17" LCD Color Monitor
Service
Service
Service
Description
Table Of Contents.....................................................1
Revision List................................................................2
Important Safety Notice.............................................3
1. Monitor Specifications................................................4
2. LCD Monitor Description............................................5
3 . O p e r a t i o n i n s t r u c t i o n s ... . . . . . . . . . . . . . . . . . . . . . . . 6
3.1General Instructions...........................................6
3.2 Control buttons...............................................6
3.3 Adjusting the Picture................................................8
3.4 Connecting to the PC .......................................10
4. Input/Output Specification......................................11
4.1 Input Signal Connector.........................................11
4.2 Factory Preset Display Modes...............................11
4.3 Pixel Defect Policy..........................................12
4.4 Failure Mode of Panel ....................................15
5. Block Diagram.................................................16
5.1 Software Flow Chart.............................................16
5.2 Electrical Block Diagram....................................18
6. Schematic Diagram.............................................20
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE
CHASSIS AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN
SERVICING ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING
REFER TO BACK COVER FOR IMPORTANT SAFETY GUIDELINES
Copyright 2008 Philips Consumer Lifestyle
170V9FB/97
170V9FB/62
170V9FB/27
170V9FB/00
170V9FB/05
170V9FB/93
170V9FB/94
Page
Page
SAFETY NOTICE
Subject to modification ○
170V9FB/97
(1)
(2)
170V9FB/93
(1)
(2)
170V9FB/94(2)
(1)
170V9FB/00(2)
(1)
170V9FB/05(2)
(1)
170V9FB/62(2)
(1)
170V9FB/27(2)
(1)
Description
6.1 Main Board....................................................20
6.2 Power Board.....................................................25
6.3 Key Board.........................................................29
7. PCB Layout.........................................................30
7.1 Main Board......................................................30
7.2 Power Board......................................................32
7.3 Key Board.........................................................36
8. Wiring Diagram...................................................37
9. Scalar Board Overview........................................38
10. Mechanical Instructions........................................39
11. Trouble shooting.................................................43
12. Repair Flow Chart...............................................45
13. ISP Instructions...........................................................51
14. DDC Instructions.........................................................59
15. White Balance, Luminance Adjustment..................68
16. Monitor Exploded View................................................70
17. Recommended & Spare Parts List............................71
18. Different Parts List......................................................75
19. General Product Specification................................79
Mar, 19, 2008
K
Chassis: HUDSON 9
Page
GB
3122 785 17830
Advertisement
Chapters
Table of Contents
Related Manuals for Philips 170V9FB/97
Summary of Contents for Philips 170V9FB/97
-
Page 1: Table Of Contents
SERVICING ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES. CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING REFER TO BACK COVER FOR IMPORTANT SAFETY GUIDELINES Copyright 2008 Philips Consumer Lifestyle Subject to modification ○ Mar, 19, 2008 3122 785 17830... -
Page 2: Revision List
Revision History Mar.19, 2008 Initial release, Draft Version Add CTV Model 170V9FB/62, 170V9FB/27, 170V9FB/05,170V9FB/00 Apr.03, 2008 Add Philips 12NC for 170V9FB/97 Apr.17, 2008 Add a new panel 750GLU70G1D42N Apr.25, 2008 Add CTV Model 170V9FB/93 and 170V9FB/94 Add CTV Model 170V9FB/97(2) May.27, 2008... -
Page 3: Important Safety Notice
HUDSON 9 Important Safety Notice Proper service and repair is important to the safe, reliable operation of all Philips Company Equipment. The service procedures recommended by Philips and described in this service manual are effective methods of performing service operations. Some of these service operations require the use of tools specially designed for the purpose. -
Page 4: Monitor Specifications
HUDSON 9 1. Monitor Specifications... -
Page 5: Lcd Monitor Description
HUDSON 9 2. LCD Monitor Description The LCD monitor will contain a main board, a power board and a key board which house the flat panel control logic, brightness control logic and DDC. The power board will provide AC to DC Inverter voltage to drive the backlight of panel and the main board chips each voltage. -
Page 6: General Instructions
HUDSON 9 3. Operating Instructions 3.1 General Instructions Press the power button to turn the monitor on or off. The other control buttons are located at the front of the panel of the monitor. By changing these settings, the picture can be adjusted to your personal preferences. The power cord should be connected. - Page 7 HUDSON 9 Rear View...
-
Page 8: Adjusting The Picture
HUDSON 9 3.3 Adjusting the Picture Description of the On Screen Display When you press the button on the front control of your monitor, the On-Screen Display (OSD) Main Controls window will pop up and you can then start making adjustments to your monitor's various features. Use the keys to make your adjustments. - Page 9 HUDSON 9 The OSD Tree Below is an overall view of the structure of the On-Screen Display. You can use this as a reference when you want to work your way around the different adjustments later on.
-
Page 10: Connecting To The Pc
HUDSON 9 3.4 Connecting to the PC 1) Connect the power cord to the back of the monitor firmly. 2) Connect to PC (a) Turn off your computer and unplug its power cable. (b) Connect the monitor signal cable to the video connector on the back of your computer. (c) Plug the power cord of your computer and your monitor into a nearby outlet. -
Page 11: Input/Output Specification
HUDSON 9 4. Input/ Output Specification 4.1 Input Signal Connector Analog connectors Pin No. Description Pin No. Description Red video input DDC+5V Green video input/SOG Logic Ground Blue video input Ground Sense (GND) Serial data line (SDA) Cable detect (GND) H. -
Page 12: Pixel Defect Policy
HUDSON 9 4.3 Pixel Defect Policy... - Page 13 HUDSON 9...
- Page 14 HUDSON 9...
-
Page 15: Failure Mode Of Panel
HUDSON 9 4.4 Failure Mode Of Panel Quick reference for failure mode of LCD panel this page presents problems that could be made by LCD panel. It is not necessary to repair circuit board. Simply follow the mechanical Polarizer has bubbles instruction on this manual to eliminate failure by replace LCD panel. -
Page 16: Block Diagram
HUDSON 9 5. Block Diagram 5.1 Software Flow Chat... - Page 17 HUDSON 9 1) MCU initialize. 2) Is the EPROM blank? 3) Program the EPROM by default values. 4) Get the PWM value of brightness from EPROM. 5) Is the power key pressed? 6) Clear all global flags. 7) Are the AUTO and SELECT keys pressed? 8) Enter factory mode.
-
Page 18: Electrical Block Diagram
HUDSON 9 5.2 Electrical Block Diagram 5.2.1 Main Board Panel Interface (CN403) Scalar TSUM1PFR-LF EEPROM Keypad Interface (Include MCU, ADC, OSD) M24C16 (CN401) (U401) (U403) H sync V sync Flash Memory Crystal SST25VF010A-33-4C 14.31818MHZ (U402) (X401) D-Sub Connector (CN101) VGA_R+, VGA_SDA, VGA_G+, VGA_SCL... - Page 19 HUDSON 9 5.2.2 Inverter/Power Board AC input Bridge Rectifier Transformer Rectifier diodes EMI filter and Filter Start Circuit: R904、R905、R906 Feedback Circuit Control IC ON/OFF Output MOSFET Circuit Transformer Lamp Over ON/OFF Feedback Voltage Control Circuit Control IC...
-
Page 20: Schematic Diagram
HUDSON 9 6. Schematic 6.1 Main Board 715G2904-1 TSUM16FWR SCHEMATIC XGA/SXGA LVDS OUTPUT DSUB_R+ DSUB_R+ VCC1.8 DSUB_R- DSUB_R- DSUB_G+ DSUB_G+ VCC3.3 DSUB_G- DSUB_G- VCC1.8 DSUB_SOG DSUB_SOG CMVCC DSUB_B+ DSUB_B+ DSUB_5V DSUB_B- DSUB_B- VCC3.3 CMVCC1 DSUB_H DSUB_H CMVCC1 DSUB_V DSUB_V DSUB_5V DDC1_SDA DDC1_SDA CMVCC... - Page 21 HUDSON 9 Input H_Sync R101 0R05 1/10W 5% R102 100R 1/16W 5% DSUB_H V_Sync R103 100R 1/16W 5% FB102 DSUB_V C101 R104 VGA_B+ CN101 B3 DSUB_B+ VCC3.3 R105 R106 C102 C103 BEAD 100R 1/16W 5% C101 A7 2K2 1/16W 5% 2K2 1/16W 5% 0.047uF C102 A4...
- Page 22 HUDSON 9 Scalar AVDD VDDP VDDC CN401 G1 VCC3.3 VDDP AVDD FB401 CN402 G7 C401 C3 U401 VCC3.3 C403 A9 300OHM C404 A9 VCTRL VCTRL C403 C404 C406 B9 LVA3P C407 B9 0.1uF/16V 0.1uF/16V DSUB_R+ RIN0P LVA3M C408 C1 DSUB_R- RIN0M PA[0..1] C409 D10...
- Page 23 HUDSON 9 Output PANEL_VCC CN403 PA[0..1] PB[0..9] PA[0..1] PB[0..9] CN403 A5 C419 C2 C420 A4 R434 C420 C421 C3 PA[4..9] PA[4..9] FB402 C3 330 OHM 1/4W 0.1uF/16V Q404 C2 Q405 C3 R433 C2 R434 A4 R435 C1 R436 C2 CMVCC AO3401L CMVCC R433...
- Page 24 HUDSON 9 Power Due to LG doen't request PC'99 Function. CN404 B1 C422 D6 D401 R458 C423 B7 C425 B3 0Ohm 1/16W C426 D5 C427 D7 ESD_VCC 2 C428 D5 OTHER BAV99 C432 B7 DSUB_5V D401 A2 CMVCC D402 B2 DSUB_5V 2 FB403 C6 Q406 B4...
-
Page 25: Power Board
HUDSON 9 6.2 Power Board 715G2824-1 for 170V9FB/97(1) Power 100 OHM 1/4W R918 FB904 L904 +16V 100 OHM 1/4W R919 3.5uH C912 BEAD BD901 0.001uF R946 ZD902 100 OHM 1/4W R920 150OHM2W RLZ18B KBP208G C917 C918 680uF25V 680uF25V FB902 80OHM... - Page 26 HUDSON 9 Inverter +16V R805 100R 1/10W 5% ON/OFF D801 1N4148W Q805 CN801 PT801 CN801 A7 CN802 A7 POWER X'FMR C819 CN803 C7 CN804 C7 R806 100R 1/8W 68pF/3KV ZD802 C816 C801 B3 C802 B3 RLZ5.6B 22pF/6KV C803 C1 C804 C1 ZD803 D802 1N4148W C805 C2...
- Page 27 HUDSON 9 715G2824-1-2 for 170V9FB/97(2) CN902 C930 C939 C915 R914 F901 D901 C910 R918 D909 D909 NC/31DQ10FC NC/31DQ10FC R904 L904 C909 C932 R918 R918 L904 L904 100 OHM 1/4W 100 OHM 1/4W C907 F903 2A(INVERTER) R919 R919 R919 R939 100 OHM 1/4W...
- Page 28 HUDSON 9 CN801 CN801 C822 R811 CONN CONN T801 T801 R801 0R05 1/8W R801 0R05 1/8W D813 D808 C810 Q811 C801 C801 R850 C820 18pF/3KV 18pF/3KV L801 L801 +16V NC / L NC / L D810 C804 R802 R802 CN802 CN802 100R 1/8W 100R 1/8W...
-
Page 29: Key Board
HUDSON 9 6.3 Key Board 715G3016-1 LED_RED# LED_GRN# LED001 CN001 R001 4.3K OHM 1% 1/8W LBADC1 R002 2.4K OHM 1% 1/8W LBADC2 DC_POWERON R003 910R 1/8W LED_GRN# LED_RED# R004 4.3K OHM 1% 1/8W C001 C002 C003 C004 C005 R005 2.4K OHM 1% 1/8W NC/0.001uF NC/0.001uF NC/0.001uF... -
Page 30: Pcb Layout
HUDSON 9 7. PCB Layout 7.1 Main Board 715G2904-1 C101 FB101 B2 R418 C428 C102 FB102 B2 R419 R405 C103 FB103 B2 R420 SEN4 C104 FB401 B2 R421 C429 C105 FB402 A2 R424 R406 C106 FB403 A1 R425 U102 C107 FDT2 R426 C432... - Page 31 HUDSON 9...
-
Page 32: Power Board
HUDSON 9 7.2 Power Board 715G2824-1 for 170V9FB/97(1) BD901 D3 J821 BD901A D3 J823 BD901B D3 J824 C604 J825 C812 J826 C816 J829 C817 J830 C819 J831 C820 J832 C821 J833 C822 J834 C824 J835 C900 J836 C901 J837 C902... - Page 33 HUDSON 9 C601 R818 D805 R926 C602 R819 D806 R927 C603 R820 D807 R930 C606 R821 D808 R935 C608 R822 D809 R938 C609 R823 D903 R939 C610 R824 FB902 C3 R940 C611 R825 IC801 B2 R942 C612 R826 IC901 C3 R943 C613 R827...
- Page 34 HUDSON 9 for 170V9FB/97(2) 715G2824-1-2 BD901 BD901A D3 C604 D4 J601 J602 C605 C801 B1 J603 J604 C805 C811 J605 J606 C812 C825 C1 J801 J802 C826 C900 B4 J803 J804 C901 C902 E2 J806 J807 C903 C905 C3 J809...
- Page 35 HUDSON 9 C601 C602 R807 R808 C603 C606 R809 R810 C608 C609 R811 R812 C610 C611 R813 R814 C612 C613 R815 R816 C802 C803 R817 R818 C804 C806 R819 R820 C807 C808 R821 R822 C809 C810 R823 R824 C813 C814 R825 R826 C815...
-
Page 36: Key Board
HUDSON 9 7.3 Key Board 715G3016-1 CN001 A3 GND1 GND2 LED001 A2 SW001 A1 SW002 A2 SW003 A1 SW004 A2 SW005 A3 C001 C002 C003 C004 C005 C006 C007 C008 C009 C010 R001 R002 R003 R004 R005 R007 ZD001 A1 ZD002 A3 ZD003 A1 ZD004 A2... -
Page 37: Wiring Diagram
Key Board CN001 Note: The wiring diagram can be used for 170V9FB/97(1) and 170V9FB/97(2). The differences between 170V9FB/97(2) and 170V9FB/97(1) are the wire harness and FFC cable. Noted in the diagram are for 170V9FB/97(1). The FFC cable for 170V9FB/97(2) is 089G179J30N568. -
Page 38: Scalar Board Overview
HUDSON 9 9. Scalar Board Overview DC-DC Converters DC-DC Converters D-SUB Morning Star chip D-SUB Flash ROM EEPROM... -
Page 39: Mechanical Instructions
HUDSON 9 10. Mechanical Instructions 1. Back View as Fig1 Place the monitor face down on a smooth surface as Fig 1. Be careful to avoid scratch and injury during the uninstallation. Fig1 2. Remove the hinge as Fig2. Remove the three screws remarked in red to remove the hinge as Fig2. Fig2... - Page 40 HUDSON 9 3. Remove bezel and rear cover as Fig3~ Fig5. Fig3 Fig4...
- Page 41 HUDSON 9 Fig5 4. Remove main frame cover as Fig6~Fig7. a. Remove the two screws marked in red as Fig6. b. Disconnect the four connector marked in blue as Fig6. c. Remove the two screws marked in red as Fig7. Fig6 Fig7...
- Page 42 HUDSON 9 5. Remove power board as Fig8. a. Remove the two screws marked in red as Fig8. b. Disconnect the connector marked in blue as Fig8. Fig8 6. Remove scalar board as Fig9~Fig10. a. Remove the screw remarked in red as Fig9. b.
-
Page 43: Trouble Shooting
HUDSON 9 11. Trouble Shooting This page deals with problems that can be corrected by a user. If the problem still persists after you have tried these solutions, contact Philips customer service representative. - Page 44 HUDSON 9...
-
Page 45: Repair Flow Chart
HUDSON 9 12. Repair Flow Chart 12.1 Main Board (1). No Power No power Press power key and look if the picture is normal Please reinsert and make sure the AC of 100-240 is normal Reinsert or check the Adapter/Inverter section Measure U404 PIN2=3.3V Q409 V =1.8V... - Page 46 HUDSON 9 (2). No Picture No picture The button if X401 oscillate Replace X401 under control waveform is normal Check reset circuit of Check Correspondent component U401 is normal Measure U404 PIN2=3.3V Q409 V =1.8V collector Replace U401 Check U404, Q409 and Q410 X401 oscillate waveform is normal Replace X401...
- Page 47 HUDSON 9 (3). White screen White screen Measure Q404 base X401 oscillate waveform is normal is low level? Replace X401 Check Q404, Q405 is broken or CN403 solder? Check reset circuit of U401 is normal Check Correspondent Check Correspondent component. component.
- Page 48 HUDSON 9 11.2. Power/Inverter Board (1) No power Check ZD902 (-) = 16V Check AC line volt 110V or 220V Check AC input Check the voltage of C905 (+) Check bridge rectified circuit and F901 circuit Check start voltage for the pin3 of IC901 Check R904, R905, R906 and Change IC901 Check the auxiliary voltage is bigger than 10V and smaller than 20V...
- Page 49 HUDSON 9 (2) W / LED, No Backlight Check CN902 pin4 = 16V Check adapter or MB Check ON/OFF signal Check Interface board Check IC801 PIN2=5V Check Q801 and ZD801 Check IC801 PIN1, 15 have the output of square wave at short Change IC801 Check Q805 and Q806 PIN5, 6, 7, 8 have the output of square wave at short time.
- Page 50 HUDSON 9 12.3 Key Board OSD is unstable or not working Is Key Pad Board connecting normally? Connect Key Pad Board Replace Button Switch Is Button Switch normally? Replace Key Pad Board Is Key Pad Board normally? Check Main Board...
-
Page 51: Isp Instructions
HUDSON 9 13. ISP Instruction 1. When do the part, need the tools as follow: a. An i486 (or above) personal computer or compatible. b. Microsoft operation system Windows 95/98/2000/XP. c. “ PORT95NT.exe” program d. Software ISP SN Alignment kits The kit contents: a. - Page 52 HUDSON 9...
- Page 53 HUDSON 9...
- Page 54 HUDSON 9 Click to complete the installation.
- Page 55 HUDSON 9 Note: After installation, you must restart the PC to take the setup to effect. 3. Connect the ISP board as follow: Connect to Connect to the the PC LPT Philips 170V9...
- Page 56 HUDSON 9 4. The process of ISP write is as follows. a. Double-click ，running the program as follows:...
- Page 57 HUDSON 9 b. Click icon, search the program” 170V9_TSUM1PFR_LM170E03_Q2PowerBoard_20080520_V101”, and click open: c. Click icon. If connects success, it will show as the follow picture:...
- Page 58 HUDSON 9 d. Click icon and click icon. If burn in success, it will show as the follow picture:...
-
Page 59: Ddc Instructions
HUDSON 9 14. DDC Instruction General DDC Data Re-programming In case the main EEPROM with Software DDC which store all factory settings were replaced because a defect, repaired monitor’ the serial numbers have to be re-programmed. It is advised to re- soldered the main EEPROM with Software DDC from the old board onto the new board if circuit board have been replaced, in this case the DDC data does not need to be re-programmed. - Page 60 HUDSON 9 2. Install the “WinDDC_ setup” Second, you must install the . The processing as follows:...
- Page 61 HUDSON 9...
- Page 62 HUDSON 9 Click to complete the installation. 3. Connect the DDC board as follow: Connect to the PC LPT When you write analog EDID, Connect this port to the Philips 170V9’s VGA port 12V Input...
- Page 63 HUDSON 9 4. Take analog DDC write for example, as follow a. Double-click ，appear as follow Figs：...
- Page 64 HUDSON 9 b. Click , then click “OK”. It will appear as follow. c. Double-click , appear as follow Figs：...
- Page 65 HUDSON 9 d. Key “1”, press “Enter” key, and key 14 numbers after “Input Serial Number” as follow, e. Now analog DDC Write completes, as bellow,...
- Page 66 HUDSON 9 170V9 EDID Analog 128 bytes EDID Data (Hex): x0 x1 x2 x3 x4 x5 x6 x7 x8 x9 xA xB xC xD xE xF 00 FF FF FF FF FF FF 00 41 0C 1F C0 E0 D9 01 00 10: 17 0D 01 03 0E 22 1B 78 2A AD B0 A2 57 4A 9C 25 20: 11 50 54 BF EF 80 71 4F 81 40 81 80 01 01 01 01 30: 01 01 01 01 01 01 30 2A 00 98 51 00 2A 40 30 70...
- Page 67 Detailed Timing: 1280x1024 @ 60Hz. <-x-Detailed Timing Descriptions-x-> <---Detailed Timing Descriptions---> Detailed Timing: FF (Monitor SN) '123132312131' Detailed Timing: FC (Monitor Name) 'Philips 170V' Detailed Timing: FD (Monitor limits) Min. V. rate: 56Hz Max. V. rate: 76Hz Min. H. rate: 30KHz Max.
-
Page 68: White Balance, Luminance Adjustment
HUDSON 9 15. White Balance, Luminance Adjustment 1. Apparatuses and program: analyzer CA-210, PC, tool, FGA adjustment program (PHILIPS170V9.DDCI), Pattern generator. 2. Equipment installation: a. Connect analyzer CA-210 to PC by USB connector, install drive program CA-SDK Ver4.00 for CA-210 and restart PC after finish installing. - Page 69 HUDSON 9 4. Color Temp confirmation Connect the signal to the monitor, the monitor display white-picture, use CA-210 to measure the Color Temp of the screen center and select the OSD to make sure whether the Color Temps accord with the SPEC.
-
Page 70: Monitor Exploded View
HUDSON 9 16. Monitor Exploded View 170V9 Item Part No. BEZEL PANEL SCALAR BOARD ASSY POWER BOARD ASSY REAR COVER 170V9 STAND_BASE ASS'Y KEY BOARD ASSY KEY PAD... -
Page 71: Recommended & Spare Parts List
HUDSON 9 17. Recommended & Spare Parts List 170V9FB/97(1) Item Location Philips 12NC PCM Codes Description Remark FQ106 996510017733 Q34G0369ADTE1B0130 BEZEL L17-8QPH1(HUDSON9-170V) E750 750GLU70G1D3QN PANEL M170EG01 VD0B FQ AUO E750 750GLU70G1D4QN PANEL M170EG01 VD0C FQ AUO FQ002 996510014909 CBPC7AM5P1Q1 SCALER BOARD ASSY... - Page 72 HUDSON 9 IC903 996500036055 056G 139 3A PC123Y22FZOF IC904 996510002780 056G 158 10 T IC AZ431AZ-AE1 TO-92 BY AAC U102 996510014826 056G 662 13 IC AZC099-04S SOT23-6L U103 996510014826 056G 662 13 IC AZC099-04S SOT23-6L U401 996510014825 056G 562557 IC TSUM1PFR-LF U402 996510014910 705GQ756434...
- Page 73 HUDSON 9 170V9FB/97(2) Item Location Philips 12NC PCM Codes Description Remark FQ106 996510017733 Q34G0369ADTE1B0130 BEZEL L17-8QPH1(HUDSON9-170V) E750 996510017346 750GLC170A7P13M0PH PANEL CLAA170EA07P 8H4 FZ CPT E750 996510017345 750GLC170A7P12M0PH PANEL CLAA170EA07P 8H4 WJ CPT E750 996510017349 750GLC170A7P23M0PH PANEL CLAA170EA07P 8J4 FZ CPT...
- Page 74 E08907 996510014899 089G179E30N568 FFC CABLE 3rd source E08907 996510017569 089G179W30N568 FFC CABLE Service Kit Description Philips 12NC PCM Codes Remark DDC KIT 9965 000 43197 715L2005C2 FOR ALL MODEL OSD SN KIT 9965 000 43252 715GT033 C FOR ALL MODEL...
-
Page 75: Different Parts List
HUDSON 9 18. Different Parts List The BOMS of 170V9FB/62(1) and 170V9FB/00(1) are the same as 170V9FB/97(1). Diversity of 170V9FB/27(1) compared with 170V9FB/97(1) 170V9FB/27(1) 170V9FB/97(1) Location Philips 12NC PCM Codes Description Philips 12NC PCM Codes Description E08901 089G402A15N CX POWER CORD... - Page 76 Description Philips 12NC PCM Codes Description FQ301 089G410A15N IS POWER CORD WALL-OUT FOR UK 996510015663 089G404A15N IS POWER CORD Diversity of 170V9FB/27 (2) compared with 170V9FB/97(2) 170V9FB/27(2) 170V9FB/97(2) Location Philips 12NC PCM Codes Description Philips 12NC PCM Codes Description E08901...
- Page 77 HUDSON 9 Diversity of 170V9FB/93(2) compared with 170V9FB/97(2) 170V9FB/93(2) 170V9FB/97(2) Location Philips 12NC PCM Codes Description Philips 12NC PCM Codes Description FQ106 996510015860 Q34G0369ADTD1B0130 BEZEL 170V9 BEZEL 996510017733 Q34G0369ADTE1B0130 L17-8QPH1(HUDSON9-170V) FQ106 Q34G0369ADTF1B0130 BEZEL 170V9 FQ202 996510015863 Q44G7089813 2A 17"LCD CARTON...
- Page 78 PROE FILES REQUIRED 5.3 LOCATION OF PHILIPS LOGO PER PHILIPS MAKE-UP SHEET 5.4 GAP BETWEEN PANEL AND FRONT BEZEL 1.4MM (TYPE) 5.5 LOCATION OF CONTROL ICONS- PER PHILIPS GRAPHIC SHEET 5.6 COLOR FOR RESIN/PAINT PER PHILIPS MAKE-UP SHEET 5.7 RESINS 5.8 IF RAINT IS USED...
-
Page 79: General Product Specification
HUDSON 9 5.14 LABEL 5.15 PRODUCT DIMENSION/WEIGHT/ WEIGHT (REFER TO PHILIPS APPROVED SHT 191) 5.16 TRANSPORTATION 5.16.1 Transportation packages 5.16.2 Transportation Test 5.17 PALLET/CONTAINER LOADING (REFER TO PHILIPS APPROVED SHT 560) ENVIRONMENTAL CHARACTERISTICS 6.1 SUSCEPTIBILITY OF DISPLAY TO EXTERNAL ENVIRONMENT 6.2 TRANSPORTATION TESTS... -
Page 80: Foreword
30 minutes that brightness stability is optimal, and follow strictly after panel specification. 2. PRODUCT PROFILE This display monitor unit is a color display monitor enclosed in PHILIPS styling cabinet which has an integrated tilt base. 2.1 LCD... -
Page 81: Scanning Frequencies
HUDSON 9 2.2 Scanning frequencies Hor. : 30 – 83 K Hz Ver.: 56 - 76 Hz Video dot rate: < 140 MHz Power input: 90-264 V AC, 50/60 ± 2 Hz Power consumption : <40W maximum,< 36W ( Typ.) Functions: (1) D-SUB analog R/G/B separate inputs, H/V sync separated, Composite (H+V) TTL level, SOG sync 0 °C - 40°C... -
Page 82: Software Control Functions Via Osd /Control Adjustable Functions
HUDSON 9 3.3 Software control functions via OSD / control adjustable functions: Please refer to following Hudson8 OSD definitions 3.4 Timing requirement Factory Preset mode definition : 1. Perfect FOS while presenting all required timings. 2. Required timings need to be specified in User's Manual User mode 1. -
Page 83: Software Control Functions Via Osd / Control Adjustable Functions
OSD Time out (5, 10, 20, 30, 60) Setup Phase (0~100) Clock (0~100) H.Position (0~100) V.Position (0~100) Reset (Yes, No) Resolution Notification (On, Off) Information Power On Logo : Power On show up Philips logo 3 seconds change to input signal . -
Page 84: Horizontal Scanning
In accordance with VESA DDC/CI and MCCS ver.2.0, the monitor should be workable with Protrait Display Tune at least. 3.11 EDID 1 User visible strings on .inf file Philips 170V (17inch WIDE LCD MONITOR 170V9) 2 Manufacturer ID ( EDID data) 3 Product ID, "xxxx" 4 codes MSB(byte 12): C0... -
Page 85: Visual Characteristics
HUDSON 9 4. Visual characteristics 4.1 Test conditions Unless otherwise specified, this specification is defined under the following conditions. (1) Input signal : As defined in 3.3, 1280 x 1024 non-interlaced mode (1280 x 1024@60Hz 108MHz), signal sources must have 75 ohm output impedance. (2) Luminance setting : controls to be set to 300 nits (typical) with full screen 100 % duty cycle white signal... -
Page 86: Mechanical Characteristics
5. Mechanical characteristics 5.1 Cosmetic - Philips ID 5.2 Mechanical data files - ProE files required 5.3 Location of Philips logo - Per Philips make-up sheet 5.4 Gap between panel and front bezel < 1.4mm (typ) 5.5 Location of Control icons - Per Philips Graphic sheet 5.6 Color for resin/paint -... -
Page 87: Texture/Glossing Of Housing
HUDSON 9 5.11 Texture/Glossing of housing The texture area and texture no should follow Philips make-up sheet. The exterior surfaces shall have a uniform texture. Philips must approve the mold texturing. Detail document for texture refer to “UN-D249”, “UN-D 600”. -
Page 88: Transportation
HUDSON 9 5.15 Product dimension / Weight (Refer to SHT 191 ) Unit dimension : 371(W)*373(H)*191(D) Packed unit dimension : 375(W)* 419(D)*145(H) Net weight : 4.034Kg Gross weight : 4.874Kg. 5.16 Transportation Transportation standards follow TPV standard. 5.16.1 Transportation packages Packaging and wrapping shall be sufficient to protect the product against damage or loss during shipment from the supplier to the destination specified in the purchase order. -
Page 89: Reliability
Control II level AQL: 0.4 (major) 1.5 (minor) (Please also refer to annual quality agreement) Customer acceptance criteria: UAW0377/00 9. Philips’ Flat Panel Monitors Pixel Defect Policy Philips’ Flat Panel Monitors Pixel Defect Policy BRIGHT DOT DEFECTS ACCEPTABLE LEVEL MODEL... - Page 90 HUDSON 9 Fig 1: Measurement locations of Brightness Uniformity Fig 2: Cross talk pattern Gray level 46 (64 Gray level) Fig 3: Cross talk Pattern Center at Gray level 0 (Black)
-
Page 91: Regulatory Compliance
Remark (RSO) (NSO) Logo Q'ty Standards IEC60950-1:2001. Manufacture and Group and Applicant is national World CB Report, Philips World wide differences of all wide certificate Maximum countries listed in ambient CB Bulletin No. temperature:40°C 107A European Low Voltage Directives Declaration of... - Page 92 2004/108/EC EN55022:2006, HDMI have to test EN55024:1998+A EMC/CE test report PC mode and 1:2001+A2:2003, DVD mode EN61000-3-2:200 EN61000-3-3:199 5+A1:2001+A2:20 Philips is OEM GERMANY EN60950-1:2001 TUV certificate Optional license holder TUV-ERG certificate LCD: ISO13406-2, Philips is OEM Optional pr EN 50279:1998...
- Page 93 HUDSON 9 TUV MPR-II Philips is OEM TUV MPR-II Optional certificate license holder Philips is license EN60950-1:2001 SEMKO certificate Optional holder To add all sales TCO report and TCO'99 Optional name into certificate certificate SWEDEN TCO'03, or To add all sales...
- Page 94 EMF EN 50392 EN 50392 report 1 set provide EN50392 report (test fee 750EU) Supplier ship out Certificate of 3 samples to EN60950-1:2001 Philips Conformity Hungary and pay transportation cost. Eastern Supplier to 3 sets EN55022,EN5502 Europe provide CB, EMC...
- Page 95 HUDSON 9 Korean Safety Control law IEC EK certificate NOT REQUIRED 60950 KOREA Regulations laws: EMI 1996-78, 80. MIC certificate NOT REQUIRED EMS 1996-79,81 Supplier to SINGAPOR IEC60950 PSB certificate provide local representative Supplier have to GB4943-2001 CCC certificate check regulation information on rating label, carter label, user...
- Page 96 1 sample to AS/NZS3548:199 AUSTRALIA Australia and pay transportation AS/NZS CB, EMC report 1 set NEW-ZEAL cost, Supplier to CISPR22: 2002 apply for C-Tick Class B through Philips Saudi EN60950-1:2001 SASO Arabia EN55022, Saudi EN61000-3-2, SASO Arabia EN61000-3-3, EN55024 VCCI class B...
- Page 97 CSA C22.2 No CSA certificate Optional 60950 or CUL CANADA ICES-003 issue 3 Statement on label NOM-019-SCFI-1 MEXICO NOM certificate Philips NOT REQUIRED 2 sets TUV S-mark or Argentina EN60950-1:2001 IRAM UL 60950-1: UL certificate or CUL Optional 2003 FCC Part 15...
- Page 98 8. Supplier have to check regulation information on rating label, carton label, user manual to meet all mandatory regulation 9. Suppliers need to add Philips sales name, model no into BSMI, TCO, EK, MIC certificate 10. Suppliers have to apply all mandatory regulation based on sales country.
-
Page 99: Emc Requirements
10.2 EMC Requirements Supplier DVT EMI test result must be submitted prior to DVT samples delivery, and PVT EMI test result must be submitted again prior to PVT samples delivery, which also has to meet Philips' immunity testing specification. 10.3 RoHS Restriction on the use of certain hazardous substances. - Page 100 4. When the HV circuitry is operating properly there is no possibility of an x- tube must be the same type as the original, including suffix letter, or a Philips radiation problem. High voltage should always be kept at the manufacturer's approved type.
