ITEM 862677 - USB CUBE MP3 ALARM CLOCK RADIO
Main feature:
* Time Display with Date & Day of Week
* Indoor Temperature
* Daily Snooze Alarm function
* LED Back light
* MP3/Radio Function:
(a) As MP3 player, with five types sound effects: Normal, Classic, Bass,
Live & Rock
(b) Built-in FM radio: 20 pre set radio station & auto-search radio frequency.
(c) MP3 & Radio Playback as alarm signal
(d) MP3 & Radio sleep function
(e) Sound Output to headphone function
(f) Line In function: Built in line in jack, could be connected with mp3,
laptop, MD/CD ... via. audio cable, used as a mini louderspeaker.
Specifications:
* USB Interface: full speed USB 2.0
* SD Card slot- support SD card up to 4 GB (optional)
* FM Frequency: 87.5 -- 108 MHz
* Power Supply:
Clock: AAA size battery x 2
MP3 & Radio: AAA size battery x 4
Adaptor: Ouput: DC 6.0 V, 1000mA
* Loudspeaker: outer Diameter 50mm
* Dimension: w110 x h105 x d100 mm
Advertisement
Summary of Contents for Balance 862677
- Page 1 ITEM 862677 - USB CUBE MP3 ALARM CLOCK RADIO Main feature: * Time Display with Date & Day of Week * Indoor Temperature * Daily Snooze Alarm function * LED Back light * MP3/Radio Function: (a) As MP3 player, with five types sound effects: Normal, Classic, Bass, Live &...
- Page 2 Part A: LCD DISPLAY --- TIME/CLCOK MODE A1: Time. A2: Date A3:Indoor Temperature A4: Day of Week Part B: Structure B1: USB Jack B2: SD Card Slot B3: Battery Compartment B4: DC/AC Input Jack B5: Earphone Jack B6: Line In Jack...
- Page 3 Set Up: Remove battery compartment door at the back of the unit and Insert AAA battery Or Connect the power cord to the wall outlet When the battery been inserted properly, the LCD screen will display the time, which you can adjust accordingly. Note : Power Supply Selection: MP3 player and amplifier are powered through the following 2 methods: (1) 4 x AAA batteries...
- Page 4 then it alerts again. “ snooze” flashes on the LCD during the snooze time. This function is only available with MP3 or BIBI alarm. When SNOOZE, press any other buttons (except SNOOZE/ LIGHT button) to cancel snooze function. Thermometer: Press “-” button to select Indoor Temperature in Celsius mode/ Fahrenheit mode. FM Radio Operation Procedure: LCD DISPLAY --- FM MODE A1: Time.
- Page 5 Hold “ ” or “ ” button 2 second, the unit will start to auto select the radio frequency, it will auto stop and broadcast that radio station when it find the strong frequency. Hold “SET” button to enter the FM station pre-storage function. The pre-stored identification number (lower left corner of the LCD screen, A3) will flash, press “...
- Page 6 : Previous/ Rewind : Volume Down : Next/ Forward Set up Insert Flash Memory to USB port Or SD card to SD Slot , and press “ ” button. The symbol “ ” (A4) pops up on the LCD screen, which indicates the activation of MP3 Mode.
- Page 7 button to enter sleep timer setting mode. When the sleep timer is activate, “ sleep” symbol is appears on the LCD. You can adjust the sleep timer from 10 minutes to 3 hours by pressing “+” button or “-“button. If no button is pressed for 8 seconds, the sleep timer deactivated, and the display will return the previous mode (FM radio operation mode/ MP3 operation mode) When setting sleep timer, the timer will not be activated if any other buttons (except “+”/ “-”) been pressed.
- Page 8 Transcend TwinMos Ultra Note: The speakers must be placed on a smooth and firm surface Keep the system in a ventilate place and away from heat source or direct sunlight. Do not pour water, liquid or rubbish in the machine.
