fluids;do not however carry out TECHNICAL the vehicle.
Page 340 Coolant Checks Selection Of Coolant – Gasoline Engine KNOWING Check engine coolant (antifreeze) protection every Use only the manufacturer's recommended coolant. YOUR VEHICLE 12 months (before the onset of freezing weather, Refer to “Fluids, Lubricants, and Genuine Parts” in where applicable). If coolant is dirty or rusty in appear- “Technical Specifications”...
Page 341 Selection Of Coolant – Diesel Engine Use only high purity water such as distilled or deion- KNOWING ized water when mixing the water/engine coolant Use only the manufacturer's recommended coolant YOUR (antifreeze) solution. The use of lower quality water (antifreeze). Refer to “Fluids, Lubricants, and Genuine VEHICLE will reduce the amount of corrosion protection in the Parts”...
Page 342 Cooling System Pressure Cap Disposal Of Used Coolant KNOWING The cap must be fully tightened to prevent loss of Used ethylene glycol-based engine coolant is a regu- YOUR VEHICLE engine coolant (antifreeze), and to ensure that engine lated substance requiring proper disposal. Check with coolant (antifreeze) will return to the radiator from the your local authorities to determine the disposal rules coolant recovery tank.
Page 343 • Keep the front of the radiator clean. If your vehicle is the proper equipment, genuine FIAT spare parts equipped with air conditioning, keep the front of the CONTENTS and the necessary fluids;do not however carry out...
Page 344 Master Cylinder – Brake Fluid Level Check clutch release system. See your local authorized dealer KNOWING for service. Check the fluid level in the master cylinder immediately YOUR VEHICLE if the “Brake Warning Light” indicates system failure. Use only manufacturer's recommended brake fluid. Refer to “Fluids, Lubricants, and Genuine Parts”...
Page 345 (Continued) Using a transmission fluid other than the KNOWING • Overfilling the brake fluid reservoir can result manufacturer’s recommended fluid may YOUR VEHICLE in spilling brake fluid on hot engine parts, causing cause deterioration in transmission shift the brake fluid to catch fire. Brake fluid can also quality and/or torque converter shudder, and will damage painted and vinyl surfaces, care should require more frequent fluid and filter changes.
Page 346 27° C. SPECIFICATIONS the proper equipment, genuine FIAT spare parts and the necessary fluids;do not however carry out these operations if you have no experience. CONTENTS...
Page 347 7. Wipe the dipstick clean and reinsert it until seated. • Using a transmission fluid other than KNOWING Then, remove the dipstick and note the fluid level the manufacturer’s recommended fluid YOUR on both sides. The fluid level reading is only valid if VEHICLE may cause deterioration in transmission there is a solid coating of oil on both sides of the...
Page 348 MANUAL TRANSMISSION Frequency Of Fluid Change KNOWING (for versions/markets, where provided) Refer to the “Maintenance Schedule” for the proper YOUR VEHICLE maintenance intervals. Lubricant Selection Use only manufacturers recommended transmission POWER TRANSFER UNIT (PTU) – fluid. Do not add any materials (other than leak detec- AWD MODELS ONLY SAFETY tion dyes).
Page 349 Washing APPEARANCE CARE AND PROTECTION KNOWING FROM CORROSION • Wash your vehicle regularly. Always wash your ve- YOUR VEHICLE hicle in the shade using a mild car wash soap, and Protection Of Body And Paint From Corrosion rinse the panels completely with clear water. Vehicle body care requirements vary according to geo- graphic locations and usage.
Page 350 • If your vehicle is damaged due to an accident or Stain Repel Fabric Cleaning Procedure KNOWING similar cause, which destroys the paint and protec- (for versions/markets, where provided) YOUR tive coating, have your vehicle repaired as soon as VEHICLE Stain Repel seats may be cleaned in the following possible.
Page 351 Interior Care WARNING! KNOWING Instrument Panel Cover YOUR Do not use volatile solvents for cleaning VEHICLE The instrument panel cover has a low glare surface, purposes. Many are potentially flam- which minimizes reflections in the windshield. Do not mable,and if used in closed areas they may cause use protectants or other products, which may cause respiratory harm.
Page 352 Glass Surfaces Seat Belt Maintenance KNOWING All glass surfaces should be cleaned on a regular basis Do not bleach, dye or clean the belts with chemical YOUR VEHICLE with any commercial household-type glass cleaner. solvents or abrasive cleaners. This will weaken the Never use an abrasive type cleaner.
Page 353: Vehicle Storage
VEHICLE STORAGE TIRE ROTATION KNOWING RECOMMENDATIONS If you will not be using your vehicle for more than YOUR VEHICLE 21 days you may want to take steps to preserve your Tires on the front and rear axles of vehicles operate at battery.
Page 354: Technical Specifications
TECHNICAL SPECIFICATIONS KNOWING VEHICLE IDENTIFICATION NUMBER YOUR NOTE: It is illegal to remove or alter the VIN. VEHICLE The Vehicle Identification Number (VIN) is on the left front corner of the instrument panel and is visible from outside of the vehicle through the windshield. This SAFETY number also appears stamped on the right front door sill under the sill moulding and printed on the Automobile...
Page 355 TIRES — GENERAL INFORMATION Economy KNOWING Improper inflation pressures can cause uneven wear YOUR Tire Pressure patterns to develop across the tire tread. These abnor- VEHICLE Proper tire inflation pressure is essential to the safe and mal wear patterns will reduce tread life resulting in a satisfactory operation of your vehicle.
Page 356 At least once a month: Example: If garage temperature = 20°C and the outside KNOWING temperature = 0°C then the cold tire inflation pressure • Check and adjust tire pressure with a good quality YOUR should be increased by 21 kPa, which equals 7 kPa for VEHICLE pocket-type pressure gauge.
Page 357 Radial Ply Tires Tire Types KNOWING YOUR All Season Tires (for versions/markets, where WARNING! VEHICLE provided) Combining radial ply tires with other All Season tires provide traction for all seasons (spring, types of tires on your vehicle will cause summer, fall and winter). Traction levels may vary SAFETY your vehicle to handle poorly.
Page 358 Snow Tires Run Flat Tires (for versions/markets, where KNOWING provided) Some areas of the country require the use of snow YOUR VEHICLE tires during the winter. Snow tires can be identified by Run Flat tires allow you the capability to drive 80 km at a mountain/snowflake symbol on the tire sidewall.
Page 359 Spare Tire Matching Original Equipped Tire And tire. Do not install more than one compact spare tire KNOWING Wheel (for versions/markets, where provided) and wheel on the vehicle at any given time. YOUR Your vehicle may be equipped with a spare tire and VEHICLE WARNING! wheel equivalent in look and function to the original...
Page 360 Limited-Use Spare (for versions/markets, Tire Spinning KNOWING where provided) When stuck in mud, sand, snow, or ice conditions, do YOUR VEHICLE The limited-use spare tire is for temporary emergency not spin your vehicle's wheels above 48 km/h or for use only. This tire is identified by a label located on the longer than 30 seconds continuously without stopping.
Page 361 Tread Wear Indicators Life Of Tire KNOWING Tread wear indicators are in the original equipment The service life of a tire is dependent upon varying YOUR tires to help you in determining when your tires should factors including, but not limited to: VEHICLE be replaced.
Page 362 Replacement Tires WARNING! KNOWING The tires on your new vehicle provide a balance of YOUR • Do not use a tire, wheel size or rating VEHICLE many characteristics. They should be inspected regu- other than that specified for your ve- larly for wear and correct cold tire inflation pressure.
Page 363 TIRE CHAINS (TRACTION DEVICES) To avoid damage to your vehicle or tires, KNOWING Use of traction devices require sufficient tire-to-body observe the following precautions: YOUR VEHICLE clearance. Follow these recommendations to guard Because of restricted traction device • against damage. clearance between tires and other suspension components, it is important that only traction •...
Page 364 FUEL REQUIREMENTS — GASOLINE Methanol KNOWING ENGINE (Methyl) is used in a variety of concentrations when YOUR VEHICLE blended with unleaded gasoline. You may find fuels All engines are designed to meet all emissions regula- containing 3% or more methanol along with other tions and provide excellent fuel economy and perfor- alcohols called cosolvents.
Page 365 the lower energy content of ethanol. Problems that MMT In Gasoline KNOWING result from using methanol/gasoline or E-85 ethanol MMT is a manganese containing metallic additive that is YOUR blends are not the responsibility of the manufacturer. blended into some gasoline to increase octane. Gaso- VEHICLE While MTBE is an oxygenate made from Methanol, it line blended with MMT provides no performance ad-...
Page 366 FUEL REQUIREMENTS — DIESEL Indiscriminate use of fuel system cleaning agents should KNOWING be avoided. Many of these materials intended for gum ENGINE YOUR and varnish removal may contain active solvents or VEHICLE Use Premium Quality Diesel fuels with a Cetane rating similar ingredients.
Page 367: Fluid Capacities
FLUID CAPACITIES KNOWING YOUR VEHICLE Metric Fuel (Approximate) Front Wheel Drive Models 77.6 Liters SAFETY All Wheel Drive Models 79.8 Liters Engine Oil with Filter STARTING 2.4L Engine 4.3 Liters 3.6L Engine 5.6 Liters DRIVING 2.0L Diesel Engine 5.2 Liters WARNING Cooling System * LIGHTS...
Page 368 STARTING Reference N° F101.M01. Cooling circuit usage percentage: 50% water 50% PARAFLU UP **) DRIVING SAE Grade 5W-20 fully synthetic engine oil that meets FIAT Classification 9.55535-CR1, API SN, ILSAC GF-5 (SELENIA K POWER, Contractual WARNING LIGHTS Technical Reference N°F102.F11).
Page 369 Component Fluids and Lubricants Specs (Genuine Parts) KNOWING Spark Plugs – 2.4L Engine We recommend you use OEM Original Equipment Spark Plugs (Gap 1.1 mm) YOUR VEHICLE Spark Plugs – 3.6L Engine We recommend you use OEM Original Equipment Spark Plugs (Gap 1.1 mm) Fuel Selection –...
Page 370 9.55550-MZ6 (TUTELA TRANSMISSION GEARFORCE Contractual Technical markets, where provided) STARTING Reference N° F002.F10) Synthetic fluid that meets FIAT Classification 9.55597, FMVSS n° 116, DOT 4, DRIVING Brake/Clutch Master Cylinder ISO 4925, SAE J-1704 (TUTELA TOP 4, Contractual Technical Reference WARNING N°...
Page 371 (in particular, the engine and bodywork) and has no additional waste. To hand your vehicle over at the end of its life without extra cost, go to one of our Dealerships or FIAT-authorized collection and scrapping centres.
Page 374 CONTENTS KNOWING YOUR About Your Brakes .....133, 234 Automatic Headlights ......86 VEHICLE ABS (Anti-Lock Brake System) .
Page 375 Break-In Recommendations, New Vehicle ..229 Windshield Wiper Blades ....330 KNOWING Brightness, Interior Lights .....89 Coin Holder .
Page 376 Delay (Intermittent) Wipers ....92 Emergency, In Case of KNOWING Diagnostic System, Onboard ....143 Freeing Vehicle When Stuck .
Page 377 Exterior Folding Mirrors ..... .65 Additives ......359 KNOWING Exterior Lighting .
Page 378 Glass Cleaning ......346 Ignition KNOWING Gross Axle Weight Rating ....250 Key .
Page 379 Knee Bolster ......216 Headlights On With Wipers ....86 KNOWING Headlight Switch .
Page 380 Locks ........113 Electric Remote ......64 KNOWING Automatic Door .
Page 381 Operator Manual (Owner's Manual) ....4 Rear Air Conditioning .....71, 81 KNOWING Outside Rearview Mirrors .
Page 382 Rocking Vehicle When Stuck ....304 Security Alarm ......15, 269 KNOWING Roof Rack (Luggage Rack) .
Page 383 Tilt Column ......60 Life of Tires ......355 KNOWING Wheel, Heated .
Page 384 Transmission Warning Flasher, Hazard .....101 KNOWING Automatic ......238, 339 Warning Lights (Instrument Cluster Description).
Page 385 Notes...
Page 386 Notes Fiat Group Automobiles S.p.A. - Parts & Services - Technical Services - Service Engineering Largo Senatore G. Agnelli, 3 - 10040 Volvera - Torino (Italia) Print n. 530.02.287 - 09/2013 - Edition 1...
Page 388 ENGLISH The data contained in this publication is intended merely as a guide. FIAT reserves the right to modify the models and versions described in this booklet at any time for technical and commercial reasons. If you have any further questions please consult your FIAT dealer.

Fiat Freemont Owner's Handbook Manual

Quick Links

Related Manuals for Fiat Freemont

Summary of Contents for Fiat Freemont

Table of Contents
