Yamaha DVD-C961 Service Manual

Dvd audio/video sa-cd player
Hide thumbs Also See for DVD-C961:

Advertisement

Quick Links

DVD AUDIO/VIDEO SA-CD PLAYER
This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel.
It has been assumed that basic service procedures inherent to the industry, and more specifically YAMAHA Products, are already
known and understood by the users, and have therefore not been restated.
WARNING:
IMPORTANT:
The data provided is believed to be accurate and applicable to the unit(s) indicated on the cover. The research, engineering, and
service departments of YAMAHA are continually striving to improve YAMAHA products. Modifications are, therefore, inevitable
and specifications are subject to change without notice or obligation to retrofit. Should any discrepancy appear to exist, please
contact the distributor's Service Division.
WARNING:
IMPORTANT:
I CONTENTS
TO SERVICE PERSONNEL ...................................... 2-3
LOCALE MANAGEMENT INFORMATION ................... 4
FRONT PANEL .............................................................. 5
REAR PANEL ................................................................ 5
REMOTE CONTROL PANEL ........................................ 5
SPECIFICATIONS ...................................................... 6-7
INTERNAL VIEW ........................................................... 7
1 0 1 0 6 8
DVD-C961
IMPORTANT NOTICE
Failure to follow appropriate service and safety procedures when servicing this product may result in personal
injury, destruction of expensive components, and failure of the product to perform as specified. For these reasons,
we advise all YAMAHA product owners that any service required should be performed by an authorized
YAMAHA Retailer or the appointed service representative.
The presentation or sale of this manual to any individual or firm does not constitute authorization, certification or
recognition of any applicable technical capabilities, or establish a principle-agent relationship of any form.
Static discharges can destroy expensive components. Discharge any static electricity your body may have
accumulated by grounding yourself to the ground buss in the unit (heavy gauge black wires connect to this buss).
Turn the unit OFF during disassembly and part replacement. Recheck all work before you apply power to the unit.
2007
This manual is copyrighted by YAMAHA and may not be copied or
redistributed either in print or electronically without permission.
SERVICE MANUAL
REPAIR NOTES ............................................................. 7
DISASSEMBLY PROCEDURES ............................... 8-9
BLOCK DIAGRAM ....................................................... 10
WIRING DIAGRAM ...................................................... 11
PRINTED CIRCUIT BOARDS................................ 12-22
SCHEMATIC DIAGRAMS ...................................... 23-38
REPLACEMENT PARTS LIST .............................. 40-41
All rights reserved.
P.O.Box 1, Hamamatsu, Japan
'07.09

Advertisement

Table of Contents
loading

Summary of Contents for Yamaha DVD-C961

  • Page 1: Table Of Contents

    This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel. It has been assumed that basic service procedures inherent to the industry, and more specifically YAMAHA Products, are already known and understood by the users, and have therefore not been restated.
  • Page 2: To Service Personnel

    DVD-C961 I TO SERVICE PERSONNEL 1. Critical Components Information AC LEAKAGE WALL EQUIPMENT TESTER OR Components having special characteristics are OUTLET UNDER TEST EQUIVALENT marked s and must be replaced with parts having specifications equal to those originally installed. 2. Leakage Current Measurement (For 120V Models...
  • Page 3 DVD-C961 Laser Emitting conditions: 1) When the Top Cover is removed, and the STANDBY/ON SW is turned to the "ON" position, the laser component will emit a beam for several seconds to detect if a disc is present. During this time (5-10 sec.) the laser may radiate through the lens of the laser pick-up unit.
  • Page 4: Prevention Of Electrostatic Discharge

    DVD-C961 I PREVENTION OF ELECTROSTATIC DISCHARGE The laser diode in the DVD mechanism may be damaged due to static electricity from clothes or the human body. Use caution to prevent electrostatic damage when servicing or handling the DVD-mechanism. 1. Grounding for electrostatic damage prevention Some devices, such as the DVD player, use an optical pickup (laser diode) that will be damaged by static electricity in the working environment.
  • Page 5: Front Panel

    DVD-C961 I FRONT PANEL U model I REAR PANEL U model I REMOTE CONTROL PANEL...
  • Page 6: Specifications

    DVD-C961 I SPECIFICATIONS PLAYBACK SYSTEM Component video output DVD-video, VR (video recording) format (DVD-RW) DVD-audio Y output RCA/Phono x 1 (green) DVD-R, DVD-RW output RCA/Phono x 1 (blue) DVD+R, DVD+RW, DVD+R DL output RCA/Phono x 1 (red) Video CD, SVCD...
  • Page 7: Internal View

    DVD-C961 I INTERNAL VIEW I REPAIR NOTES 1. DVD 5-disc changer module DivX, DivX Ultra Certified, and as- sociated logos are trademarks of • When installing a new traverse unit, remove the solder from the shorted point of P.C.B. using an electrostatic DivX, Inc.
  • Page 8: Disassembly Procedures

    DVD-C961 I DISASSEMBLY PROCEDURES See replacement parts list for item numbers. When disassembling, use the special screw driver with tip shape in figure. 2.7 mm Top Cover [240] Mounting 1.7 mm ➝ Remove 7 screws. [257] (4 on side and 3 rear side.) ➝...
  • Page 9 DVD-C961 • Preventive measure for laser diode from electrostatic breakdown • How to manually open the tray ass’y When replacing the MONO P.C.B. or DVD 5-disc changer module, solder between lands of the optical pick up P.C.B. to a. Move the slider in the direction indicated with a flatblade screwdriver until the tray is ejected.
  • Page 10: Block Diagram

    DVD-C961 I BLOCK DIAGRAM Keys 1300 1100 1101 1200 Keys Disc5_Y +5VL 7100 +5V STBY Disc4_Y LED_Progressiv DISC1-5_Y Disc3_Y LED_HDMI RESET R6C_OUT Disc2_Y LED_Downmix +5V STBY STDBY_CTRL Disc1_Y +5VL 7102 Microprocessor DISC1Y_5Y +5VL +5V_STBY +5V STBY 7300 +5V_STBY 26-28 B01-03...
  • Page 11: Wiring Diagram

    DVD-C961 I WIRING DIAGRAM FMN 1.0 H FMN 1.0 H 1300 DVD 5-DISC CHANGER MODULE I2C_CLK (from MCU) I2C_CLK GND_D GND_D I2C_DATA (from MCU) I2C_DATA +5VSTDBY TRAVERSE UNIT +5VSTDBY +5VL +5VL FRONT (2) P.C.B. DISC1_Y FRONT (1) P.C.B. 1109 DISC1_Y...
  • Page 12: Printed Circuit Boards

    DVD-C961 The first digit of a component indicates the component type. I PRINTED CIRCUIT BOARDS 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper...
  • Page 13 DVD-C961 The first digit of a component indicates the component type. 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper MONO P.C.B.
  • Page 14 DVD-C961 The first digit of a component indicates the component type. 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper FRONT (1) P.C.B.
  • Page 15 DVD-C961 The first digit of a component indicates the component type. 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper FRONT (2) P.C.B.
  • Page 16 DVD-C961 The first digit of a component indicates the component type. 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper FRONT (3) P.C.B.
  • Page 17 DVD-C961 The first digit of a component indicates the component type. 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper FRONT (4) P.C.B.
  • Page 18 DVD-C961 The first digit of a component indicates the component type. 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper AV P.C.B.
  • Page 19 DVD-C961 The first digit of a component indicates the component type. 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper AV P.C.B.
  • Page 20 DVD-C961 The first digit of a component indicates the component type. 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper HDMI P.C.B.
  • Page 21 DVD-C961 The first digit of a component indicates the component type. 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper HDMI P.C.B.
  • Page 22 DVD-C961 The first digit of a component indicates the component type. 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper RS-232C P.C.B.
  • Page 23: Schematic Diagrams

    DVD-C961 The first digit of a component indicates the component type. I SCHEMATIC DIAGRAMS 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper...
  • Page 24 DVD-C961 The first digit of a component indicates the component type. 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper MONO 2/2...
  • Page 25 DVD-C961 The first digit of a component indicates the component type. 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper FRONT 1/5...
  • Page 26 DVD-C961 The first digit of a component indicates the component type. 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper FRONT 2/5...
  • Page 27 DVD-C961 The first digit of a component indicates the component type. 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper FRONT 3/5...
  • Page 28 DVD-C961 The first digit of a component indicates the component type. 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper 1500 C1...
  • Page 29 DVD-C961 The first digit of a component indicates the component type. 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper FRONT 5/5...
  • Page 30 DVD-C961 The first digit of a component indicates the component type. 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper AV 1/4...
  • Page 31 DVD-C961 The first digit of a component indicates the component type. 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper AV 2/4...
  • Page 32 DVD-C961 The first digit of a component indicates the component type. 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper AV 3/4...
  • Page 33 DVD-C961 The first digit of a component indicates the component type. 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper AV 4/4...
  • Page 34 DVD-C961 The first digit of a component indicates the component type. 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper HDMI 1/4...
  • Page 35 DVD-C961 The first digit of a component indicates the component type. 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper HDMI 2/4...
  • Page 36 DVD-C961 The first digit of a component indicates the component type. 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper HDMI 3/4...
  • Page 37 DVD-C961 The first digit of a component indicates the component type. 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper HDMI 4/4...
  • Page 38 DVD-C961 The first digit of a component indicates the component type. 1xxx : Connector 3xxx : Resistor 5xxx : Coil 7xxx : IC, Transistor, FET 2xxx : Capacitor 4xxx : SMD jumper 6xxx : Diode 9xxx : Wire jumper RS232C...
  • Page 39 DVD-C961 MEMO MEMO MEMO MEMO...
  • Page 40: Replacement Parts List

    DVD-C961 I REPLACEMENT PARTS LIST • OVERALL ASS’Y When disassembling, use the special screw driver with tip shape in figure. 2.7 mm * Note for replacement of the traverse unit 1.7 mm P.C.B. of a new traverse unit is shorted.
  • Page 41 DVD-C961 Ref. No. Part No. Description Remarks Markets AAX84040 FRONT PANEL ASS'Y 3141 079 43171 AAX84020 TRAY COVER 3139 244 17261 AAX84030 FRAME ASS'Y 3141 079 43181 AAX84050 REAR PANEL 3139 241 26882 AAX59320 TOP COVER 3139 241 22041 AAX59360...
