- Page 1 ERVICE ANUAL & PARTS LIST REF. NO. S/M-695 MAY. 2000 MODULE NO. QW-2351 BG-21 INDEX (WITHOUT PRICE)
-
Page 2: Specifications: Qw-2351
CONTENTS Page 1. SPECIFICATIONS: QW-2351 ..............1 2. OPERATION CHART: QW-2351 ..............2 3. EXPLODED VIEW: QW-2351 ..............3 4. PARTS LIST: QW-2351 ................4 1. SPECIFICATIONS: QW-2351 Item Detail Module (Movement) No. QW-2351 Battery SR-621SW Battery Life Approx. 2 years 1.43 µA (Max.) -
Page 3: Operation Chart: Qw-2351
2. OPERATION CHART: QW-2351 TO SET TIME Pull the crown out. Set the hands by turning the crown in either direction. Push the crown in on a time signal. Crown For watch with the elapsed time bezel Rotate the elapsed time bezel to align the mark with the minute hand. -
Page 4: Exploded View: Qw-2351
3. EXPLODED VIEW: QW-2351 6 13 (7436 9666) 5 12 (7435 8277) 7 15 (7436 9589) 3 Battery (SR-621SW) 9 12 (7435 8277) 7 (7436 9659) 8 6 (7436 9547) 11 (7436 9652) 3 (1003 1198) 16 (7436 9575) 10 (7436 9512) -
Page 5: Parts List: Qw-2351
4. As for order/supply of spare parts, refer to the separate publication "GUIDE BOOK for spare parts supply". Item Code No. Parts Name Specification Applicable 1001 3462 MODULE/WITH MOVEMENT QW-2351-01 (R-3D1L-201) BG-21B-2BV/3BV/4BV/6BV/8BV 7436 9498 BRIDGE/CANNON PINION 5D3A601 QW-2351-01 7436 9505 BRIDGE/TRAIN WHEEL... - Page 6 CASIO TECHNO CO.,LTD. Overseas Service Division Nishi-Shinjuku Kimuraya Bldg. 1F 5-25, Nishi-Shinjuku 7-Chome Shinjuku-ku, Tokyo 160-0023, Japan...
