TGA572C(e).book Page 1 Monday, July 10, 2006 10:51 AM
This handset is an accessory handset for use with Panasonic base units
KX-TG5762C/KX-TG5766C/KX-TG5771C/KX-TG5776C/KX-TG5778C/
KX-TG5779C. You must register this handset with your base unit before
it can be used.
Charge the handset battery for 7 hours before initial use.
Please read these Operating Instructions before using the unit and save for
future reference.
For assistance, please call 1-800-561-5505 or visit us at www.panasonic.ca
Operating Instructions
5.8 GHz Expandable Digital Cordless Handset
KX-TGA572C
Model No.

Advertisement

Table of Contents
loading

Related Manuals for Panasonic KX-TGA572C

Summary of Contents for Panasonic KX-TGA572C

  • Page 1 Operating Instructions 5.8 GHz Expandable Digital Cordless Handset KX-TGA572C Model No. This handset is an accessory handset for use with Panasonic base units KX-TG5762C/KX-TG5766C/KX-TG5771C/KX-TG5776C/KX-TG5778C/ KX-TG5779C. You must register this handset with your base unit before it can be used. Charge the handset battery for 7 hours before initial use.
