- Page 1 DISCRETE SEMICONDUCTORS DATA SHEET BGY88 CATV amplifier module Product specification Supersedes data of February 1995 File under Discrete Semiconductors, SC16 1997 Apr 09...
- Page 2 Philips Semiconductors CATV amplifier module FEATURES Excellent linearity Extremely low noise Silicon nitride passivation Rugged construction TiPtAu metallized crystals ensure optimal reliability. DESCRIPTION Hybrid amplifier module for CATV systems operating over a frequency range of 40 to 450 MHz at a voltage supply of +24 V and intended for use as a line-extender.
- Page 3 Philips Semiconductors CATV amplifier module CHARACTERISTICS Table 1 Bandwidth 40 to 450 MHz; T SYMBOL PARAMETER power gain slope cable equivalent flatness of frequency response input return losses output return losses composite triple beat cross modulation second order distortion output voltage noise figure...
-
Page 4: Package Outline
Philips Semiconductors CATV amplifier module PACKAGE OUTLINE handbook, full pagewidth 0.25 2.54 44.8 38.1 Dimensions in mm. (1) Screw 6-32 UNC-2A available on request. (2) Leads gold plated. 1997 Apr 09 13.8 max 12.7 UNC 6-32 2.4 max 4.15 3.85 Fig.2 SOT115J. -
Page 5: Life Support Applications
Philips customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify Philips for any damages resulting from such improper use or sale. - Page 6 Philips Semiconductors Product specification CATV amplifier module BGY88 NOTES 1997 Apr 09...
