DVD Micro System

TABLE OF CONTENTS

Handling chip components ........................................................... 1-1
Service tools ................................................................................. 1-1
Leadfree and safety information ................................................... 1-2
Technical specification .................................................................. 2-1
Service measurement setup ......................................................... 2-2
Connections and controls ..................................................... 3-1...3-3
Disassembly diagram ........................................................... 4-1...4-2
Software version and upgrading ................................................... 5-1
Block diagram ............................................................................... 6-1
Wiring diagram ............................................................................. 6-2
VFD / Key Board Assembly
circuit diagram .......................................................................... 7-1
layout diagram .......................................................................... 7-2
DVD Block
circuit diagram .......................................................................... 8-1
layout diagram .......................................................................... 8-2
©
Copyright 2005 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in a retrieval
system or transmitted, in any form or by any means, electronic, mechanical, photocopying,
or otherwise without the prior permission of Philips.
Published by YT 0531 Service Audio
Version 1.2
Subject to modification
MCD700, MCD702
Tuner board
circuit diagram. ......................................................................... 9-1
layout diagram .......................................................................... 9-2
DVD / MPEG board
circuit diagram .............................................................. 10-1...10-3
layout diagram ....................................................................... 10-4
AMP Block
circuit diagram. ........................................................................11-1
layout diagram .........................................................................11-2
Exploded view diagram ............................................................... 12-1
Mechanical partslist ........................................................... 12-2...12-3
Electrical partslist .............................................................. 13-1...13-2
MCL707/61 partslist .......................................................... 14-1...14-2
Revision list ................................................................................. 15-1
MCL707
all versions
© 3141 785 30432

Advertisement

Table of Contents
loading

Related Manuals for Philips MCD700

Summary of Contents for Philips MCD700

  • Page 1: Table Of Contents

    ................8-2 © Copyright 2005 Philips Consumer Electronics B.V. Eindhoven, The Netherlands All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without the prior permission of Philips.

  • Page 2: Handling Chip Components

    1 - 1 HANDLING CHIP COMPONENTS...
  • Page 3 1 - 2...
  • Page 4 DVD Part : 208 x 62 x 244 mm 4 Hz - 44 kHz (96kHz) AMP Part : 208 x 57 x 244 mm Digital Output : SPDIF (Sony Philips Weight DVD Part : 1.4 Kg digital interface) Coaxial AMP Part : 2.4 Kg No.

  • Page 5: Service Measurement Setup

    2 - 2 SERVICE MEASUREMENT Tuner FW Bandpass LF Voltmeter 250Hz-15kHz e.g. PM2534 e.g. 7122 707 48001 RF Generator e.g. PM5326 S/N and distortion meter e.g. Sound Technology ST1700B Use a bandpass filter to eliminate hum (50Hz, 100Hz) and disturbance from the pilottone (19kHz, 38kHz). Tuner AM (MW,LW) Bandpass LF Voltmeter...

  • Page 6: Connections And Controls

    3 - 1 CONNECTION AND CONTROLS...
  • Page 7 3 - 2 CONNECTION AND CONTROLS...
  • Page 8 3 - 3 CONNECTION AND CONTROLS...
  • Page 9 4 - 1 4 - 1 DISASSEMBLY INSTRUCTION - DVD PART A. Remove Bottom Cover C. Remove Side Panel (L & R) E. Remove Front Cabinet A1 remove screws M2.5x4 (washer head) - 4 pcs. C1 Slide out the Side Panels. E1 remove screws MK3x10 - 2 pcs.
  • Page 10 4 - 2 4 - 2 DISASSEMBLY INSTRUCTION - AMP PART A. Remove Bottom Cover C. Remove Side Panel (L & R) E. Remove Front Cabinet A1 remove screws M2.5x4 (washer head) - 4 pcs. C1 Slide out the Side Panels. E1 remove screws MK3x10 - 2 pcs.

  • Page 11: Software Version And Upgrading

    SOFTWARE VERSION AND UPGRADING A. MPEG SOFTWARE VERSION CHECK C. MPEG SOFTWARE UPGRADING: 1. Press SYSTEM button (on the remote control) to enter general setting page. 1. Download the firmware for Philips support website http://www.philips.com/support 2. Prepare as uploading CD. TV Screen shows 3.

  • Page 12: Block Diagram

    6 - 1 6 - 1 SET BLOCK DIAGRAM...

  • Page 13: Wiring Diagram

    6 - 2 6 - 2 SET WIRING DIAGRAM...

  • Page 14: Circuit Diagram

    7 - 1 7 - 1 CIRCUIT DIAGRAM - VFD / KEY BOARD ASSEMBLY...

  • Page 15: Layout Diagram

    7 - 2 7 - 2 LAYOUT DIAGRAM - VFD / KEY BOARD ASSEMBLY COMPONENT SIDE...

  • Page 16: Circuit Diagram

    8 - 1 8 - 1 CIRCUIT DIAGRAM - DVD BLOCK...

  • Page 17: Layout Diagram

    8 - 2 8 - 2 LAYOUT DIAGRAM - DVD BLOCK...

  • Page 18: Circuit Diagram

    9 - 1 9 - 1 CIRCUIT DIAGRAM - TUNER BOARD ANT1 0.22uF 0.33uF 3.3uF T5118 3.3k 100k SCV220 4.7uF 100uF SCV220 4(5"6((+ 203 C36 1.5k 1.5k 3.3uF 3.3uF T502B BLACK LA1823 9014 9014 D3 I384 T403B 0.47uF 450J T303B 10uF 100k 10.7M...

  • Page 19: Layout Diagram

    9 - 2 9 - 2 LAYOUT DIAGRAM - TUNER BOARD SIDE A SIDE B...

  • Page 20: Circuit Diagram

    10 - 1 10 - 1 CIRCUIT DIAGRAM - DVD MPEG BOARD (MPEG board is not repaired. diagram for reference only)
  • Page 21 10 - 2 10 - 2 CIRCUIT DIAGRAM - DVD MPEG BOARD (MPEG board is not repaired. diagram for reference only)
  • Page 22 10 - 3 10 - 3 CIRCUIT DIAGRAM - DVD MPEG BOARD (MPEG board is not repaired. diagram for reference only)

  • Page 23: Layout Diagram

    10 - 4 10 - 4 LAYOUT DIAGRAM - DVD MPEG BOARD (MPEG board is not repaired. diagram for reference only)
  • Page 24 11 - 1 11 - 1 CIRCUIT DIAGRAM - AMP BLOCK...

  • Page 25: Layout Diagram

    11 - 2 11 - 2 LAYOUT DIAGRAM - AMP BLOCK...

  • Page 26: Exploded View Diagram

    12 - 1 12 - 1 EXPLODED VIEW DIAGRAM DVD PART AMP PART...

  • Page 27: Mechanical Partslist

    MCD700 AMP CABINET FRONT 9940 000 03072 (USA version only) 9940 000 03089 CONDUCTIVE SPONGE 5×3×1MM 9940 000 02502 MCD700 AMP UNIT TOP PLATE MCD700 SIDE PLATE(L) 9940 000 02498 MCD700 SIDE PLATE(L) 9940 000 03075 (USA version only) TOROIDAL TRANSFORMER W/JTH...
  • Page 28 12 - 3 MECHANICAL PARTSLIST DVD PART 9940 000 02493 MCD700 DVD DISPLAY LENS MCD700 MCL707 DVD DISPLAY LENS 9940 000 02571 MCL700 9940 000 02497 MCD700 POWER KNOB OVERLAY FOR FUNCTION KNOB 9940 000 02506 9940 000 02505 FUNCTION KNOB METAL RING...

  • Page 29: Electrical Partslist

    JACK901 9940 000 02554 S-VIDEO SINGLE RCA SOCKET 9940 000 02513 TUNER PCB ASS'Y 9940 000 02563 DVD MECHANISM IDM520A 9940 000 02514 DVD MPEG CARD MCD700/93V1.1 MCD700/93 9940 000 02982 DVD MPEG CARD MCD700/98V1.1 MCD700/98 9940 000 02983 DVD MPEG CARD MCD700/55V1.1 MCD700/55 9940 000 02984 DVD MPEG CARD MCD700/37V2.0...
  • Page 30 13 - 1 ELECTRICAL PARTS LIST - AMP PART DIODES D101 9940 000 02521 THYRISTOR RS406(4A) ZD107 9940 000 02515 ZENER DIODE 3V ZD108 9940 000 02516 ZENER DIODE 5V1 TRANSISTORS Q100 9940 000 02518 TRANSISTOR 8050C Q101 9940 000 02517 TRANSISTOR 2SB772 Q102 9940 000 02518 TRANSISTOR 8050C Q103...
  • Page 31 9965 000 41990 NE1300 CD DOOR RIGHT BRACKET 9965 000 42478 DVD UNIT LENS DISPLAY (MCL707) 9940 000 02492 MCD700 AMP UNIT DISPLAY LENS 9940 000 02494 CAB. TOP PUSH KEY KNOB 9940 000 02495 MCD700 SWITCH PUSH KNOB 9965 000 42075...
  • Page 32 PART LIST FOR MCL707/61 14-2 ELECTRICAL PARTS - DISPLAY PCB IC701 9940 000 02539 IC PT6311/SC16311/CD16311 9965 000 41321 VFD DISPLAY S701 9940 000 02542 IR SENSOR SW701 9940 000 02543 LIGHT TOUCH SWITCH ELECTRICAL PARTS - DOOR SWITCH PCB SW401 9940 000 02536 SPECIAL SWITCH TC-V030A...
  • Page 33 PART LIST FOR MCL707/61 14-3 ELECTRICAL PARTS - SWITCH PCB SW706 9940 000 02557 SWITCH(4-DIRECTIONS) ELECTRICAL PARTS - AMP PCB ZD107 9940 000 02515 ZENER DIODE 3V ZD108 9965 000 42069 ZENER DIODE IN5231B Q101 9940 000 02517 TRANSISTOR 2SB772 D101 9940 000 02521 THYRISTOR RS406(4A)

  • Page 34: Revision List

    15 - 1 REVISION LIST Version 1.0 (3141 785 30430) - Initial Release Version 1.1 (3141 785 30431) - New versions /37, /79 and /96 are introduced. - Pages 12-1 and 12-2 : Mechanical parts list adapted. - Pages 13-1 and 13-2 : Electrical parts list adapted. Version 1.2 (3141 785 30432) - New versions MCL707/61.
