Page 1 SIP Cordless Phone KX-TGP600 Model No. Thank you for purchasing this Panasonic product. Please read this manual carefully before using this product and save this manual for future use. In this manual, the suffix of each model number is omitted unless necessary.
Page 2: Related Documentation
Briefly describes basic information about the installation of the unit. Operating Instructions Describes information about the installation and operation of the unit. Manuals and supporting information are provided on the Panasonic Web site at: https://panasonic.net/cns/pcc/support/sipphone/ Technical Support When technical support is required, contact your phone system dealer/service provider.
Page 3: Table Of Contents
Table of Contents Table of Contents 1 Initial Setup .....................23 Setup ..........................24 1.1.1 Factory Defaults ......................24 1.1.2 Language Selection for the Unit ..................24 1.1.3 Basic Network Setup ......................24 1.1.4 Overview of Programming ....................27 1.1.5 Phone User Interface Programming ................28 1.1.5.1 Changing the Language for Phone User Interface Programming .......28 1.1.6 Web User Interface Programming ..................29...
Page 4 Table of Contents 4.2.2 Handset Information .......................76 4.2.2.1 Handset Information ....................77 Handset 1–8 (Model) ....................77 Handset 1–8 (Firmware Version) ................77 4.2.3 Network Status .......................77 4.2.3.1 Network Common ......................78 MAC Address ......................78 Ethernet Link Status ....................78 IP Address Mode ......................78 4.2.3.2 IPv4 ..........................78 Connection Mode ......................78 IP Address ........................78...
Page 5 Table of Contents LAN Port ........................89 4.3.2.2 LLDP ..........................90 Enable LLDP ......................90 Packet Interval ......................90 4.3.2.3 CDP ..........................90 Enable CDP ......................90 Packet Interval ......................90 4.3.2.4 VLAN ...........................91 Enable VLAN ......................91 VLAN ID ........................91 Priority ........................91 4.3.3 HTTP Client Settings ......................92 4.3.3.1 HTTP Client .........................92 HTTP Version ......................92...
Page 6 Table of Contents User ID (Line 1–8) ....................101 Password (Line 1–8) ....................102 Enable Phonebook (Line 1–8) ................102 Phonebook Type (Line 1–8) ...................102 Group ........................102 GroupCommon .......................103 Enterprise ........................103 EnterpriseCommon ....................103 Personal ........................104 Enable Call Log (Line 1–8) ..................104 4.3.8 UC Settings ........................105 4.3.8.1 Presence Feature ......................105 Enable UC .......................105...
Page 7 Table of Contents 4.4.4.1 Admin Password ......................117 Current Password ....................117 New Password ......................117 Confirm New Password ..................117 4.4.5 Time Adjust Settings ....................118 4.4.5.1 Synchronization ......................118 Server Address .......................118 Synchronization Interval ..................118 4.4.5.2 Time Zone .........................119 Time Zone .......................119 4.4.5.3 Daylight Saving Time (Summer Time) ...............119 Enable DST (Enable Summer Time) ..............119 DST Offset (Summer Time Offset) ................119 4.4.5.4...
Page 8 Table of Contents 4.5.2.1 Basic ..........................132 Phone Number ......................132 Registrar Server Address ..................132 Registrar Server Port ....................133 Proxy Server Address .....................133 Proxy Server Port ....................133 Presence Server Address ..................133 Presence Server Port ....................133 Outbound Proxy Server Address ................134 Outbound Proxy Server Port ...................134 Service Domain .......................134 Authentication ID .....................134 Authentication Password ..................134...
Page 9 Table of Contents G.729A (Priority) .....................145 PCMU (Enable) .......................145 PCMU (Priority) .......................145 DTMF Type ......................145 4.5.4.2 Advanced ........................146 RTP Packet QoS (DSCP) ..................146 RTCP Packet QoS (DSCP) ..................146 Enable RTCP ......................146 Enable RTCP-XR ....................146 RTCP&RTCP-XR Interval ..................147 SRTP Mode ......................147 Enable Mixed SRTP &...
Page 10 Table of Contents Enable Call Forwarding No Answer ................158 Forwarding Number (No Answer) ................159 Ring Counts (No Answer) ..................159 Enable Shared Call ....................159 Enable Key Synchronization ...................159 Enable Call Park Notification ..................160 Enable Click to Call ....................160 MoH Server URI ......................160 4.6.3.2 Dial Plan ........................160 Dial Plan (max 1000 columns) ................160...
Page 11 Table of Contents 4.7.3 Upgrade Firmware ......................173 4.7.3.1 Upgrade Firmware .....................173 File Name ........................173 4.7.4 Import Wallpaper ......................174 4.7.4.1 Import Wallpaper .......................174 Gradation Type .......................174 File Name ........................174 4.7.5 Export Logging File ......................174 4.7.5.1 Export Logging File ....................175 Logging File Type ....................175 4.7.6 Reset to Defaults ......................175 4.7.7...
Page 12 Table of Contents CODEC_VAD_CNG_ENABLE ..................210 ERROR_AUTO_REBOOT_TIME ................210 BLOCK_CID_MENU_ENABLE .................210 5.3.2 Handset Registration Settings ..................210 IPEI_HSy ........................210 IPEI_AUTOREGMODE_ENABLE ................211 IPEI_RESTRICTION_ENABLE .................211 NEXT_REGISTERED_HS_NUMBER ...............211 IPEI_CHANGE_HS_ENABLE ...................211 5.3.3 Basic Network Settings ....................212 IP_ADDR_MODE ......................212 CONNECTION_TYPE ....................212 STATIC_IP_ADDRESS .....................212 STATIC_SUBNET .....................212 STATIC_GATEWAY ....................213 USER_DNS1_ADDR ....................213 USER_DNS2_ADDR ....................214 DHCP_DNS_ENABLE ....................214 DHCP_HOST_NAME ....................214...
Page 13 Table of Contents CFG_ROOT_CERTIFICATE_PATH ................224 CFG_CLIENT_CERT_PATH ..................224 CFG_PKEY_PATH ....................224 HTTP_SSL_VERIFY ....................225 CFG_RESYNC_DURATION ..................225 CFG_BOOTUP_DURATION_ENABLE ..............225 5.3.7 Firmware Update Settings ....................226 FIRM_UPGRADE_ENABLE ..................226 FIRM_FILE_PATH .....................226 FIRM_VERSION ......................226 FWDL_RANDOM_DURATION ..................227 5.3.8 HTTP Settings ......................227 HTTP_VER ........................227 HTTP_USER_AGENT ....................227 HTTP_AUTH_ID ......................228 HTTP_AUTH_PASS ....................228 HTTP_PROXY_ENABLE ..................228 HTTP_PROXY_ADDR ....................229 HTTP_PROXY_PORT ....................229...
Page 14 Table of Contents XMLAPP_LDAP_USERPASS ...................238 XMLAPP_NPB_SEARCH_TIMER ................238 XMLAPP_LDAP_MAXRECORD ................239 XML_HTTPD_PORT ....................239 XML_ERROR_INFORMATION .................239 XML_PHONEBOOK_URL ..................239 XML_PHONEBOOK_CYCLIC_INTVL ...............239 XMLAPP_SELECT_HS_PB ..................240 XMLAPP_RCV_IP_ADDRESSx ................240 5.3.12 XSI Settings ........................240 XSI_ENABLE ......................240 XSI_SERVER ......................240 XSI_SERVER_TYPE ....................241 XSI_SERVER_PORT ....................241 XSI_USERID_n ......................241 XSI_PASSWORD_n ....................241 XSI_PHONEBOOK_ENABLE_n ................242 XSI_PHONEBOOK_CYCLIC_INTVL ................242 XSI_PHONEBOOK_RESYNC_DURATION ..............242 XSI_PHONEBOOK_TYPE_n ..................242 XSI_CALLLOG_ENABLE_n ..................243...
Page 15 Table of Contents LDAP_NAME_ATTRIBUTE ..................251 LDAP_NUMB_ATTRIBUTE ..................251 LDAP_BASEDN ......................252 LDAP_SSL_VERIFY ....................252 LDAP_ROOT_CERT_PATH ..................252 LDAP_CLIENT_CERT_PATH ...................252 LDAP_PKEY_PATH ....................253 LDAP_DISPLAY_FORMAT ..................253 5.3.15 SNMP Settings ......................253 SNMP_ENABLE ......................253 SNMP_TRUST_IP .....................253 SNMP_TRUST_PORT ....................254 SNMP_RO_COMMUNITY_STRING .................254 SNMP_SECURITY_TYPE ..................254 SNMP_SECURITY_USER ..................254 SNMP_AUTH_TYPE ....................254 SNMP_AUTH_PASSWORD ..................255 SNMP_ENCRYPT_TYPE ..................255 SNMP_ENCRYPT_PASSWORD ................255 5.3.16 Multicast Paging Settings .....................255...
Page 16 Table of Contents HS_LANGUAGE_PATHx ..................265 HS_LANGUAGE_VERx ....................265 AVAILABLE_LANGUAGE_WEB ................266 WEB_LANGUAGE ....................266 WEB_LANGUAGE_PATHx ..................266 WEB_LANGUAGE_VERx ..................266 5.3.21 NAT Settings ........................267 STUN_SERV_ADDR ....................267 STUN_SERV_PORT ....................267 STUN_2NDSERV_ADDR ..................267 STUN_2NDSERV_PORT ..................267 STUN_INTVL ......................268 SIP_ADD_RPORT .....................268 PORT_PUNCH_INTVL ....................268 RTP_PORT_PUNCH_INTVL ..................268 EXTERNAL_RTP_PORTx ..................269 5.3.22 SIP Settings ........................269 SIP_USER_AGENT ....................269 PHONE_NUMBER_n ....................269 SIP_URI_n .........................270...
Page 17 Table of Contents SUB_RTX_INTVL_n ....................280 SIP_P_PREFERRED_ID_n ..................281 SIP_PRIVACY_n .......................281 ADD_USER_PHONE_n ....................281 SIP_ANM_DISPNAME_n ..................282 SIP_ANM_USERNAME_n ..................282 SIP_ANM_HOSTNAME_n ..................282 SIP_DETECT_SSAF_n .....................282 SIP_RCV_DET_HEADER_n ..................283 SIP_RCV_DET_REQURI_n ..................283 SIP_CONTACT_ON_ACK_n ..................284 VOICE_MESSAGE_AVAILABLE ................284 SIP_INVITE_EXPIRE_n ....................284 SIP_FOVR_NORSP_n ....................284 SIP_FOVR_MAX_n ....................285 SIP_FOVR_MODE_n ....................285 SIP_FOVR_DURATION_n ..................285 SIP_ADD_ROUTE_n ....................286 SIP_REQURI_PORT_n .....................286 ADD_EXPIRES_HEADER_n ..................286 ADD_TRANSPORT_UDP_n ..................287 SIP_ADD_DIVERSION_n ..................287...
Page 18 Table of Contents 5.3.23 SIP-TLS Settings ......................296 SIP_TRANSPORT_n ....................296 SIP_TLS_MODE_n ....................297 SIP_TLS_RECONNECT_n ..................297 SIP_TLS_SRV_PREFIX_n ..................297 SIP_TLS_VERIFY_n ....................298 SIP_TLS_ROOT_CERT_PATH ................298 SIP_TLS_CLIENT_CERT_PATH ................298 SIP_TLS_PKEY_PATH .....................298 SIP_TLS_RANDOM_PORT ..................299 5.3.24 CODEC Settings ......................299 CODEC_G729_PARAM_n ..................299 CODEC_ENABLEx_n ....................299 CODEC_PRIORITYx_n .....................300 CODEC_PAYLOAD2 ....................301 CODEC_G711_REQ ....................301 5.3.25 DTMF Settings ......................301 DTMF_METHOD_n ....................301 OUTBANDDTMF_VOL ....................302...
Page 19 Table of Contents UACSTA_ENABLE_n ....................311 UACSTA_UNIQUE_ID ....................311 CSTA_PORT ......................312 CSTA_PRXY_ADDR ....................312 CSTA_PRXY_PORT ....................312 CSTA_RGSTR_ADDR ....................312 CSTA_RGSTR_PORT ....................312 CSTA_REG_EXPIRE_TIME ..................313 CSTA_TRANSPORT ....................313 CSTA_RGSTR_AUTHID ...................313 CSTA_RGSTR_PASS ....................313 5.3.30 Telephone Settings ......................313 POWER_ON_DISPLAY_LOGO_PATH ..............313 DISPLAY_WALLPAPER_DARK_PATH ..............314 DISPLAY_WALLPAPER_LIGHT_PATH ..............314 FIRSTDIGIT_TIM .......................314 INTDIGIT_TIM ......................315 POUND_KEY_DELIMITER_ENABLE ...............315 POST_DIAL_TALK_ENABLE ..................315 RINGTONE_SETTING_HSy_n .................315 INTERCOM_RINGTONE_SETTING_HSy ..............316...
Page 20 Table of Contents CNIP_CALL_PAI_ENABLE ..................324 5.3.31 Tone Settings .......................325 OUTSIDE_DIAL_TONE_FRQ ...................325 OUTSIDE_DIAL_TONE_GAIN ..................325 OUTSIDE_DIAL_TONE_RPT ...................325 OUTSIDE_DIAL_TONE_TIMING ................325 REORDER_TONE_ENABLE ..................325 TONE_LEN_DISCONNECT ..................326 DIAL_TONE1_FRQ ....................326 DIAL_TONE1_GAIN ....................326 DIAL_TONE1_RPT ....................326 DIAL_TONE1_TIMING ....................326 DIAL_TONE2_FRQ ....................327 DIAL_TONE2_GAIN ....................327 DIAL_TONE2_RPT ....................327 DIAL_TONE2_TIMING ....................327 DIAL_TONE4_FRQ ....................328 DIAL_TONE4_GAIN ....................328 DIAL_TONE4_RPT ....................328 DIAL_TONE4_TIMING ....................328 BUSY_TONE_FRQ ....................329...
Page 21 Table of Contents DIAL_PLAN_NOT_MATCH_ENABLE_n ..............339 MACRODIGIT_TIM ....................339 INTERNATIONAL_ACCESS_CODE .................339 COUNTRY_CALLING_CODE ...................340 NATIONAL_ACCESS_CODE ...................340 IDLE_SOFT_KEY_A ....................340 IDLE_SOFT_KEY_B ....................341 IDLE_SOFT_KEY_C ....................341 ADMIN_ABILITY_ENABLE_HSy ................342 HANDSET_NAME_HSy ....................342 EMERGENCY_CALLx ....................342 CALL_REJECTIONx_n .....................343 CLICKTO_ENABLE_n ....................343 CALLPARK_NOTIFICATION_ENABLE_n ..............343 SHARED_CALL_ENABLE_n ..................344 SHARED_STOP_LINE_SEIZE .................344 FWD_DND_SYNCHRO_ENABLE_n ................344 MOH_SERVER_URI_n .....................345 FWD_DND_CONTROL_ENABLE ................345 FWD_DND_SYNCHRO_MODE ................345 HOLD_AND_CALL_ENABLE ..................345 AUTO_CALL_HOLD ....................346...
Page 22 Upgrade Firmware ......................382 8 Troubleshooting ...................383 Troubleshooting ......................384 9 Appendix ....................389 Revision History ......................390 9.1.1 KX-TGP600 Software File Version 01.082 or later ............390 9.1.2 KX-TGP600 Software File Version 01.094 or later ............390 9.1.3 KX-TGP600 Software File Version 01.129 or later ............391 9.1.4 KX-TGP600 Software File Version 01.148 or later ............391...
Page 23: Initial Setup
Section 1 Initial Setup This section provides an overview of the setup procedures for the unit. Document Version 2017-07 Administrator Guide...
Page 24: Setup
Note • To select the display language for the unit, refer to the Operating Instructions on the Panasonic Web site (® see Introduction). • To select the display language for the Web user interface, see 4.4.2 Language Settings.
Page 25 1.1.3 Basic Network Setup For details about the DHCP server, consult your network administrator. Using a Static IP Address Specified by Your Network Administrator If IP addresses for network devices are specified individually by your network administrator, you will need to manually configure settings such as the IP address, subnet mask, default gateway, and DNS servers.
Page 26 For details about the individual network settings that can be configured via the unit, refer to the Operating Instructions on the Panasonic Web site (® see Introduction). For details about configuring network settings via the Web user interface, see 4.3.1 Basic Network Settings.
Page 27: Overview Of Programming
1.1.4 Overview of Programming [ ]/[ ]: "Network Settings" ® [ ]/[ ]: "IPv6 Settings" ® [ ]/[ ]: "DHCP" ® [ ]/[ ]: "Auto" ® • Select "Manual" to enter the addresses for DNS1 (primary DNS server) and, if necessary, DNS2 (secondary DNS server) manually, and then press To configure network settings automatically using RA ®...
Page 28: Phone User Interface Programming
You can change the language used on the LCD. Because the language settings for the LCD of the unit are not synchronized, you must set the languages individually for the unit. For details about changing the setting, refer to the Operating Instructions on the Panasonic Web site (® see Introduction).
Page 29: Web User Interface Programming
PC connected to the same network. For details, see Section 4 Web User Interface Programming. Router Switching Hub KX-TGP600 KX-TPA60 KX-TPA65 1.1.6.1 Password for Web User Interface Programming To program the unit via the Web user interface, a login account is required. There are 2 types of accounts, and each has different access privileges.
Page 30: Changing The Language For Web User Interface Programming
Opening/Closing the Web Port To access the Web user interface, you must open the unit’s Web port beforehand. For details, refer to the Operating Instructions on the Panasonic Web site (® see Introduction). Configuring Settings from the Unit To open the unit’s Web port ®...
Page 31 1.1.6 Web User Interface Programming To close the unit’s Web port ® [ ]/[ ]/[ ]/[ ]: [ ]/[ ]: "Other Option" ® [ ]/[ ]: "Embedded Web" ® [ ]/[ ]: "Off" for "Embedded Web" ® Configuring Settings from the Web User Interface To close the unit’s Web port In the Web user interface, click [Web Port Close].
Page 32: Accessing The Web User Interface
1.1.6 Web User Interface Programming Notice • Only one account can be logged in to the Web user interface at a time. If you try to access the Web user interface while someone is logged in, you will be denied access. •...
Page 33: Controls On The Window
1.1.6 Web User Interface Programming Controls on the Window The Web user interface window contains various controls for navigating and configuring settings. The following figure shows the controls that are displayed on the [Basic Network Settings] screen as an example: Note •...
Page 34: Entering Characters
1.1.6 Web User Interface Programming Button Function Save Applies changes and displays a result message (® see Result Messages in this section). Cancel Discards changes. The settings on the current screen will return to the values they had before being changed. Refresh Updates the status information displayed on the screen.
Page 35 1.1.6 Web User Interface Programming Result Message Description Applicable Screens Complete The operation has successfully completed. All screens except 4.6.7 Export Phonebook Failed (Parameter Error) The operation failed because: All screens • Some specified values are out of range or invalid. Failed (Memory Access The operation failed because: All screens...
Page 36: Firmware Update
1.2.1 Firmware Update Result Message Description Applicable Screens Failed (Charge Battery) The operation failed because: 4.6.7 Export Phonebook • The battery needs to be charged. No Data The operation failed because: 4.6.6 Import Phonebook • The imported phonebook file contains no valid phonebook entries.
Page 37: General Information On Provisioning
Section 2 General Information on Provisioning This section provides an overview of the configuration file programming procedures for the unit, including pre-provisioning and provisioning. Document Version 2017-07 Administrator Guide...
Page 38: Pre-Provisioning
2.1.3 Server Address Formats 2.1 Pre-provisioning 2.1.1 What is Pre-provisioning? Pre-provisioning is an auto-provisioning mechanism that automatically obtains the server address saved in the configuration file administered by the carrier or distributor. There are two methods for automatically obtaining the server address saved in the configuration file. SIP PnP The phone multicasts a SIP SUBSCRIBE message and obtains a provisioning server address via a SIP NOTIFY message.
Page 39: Obtaining A Provisioning Server Address Via Sip Pnp
Macro Expansion {MODEL} If the URL contains {MODEL}, it will be replaced with the device’s model name. Example: {MODEL} ® KX-TGP600 {fwver} If the URL contains {fwver}, it will be replaced with the device’s firmware version. Example: {fwver} ® 01.000 Note •...
Page 40: Obtaining A Provisioning Server Address From Dhcp Options
2.1.5 Obtaining a Provisioning Server Address from DHCP Options CFG_PRODUCT_FILE_PATH CFG_MASTER_FILE_PATH Provisioning server URL formats Format: <scheme>://<user>:<password>@<host>:<port>/<url-path>/<file name> <scheme> Mandatory Protocol (TFTP/FTP/HTTP/HTTPS) <user> Optional User name <password> Optional Password <host> Mandatory IP Address or Domain <port> Optional Port number <url-path> Optional Full path of the resource <file name>...
Page 41 2.1.5 Obtaining a Provisioning Server Address from DHCP Options KX-TGP600 DHCP Server Pre-provisioning Server KX-TGP600.cfg DHCP DISCOVER DHCP OFFER DHCP REQUEST DHCP ACK TFTP {MODEL}.cfg 200OK Obtain provisioning server information CFG_STANDARD_FILE_PATH CFG_PRODUCT_FILE_PATH CFG_MASTER_FILE_PATH Format for pre-provisioning files obtained from DHCP option 67 Format: <path>/<file name>...
Page 42 2.1.5 Obtaining a Provisioning Server Address from DHCP Options <password> Optional Password <host> Mandatory IP Address or Domain <port> Optional Port number Path <path> Optional The obtained file is the <path>/<file name> set in DHCP option 67. If DHCP option 67 is not set, {MODEL}.cfg is obtained. The examples in parentheses below are when {MODEL}.cfg is set for DHCP option 67.
Page 43 2.1.5 Obtaining a Provisioning Server Address from DHCP Options Note • DHCP option 17 is enabled in the initial state and can be enabled and disabled from the configuration parameters ("DHCPV6_OPTION17_PROV_ENABLE"). KX-TGP600 DHCP Server Pre-provisioning Server KX-TGP600.cfg DHCPv6 REQUEST DHCPv6 REPLY TFTP {MODEL}.cfg...
Page 44: Provisioning
IP addresses of the DNS and NTP (Network Time Protocol) servers managed by your phone system dealer/ service provider. This configuration file is used by all the units. Example of the configuration file’s URL: http://prov.example.com/Panasonic/ConfigCommon.cfg Administrator Guide Document Version 2017-07...
Page 45 The same number of configuration files as models being used on the network are stored on the provisioning server, and units with the same model name download the corresponding configuration file. Example of the configuration file’s URL: http://prov.example.com/Panasonic/Config{MODEL}.cfg Note • When a unit requests the configuration file, "{MODEL}" is replaced by the model name of the unit.
Page 46: Downloading Configuration Files
Confirm that the provisioning server’s IP address/FQDN and directory are correct, and store the configuration files in the directory (e.g., http://provisioning.example.com/Panasonic/Config_Sample.cfg). Enter the IP address of the unit into the PC’s Web browser (® see 1.1.6.3 Before Accessing the Web User Interface).
Page 47 The configuration files are downloaded at specified intervals of time, set in minutes. In the example below, the unit has been programmed to download configuration files from the provisioning server every 3 days (4320 minutes). CFG_CYCLIC_INTVL="4320" KX-TGP600 Provisioning Server A Power on B 3 days later C 6 days later...
Page 48 Explanation At a specified time each day After the unit is powered on, it will download configuration files once per day at the specified time. CFG_RESYNC_TIME="02:00" KX-TGP600 Provisioning Server A power on at 12:00 B 02:00 C 02:00 : Check : Download •...
Page 49: Provisioning Server Setting Example
Panasonic/Config{MAC}.cfg" • CFG_MASTER_FILE_PATH="http://prov.example.com/ Panasonic/ConfigCommon.cfg" Directory on the provisioning Create the "Panasonic" directory just under the HTTP root directory of the server containing the provisioning server. configuration files File name of configuration Store the following configuration files in the "Panasonic" directory.
Page 50: Encryption
2.2.6 Encryption Example Provisioning Direction from the Server The following figure shows an example NOTIFY message from the server, directing the units to perform provisioning. The text "check-sync" is specified for "CFG_RESYNC_FROM_SIP". NOTIFY sip:1234567890@sip.example.com SIP/2.0 Via: SIP/2.0/UDP xxx.xxx.xxx.xxx:5060;branch=abcdef-ghijkl From: sip:prov@sip.example.com To: sip:1234567890@sip.example.com Date: Wed, 1 Jan 2014 01:01:01 GMT Call-ID: 123456-1234567912345678...
Page 51: Priority Of Setting Methods
2.3 Priority of Setting Methods To decrypt configuration files, the unit uses the encryption key registered to it beforehand. The unit determines the encryption status by checking the extension of the downloaded configuration file. For details about encrypting configuration files, contact the appropriate person in your organization. Extension of Configuration Configuration File Parameters Used for Decrypting File...
Page 52: Configuration File Specifications
To prevent the designated character sequence being altered by chance, it is recommended that the configuration file starts with the comment line shown below: # Panasonic SIP Phone Standard Format File # DO NOT CHANGE THIS LINE! • Configuration files must end with an empty line.
Page 53 "VM_NUMBER_8": for line 8 Note • The number of lines available varies depending on the phone being used, as follows: – KX-TGP600: 1–8 • Some parameter values can be specified as "empty" to set the parameter values to empty. Example: NTP_ADDR=""...
Page 54: Configuration File Examples
2.5.1 Examples of Codec Settings 2.5 Configuration File Examples The following examples of configuration files are provided on the Panasonic Web site (® see Introduction). • Simplified Example of the Configuration File • Comprehensive Example of the Configuration File 2.5.1 Examples of Codec Settings Setting the Codec Priority to (1)G.729A, (2)G.722.2, (3)PCMU, (4)G.722...
Page 55: Example With Incorrect Descriptions
The following listing shows an example of a configuration file that contains incorrect formatting: An improper description is entered in the first line. A configuration file must start with the designated character sequence "# Panasonic SIP Phone Standard Format File #". Comment lines start in the middle of the lines.
Page 56 2.5.2 Example with Incorrect Descriptions Administrator Guide Document Version 2017-07...
Page 57: Phone User Interface Programming
Section 3 Phone User Interface Programming This section explains how to configure the unit by entering direct commands through the phone user interface. Document Version 2017-07 Administrator Guide...
Page 58: Phone User Interface Programming
3.1.1 Opening/Closing the Web Port 3.1 Phone User Interface Programming This section provides information about the features that can be configured directly from the unit, but that are not mentioned in the Operating Instructions. 3.1.1 Opening/Closing the Web Port To access the Web user interface, you must open the unit’s Web port beforehand. To open the unit’s Web port ®...
Page 59: Web User Interface Programming
Section 4 Web User Interface Programming This section provides information about the settings available in the Web user interface. Document Version 2017-07 Administrator Guide...
Page 60: Web User Interface Setting List
4.1 Web User Interface Setting List 4.1 Web User Interface Setting List The following tables show all the settings that you can configure from the Web user interface and the access levels. For details about each setting, see the reference pages listed. For details about setting up Web user interface programming, see 1.1.6 Web User Interface Programming.
Page 61 4.1 Web User Interface Setting List Access Level Menu Item Section Title Setting Ref. Network Status Network Common MAC Address ü ü Page 78 Ethernet Link Status ü ü Page 78 IP Address Mode ü ü Page 78 IPv4 Connection Mode ü...
Page 62 4.1 Web User Interface Setting List Network Access Level Menu Item Section Title Setting Ref. Basic Network IP Addressing Mode IP Addressing Mode ü Page 84 Settings IPv4 Connection Mode ü Page 85 DHCP Host Name ü Page 85 IP Address ü...
Page 63 4.1 Web User Interface Setting List Access Level Menu Item Section Title Setting Ref. HTTP Client HTTP Client HTTP Version ü Page 92 Settings HTTP User Agent ü Page 92 Authentication ID ü Page 93 Authentication Password ü Page 93 Proxy Server Enable Proxy Page 93...
Page 64 4.1 Web User Interface Setting List Access Level Menu Item Section Title Setting Ref. Xtended Service Xtended Service Enable Xtended Service ü Page 100 Settings Server Address ü Page 101 Port ü Page 101 Protocol ü Page 101 SIP Credentials Page 101 ü...
Page 65 4.1 Web User Interface Setting List Access Level Menu Item Section Title Setting Ref. TWAMP Settings TWAMP Enable TWAMP ü Page 109 Control Port ü Page 109 Test Port ü Page 109 Wait Time for Control ü Page 110 Wait Time for Reflector Page 110 ü...
Page 66 4.1 Web User Interface Setting List Access Level Menu Item Section Title Setting Ref. Time Adjust Synchronization Server Address ü Page 118 Settings Synchronization Interval ü Page 118 Time Zone Time Zone ü Page 119 Daylight Saving Time Enable DST (Enable Summer ü...
Page 67 4.1 Web User Interface Setting List Access Level Menu Item Section Title Setting Ref. Parallel Mode Parallel Mode Slave Handset Number ü Page 128 Settings Mode ü Page 128 The access levels are abbreviated as follows: U: User; A: Administrator A check mark indicates that the setting is available for that access level.
Page 68 4.1 Web User Interface Setting List Access Level Menu Item Section Title Setting Ref. SIP Settings Basic Phone Number ü Page 132 [Line 1]–[Line 8] Registrar Server Address ü Page 132 Registrar Server Port ü Page 133 Proxy Server Address ü...
Page 69 4.1 Web User Interface Setting List Access Level Menu Item Section Title Setting Ref. VoIP Settings RTP Packet Time ü Page 140 Minimum RTP Port Number ü Page 140 Maximum RTP Port Number ü Page 141 Telephone-event Payload ü Page 141 Type Voice Quality Report Server Address...
Page 70 4.1 Web User Interface Setting List Access Level Menu Item Section Title Setting Ref. VoIP Settings Basic G.722 – – – [Line 1]–[Line 8] - Enable ü Page 143 *2*3 - Priority ü Page 144 *2*3 PCMA – – – - Enable Page 144 ü...
Page 71 4.1 Web User Interface Setting List Telephone Access Level Menu Item Section Title Setting Ref. Multi Number Group Handset / Line ü ü Page 149 Settings Handset select for Phone Number ü ü Page 150 receiving call Handset Number ü ü...
Page 72 4.1 Web User Interface Setting List Access Level Menu Item Section Title Setting Ref. Call Control [Line Call Features Display Name ü Page 156 1]–[Line 8] Voice Mail Access Number ü Page 157 Enable Anonymous Call ü Page 157 Enable Block Anonymous ü...
Page 73 4.1 Web User Interface Setting List Access Level Menu Item Section Title Setting Ref. Tone Settings Dial Tone Tone Frequencies ü Page 163 Tone Timings ü Page 164 Busy Tone Tone Frequencies ü Page 164 Tone Timings ü Page 164 Ringing Tone Tone Frequencies Page 165...
Page 74 4.1 Web User Interface Setting List Access Level Menu Item Section Title Setting Ref. Firmware Firmware Maintenance Enable Firmware Update ü Page 172 Maintenance Firmware File URL ü Page 173 Upgrade Upgrade Firmware File Name ü Page 173 Firmware Import Wallpaper Import Wallpaper Gradation Type ü...
Page 75: Status
4.2.1 Version Information 4.2 Status This section provides detailed descriptions about all the settings classified under the [Status] tab. 4.2.1 Version Information This screen allows you to view the current version information such as the model number and the firmware version of the unit.
Page 76: Ipl Version
4.2.2 Handset Information IPL Version Description Indicates the version of the IPL (Initial Program Load) that runs when starting the unit and the SIP software version of the unit (reference only). Value Range IPL version ("nn.nnn" [n=0–9]) SIP software version ("[SIP: n.nn]" [n=0–9]) Firmware Version Description Indicates the version of the firmware that is currently installed on the...
Page 77: Handset Information
4.2.3 Network Status 4.2.2.1 Handset Information Handset 1–8 (Model) Description Indicates the model number of the handset (reference only). Value Range Model number Handset 1–8 (Firmware Version) Description Indicates the version of the firmware that is currently installed on the handset (reference only).
Page 78: Network Common
4.2.3 Network Status 4.2.3.1 Network Common MAC Address Description Indicates the MAC address of the unit (reference only). Value Range Not applicable. Ethernet Link Status Description Indicates the current connection status of the Ethernet LAN port (reference only). Value Range •...
Page 79: Default Gateway
4.2.3 Network Status Default Gateway Description Indicates the specified IP address of the default gateway for the network (reference only). Note • If the default gateway address is not specified, this field will be left blank. Value Range IP address of the default gateway DNS1 Description Indicates the specified IP address of the primary DNS server (reference...
Page 80: Prefix
4.2.3 Network Status Prefix Description Indicates the prefix for IPv6. Value Range 0–128 Default Gateway Description Indicates the specified IP address of the default gateway for the network (reference only). Note • If the default gateway address is not specified, this field will be left blank.
Page 81: Vlan Priority
4.2.4 VoIP Status Value Range • Disable • LLDP • • LLDP/CDP • Manual VLAN ID Description Indicates the VLAN ID (reference only). Value Range 0–4094 VLAN Priority Description Indicates the priority number (reference only). Value Range 0–7 4.2.4 VoIP Status This screen allows you to view the current VoIP status of each line’s unit.
Page 82: Phone Number
4.2.4 VoIP Status Phone Number Description Indicates the currently assigned phone numbers (reference only). Note • The corresponding field is blank if a line has not yet been leased or if the unit has not been configured. Value Range Max. 32 digits VoIP Status Description Indicates the current VoIP status of each line (reference only).
Page 83: Network
4.3.1 Basic Network Settings 4.3 Network This section provides detailed descriptions about all the settings classified under the [Network] tab. 4.3.1 Basic Network Settings This screen allows you to change basic network settings such as whether to use a DHCP server, and the IP address of the unit.
Page 84: Ip Addressing Mode
4.3.1 Basic Network Settings Note • Changes to the settings on this screen are applied when the message "Complete" appears after clicking [Save]. Because the IP address of the unit will probably be changed if you change these settings, you will not be able to continue using the Web user interface.
Page 85: Ipv4
4.3.1 Basic Network Settings 4.3.1.2 IPv4 Connection Mode Description Selects the IP address setting mode for IPv4. Value Range • Static • DHCP Default Value DHCP Configuration File Reference CONNECTION_TYPE (Page 212) DHCP Host Name Description Specifies the host name to option12 in DHCPv4 or option15 in DHCPv6. Note •...
Page 86: Default Gateway
4.3.1 Basic Network Settings Value Range Max. 15 characters n.n.n.n [n=0–255] Default Value Not stored. Configuration File Reference STATIC_SUBNET (Page 212) Default Gateway Description Specifies the default gateway for IPv4. Note • This setting is available only when [Connection Mode] is set to [Static].
Page 87: Ipv6
4.3.1 Basic Network Settings Value Range Max. 15 characters n.n.n.n [n=0–255] Default Value Not stored. Configuration File Reference USER_DNS2_ADDR (Page 214) 4.3.1.3 IPv6 Connection Mode Description Selects the IP address setting mode for IPv6. Value Range • Static • DHCP •...
Page 88: Default Gateway
4.3.1 Basic Network Settings Default Gateway Description Specifies the default gateway for IPv6. Note • This setting is available only when [Connection Mode] is set to [Static]. Value Range Max. 39 characters n:n:n:n:n:n:n:n [n=0-FFFF, abbreviation available] Default Value Not stored. Configuration File Reference STATIC_GATEWAY_IPV6 (Page 215) Auto DNS via DHCP...
Page 89: Ethernet Port Settings
4.3.2 Ethernet Port Settings 4.3.2 Ethernet Port Settings This screen allows you to change the connection mode of the Ethernet ports, LLDP and the VLAN settings. Note • When you change the settings on this screen and click [Save], after the message "Complete" has been displayed, the unit will restart automatically with the new settings applied.
Page 90: Lldp
4.3.2 Ethernet Port Settings 4.3.2.2 LLDP Enable LLDP Description Selects whether to enable or disable the LLDP-MED feature. Note • You should specify "Yes" for only one of "Enable LLDP", or "Enable VLAN". • If "Yes" is specified for two or more of the parameters above, the settings are prioritized as follows: "Enable VLAN"...
Page 91: Vlan
4.3.2 Ethernet Port Settings Configuration File Reference CDP_INTERVAL (Page 218) 4.3.2.4 VLAN Enable VLAN Description Selects whether to use the VLAN feature to perform VoIP communication securely. Note • You should specify "Yes" for only one of "Enable LLDP", or "Enable VLAN".
Page 92: Http Client Settings
4.3.3 HTTP Client Settings 4.3.3 HTTP Client Settings This screen allows you to change the HTTP client settings for the unit in order to access the HTTP server of your phone system and download configuration files. 4.3.3.1 HTTP Client HTTP Version Description Selects which version of the HTTP protocol to use for HTTP communication.
Page 93: Authentication Id
4.3.3 HTTP Client Settings Value Range Max. 64 characters Note • If "{mac}" is included in this parameter, it will be replaced with the unit’s MAC address in lower-case. • If "{MAC}" is included in this parameter, it will be replaced with the unit’s MAC address in upper-case.
Page 94: Proxy Server Address
4.3.4 STUN Settings Proxy Server Address Description Specifies the IP address or FQDN of the proxy server. Value Range Max. 256 characters Default Value Not stored. Configuration File Reference HTTP_PROXY_ADDR (Page 229) Proxy Server Port Description Specifies the port number of the proxy server. Value Range 1–65535 Default Value...
Page 95: Port
4.3.5 Multicast Paging Settings Configuration File Reference STUN_SERV_ADDR (Page 267) Port Description Specifies the port number of the STUN server for the CPE to send Binding Requests. Value Range 1–65535 Default Value 3478 Configuration File Reference STUN_SERV_PORT (Page 267) Binding Interval Description Specifies the interval of the sending binding request.
Page 96: Multicast Paging
4.3.5 Multicast Paging Settings 4.3.5.1 Multicast Paging IPv4 Address (Group 1–5) Description Specifies the address for multi-cast paging for each channel group. {Priority: Group 5 > Group 4 > Group 3, Group2, Group1 (depending on the configuration)} Value Range 224.0.0.0–239.255.255.255 Default Value Not stored.
Page 97: Enable Transmission (Group 1–5)
4.3.6 LDAP Settings Value Range Max. 24 characters Default Value Not stored. Configuration File Reference MPAGE_LABELm (Page 256) Enable Transmission (Group 1–5) Description Selects the sending multi-cast paging. Value Range • • Default Value Configuration File Reference MPAGE_SEND_ENABLEm (Page 257) 4.3.6 LDAP Settings This screen allows you to change the LDAP Settings.
Page 98: Server Address
4.3.6 LDAP Settings Server Address Description Specifies the server host of LDAP. Value Range Max. 256 characters Note • The LDAP server address should start with "ldap://" or "ldaps://". Default Value Not stored. Configuration File Reference LDAP_SERVER (Page 249) Port Description Specifies the port of server.
Page 99: Name Filter
4.3.6 LDAP Settings Configuration File Reference LDAP_MAXRECORD (Page 250) Name Filter Description Specifies the name filter which is the search criteria for name look up. Value Range Max. 256 characters Default Value (|(cn=%)(sn=%)) Configuration File Reference LDAP_NAME_FILTER (Page 251) Number Filter Description Specifies the number filter which is the search criteria for number look Value Range...
Page 100: Enable Dns Srv Lookup
4.3.7 Xtended Service Settings Configuration File Reference LDAP_BASEDN (Page 252) Enable DNS SRV lookup Description Selects whether to request the DNS server to translate domain names into IP addresses using the SRV record. Value Range • • Default Value Configuration File Reference LDAP_DNSSRV_ENABLE (Page 249) 4.3.7 Xtended Service Settings This screen allows you to change the Xtended Service Settings.
Page 101: Server Address
4.3.7 Xtended Service Settings Value Range • • Default Value Configuration File Reference XSI_ENABLE (Page 240) Server Address Description Specifies the IP address or FQDN of the Xsi server. Value Range Max. 256 characters Default Value Not stored. Configuration File Reference XSI_SERVER (Page 240) Port Description...
Page 102: Password (Line 1–8)
4.3.7 Xtended Service Settings Value Range Max. 128 characters Default Value Not stored. Configuration File Reference XSI_USERID_n (Page 241) Password (Line 1–8) Description Specifies the authentication password required to access the Xsi server. Value Range Max. 128 characters Default Value Not stored.
Page 103: Groupcommon
4.3.7 Xtended Service Settings Value Range • • Note • This setting is available only when "BSD_MULTI_TYPE_ENABLE" is set to "Y". Default Value Configuration File Reference BSD_GROUP_ENABLE_n (Page 243) GroupCommon Description Specifies whether to enable or disable the "GroupCommon" type for Xsi phonebooks.
Page 104: Personal
4.3.7 Xtended Service Settings Value Range • • Note • This setting is available only when "BSD_MULTI_TYPE_ENABLE" is set to "Y". Default Value Configuration File Reference BSD_ENTERPRISECOM_ENABLE_n (Page 244) Personal Description Specifies whether to enable or disable the "Personal" type for Xsi phonebooks.
Page 105: Uc Settings
4.3.8 UC Settings 4.3.8 UC Settings This screen allows you to change the UC Settings. 4.3.8.1 Presence Feature Enable UC Description Selects whether to enable the UC service. Value Range • • Default Value Configuration File Reference UC_ENABLE (Page 245) Server Address Description Specifies the IP address or FQDN of the XMPP server.
Page 106: Local Xmpp Port
4.3.9 XML Application Settings Local XMPP Port Description Specifies the local XMPP port. Value Range 1–65535 Default Value 5222 Configuration File Reference XMPP_PORT (Page 246) Handset 1–8 (User ID) Description Specifies the authentication ID required to access the UC server. Value Range Max.
Page 107: Xml Application
4.3.9 XML Application Settings 4.3.9.1 XML Application Enable XMLAPP Description Selects whether to enable or disable the XML application feature. Value Range • • Default Value Configuration File Reference XMLAPP_ENABLE (Page 237) User ID Description Specifies the authentication ID required to access the XML application server.
Page 108: Password
4.3.9 XML Application Settings Default Value Not stored. Configuration File Reference XMLAPP_LDAP_URL (Page 238) User ID Description Specifies the authentication ID required to access the LDAP server. Value Range Max. 128 characters Default Value Not stored. Configuration File Reference XMLAPP_LDAP_USERID (Page 238) Password Description Specifies the authentication password used to access the LDAP server.
Page 109: Twamp Settings
4.3.10 TWAMP Settings 4.3.10 TWAMP Settings This screen allows you to change the TWAMP settings. 4.3.10.1 TWAMP Enable TWAMP Description Selects whether to enable the TWAMP server function. • Value Range • Default Value Configuration File Reference TWAMP_ENABLE (Page 355) Control Port Description Specifies the port for the TWAMP control session.
Page 110: Wait Time For Control
4.3.10 TWAMP Settings Wait Time for Control Description Specifies the time, in seconds, for the TWAMP server to wait for incoming packets for maintaining the session. Value Range 1–65535 Default Value Configuration File Reference TWAMP_SERVER_WAIT_TIME (Page 356) Wait Time for Reflector Description Specifies the time, in seconds, for the TWAMP reflector to wait for incoming packets for maintaining the session.
Page 111: System
4.4.1 System Settings 4.4 System This section provides detailed descriptions about all the settings classified under the [System] tab. 4.4.1 System Settings This screen allows you to perform system settings on IP terminals. 4.4.1.1 System Enable Multi Number Description Specifies whether to enable or disable the multi number mode. Value Range •...
Page 112: Enable Non-Registering Sip Ua
4.4.2 Language Settings Value Range • • Default Value Configuration File Reference SIP_TRUNK_MODE_ENABLE (Page 202) Enable Non-Registering SIP UA Description Specifies whether to enable or disable SIP UA registration. Note • This setting is available only when [Enable SIP Trunk Service] is set to [Yes].
Page 113: Selectable Language
4.4.2 Language Settings • The language used for the unit remains unchanged even if the language for the Web user interface is changed. 4.4.2.1 Selectable Language Handset Description Specifies the selectable language on the handset. Up to 10 languages separated by commas can be registered. (e.g., "en,es,fr,de,it,nl,pt") Value Range •...
Page 114: Web Language
4.4.2 Language Settings Configuration File Reference AVAILABLE_LANGUAGE_HS (Page 265) Description Specifies the selectable language on the Web. Up to 10 languages separated by commas can be registered. (e.g., "en,es,fr,de,it,nl,pt") Value Range • en: English • es: Spanish • fr: French •...
Page 115: User Password Settings
4.4.3 User Password Settings Value Range • en: English • es: Spanish • fr: French • de: German • it: Italian • nl: Dutch • el: Greek • hu: Hungarian • pt: Portuguese • pl: Polish • sk: Slovakian • cs: Czech •...
Page 116: User Password
4.4.4 Admin Password Settings 4.4.3.1 User Password Current Password Description Specifies the current password to use to authenticate the User account when logging in to the Web user interface. Value Range 6–64 characters (except !, ", #, $, %, &, ', (, ), @, *, +, ,, /, :, ;, <, =, >, ?, [, ], ^, `, {, |, }, ~, \ and space) Default Value Not stored.
Page 117: Admin Password
4.4.4 Admin Password Settings Unauthorized"). This restriction only applies the first time you attempt to log in after changing the password. In all other circumstances, an error occurs after 3 unsuccessful login attempts. 4.4.4.1 Admin Password Current Password Description Specifies the current password to use to authenticate the Administrator account when logging in to the Web user interface.
Page 118: Time Adjust Settings
4.4.5 Time Adjust Settings 4.4.5 Time Adjust Settings This screen allows you to enable automatic clock adjustment using an NTP server and configure the settings for DST (Daylight Saving Time), also known as Summer Time. 4.4.5.1 Synchronization Server Address Description Specifies the IP address or FQDN of NTP server.
Page 119: Time Zone
4.4.5 Time Adjust Settings 4.4.5.2 Time Zone Time Zone Description Selects your time zone. Value Range GMT -12:00–GMT +13:00 Default Value Configuration File Reference TIME_ZONE (Page 259) 4.4.5.3 Daylight Saving Time (Summer Time) Enable DST (Enable Summer Time) Description Selects whether to enable Daylight Saving Time (Summer Time). Value Range •...
Page 120 4.4.5 Time Adjust Settings Value Range • January • February • March • April • • June • July • August • September • October • November • December Default Value March Configuration File Reference DST_START_MONTH (Page 261) Day of Week Using the 2 following settings, specify on which day of the selected month DST (Summer Time) starts.
Page 121: Time
4.4.5 Time Adjust Settings Time Description Specifies the start time of DST (Summer Time) in minutes after 12:00 Value Range 0–1439 (min) Default Value Configuration File Reference DST_START_TIME (Page 262) 4.4.5.5 End Day and Time of DST (End Day and Time of Summer Time) Month Description Selects the month in which DST (Summer Time) ends.
Page 122: Time
4.4.6 Handset Basic Settings Value Range • Sunday • Monday • Tuesday • Wednesday • Thursday • Friday • Saturday Default Value Sunday Configuration File Reference DST_STOP_DAY_OF_WEEK (Page 263) Time Description Specifies the end time of DST (Summer Time) in minutes after 12:00 Value Range 0–1439 (min) Default Value...
Page 123: Handset 1–8
4.4.6 Handset Basic Settings 4.4.6.1 Handset 1–8 Handset Name Description Specifies the handset name. Value Range Max. 16 characters Default Value HANDSET_NAME_HS1="Handset 1" HANDSET_NAME_HS2="Handset 2" HANDSET_NAME_HS3="Handset 3" HANDSET_NAME_HS4="Handset 4" HANDSET_NAME_HS5="Handset 5" HANDSET_NAME_HS6="Handset 6" HANDSET_NAME_HS7="Handset 7" HANDSET_NAME_HS8="Handset 8" Configuration File Reference HANDSET_NAME_HSy (Page 342) Language Description...
Page 124: Handset Advanced Settings
4.4.7 Handset Advanced Settings 4.4.7 Handset Advanced Settings This screen allows you to change the Soft Key function settings. 4.4.7.1 Soft Key during IDLE Status Soft Key A (Left) Description Selects soft key (A) during IDLE state. Value Range • Phonebook •...
Page 125: Soft Key C (Right)
4.4.7 Handset Advanced Settings Value Range • Phonebook • Menu • Outgoing Call Log • Incoming Call Log • Redial • Page (Used when performing Multicast Paging) Default Value Menu Configuration File Reference IDLE_SOFT_KEY_B (Page 341) Soft Key C (Right) Description Selects soft key (C) during IDLE state.
Page 126: Password For Unlocking
4.4.7 Handset Advanced Settings Password for Unlocking Description Specifies the password for unlocking handset. Value Range Null, 4 digits (0–9) Default Value Not stored. Configuration File Reference SYS_LOCK_PASSWORD_HSy (Page 320) Missed Call Notification—Message Description Selects whether to display "Missed Calls" on the screen in standby mode.
Page 127: Voice Message Notification—Led
4.4.7 Handset Advanced Settings Configuration File Reference NOTIFY_VOICEMAIL_ENABLE_HSy (Page 207) Voice Message Notification—LED Description Selects whether the LED is used to indicate a new voice message. Note • This setting is available only when "NOTIFICATION_MENU_ENABLE" is set to "Y". Value Range •...
Page 128: Parallel Mode Settings
4.4.9 Delete Handset 4.4.8 Parallel Mode Settings This screen allows you to change the Parallel Mode settings that are Linking the desk phone and handset due to have the relation with master and slave. ( ® see 6.6 Pairing (Parallel Mode)) 4.4.8.1 Parallel Mode Slave Handset Number (Master Desk Phone Number 1–8) Description...
Page 129: Delete Handset Registration
4.4.9 Delete Handset of the handsets you want to delete, and then click [Execute]. The check boxes that were selected will become grayed out. The base unit will restart automatically, and registration of the handsets whose check boxes were selected will be deleted. 4.4.9.1 Delete Handset Registration Registration Number (1–8) Description...
Page 130: Sip Settings
If "{fwver}" is included in this field, it will be replaced with the firmware version of the unit. • If "{sipver}" is included in this parameter, it will be replaced with the SIP software version of the unit. Default Value Panasonic-{MODEL}/{fwver} ({mac}) Administrator Guide Document Version 2017-07...
Page 131: Nat Identity
4.5.1 SIP Settings Configuration File Reference SIP_USER_AGENT (Page 269) 4.5.1.2 NAT Identity Enable Rport (RFC 3581) Description Selects whether to add the 'rport' parameter to the top Via header field value of requests generated. Value Range • • Default Value Configuration File Reference SIP_ADD_RPORT (Page 268) Enable Port Punching for SIP...
Page 132: Basic
4.5.2 SIP Settings [Line 1]–[Line 8] 4.5.2 SIP Settings [Line 1]–[Line 8] This screen allows you to change the SIP settings that are specific to each line. 4.5.2.1 Basic Phone Number Description Specifies the phone number to use as the user ID required for registration to the SIP registrar server.
Page 133: Registrar Server Port
4.5.2 SIP Settings [Line 1]–[Line 8] Default Value Not stored. Configuration File Reference SIP_RGSTR_ADDR_n (Page 270) Registrar Server Port Description Specifies the port number to use for communication with the SIP registrar server. Value Range 1–65535 Default Value 5060 Configuration File Reference SIP_RGSTR_PORT_n (Page 270) Proxy Server Address Description...
Page 134: Outbound Proxy Server Address
4.5.2 SIP Settings [Line 1]–[Line 8] Default Value 5060 Configuration File Reference SIP_PRSNC_PORT_n (Page 271) Outbound Proxy Server Address Description Specifies the IP address or FQDN of the SIP outbound proxy server. Value Range Max. 256 characters Default Value Not stored. Configuration File Reference SIP_OUTPROXY_ADDR_n (Page 272) Outbound Proxy Server Port...
Page 135: Advanced
4.5.2 SIP Settings [Line 1]–[Line 8] Default Value Not stored. Configuration File Reference SIP_PASS_n (Page 273) 4.5.2.2 Advanced SIP Packet QoS (DSCP) Description Specifies the DSCP (Differentiated Services Code Point) level of DiffServ applied to SIP packets. Value Range 0–63 Default Value Configuration File Reference DSCP_SIP_n (Page 273)
Page 136: Srv Lookup Prefix For Tcp
4.5.2 SIP Settings [Line 1]–[Line 8] SRV lookup Prefix for TCP Description Specifies a prefix to add to the domain name when performing a DNS SRV lookup using TCP. Note • This setting is available only when [Enable DNS SRV lookup] is set to [Yes].
Page 137: T1 Timer
4.5.2 SIP Settings [Line 1]–[Line 8] SIP URI Description Specifies the unique ID used by the SIP registrar server, which consists of "sip:", a user part, the "@" symbol, and a host part, for example, "sip:user@example.com", "2405551111_1". Note • When registering using a user ID that is not a phone number, you should use this setting.
Page 138: Register Expires Timer
4.5.2 SIP Settings [Line 1]–[Line 8] REGISTER Expires Timer Description Specifies the length of time, in seconds, that the registration remains valid. This value is set in the "Expires" header of the REGISTER request. Value Range 1–4294967295 Default Value 3600 Configuration File Reference REG_EXPIRE_TIME_n (Page 275) Enable Session Timer (RFC 4028)
Page 139: Enable Ssaf (Sip Source Address Filter)
4.5.2 SIP Settings [Line 1]–[Line 8] Enable SSAF (SIP Source Address Filter) Description Selects whether to enable SSAF for the SIP servers (registrar server, proxy server, and presence server). Value Range • • Default Value Configuration File Reference SIP_DETECT_SSAF_n (Page 282) Enable c=0.0.0.0 Hold (RFC 2543) Description Selects whether to enable the RFC 2543 Call Hold feature on this line.
Page 140: Voip Settings
4.5.3 VoIP Settings 4.5.3 VoIP Settings This screen allows you to change the VoIP settings that are common to all lines. 4.5.3.1 RTP RTP Packet Time Description Selects the interval, in milliseconds, between transmissions of RTP packets. Value Range • •...
Page 141: Maximum Rtp Port Number
4.5.3 VoIP Settings Maximum RTP Port Number Description Specifies the highest port number that the unit will use for RTP packets. Value Range 1424–59998 (even number only) Default Value 20000 Configuration File Reference RTP_PORT_MAX (Page 304) Telephone-event Payload Type Description Specifies the RFC 2833 payload type for DTMF tones.
Page 142: Alert Report Trigger
4.5.3 VoIP Settings Value Range • Disable • End of Session Report Using PUBLISH • Interval report Using PUBLISH • Alert Report Using PUBLISH Default Value Disable Configuration File Reference VQREPORT_SEND (Page 309) Alert Report Trigger Description Selects the trigger to notify the VQ report. Value Range •...
Page 143: Threshold Delay (Warning)
4.5.4 VoIP Settings [Line 1]–[Line 8] Threshold Delay (Warning) Description Specifies the criteria (warning) to send the VQ report when a delay occurs. Value Range 0–2000 Default Value Configuration File Reference ALERT_REPORT_DELAY_WARNING (Page 310) 4.5.4 VoIP Settings [Line 1]–[Line 8] This screen allows you to change the VoIP settings that are specific to each line.
Page 144: G.722 (Priority)
4.5.4 VoIP Settings [Line 1]–[Line 8] G.722 (Priority) Description Specifies the numerical order usage priority for the G.722 codec. Value Range 1–255 Default Value Configuration File Reference CODEC_PRIORITYx_n (Page 300) PCMA (Enable) Description Selects whether to enable the PCMA codec for voice data transmission. Value Range •...
Page 145: G.729A (Enable)
4.5.4 VoIP Settings [Line 1]–[Line 8] G.729A (Enable) Description Selects whether to enable the G.729A codec for voice data transmission. Value Range • • Default Value Configuration File Reference CODEC_ENABLEx_n (Page 299) G.729A (Priority) Description Specifies the numerical order usage priority for the G.729A codec. Value Range 1–255 Default Value...
Page 146: Advanced
4.5.4 VoIP Settings [Line 1]–[Line 8] Value Range • RFC2833 • Inband • SIP INFO Note • RFC2833 refers to Outband DTMF. • Inband refers to Inband DTMF. Default Value RFC2833 Configuration File Reference DTMF_METHOD_n (Page 301) 4.5.4.2 Advanced RTP Packet QoS (DSCP) Description Specifies the DSCP level of DiffServ applied to RTP packets.
Page 147: Rtcp&Rtcp-Xr Interval
SRTP Mode Description Selects the mode of SRTP feature. Value Range • 0: SRTP • 1: RTP/SRTP • 2: Panasonic Original • 3: SRTP/RTP Note • 0: SRTP Use only SRTP for outgoing and incoming calls. • 1: RTP/SRTP Use only RTP for outgoing calls, and RTP or SRTP for incoming calls.
Page 148: Enable Mixed Srtp & Rtp By Transfer
4.5.4 VoIP Settings [Line 1]–[Line 8] Default Value Configuration File Reference SRTP_MIX_CONFERENCE_ENABLE_n (Page 307) Enable Mixed SRTP & RTP by Transfer Description Selects whether to allow call transfers between a user who is using SRTP and a user who is using RTP. Value Range •...
Page 149: Telephone
4.6.1 Multi Number Settings 4.6 Telephone This section provides detailed descriptions about all the settings classified under the [Telephone] tab. 4.6.1 Multi Number Settings This screen allows you to assign phone numbers for incoming and outgoing calls to the base unit and handsets. A maximum of 8 phone numbers can be assigned for each unit.
Page 150: Phone Number
4.6.1 Multi Number Settings Phone Number Description Indicates the currently assigned phone numbers (reference only). Value Range Max. 32 digits Default Value Not applicable. Configuration File Reference INCOMING_CALL_GROUP_n (Page 335) Handset Number (1–8) Description Selects the handsets (1–8) that calls will arrive at for each line. Value Range Selected, Not selected Default Value...
Page 151: Default
4.6.2 Call Control Default Description Selects which line to seize automatically when going off-hook to make a call for the base unit and each handset. Value Range 1–8 Default Value Configuration File Reference DEFAULT_LINE_SELECT_HSy (Page 335) 4.6.2 Call Control This screen allows you to configure various call features that are common to all lines. 4.6.2.1 Call Control Send SUBSCRIBE to Voice Mail Server Description...
Page 152: Conference Server Uri
4.6.2 Call Control Default Value Configuration File Reference VM_SUBSCRIBE_ENABLE (Page 337) Conference Server URI Description Specifies the URI for a conference server, which consists of "sip:", a user part, the "@" symbol, and a host part, for example, "sip:conference@example.com". Note •...
Page 153: Enable # Key As Delimiter
4.6.2 Call Control Enable # Key as delimiter Description Selects whether the # key is treated as a regular dialed digit or a delimiter, when dialed as or after the second digit. Value Range • Yes: # is treated as the end of dialing delimiter. •...
Page 154: Enable Call Park Key
4.6.2 Call Control Configuration File Reference NUM_PLAN_PARKING (Page 317) Enable Call Park Key Description Selects whether to display "Call Park" in the Call Parking Func menu. Value Range • • Default Value Configuration File Reference CALLPARK_KEY_ENABLE (Page 318) Park Retrieve Number Description Specifies the call park retrieve number.
Page 155: Private Hold
4.6.2 Call Control Private Hold Description Selects whether to enable or disable "Private Hold". Value Range • • Default Value Configuration File Reference PRIVATE_HOLD_ENABLE (Page 205) 4.6.2.2 Emergency Call Phone Numbers 1–5 Description Specifies the phone numbers used for making emergency calls. A user can dial any of the specified phone numbers at any time regardless of any restrictions imposed on the unit.
Page 156: Call Features
4.6.3 Call Control [Line 1]–[Line 8] 4.6.3 Call Control [Line 1]–[Line 8] This screen allows you to configure various call features that are specific to each line. 4.6.3.1 Call Features Display Name Description Specifies the name to display as the caller on the other party’s phone when you make a call.
Page 157: Voice Mail Access Number
4.6.3 Call Control [Line 1]–[Line 8] Voice Mail Access Number Description Specifies the phone number used to access the voice mail server. Note • Your phone system must support voice mail. Value Range Max. 32 characters Default Value Not stored. Configuration File Reference VM_NUMBER_n (Page 338) Enable Anonymous Call...
Page 158: Enable Call Forwarding Always
4.6.3 Call Control [Line 1]–[Line 8] Default Value Configuration File Reference CW_ENABLE_n (Page 346) Enable Call Forwarding Always Description Selects whether to forward all incoming calls to a specified destination. Value Range • • Default Value Forwarding Number (Always) Description Specifies the phone number of the destination to forward all incoming calls to.
Page 159: Forwarding Number (No Answer)
4.6.3 Call Control [Line 1]–[Line 8] Forwarding Number (No Answer) Description Specifies the phone number of the destination to forward calls to when a call is not answered after it has rung a specified number of times. Value Range Max. 32 characters Default Value Not stored.
Page 160: Enable Call Park Notification
4.6.3 Call Control [Line 1]–[Line 8] Configuration File Reference FWD_DND_SYNCHRO_ENABLE_n (Page 344) Enable Call Park Notification Description Selects whether to respond to call park notifications from the server. Value Range • • Default Value Configuration File Reference CALLPARK_NOTIFICATION_ENABLE_n (Page 343) Enable Click to Call Description Selects whether to enable Click to Dial/Answer/Hold functions.
Page 161: Call Even If Dial Plan Does Not Match
4.6.3 Call Control [Line 1]–[Line 8] Call Even If Dial Plan Does Not Match Description Selects whether to make a call even if the dialed number does not match any of the dial formats specified in [Dial Plan]. Value Range •...
Page 162: Hotline Settings
4.6.4 Hotline Settings 4.6.4 Hotline Settings 4.6.4.1 Hotline Handset 1–8 (Enable) Description Selects whether to enable or disable the Hot line feature. Value Range • • Default Value Configuration File Reference HOTLINE_ENABLE_HSy (Page 336) Handset 1–8 (Hotline Number) Description Specifies the Hot line number. Value Range Max.
Page 163: Hotline Delay
4.6.5 Tone Settings Hotline Delay Description Specifies a time after off hook for Hot line. Value Range 0–10 (s) Default Value Configuration File Reference HOTLINE_TIM (Page 337) 4.6.5 Tone Settings This screen allows you to configure the dual-tone frequencies and ringtone patterns of each tone. 4.6.5.1 Dial Tone Tone Frequencies Description...
Page 164: Tone Timings
4.6.5 Tone Settings Tone Timings Description Specifies the pattern, in milliseconds, of dial tones using up to 10 whole numbers (off 1, on 1, off 2, on 2…) separated by commas. Note • The unit will not play the tone for the duration of the first value, play it for the duration of the second value, stop it for the duration of the third value, play it again for the duration of the fourth value, and so on.
Page 165: Ringing Tone
4.6.5 Tone Settings Configuration File Reference BUSY_TONE_TIMING (Page 330) 4.6.5.3 Ringing Tone Tone Frequencies Description Specifies the dual-tone frequencies, in hertz, of ringback tones using 2 whole numbers separated by a comma. Value Range 0, 200–2000 (0: No tone) Note •...
Page 166: Tone Timings
4.6.5 Tone Settings Configuration File Reference DIAL_TONE4_FRQ (Page 328) Tone Timings Description Specifies the pattern, in milliseconds, of stutter dial tones to notify that a voice mail is waiting, using up to 22 whole numbers (off 1, on 1, off 2, on 2…) separated by commas.
Page 167: Import Phonebook
4.6.6 Import Phonebook Default Value 60,250,190 Note • Avoid setting 1–50 for any of the values. Configuration File Reference REORDER_TONE_TIMING (Page 331) 4.6.6 Import Phonebook This screen allows you to import phonebook data from a PC to the specified unit. For details, see 6.2.1 Import/ Export Operation.
Page 168: File Name
4.6.7 Export Phonebook File Name Description Specifies the path of the TSV (Tab-separated Value) file to import from the PC. Value Range No limitation Note • There are no limitations for the field entry. However, it is recommended that paths of less than 256 characters be used: longer paths may cause longer data transfer times and result in an internal error.
Page 169: Export Phonebook
4.6.7 Export Phonebook 4.6.7.1 Export Phonebook Handset Number Description Selects the handset to export the phonebook data from. Value Range • Handset 1 • Handset 2 • Handset 3 • Handset 4 • Handset 5 • Handset 6 • Handset 7 •...
Page 170: Maintenance
4.7.1 Provisioning Maintenance 4.7 Maintenance This section provides detailed descriptions about all the settings classified under the [Maintenance] tab. 4.7.1 Provisioning Maintenance This screen allows you to change the provisioning setup to download the configuration files from the provisioning server of your phone system. 4.7.1.1 Provisioning Maintenance Standard File URL Description...
Page 171: Master File Url
4.7.1 Provisioning Maintenance Default Value Not stored. Configuration File Reference CFG_PRODUCT_FILE_PATH (Page 220) Master File URL Description Specifies the URL of the master configuration file, which is used when all units need the same settings. Value Range Max. 384 characters Note •...
Page 172: Header Value For Resync Event
4.7.2 Firmware Maintenance Header Value for Resync Event Description Specifies the value of the "Event" header sent from the SIP server to the unit so that the unit can access the configuration files on the provisioning server. Value Range Max. 15 characters Default Value check-sync Configuration File Reference...
Page 173: Firmware File Url
4.7.3 Upgrade Firmware Firmware File URL Description Specifies the URI where the firmware file is stored. Note • This setting is available only when [Enable Firmware Update] is set to [Yes]. Value Range Max. 384 characters Note • If "{fwver}" is included in this parameter, it will be replaced with the value specified in [Firmware Version].
Page 174: Import Wallpaper
4.7.5 Export Logging File 4.7.4 Import Wallpaper This screen allows you to import the Wallpaper data from a PC. 4.7.4.1 Import Wallpaper Gradation Type Description Selects the Gradation Type setting. Value Range • Dark • Light Default Value Dark File Name Description Specifies the path of the Wallpaper file to import from the PC.
Page 175: Export Logging File
4.7.7 Restart 4.7.5.1 Export Logging File Logging File Type Description Selects the Logging File Type setting. Value Range • Power Down • Event • SIP Packet Note • The line break code for the log file is <LF>. • If a file is exported when Power Down is selected, the saved file is power.log.
Page 176 4.7.7 Restart Notice • The unit will restart even if it is being accessed through the phone user interface, or on calls. Administrator Guide Document Version 2017-07...
Page 177: Configuration File Programming
Section 5 Configuration File Programming This section provides information about the configuration parameters used in the configuration files. Document Version 2017-07 Administrator Guide...
Page 178: Configuration File Parameter List
5.1 Configuration File Parameter List 5.1 Configuration File Parameter List The following tables show all the parameters that can be programmed using configuration file programming. For details about each parameter, see the reference pages listed. For details about configuration file specifications, see 2.4 Configuration File Specifications. System Settings Parameter Name Ref.
Page 179: Basic Network Settings
5.1 Configuration File Parameter List Parameter Name Ref. NOTIFICATION_MENU_ENABLE Page 207 Page 207 NOTIFY_MISSEDCALL_ENABLE_HSy Page 207 NOTIFY_VOICEMAIL_ENABLE_HSy Page 208 NOTIFY_MISSEDCALL_LED_ENABLE_HSy Page 208 NOTIFY_VOICEMAIL_LED_ENABLE_HSy Page 209 NOTIFY_VOICEMAIL_ALARM_ENABLE_HSy NOTIFICATION_ALARM_TYPE Page 209 BOOTLOG_SERVER_URI Page 209 NOISE_SUPPRESSOR_ENABLE Page 209 CODEC_VAD_CNG_ENABLE Page 210 ERROR_AUTO_REBOOT_TIME Page 210 BLOCK_CID_MENU_ENABLE Page 210 Handset Registration Settings...
Page 180 5.1 Configuration File Parameter List Parameter Name Ref. Page 214 DHCP_HOST_NAME DHCP_VENDOR_CLASS Page 214 Page 215 CONNECTION_TYPE_IPV6 Page 215 STATIC_IP_ADDRESS_IPV6 Page 215 PREFIX_IPV6 Page 215 STATIC_GATEWAY_IPV6 Page 216 USER_DNS1_ADDR_IPV6 Page 216 USER_DNS2_ADDR_IPV6 Page 216 DHCP_DNS_ENABLE_IPV6 Ethernet Port Settings Parameter Name Ref.
Page 181: Firmware Update Settings
5.1 Configuration File Parameter List Provisioning Settings Parameter Name Ref. Page 220 CFG_STANDARD_FILE_PATH Page 220 CFG_PRODUCT_FILE_PATH Page 221 CFG_MASTER_FILE_PATH Page 221 CFG_CYCLIC Page 222 CFG_CYCLIC_INTVL Page 222 CFG_RESYNC_TIME CFG_RTRY_INTVL Page 222 Page 222 CFG_RESYNC_FROM_SIP CFG_RESYNC_ACTION Page 223 CFG_FILE_KEY2 Page 223 CFG_FILE_KEY3 Page 223 CFG_FILE_KEY_LENGTH...
Page 182 5.1 Configuration File Parameter List Parameter Name Ref. Page 228 HTTP_AUTH_ID Page 228 HTTP_AUTH_PASS Page 228 HTTP_PROXY_ENABLE Page 229 HTTP_PROXY_ADDR Page 229 HTTP_PROXY_PORT HTTP_PROXY_ID Page 229 HTTP_PROXY_PASS Page 229 HTTPD/WEB Settings Parameter Name Ref. HTTPD_LISTEN_PORT Page 229 HTTPD_PORTOPEN_AUTO Page 230 HTTPD_PORTCLOSE_TM Page 230 USER_ID...
Page 183 5.1 Configuration File Parameter List Parameter Name Ref. ANNEX_G_STUN_USER_ID Page 235 ANNEX_G_STUN_PASS Page 235 ANNEX_G_STUN_MAX_KEEP_ALIVE Page 235 ANNEX_G_STUN_MIN_KEEP_ALIVE Page 236 UDP_CON_REQ_ADDR_NOTIFY_LIMIT Page 236 DEVICE_PROVISIONING_CODE Page 236 TR069_REGISTERING Page 237 TR069_REGISTERED Page 237 XML Settings Parameter Name Ref. Page 237 XMLAPP_ENABLE Page 237 XMLAPP_USERID Page 237...
Page 184 5.1 Configuration File Parameter List Parameter Name Ref. Page 241 XSI_SERVER_PORT Page 241 XSI_USERID_n Page 241 XSI_PASSWORD_n Page 242 XSI_PHONEBOOK_ENABLE_n XSI_PHONEBOOK_CYCLIC_INTVL Page 242 XSI_PHONEBOOK_RESYNC_DURATION Page 242 Page 242 XSI_PHONEBOOK_TYPE_n Page 243 XSI_CALLLOG_ENABLE_n Page 243 XSI_SIP_CREDENTIALS_ENABLE Page 243 BSD_GROUP_ENABLE_n Page 244 BSD_GROUPCOM_ENABLE_n Page 244 BSD_ENTERPRISE_ENABLE_n...
Page 185 5.1 Configuration File Parameter List LDAP Settings Parameter Name Ref. Page 249 LDAP_ENABLE Page 249 LDAP_DNSSRV_ENABLE Page 249 LDAP_SERVER Page 249 LDAP_SERVER_PORT Page 250 LDAP_MAXRECORD LDAP_NUMB_SEARCH_TIMER Page 250 LDAP_NAME_SEARCH_TIMER Page 250 Page 250 LDAP_USERID Page 250 LDAP_PASSWORD Page 251 LDAP_NAME_FILTER Page 251 LDAP_NUMB_FILTER Page 251...
Page 186 5.1 Configuration File Parameter List Parameter Name Ref. SNMP_ENCRYPT_PASSWORD Page 255 Multicast Paging Settings Parameter Name Ref. Page 255 MPAGE_ADDRm Page 256 MPAGE_IPV6_ADDRm Page 256 MPAGE_PORTm Page 256 MPAGE_PRIORITYm Page 256 MPAGE_LABELm Page 257 MPAGE_SEND_ENABLEm MPAGE_CODEC Page 257 MPAGE_SP_VOL_EMERGENCY Page 257 MPAGE_SP_VOL_PRIORITY Page 257 MPAGE_DND_ENABLE_HSy...
Page 187 5.1 Configuration File Parameter List Parameter Name Ref. Page 262 DST_START_TIME Page 262 DST_STOP_MONTH Page 263 DST_STOP_ORDINAL_DAY Page 263 DST_STOP_DAY_OF_WEEK Page 263 DST_STOP_TIME Network Phonebook (Common) Parameter Name Ref. ONLY_NPB_ENABLE Page 264 NETWORK_SEARCH_ENABLE Page 264 NW_PHONEBOOK_ADVANCED_SERACH Page 264 Language Settings Parameter Name Ref.
Page 188 5.1 Configuration File Parameter List Parameter Name Ref. Page 268 PORT_PUNCH_INTVL Page 268 RTP_PORT_PUNCH_INTVL EXTERNAL_RTP_PORTx Page 269 SIP Settings Parameter Name Ref. Page 269 SIP_USER_AGENT Page 269 PHONE_NUMBER_n Page 270 SIP_URI_n Page 270 SIP_RGSTR_ADDR_n Page 270 SIP_RGSTR_PORT_n Page 271 SIP_PRXY_ADDR_n Page 271 SIP_PRXY_PORT_n Page 271...
Page 189 5.1 Configuration File Parameter List Parameter Name Ref. Page 277 SIP_TIMER_T1_n Page 277 SIP_TIMER_T2_n SIP_TIMER_T4_n Page 278 SIP_TIMER_B_n Page 278 SIP_TIMER_D_n Page 278 SIP_TIMER_F_n Page 278 SIP_TIMER_H_n Page 279 SIP_TIMER_J_n Page 279 Page 279 SIP_100REL_ENABLE_n SIP_18X_RTX_INTVL_n Page 280 SIP_SUBS_EXPIRE_n Page 280 SUB_INTERVAL_RATE_n Page 280 SUB_RTX_INTVL_n...
Page 190 5.1 Configuration File Parameter List Parameter Name Ref. SIP_ADD_DIVERSION_n Page 287 TRANSFER_RECALL_TIM Page 287 SIGNAL_COMPRESSION_n Page 287 MAX_BREADTH_n Page 288 MUTIPART_BOUNDARY_DELIMITTER_n Page 288 RINGTONE_183_180_ENABLE_n Page 288 SIP_403_REG_SUB_RTX_n Page 288 SIP_FORK_MODE_n Page 289 AKA_AUTHENTICATION_ENABLE_n Page 289 Page 289 RFC2543_HOLD_ENABLE_n SIP_HOLD_ATTRIBUTE_n Page 290 SDP_USER_ID_n Page 290 Page 290...
Page 191 5.1 Configuration File Parameter List Parameter Name Ref. ESCAPECODE_CONVERSION_RFC3986 Page 296 SIP-TLS Settings Parameter Name Ref. Page 296 SIP_TRANSPORT_n Page 297 SIP_TLS_MODE_n SIP_TLS_RECONNECT_n Page 297 Page 297 SIP_TLS_SRV_PREFIX_n SIP_TLS_VERIFY_n Page 298 SIP_TLS_ROOT_CERT_PATH Page 298 SIP_TLS_CLIENT_CERT_PATH Page 298 SIP_TLS_PKEY_PATH Page 298 SIP_TLS_RANDOM_PORT Page 299 CODEC Settings...
Page 192 5.1 Configuration File Parameter List RTP/RTCP/RTCP-XR Settings Parameter Name Ref. Page 302 DSCP_RTP_n Page 303 DSCP_RTCP_n MAX_DELAY_n Page 303 MIN_DELAY_n Page 303 NOM_DELAY_n Page 304 Page 304 RTP_PORT_MIN Page 304 RTP_PORT_MAX Page 304 RTP_PTIME Page 305 RTCP_ENABLE_n Page 305 RTCP_INTVL_n RTCP_SEND_BY_SDP_n Page 305 RTP_CLOSE_ENABLE_n...
Page 193 5.1 Configuration File Parameter List Parameter Name Ref. Page 310 ALERT_REPORT_DELAY_CRITICAL Page 310 ALERT_REPORT_DELAY_WARNING VQREPORT_SIGNAL_COMPRESSION Page 310 VQREPORT_SEND_OPT_CODEC_ENABLE Page 310 VQREPORT_SEND_OPT_NW_CHANGE Page 311 uaCSTA Settings Parameter Name Ref. UACSTA_ENABLE_n Page 311 UACSTA_UNIQUE_ID Page 311 CSTA_PORT Page 312 CSTA_PRXY_ADDR Page 312 CSTA_PRXY_PORT Page 312 CSTA_RGSTR_ADDR...
Page 194 5.1 Configuration File Parameter List Parameter Name Ref. DISPLAY_NAME_REPLACE Page 316 NUMBER_MATCHING_LOWER_DIGIT Page 316 NUMBER_MATCHING_UPPER_DIGIT Page 317 INCOMING_BUSY_ENABLE Page 317 FLASH_RECALL_TERMINATE Page 317 FLASHHOOK_CONTENT_TYPE Page 317 Page 317 NUM_PLAN_PARKING Page 318 CALLPARK_KEY_ENABLE Page 318 NUM_PLAN_PARK_RETRIEVING Page 318 IDLE_SOFT_KEY_PARK_RETRIEVING HOLD_RECALL_TIM Page 319 HOLD_TRANSFER_OPERATION Page 319 ONHOOK_TRANSFER_ENABLE...
Page 195 5.1 Configuration File Parameter List Parameter Name Ref. RINGER_VOL_OPERATION_ENABLE Page 324 CNIP_CALL_PAI_ENABLE Page 324 Tone Settings Parameter Name Ref. OUTSIDE_DIAL_TONE_FRQ Page 325 OUTSIDE_DIAL_TONE_GAIN Page 325 OUTSIDE_DIAL_TONE_RPT Page 325 OUTSIDE_DIAL_TONE_TIMING Page 325 REORDER_TONE_ENABLE Page 325 TONE_LEN_DISCONNECT Page 326 Page 326 DIAL_TONE1_FRQ DIAL_TONE1_GAIN Page 326 DIAL_TONE1_RPT...
Page 196 5.1 Configuration File Parameter List Parameter Name Ref. RINGBACK_TONE_GAIN Page 331 RINGBACK_TONE_RPT Page 331 Page 332 RINGBACK_TONE_TIMING HOLD_TONE_FRQ Page 332 HOLD_TONE_GAIN Page 332 BELL_CORE_PATTERN1_TIMING Page 332 BELL_CORE_PATTERN2_TIMING Page 333 BELL_CORE_PATTERN3_TIMING Page 333 BELL_CORE_PATTERN4_TIMING Page 333 BELL_CORE_PATTERN5_TIMING Page 334 Page 334 KEY_PAD_TONE_HSy Call Control Settings Parameter Name...
Page 197 5.1 Configuration File Parameter List Parameter Name Ref. Page 340 NATIONAL_ACCESS_CODE Page 340 IDLE_SOFT_KEY_A Page 341 IDLE_SOFT_KEY_B Page 341 IDLE_SOFT_KEY_C Page 342 ADMIN_ABILITY_ENABLE_HSy Page 342 HANDSET_NAME_HSy Page 342 EMERGENCY_CALLx Page 343 CALL_REJECTIONx_n Page 343 CLICKTO_ENABLE_n Page 343 CALLPARK_NOTIFICATION_ENABLE_n Page 344 SHARED_CALL_ENABLE_n SHARED_STOP_LINE_SEIZE Page 344...
Page 198 5.1 Configuration File Parameter List Parameter Name Ref. TALKING_SOFT_KEY_C Page 351 DISPLAY_VM_WITH_NUMBER Page 352 FWD_DND_MISSEDLOG_ENABLE Page 352 RETRIVE_TRANS_HOLD_OPER_CHANGE Page 353 REMOVE_PREFIX_ENABLE Page 353 Logging Settings Parameter Name Ref. SYSLOG_ADDR Page 353 SYSLOG_PORT Page 353 LOGGING_LEVEL_DNS Page 354 LOGGING_LEVEL_NW1 Page 354 LOGGING_LEVEL_FILE Page 354 LOGGING_LEVEL_SIP...
Page 199: General Information On The Configuration Files
Certain parameter names end with "_n". This signifies that these settings can be made to each line individually. The number of lines available varies depending on the phone being used, as follows: – KX-TGP600: 1–8 Value Format Each parameter value is categorized into Integer, Boolean, or String. Some parameters require a composite form such as "Comma-separated Integer"...
Page 200: Characters Available For String Values
5.2.2 Characters Available for String Values 5.2.2 Characters Available for String Values Unless noted otherwise in "Value Range", only ASCII characters can be used for parameter values. Unicode characters can also be used in some parameter values. Available ASCII characters are shown on a white background in the following table: Administrator Guide Document Version 2017-07...
Page 201: System Settings
5.3.1 System Settings 5.3 System Settings 5.3.1 System Settings MULTI_NUMBER_ENABLE Value Format BOOLEAN Description Specifies whether to enable or disable the multi number mode. • Value Range Y: Enable multi number mode. • N: Disable (1 to 1 mode) Default Value WIDEBAND_AUDIO_ENABLE Value Format BOOLEAN...
Page 202: Sip_Trunk_Mode_Enable
5.3.1 System Settings SIP_TRUNK_MODE_ENABLE Value Format BOOLEAN Description Specifies whether you are using a SIP trunk service or not. • Value Range Y: Enable the usage of a SIP trunk service • N: Disable Default Value Web User Interface Reference Enable SIP Trunk Service (Page 111) SIP_NON_REGISTER_ENABLE Value Format...
Page 203: Block_Anony_Menu_Enable
5.3.1 System Settings Description Specifies whether the "FWD/DND" setting is displayed in MENU. Value Range • Y: Displayed • N: Not displayed Default Value BLOCK_ANONY_MENU_ENABLE Value Format BOOLEAN Description Specifies whether the "Block Anonymous" setting is displayed in MENU. Value Range •...
Page 204: Call_Settings_Menu_Enable
5.3.1 System Settings CALL_SETTINGS_MENU_ENABLE Value Format BOOLEAN Description Specifies whether the "Call Settings" setting is displayed in MENU. • Value Range Y: Displayed • N: Not displayed Default Value DISCLOSE_FUNCTION_ENABLE Value Format BOOLEAN Description Specifies whether to disclose functions and some keys for HOTEL telephones.
Page 205: Private_Hold_Enable
5.3.1 System Settings Description Specifies whether to enable or disable the Off-hook Monitor function. (KX-TPA65 only) Value Range • Y: Enable Off-hook Monitor • N: Disable Default Value PRIVATE_HOLD_ENABLE Value Format BOOLEAN Description Specifies whether to enable or disable "Private Hold". Value Range •...
Page 206: Pcap_Remote_Pass
5.3.1 System Settings Value Range 1–16 characters Default Value Empty string PCAP_REMOTE_PASS Value Format STRING Description Specifies the password of the IP phone whose packets will be captured using the Wireshark utility (PCAP Remote). Value Range 0, 6–64 characters Default Value Empty string PCAP_REMOTE_PORT Value Format...
Page 207: Notification_Menu_Enable
5.3.1 System Settings Description Specifies whether to enable or disable the range alarm. Value Range • Y: Enable the range alarm • N: Disable Default Value NOTIFICATION_MENU_ENABLE Value Format BOOLEAN Description Specifies whether to display the notification settings under MENU. Value Range •...
Page 208: Notify_Missedcall_Led_Enable_Hsy
5.3.1 System Settings Description Specifies whether to display "Voice MSG" on the screen in standby mode. Note • This setting is available only when "NOTIFICATION_MENU_ENABLE" is set to "Y". Value Range • Y: Enable displaying "Voice MSG" in standby mode. •...
Page 209: Notify_Voicemail_Alarm_Enable_Hsy
5.3.1 System Settings NOTIFY_VOICEMAIL_ALARM_ENABLE_HSy Parameter Name Example NOTIFY_VOICEMAIL_ALARM_ENABLE_HS1, NOTIFY_VOICEMAIL_ALARM_ENABLE_HS2, …, NOTIFY_VOICEMAIL_ALARM_ENABLE_HS8 Value Format BOOLEAN Description Specifies whether an alarm sound is used to indicate a new voice message. Note • This setting is available only when "NOTIFICATION_MENU_ENABLE" is set to "Y". •...
Page 210: Codec_Vad_Cng_Enable
5.3.2 Handset Registration Settings CODEC_VAD_CNG_ENABLE Value Format BOOLEAN Description Specifies whether to enable the VAD and CNG functions. (VAD: Voice Activity Detector, CNG: Comfort Noise Generator) Value Range • Y: Enable the VAD and CNG functions • N: Disable Default Value ERROR_AUTO_REBOOT_TIME Value Format INTEGER...
Page 211: Ipei_Autoregmode_Enable
5.3.2 Handset Registration Settings IPEI_AUTOREGMODE_ENABLE Value Format BOOLEAN Description Specifies whether to perform the HS registration mode automatically after IPEI was set. Value Range • Y: Enable automatically registration • N: Disable Default Value IPEI_RESTRICTION_ENABLE Value Format BOOLEAN Description Specifies whether to perform the HS registration limit after IPEI was set. •...
Page 212: Basic Network Settings
5.3.3 Basic Network Settings 5.3.3 Basic Network Settings IP_ADDR_MODE Value Format INTEGER Description Specifies the IP addressing mode. Value Range • 0: IPv4 • 1: IPv6 • 2: IPv4&IPv6 Default Value Web User Interface Reference IP Addressing Mode (Page 84) CONNECTION_TYPE Value Format INTEGER...
Page 213: Static_Gateway
5.3.3 Basic Network Settings Description Specifies the subnet mask for IPv4. Note • This setting is available only when "CONNECTION_TYPE" is set to "0". • When you specify this parameter, you must specify "STATIC_IP_ADDRESS" together in a configuration file. Value Range Max.
Page 214: User_Dns2_Addr
5.3.3 Basic Network Settings USER_DNS2_ADDR Value Format IPADDR Description Specifies the IP address of the secondary DNS server for IPv4. Note • This setting is available only when "CONNECTION_TYPE" is set to "0". Value Range Max. 15 characters n.n.n.n [n=0–255] Default Value Empty string Web User Interface Reference...
Page 215: Connection_Type_Ipv6
5.3.3 Basic Network Settings Description Specifies the vendor class to option60 in DHCPv4 or option16 in DHCPv6. Value Range Max. 64 characters Default Value Panasonic CONNECTION_TYPE_IPV6 Value Format INTEGER Description Specifies the IP address setting mode for IPv6. • Value Range 0: Static •...
Page 216: User_Dns1_Addr_Ipv6
5.3.4 Ethernet Port Settings Default Value Empty string Web User Interface Reference Default Gateway (Page 88) USER_DNS1_ADDR_IPV6 Value Format IPADDR-V6 Description Specifies the IP address of primary DNS server for IPv6. Value Range Max. 39 characters n:n:n:n:n:n:n:n [n=0-FFFF, abbreviation available] Default Value Empty string Web User Interface Reference...
Page 217: Vlan_Enable
5.3.4 Ethernet Port Settings Value Range • 1: Auto Negotiation • 2: 100Mbps/Full Duplex • 3: 100Mbps/Half Duplex • 4: 10Mbps/Full Duplex • 5: 10Mbps/Half Duplex Default Value Web User Interface Reference LAN Port (Page 89) VLAN_ENABLE Value Format BOOLEAN Description Specifies whether to use the VLAN feature to perform VoIP communication securely.
Page 218: Lldp_Enable
5.3.4 Ethernet Port Settings Web User Interface Reference Priority (Page 91) LLDP_ENABLE Value Format BOOLEAN Description Specifies whether to enable or disable the LLDP-MED feature. Note • You should specify "Y" for only one of "LLDP_ENABLE", or "VLAN_ENABLE". If "Y" is specified for two or more of the parameters above, the settings are prioritized as follows: VLAN_ENABLE >LLDP_ENABLE.
Page 219: Pre-Provisioning Settings
5.3.5 Pre-Provisioning Settings Description Specifies the interval, in seconds, between sending CDP frames. Value Range 1–3600 Default Value Web User Interface Reference Packet Interval (Page 90) 5.3.5 Pre-Provisioning Settings SIPPNP_PROV_ENABLE Value Format BOOLEAN Description Specifies whether to enable or disable the SIP PNP provisioning. Value Range •...
Page 220: Option160_Prov_Enable
5.3.6 Provisioning Settings OPTION160_PROV_ENABLE Value Format BOOLEAN Description Specifies whether to enable or disable the DHCP option160 provisioning. Value Range • Y: Enable DHCP option160 provisioning • N: Disable Default Value DHCPV6_OPTION17_PROV_ENABLE Value Format BOOLEAN Description Specifies whether to enable or disable DHCPv6 option17 provisioning. •...
Page 221: Cfg_Master_File_Path
5.3.6 Provisioning Settings Value Range Max. 384 characters Note • If this URL ends with "/" (slash), "{MODEL}.cfg" is automatically added at the end of the URL. For example, CFG_PRODUCT_FILE_PATH="http://host/dir/" becomes CFG_PRODUCT_FILE_PATH="http://host/ dir/{MODEL}.cfg". • For details about the formats, see 2.1.3 Server Address Formats.
Page 222: Cfg_Cyclic_Intvl
5.3.6 Provisioning Settings CFG_CYCLIC_INTVL Value Format INTEGER Description Specifies the interval, in minutes, between periodic checks for updates of the configuration files. Value Range 1–40320 Default Value 10080 Web User Interface Reference Resync Interval (Page 171) CFG_RESYNC_TIME Value Format STRING Description Specifies the time (hour:minute) that the unit checks for updates of configuration files.
Page 223: Cfg_Resync_Action
5.3.6 Provisioning Settings Value Range Max. 15 characters Default Value check-sync Web User Interface Reference Header Value for Resync Event (Page 172) CFG_RESYNC_ACTION Value Format INTEGER Description Specifies the value of the action after received resync NOTIFY. • Value Range 0: Provisioning •...
Page 224: Cfg_File_Key_Length
5.3.6 Provisioning Settings Default Value Empty string CFG_FILE_KEY_LENGTH Value Format INTEGER Description Specifies the key lengths in bits used to decrypt configuration files. Value Range 128,192, 256 Default Value CFG_ROOT_CERTIFICATE_PATH Value Format STRING Description Specifies the URI where the root certificate is stored. Note •...
Page 225: Http_Ssl_Verify
5.3.6 Provisioning Settings Value Range Max. 384 characters Note • For details about the formats, see 2.1.3 Server Address Formats. Default Value Empty string HTTP_SSL_VERIFY Value Format INTEGER Description Specifies whether to enable the verification of the root certificate. Value Range •...
Page 226: Firmware Update Settings
5.3.7 Firmware Update Settings Value Range • Y: Enable • N: Disable Default Value 5.3.7 Firmware Update Settings FIRM_UPGRADE_ENABLE Value Format BOOLEAN Description Specifies whether to perform firmware updates when the unit detects a newer version of firmware. Note • Local firmware updates from the Web user interface (®...
Page 227: Fwdl_Random_Duration
5.3.8 HTTP Settings Description Specifies the firmware version of the unit. Value Range Max. 32 characters Default Value Empty string FWDL_RANDOM_DURATION Value Format INTEGER Description Specifies, in minutes, a time range during which connected units can access the server. Units will download the firmware file at a random time within this range.
Page 228: Http_Auth_Id
5.3.8 HTTP Settings Value Range Max. 64 characters Note • If "{mac}" is included in this parameter, it will be replaced with the unit’s MAC address in lower-case. • If "{MAC}" is included in this parameter, it will be replaced with the unit’s MAC address in upper-case.
Page 229: Http_Proxy_Addr
5.3.9 HTTPD/WEB Settings HTTP_PROXY_ADDR Value Format STRING Description Specifies the IP address or FQDN of the proxy server. Value Range Max. 256 characters Default Value Empty string Web User Interface Reference Proxy Server Address (Page 94) HTTP_PROXY_PORT Value Format INTEGER Description Specifies the port of the proxy server.
Page 230: Httpd_Portopen_Auto
5.3.9 HTTPD/WEB Settings Default Value HTTPD_PORTOPEN_AUTO Value Format BOOLEAN Description Specifies whether the unit’s Web port is always open. Value Range • Y (Web port is always open) • N (Web port is closed [can be opened temporarily through phone user interface programming]) Notice •...
Page 231: Admin_Id
5.3.9 HTTPD/WEB Settings Description Specifies the password to use to authenticate the User account when logging in to the Web user interface. Value Range 6–64 characters (except !, ", #, $, %, &, ', (, ), @, *, +, ,, /, :, ;, <, =, >, ?, [, ], ^, `, {, |, }, ~, \ and space) Note •...
Page 232: Tr-069 Settings
5.3.10 TR-069 Settings 5.3.10 TR-069 Settings ACS_URL Value Format STRING Description Specifies the URL of the Auto-Configuration Server for using TR-069. Note • This parameter must be in the form of a valid HTTP or HTTPS URL, as defined in RFC 3986. Value Range Max.
Page 233: Periodic_Inform_Interval
5.3.10 TR-069 Settings PERIODIC_INFORM_INTERVAL Value Format INTEGER Description Specifies the interval length, in seconds, when the CPE must attempt to connect with the ACS and call the Inform method. Note • This setting is available only when "PERIODIC_INFORM_ENABLE" is set to "Y". Value Range 30–2419200 Default Value...
Page 234: Con_Req_Pass
5.3.10 TR-069 Settings Default Value Empty string CON_REQ_PASS Value Format STRING Description Specifies the password used to authenticate an ACS making a Connection Request to the CPE. Note • When the "CON_REQ_USER_ID" parameter is specified, an empty string for this parameter is not allowed. Value Range Max.
Page 235: Annex_G_Stun_Serv_Port
5.3.10 TR-069 Settings ANNEX_G_STUN_SERV_PORT Value Format INTEGER Description Specifies the port number of the STUN server for the CPE to send Binding Requests. Note • This setting is available only when "ANNEX_G_STUN_ENABLE" is set to "Y". Value Range 1–65535 Default Value 3478 ANNEX_G_STUN_USER_ID Value Format...
Page 236: Annex_G_Stun_Min_Keep_Alive
5.3.10 TR-069 Settings Description Specifies the maximum period, in seconds, that STUN Binding Requests must be sent by the CPE for the purpose of maintaining the binding in the Gateway. This applies specifically to Binding Requests sent from the UDP Connection Request address and port. Note •...
Page 237: Tr069_Registering
5.3.11 XML Settings TR069_REGISTERING Value Format STRING Description Specifies the line status that TR-069 outputs while the line is being registered. Value Range Max. 16 characters Default Value Error TR069_REGISTERED Value Format STRING Description Specifies the line status that TR-069 outputs when the line has been registered.
Page 238: Xmlapp_Ldap_Url
5.3.11 XML Settings Description Specifies the authentication password used to access the XML application server. Value Range Max. 128 characters Default Value Empty string Web User Interface Reference Password (Page 107) XMLAPP_LDAP_URL Value Format STRING Description Specifies the URL that is accessed when the phonebook is accessed, to check for XML data.
Page 239: Xmlapp_Ldap_Maxrecord
5.3.11 XML Settings XMLAPP_LDAP_MAXRECORD Value Format INTEGER Description Specifies the maximum number of search results to be returned by the LDAP server. Value Range 20–500 Default Value Web User Interface Reference Max Hits (Page 108) XML_HTTPD_PORT Value Format INTEGER Description Specifies the local HTTP port for XML application.
Page 240: Xmlapp_Select_Hs_Pb
5.3.12 XSI Settings Value Range 0, 1–40320 Default Value XMLAPP_SELECT_HS_PB Value Format BOOLEAN Description Specifies whether to download an individual XML phonebook for each handset. Value Range • Y: Enable individual phonebooks • N: Disable Default Value XMLAPP_RCV_IP_ADDRESSx Value Format IPADDR Description x=1–20...
Page 241: Xsi_Server_Type
5.3.12 XSI Settings Value Range Max. 256 characters Default Value Empty string Web User Interface Reference Server Address (Page 101) XSI_SERVER_TYPE Value Format STRING Description Specifies the type of the Xsi server. • Value Range HTTP • HTTPS Default Value HTTP Web User Interface Reference Protocol (Page 101)
Page 242: Xsi_Phonebook_Enable_N
5.3.12 XSI Settings Default Value Empty string Web User Interface Reference Password (Line 1–8) (Page 102) XSI_PHONEBOOK_ENABLE_n Parameter Name Example XSI_PHONEBOOK_ENABLE_1, XSI_PHONEBOOK_ENABLE_2, …, XSI_PHONEBOOK_ENABLE_8 Value Format BOOLEAN Description Specifies whether to enable or disable the Xsi phonebook service. Value Range •...
Page 243: Xsi_Calllog_Enable_N
5.3.12 XSI Settings Value Range 1: Group 2: GroupCommon 3: Enterprise 4: EnterpriseCommon 5: Personal Default Value Web User Interface Reference Phonebook Type (Line 1–8) (Page 102) XSI_CALLLOG_ENABLE_n Parameter Name Example XSI_CALLLOG_ENABLE_1, XSI_CALLLOG_ENABLE_2, …, XSI_CALLLOG_ENABLE_8 Value Format BOOLEAN Description Specifies whether to enable or disable the Xsi call log service. Value Range •...
Page 244: Bsd_Groupcom_Enable_N
5.3.12 XSI Settings BSD_GROUPCOM_ENABLE_n Parameter Name Example BSD_GROUPCOM_ENABLE_1, BSD_GROUPCOM_ENABLE_2, …, BSD_GROUPCOM_ENABLE_8 Value Format BOOLEAN Description Specifies whether to enable or disable the "GroupCommon" type for Xsi phonebooks. • Value Range Y: Enable • N: Disable Default Value Web User Interface Reference GroupCommon (Page 103) BSD_ENTERPRISE_ENABLE_n Parameter Name Example...
Page 245: Bsd_Personal_Enable_N
5.3.13 XMPP (UC-ONE) Settings BSD_PERSONAL_ENABLE_n Parameter Name Example BSD_PERSONAL_ENABLE_1, BSD_PERSONAL_ENABLE_2, …, BSD_PERSONAL_ENABLE_8 Value Format BOOLEAN Description Specifies whether to enable or disable the "Personal" type for Xsi phonebooks. • Value Range Y: Enable • N: Disable Default Value Web User Interface Reference Personal (Page 104) BSD_MULTI_TYPE_ENABLE Value Format...
Page 246: Uc_Password_Hsy
5.3.13 XMPP (UC-ONE) Settings Web User Interface Reference Handset 1–8 (User ID) (Page 106) UC_PASSWORD_HSy Parameter Name Example UC_PASSWORD_HS1, UC_PASSWORD_HS2, …, UC_PASSWORD_HS8 Value Format STRING Description Specifies the authentication password required to access the UC server. Value Range Max. 128 characters Default Value Empty string Web User Interface Reference...
Page 247: Xmpp_Root_Cert_Path
5.3.13 XMPP (UC-ONE) Settings XMPP_ROOT_CERT_PATH Value Format STRING Description Specifies the URI where the root certificate is stored. Value Range Max. 384 characters Note • For details about the formats, see 2.1.3 Server Address Formats. Default Value Empty string XMPP_CLIENT_CERT_PATH Value Format STRING Description...
Page 248: Uc_Tcp_Srv_Prefix
5.3.13 XMPP (UC-ONE) Settings UC_TCP_SRV_PREFIX Value Format STRING Description Specifies a prefix to add to the domain name when performing a DNS SRV lookup using TCP. Value Range Max. 32 characters Default Value _xmpp-client._tcp. UC_USERID_CASE_SENSITIVE Value Format BOOLEAN Description Specifies whether the authentication ID is case-sensitive when accessing the UC server.
Page 249: Ldap Settings
5.3.14 LDAP Settings 5.3.14 LDAP Settings LDAP_ENABLE Value Format BOOLEAN Description Specifies whether to enable or disable the LDAP service. Value Range • Y: Enable LDAP service • N: Disable Default Value Web User Interface Reference Enable LDAP (Page 97) LDAP_DNSSRV_ENABLE Value Format BOOLEAN...
Page 250: Ldap_Maxrecord
5.3.14 LDAP Settings Web User Interface Reference Port (Page 98) LDAP_MAXRECORD Value Format INTEGER Description Specifies the maximum number of search results to be returned by the LDAP server. Value Range 20–500 Default Value Web User Interface Reference Max Hits (Page 98) LDAP_NUMB_SEARCH_TIMER Value Format INTEGER...
Page 251: Ldap_Name_Filter
5.3.14 LDAP Settings Description Specifies the authentication password required to access the LDAP server. Value Range Max. 128 characters Default Value Empty string Web User Interface Reference Password (Page 98) LDAP_NAME_FILTER Value Format STRING Description Specifies the name filter which is the search criteria for name look up. Value Range Max.
Page 252: Ldap_Basedn
5.3.14 LDAP Settings Default Value telephoneNumber,mobile,homePhone Web User Interface Reference Number Attributes (Page 99) LDAP_BASEDN Value Format STRING Description Specifies the entry information on the screen. Value Range Max. 256 characters Default Value Empty string Web User Interface Reference Distinguished Name(Base DN) (Page 99) LDAP_SSL_VERIFY Value Format INTEGER...
Page 253: Ldap_Pkey_Path
5.3.15 SNMP Settings Default Value Empty string LDAP_PKEY_PATH Value Format STRING Description Specifies the URI where the private key is stored. Value Range Max. 384 characters Note • For details about the formats, see 2.1.3 Server Address Formats. Default Value Empty string LDAP_DISPLAY_FORMAT Value Format...
Page 254: Snmp_Trust_Port
5.3.15 SNMP Settings Default Value Empty string SNMP_TRUST_PORT Value Format INTEGER Description Specifies the port of the trusted SNMP server. Value Range 1–65535 Default Value SNMP_RO_COMMUNITY_STRING Value Format STRING Description Specifies the community name for read-only. Value Range Max. 32 characters Default Value Empty string SNMP_SECURITY_TYPE...
Page 255: Snmp_Auth_Password
5.3.16 Multicast Paging Settings Value Range 0: MD5 1: SHA Default Value SNMP_AUTH_PASSWORD Value Format STRING Description Specifies the authentication password of SNMPv3. Value Range 0, 8–64 characters Default Value Empty string SNMP_ENCRYPT_TYPE Value Format INTEGER Description Specifies the encryption type of SNMPv3. Value Range 0: DES 1: AES...
Page 256: Mpage_Ipv6_Addrm
5.3.16 Multicast Paging Settings MPAGE_IPV6_ADDRm Parameter Name Example MPAGE_IPV6_ADDR1, MPAGE_IPV6_ADDR2, …, MPAGE_IPV6_ADDR5 Value Format IPADDR-V6 Description Specifies the IPv6 address for multi-cast paging for each channel group. (m=1–5, the channel group) {Priority: 5 > 4 > 3, 2, 1 (depending on the configuration)} Value Range FF00::/8...
Page 257: Mpage_Send_Enablem
5.3.16 Multicast Paging Settings Description Specifies a label for each channel group. (m=1–5, the channel group) Value Range Max. 24 characters Default Value Empty string Web User Interface Reference Label (Group 1–5) (Page 96) MPAGE_SEND_ENABLEm Parameter Name Example MPAGE_SEND_ENABLE1, MPAGE_SEND_ENABLE2, …, MPAGE_SEND_ENABLE5 Value Format BOOLEAN...
Page 258: Mpage_Dnd_Enable_Hsy
5.3.17 NTP Settings Description Specifies the speaker level for new received multi-cast paging (priority channel). Value Range 0–6 0: No control Default Value MPAGE_DND_ENABLE_HSy Parameter Name Example MPAGE_DND_ENABLE_HS1, MPAGE_DND_ENABLE_HS2, …, MPAGE_DND_ENABLE_HS8 Value Format BOOLEAN Description Specifies the DND setting (on/off) for multi-cast paging. Value Range •...
Page 259: Time_Query_Intvl
5.3.18 Time Settings Description Specifies the interval, in seconds, to resynchronize after having detected no reply from the NTP server. Value Range 10–86400 Default Value TIME_QUERY_INTVL Value Format INTEGER Description Specifies the interval, in seconds, between synchronizations with the NTP server. Value Range 10–86400 Default Value...
Page 260: Dst_Enable
5.3.18 Time Settings Description Specifies the offset of local standard time from UTC (GMT), in minutes. Value Range -720–780 Note • Only the following values are available: -720 (GMT -12:00), -660 (GMT -11:00), -600 (GMT -10:00), -540 (GMT -09:00), -480 (GMT -08:00), -420 (GMT -07:00), -360 (GMT -06:00), -300 (GMT -05:00), -240 (GMT -04:00), -210 (GMT -03:30), -180 (GMT -03:00), -120 (GMT -02:00), -60 (GMT -01:00), 0 (GMT), 60 (GMT +01:00), 120 (GMT +02:00),...
Page 261: Dst_Start_Month
5.3.18 Time Settings Value Range 0–720 Note • This parameter is usually set to "60". Default Value Web User Interface Reference DST Offset (Summer Time Offset) (Page 119) DST_START_MONTH Value Format INTEGER Description Specifies the month in which DST (Summer Time) starts. Note •...
Page 262: Dst_Start_Time
5.3.18 Time Settings Description Specifies the day of the week on which DST (Summer Time) starts. Note • This parameter is disabled when the "LOCAL_TIME_ZONE_POSIX" parameter is specified. Value Range 0–6 – 0: Sunday – 1: Monday – 2: Tuesday –...
Page 263: Dst_Stop_Ordinal_Day
5.3.18 Time Settings DST_STOP_ORDINAL_DAY Value Format INTEGER Description Specifies the number of the week on which DST (Summer Time) ends. The actual end day is specified in "DST_STOP_DAY_OF_WEEK". For example, to specify the second Sunday, specify "2" in this parameter, and "0"...
Page 264: Network Phonebook (Common)
5.3.19 Network Phonebook (Common) Description Specifies the end time of DST (Summer Time) in minutes after 12:00 Note • This parameter is disabled when the "LOCAL_TIME_ZONE_POSIX" parameter is specified. Value Range 0–1439 Default Value Web User Interface Reference Time (Page 122) 5.3.19 Network Phonebook (Common) ONLY_NPB_ENABLE Value Format...
Page 265: Language Settings
5.3.20 Language Settings 5.3.20 Language Settings AVAILABLE_LANGUAGE_HS Value Format STRING Description Specifies the selectable language on the handset. Value Range en, es, fr, de, it, da, nl, sv, fi, el, hu, pt, pl, sk, cs, sh, ru, uk, tr, no, ro, ct, kk, me ®...
Page 266: Available_Language_Web
5.3.20 Language Settings Description Specifies the version of the language file. x=1–10 Value Range "00.000.000"–"15.999.999" Default Value Empty string AVAILABLE_LANGUAGE_WEB Value Format STRING Description Specifies the selectable language on the Web. en, es, fr, de, it, nl, el, hu, pt, pl, sk, cs, sh, ru, uk, tr, ro, ct, kk, me ® Value Range see 4.4.2.1 Selectable Language Web User Interface Reference...
Page 267: Nat Settings
5.3.21 NAT Settings Value Format STRING Description Specifies the version of the language file. x=1–10 Value Range "00.000.000"–"15.999.999" Default Value Empty string 5.3.21 NAT Settings STUN_SERV_ADDR Value Format STRING Description Specifies the IP address or FQDN of the primary STUN server. Value Range Max.
Page 268: Stun_Intvl
5.3.21 NAT Settings STUN_INTVL Value Format INTEGER Description Specifies the interval of the sending binding request. Value Range 60–86400 Default Value Web User Interface Reference Binding Interval (Page 95) SIP_ADD_RPORT Value Format BOOLEAN Description Specifies whether to add the 'rport' parameter to the top Via header field value of requests generated.
Page 269: External_Rtp_Portx
• If "{sipver}" is included in this parameter, it will be replaced with the SIP software version of the unit. Default Value Panasonic-{MODEL}/{fwver} ({mac}) Web User Interface Reference User Agent (Page 130) PHONE_NUMBER_n Parameter Name Example PHONE_NUMBER_1, PHONE_NUMBER_2, …, PHONE_NUMBER_8...
Page 270: Sip_Uri_N
5.3.22 SIP Settings Web User Interface Reference Phone Number (Page 132) SIP_URI_n Parameter Name Example SIP_URI_1, SIP_URI_2, …, SIP_URI_8 Value Format STRING Description Specifies the unique ID used by the SIP registrar server, which consists of "sip:", a user part, the "@" symbol, and a host part, for example, "sip:user@example.com", "2405551111_1".
Page 271: Sip_Prxy_Addr_N
5.3.22 SIP Settings SIP_PRXY_ADDR_n Parameter Name Example SIP_PRXY_ADDR_1, SIP_PRXY_ADDR_2, …, SIP_PRXY_ADDR_8 Value Format STRING Description Specifies the IP address or FQDN of the SIP proxy server. Value Range Max. 256 characters Default Value Empty string Web User Interface Reference Proxy Server Address (Page 133) SIP_PRXY_PORT_n Parameter Name Example SIP_PRXY_PORT_1, SIP_PRXY_PORT_2, …, SIP_PRXY_PORT_8...
Page 272: Sip_Outproxy_Addr_N
5.3.22 SIP Settings Web User Interface Reference Presence Server Port (Page 133) SIP_OUTPROXY_ADDR_n Parameter Name Example SIP_OUTPROXY_ADDR_1, SIP_OUTPROXY_ADDR_2, …, SIP_OUTPROXY_ADDR_8 Value Format STRING Description Specifies the IP address or FQDN of the SIP outbound proxy server. Value Range Max. 256 characters Default Value Empty string Web User Interface Reference...
Page 273: Sip_Pass_N
5.3.22 SIP Settings Description Specifies the authentication ID required to access the SIP server. Value Range Max. 128 characters (except ", &, ', :, <, >, and space) Default Value Empty string Web User Interface Reference Authentication ID (Page 134) SIP_PASS_n Parameter Name Example SIP_PASS_1, SIP_PASS_2, …, SIP_PASS_8...
Page 274: Sip_Dnssrv_Ena_N
5.3.22 SIP Settings Value Range 0–63 Default Value Web User Interface Reference SIP Packet QoS (DSCP) (Page 135) SIP_DNSSRV_ENA_n Parameter Name Example SIP_DNSSRV_ENA_1, SIP_DNSSRV_ENA_2, …, SIP_DNSSRV_ENA_8 Value Format BOOLEAN Description Specifies whether to request the DNS server to translate domain names into IP addresses using the SRV record.
Page 275: Sip_Tcp_Srv_Prefix_N
5.3.22 SIP Settings SIP_TCP_SRV_PREFIX_n Parameter Name Example SIP_TCP_SRV_PREFIX_1, SIP_TCP_SRV_PREFIX_2, …, SIP_TCP_SRV_PREFIX_8 Value Format STRING Description Specifies a prefix to add to the domain name when performing a DNS SRV lookup using TCP. Note • This setting is available only when "SIP_DNSSRV_ENA_n" is set to "Y".
Page 276: Use_Del_Reg_Open_N
5.3.22 SIP Settings Value Format INTEGER Description Specifies the interval, in seconds, between transmissions of the REGISTER request when a registration results in failure (server no reply or error reply). Value Range 1–86400 Default Value USE_DEL_REG_OPEN_n Parameter Name Example USE_DEL_REG_OPEN_1, USE_DEL_REG_OPEN_2, …, USE_DEL_REG_OPEN_8 Value Format BOOLEAN...
Page 277: Sip_Session_Method_N
5.3.22 SIP Settings Web User Interface Reference Enable Session Timer (RFC 4028) (Page 138) SIP_SESSION_METHOD_n Parameter Name Example SIP_SESSION_METHOD_1, SIP_SESSION_METHOD_2, …, SIP_SESSION_METHOD_8 Value Format INTEGER Description Specifies the refreshing method of SIP sessions. Value Range 0–2 – 0: reINVITE – 1: UPDATE –...
Page 278: Sip_Timer_T4_N
5.3.22 SIP Settings Default Value Web User Interface Reference T2 Timer (Page 137) SIP_TIMER_T4_n Parameter Name Example SIP_TIMER_T4_1, SIP_TIMER_T4_2, …, SIP_TIMER_T4_8 Value Format INTEGER Description Specifies the maximum period, in seconds, that a message can remain on the network. • Value Range •...
Page 279: Sip_Timer_H_N
5.3.22 SIP Settings Description Specifies the value of SIP timer F (non-INVITE transaction timeout timer), in milliseconds. For details, refer to RFC 3261. Value Range 250–64000 Default Value 32000 SIP_TIMER_H_n Parameter Name Example SIP_TIMER_H_1, SIP_TIMER_H_2, …, SIP_TIMER_H_8 Value Format INTEGER Description Specifies the value of SIP timer H (wait time for ACK reception), in milliseconds.
Page 280: Sip_18X_Rtx_Intvl_N
5.3.22 SIP Settings Web User Interface Reference Enable 100rel (RFC 3262) (Page 138) SIP_18X_RTX_INTVL_n Parameter Name Example SIP_18X_RTX_INTVL_1, SIP_18X_RTX_INTVL_2, …, SIP_18X_RTX_INTVL_8 Value Format INTEGER Description Specifies the retransmission interval, in seconds, for "18x" responses. Value Range 0, 1–600 (0: Disable) Default Value SIP_SUBS_EXPIRE_n Parameter Name Example...
Page 281: Sip_P_Preferred_Id_N
5.3.22 SIP Settings Value Range 1–86400 Default Value SIP_P_PREFERRED_ID_n Parameter Name Example SIP_P_PREFERRED_ID_1, SIP_P_PREFERRED_ID_2, …, SIP_P_PREFERRED_ID_8 Value Format BOOLEAN Description Specifies whether to add the "P-Preferred-Identity" header to SIP messages. Value Range • Y (Add the "P-Preferred-Identity" header) • N (Do not add the "P-Preferred-Identity" header) Default Value SIP_PRIVACY_n Parameter Name Example...
Page 282: Sip_Anm_Dispname_N
5.3.22 SIP Settings SIP_ANM_DISPNAME_n Parameter Name Example SIP_ANM_DISPNAME_1, SIP_ANM_DISPNAME_2, …, SIP_ANM_DISPNAME_8 Value Format INTEGER Description Specifies the text string to set as the display name in the "From" header when making anonymous calls. • Value Range 0 (Use normal display name) •...
Page 283: Sip_Rcv_Det_Header_N
5.3.22 SIP Settings Description Specifies whether to enable SSAF for the SIP servers (registrar server, proxy server, and presence server). Value Range • Y (Enable SSAF) • N (Disable SSAF) Note • If set to "Y", the unit receives SIP messages only from the source addresses stored in the SIP servers (registrar server, proxy server, and presence server), and not from other addresses.
Page 284: Sip_Contact_On_Ack_N
5.3.22 SIP Settings Default Value SIP_CONTACT_ON_ACK_n Parameter Name Example SIP_CONTACT_ON_ACK_1, SIP_CONTACT_ON_ACK_2, …, SIP_CONTACT_ON_ACK_8 Value Format BOOLEAN Description Specifies whether to add the "Contact" header to SIP ACK message. Value Range • Y (Add the "Contact" header) • N (Do not add the "Contact" header) Default Value VOICE_MESSAGE_AVAILABLE Value Format...
Page 285: Sip_Fovr_Max_N
5.3.22 SIP Settings Description Specifies whether to perform the fail-over process when the unit detects that the SIP server is not replying to SIP message. Value Range • Y (Enable fail-over) • N (Disable fail-over) Note • If set to "Y", the unit will try to use the other SIP servers via the DNS SRV and A records.
Page 286: Sip_Add_Route_N
5.3.22 SIP Settings SIP_ADD_ROUTE_n Parameter Name Example SIP_ADD_ROUTE_1, SIP_ADD_ROUTE_2, …, SIP_ADD_ROUTE_8 Value Format BOOLEAN Description Specifies whether or not to add Route headers when setting OutBoundProxy. Note • Route headers are not added when OutBoundProxy and other server settings are the same. •...
Page 287: Add_Transport_Udp_N
5.3.22 SIP Settings Default Value ADD_TRANSPORT_UDP_n Parameter Name Example ADD_TRANSPORT_UDP_1, ADD_TRANSPORT_UDP_2, …, ADD_TRANSPORT_UDP_8 Value Format BOOLEAN Description Specifies whether to add the attribute "transport=udp" to the SIP header URI. Value Range • Y (Add Transport UDP) • N (Do not add Transport UDP) Default Value SIP_ADD_DIVERSION_n Parameter Name Example...
Page 288: Max_Breadth_N
5.3.22 SIP Settings Value Range • 0: Disable • 1: Enable (Required) • 2: Enable (Supported) Default Value MAX_BREADTH_n Parameter Name Example MAX_BREADTH_1, MAX_BREADTH_2, …, MAX_BREADTH_8 Value Format INTEGER Description Specifies the Max Breadth that is max Folk number at Proxy. Value Range 0–99 (0: Not add max-breadth header) Default Value...
Page 289: Sip_Fork_Mode_N
5.3.22 SIP Settings Value Format BOOLEAN Description Specifies whether or not to send a request when a 403 Forbidden reply is received from the server in response to an REGISTER or SUBSCRIBE. Value Range • Y (Send) • N (Do not send) Default Value SIP_FORK_MODE_n Parameter Name Example...
Page 290: Sip_Hold_Attribute_N
5.3.22 SIP Settings Value Range • Y (Enable RFC 2543 Call Hold) • N (Disable RFC 2543 Call Hold) Note • If set to "Y", the "c=0.0.0.0" syntax will be set in SDP when sending a re-INVITE message to hold the call. •...
Page 291: Hold_Sound_Path_N
5.3.22 SIP Settings HOLD_SOUND_PATH_n Parameter Name Example HOLD_SOUND_PATH_1, HOLD_SOUND_PATH_2, …, HOLD_SOUND_PATH_8 Value Format INTEGER Description Specifies whether the unit’s hold tone or the network server’s hold tone (Music on hold) is played when a party is put on hold. Note •...
Page 292: Rfc3319_Support_Join
5.3.22 SIP Settings Description Specifies whether to add "supported: history" to support History info header. Value Range • Y: Adds supported: history • N: Does not add Default Value RFC3319_SUPPORT_JOIN Value Format BOOLEAN Description Specifies whether to add "supported: join" to support join header. Value Range •...
Page 293: Sip_Replace_Enable_N
5.3.22 SIP Settings Default Value SIP_REPLACE_ENABLE_n Parameter Name Example SIP_REPLACE_ENABLE_1, SIP_REPLACE_ENABLE_2, …, SIP_REPLACE_ENABLE_8 Value Format BOOLEAN Description Specifies whether to use the "Replaces" header. • Value Range Y: Use the "Replaces" header • N: Do not use the "Replaces" header Default Value SEND_180_ALERT_ENABLE Value Format...
Page 294: Sip_Dnssrv_Ena_Naptr_N
5.3.22 SIP Settings Default Value SIP_DNSSRV_ENA_NAPTR_n Parameter Name Example SIP_DNSSRV_ENA_NAPTR_1, SIP_DNSSRV_ENA_NAPTR_2, …, SIP_DNSSRV_ENA_NAPTR_8 Value Format BOOLEAN Description Specifies whether to enable the use of the NAPTR sequence. Value Range • Y: Enable • N: Disable Default Value SIP_REFRESHER_n Parameter Name Example SIP_REFRESHER_1, SIP_REFRESHER_2, …, SIP_REFRESHER_8 Value Format INTEGER...
Page 295: Enh_Fovr_Random_Max_Time_N
5.3.22 SIP Settings Description Specifies whether the retry timer is a fixed value or a random value when the unit re-sends a REGISTER request when a failover failure has occurred. Note • This setting is available only when "ENH_FOVR_ENABLE_n" is set to "Y".
Page 296: Invite_403_Regsend_Enable_N
5.3.23 SIP-TLS Settings INVITE_403_REGSEND_ENABLE_n Parameter Name Example INVITE_403_REGSEND_ENABLE_1, INVITE_403_REGSEND_ENABLE_2, …, INVITE_403_REGSEND_ENABLE_8 Value Format BOOLEAN Description Specifies whether to enable sending a REGISTER request to the SIP server after receiving a 403 error in response to an INVITE request. Value Range •...
Page 297: Sip_Tls_Mode_N
5.3.23 SIP-TLS Settings Value Range • 0 (UDP) • 1 (TCP) • 2 (TLS) Default Value Web User Interface Reference Transport Protocol (Page 139) SIP_TLS_MODE_n Parameter Name Example SIP_TLS_MODE_1, SIP_TLS_MODE_2, …, SIP_TLS_MODE_8 Value Format INTEGER Description Select the secure SIP protocol. Value Range •...
Page 298: Sip_Tls_Verify_N
5.3.23 SIP-TLS Settings SIP_TLS_VERIFY_n Parameter Name Example SIP_TLS_VERIFY_1, SIP_TLS_VERIFY_2, …, SIP_TLS_VERIFY_8 Value Format INTEGER Description Specifies whether to enable the verification of the root certificate. • Value Range 0: No verification • 1: Simple verification • 2: Precise verification Default Value SIP_TLS_ROOT_CERT_PATH Value Format STRING...
Page 299: Sip_Tls_Random_Port
5.3.24 CODEC Settings Default Value Empty string SIP_TLS_RANDOM_PORT Value Format BOOLEAN Description Specifies whether to assign a random port (ephemeral port) number or a static port number. Note • All lines that use SIP-TLS are defined by this parameter. • UDP/TCP ports are unaffected by this parameter.
Page 300: Codec_Priorityx_N
5.3.24 CODEC Settings Description Specifies whether to enable the codec specified in the parameter list. Note • The "x" character in the parameter title should be changed to one of the following numbers, according to the codec to be changed. –...
Page 301: Codec_Payload2
5.3.25 DTMF Settings Web User Interface Reference • G.722 (Priority) (Page 144) • PCMA (Priority) (Page 144) • G.722.2 (AMR-WB) (Priority) (Page 144) • G.729A (Priority) (Page 145) • PCMU (Priority) (Page 145) CODEC_PAYLOAD2 Value Format INTEGER Description Specifies the payload type for the codec (G.722.2). Value Range 96–127 Default Value...
Page 302: Outbanddtmf_Vol
5.3.26 RTP/RTCP/RTCP-XR Settings OUTBANDDTMF_VOL Value Format INTEGER Description Specifies the volume (in decibels [dB]) of the DTMF tone using RFC 2833. Value Range -63–0 Default Value INBANDDTMF_VOL Value Format INTEGER Description Specifies the volume (in decibels [dB]) of in-band DTMF tones. Value Range -46–0 Default Value...
Page 303: Dscp_Rtcp_N
5.3.26 RTP/RTCP/RTCP-XR Settings Web User Interface Reference RTP Packet QoS (DSCP) (Page 146) DSCP_RTCP_n Parameter Name Example DSCP_RTCP_1, DSCP_RTCP_2, …, DSCP_RTCP_8 Value Format INTEGER Description Specifies the DSCP level of DiffServ applied to RTCP/RTCP-XR packets. Value Range 0–63 Default Value Web User Interface Reference RTCP Packet QoS (DSCP) (Page 146) MAX_DELAY_n...
Page 304: Nom_Delay_N
5.3.26 RTP/RTCP/RTCP-XR Settings NOM_DELAY_n Parameter Name Example NOM_DELAY_1, NOM_DELAY_2, …, NOM_DELAY_8 Value Format INTEGER Description Specifies the initial delay, in 10-millisecond units, of the jitter buffer. Value Range 1–7 (´ 10 ms) Note • This setting is subject to the following conditions: –...
Page 305: Rtcp_Enable_N
5.3.26 RTP/RTCP/RTCP-XR Settings Web User Interface Reference RTP Packet Time (Page 140) RTCP_ENABLE_n Parameter Name Example RTCP_ENABLE_1, RTCP_ENABLE_2, …, RTCP_ENABLE_8 Value Format BOOLEAN Description Specifies whether to enable or disable RTCP (Real-Time Transport Control Protocol). For details, refer to RFC 3550. Value Range •...
Page 306: Rtp_Close_Enable_N
5.3.27 SRTP Settings RTP_CLOSE_ENABLE_n Parameter Name Example RTP_CLOSE_ENABLE_1, RTP_CLOSE_ENABLE_2, …, RTP_CLOSE_ENABLE_8 Value Format BOOLEAN Description Specifies whether to enable processing to close held RTP sockets. • Value Range Y (Enable RTP Close) • N (Disable RTP Close) Default Value RTCPXR_ENABLE_n Parameter Name Example RTCPXR_ENABLE_1, RTCPXR_ENABLE_2, …, RTCPXR_ENABLE_8 Value Format...
Page 307: Srtp_Mix_Conference_Enable_N
1: Use only RTP for outgoing calls, and RTP or SRTP for incoming calls. • 2: Use RTP or SRTP for both outgoing and incoming calls. This value is valid only when the unit is connected to a Panasonic PBX. "SRTP_MIX_TRANSFER_ENABLE_n" must also be set to "Y". •...
Page 308: Srtp_Held_Call_Rtp_Enable
5.3.28 VQ Report by PUBLISH Default Value Web User Interface Reference Enable Mixed SRTP & RTP by Transfer (Page 148) SRTP_HELD_CALL_RTP_ENABLE Value Format BOOLEAN Description Specifies whether to allow playing the melody on hold over RTP on a call that is using SRTP. Value Range •...
Page 309: Vqreport_Send
5.3.28 VQ Report by PUBLISH Description Specifies the port of the collector server. Value Range 1–65535 Default Value 5060 Web User Interface Reference Port (Page 141) VQREPORT_SEND Value Format INTEGER Description Specifies the sending type of the VQ report using PUBLISH. Value Range •...
Page 310: Alert_Report_Delay_Critical
5.3.28 VQ Report by PUBLISH Description Specifies the warning criteria to send VQ report at the time of occurring the MOSQ. Value Range 0–40 Default Value Web User Interface Reference Threshold MOS-LQ (Warning) (Page 142) ALERT_REPORT_DELAY_CRITICAL Value Format INTEGER Description Specifies the critical criteria to send VQ report at the time of occurring the delay.
Page 311: Vqreport_Send_Opt_Nw_Change
5.3.29 uaCSTA Settings Value Range • Y: Send VQREPORT when a change of codec is detected • N: Send VQREPORT at the end of a conversation Default Value VQREPORT_SEND_OPT_NW_CHANGE Value Format INTEGER Description Specifies the number of consecutive times the MOS (Mean Opinion Score) value may fall below the threshold value specified by either "ALERT_REPORT_MOSQ_CRITICAL"...
Page 312: Csta_Port
5.3.29 uaCSTA Settings CSTA_PORT Value Format INTEGER Description Specifies the source port number used by the unit for uaCSTA communication. Value Range 1–65535 Default Value 6060 CSTA_PRXY_ADDR Value Format STRING Description Specifies the IP address or FQDN of the proxy server for CSTA. Value Range Max.
Page 313: Csta_Reg_Expire_Time
5.3.30 Telephone Settings CSTA_REG_EXPIRE_TIME Value Format INTEGER Description Specifies the length of time, in seconds, that the registration remains valid. This value is set in the "Expires" header of the REGISTER request for CSTA. Value Range 1–4294967295 Default Value 3600 CSTA_TRANSPORT Value Format INTEGER...
Page 314: Display_Wallpaper_Dark_Path
5.3.30 Telephone Settings Value Range Max. 384 characters Note • For details about the formats, see 2.1.3 Server Address Formats. Default Value Empty string DISPLAY_WALLPAPER_DARK_PATH Value Format STRING Description Specifies the Wallpaper for DARK display setting in IDLE mode. Size: 128 x 116 File type: BMP (1/4/8/24 bit) Value Range Max.
Page 315: Intdigit_Tim
5.3.30 Telephone Settings INTDIGIT_TIM Value Format INTEGER Description Specifies the length of time, in seconds, within which subsequent digits of a dial number must be dialed. Value Range 1–15 (s) Default Value Web User Interface Reference Inter-digit Timeout (Page 152) POUND_KEY_DELIMITER_ENABLE Value Format BOOLEAN...
Page 316: Intercom_Ringtone_Setting_Hsy
5.3.30 Telephone Settings Default Value RINGTONE_SETTING_HS1_1=1, RINGTONE_SETTING_HS2_1=1, …, RINGTONE_SETTING_HS8_1=1, RINGTONE_SETTING_HS1_2=2, RINGTONE_SETTING_HS2_2=2, …, RINGTONE_SETTING_HS8_2=2, RINGTONE_SETTING_HS1_3=3, RINGTONE_SETTING_HS2_3=3, …, RINGTONE_SETTING_HS8_3=3, RINGTONE_SETTING_HS1_4=4, RINGTONE_SETTING_HS2_4=4, …, RINGTONE_SETTING_HS8_4=4, RINGTONE_SETTING_HS1_5=5, RINGTONE_SETTING_HS2_5=5, …, RINGTONE_SETTING_HS8_5=5, RINGTONE_SETTING_HS1_6=6, RINGTONE_SETTING_HS2_6=6, …, RINGTONE_SETTING_HS8_6=6, RINGTONE_SETTING_HS1_7=7, RINGTONE_SETTING_HS2_7=7, …, RINGTONE_SETTING_HS8_7=7, RINGTONE_SETTING_HS1_8=8, RINGTONE_SETTING_HS2_8=8, …, RINGTONE_SETTING_HS8_8=8 INTERCOM_RINGTONE_SETTING_HSy Value Format INTEGER Description Specifies the intercom ringtone to each handset.
Page 317: Number_Matching_Upper_Digit
5.3.30 Telephone Settings NUMBER_MATCHING_UPPER_DIGIT Value Format INTEGER Description Specifies the maximum number of digits with which to match a phonebook entry with an incoming call’s caller ID. Value Range 0–15 Default Value INCOMING_BUSY_ENABLE Value Format BOOLEAN Description Operation of a second incoming call on the same line when the device is using the radio broadcast.
Page 318: Callpark_Key_Enable
5.3.30 Telephone Settings Description Specifies the call parking number. Value Range 0–4 digits (0–9,*, #) Default Value Empty string Web User Interface Reference Call Park Number (Page 153) CALLPARK_KEY_ENABLE Value Format BOOLEAN Description Specifies whether to display "Call Park" in the Call Parking Func menu. Value Range •...
Page 319: Hold_Recall_Tim
5.3.30 Telephone Settings HOLD_RECALL_TIM Value Format INTEGER Description Specifies the duration of the hold recall timer. If set to "0", the function is disabled. Value Range 0–240 (0: Disable) Default Value HOLD_TRANSFER_OPERATION Value Format BOOLEAN Description Specifies whether to transfer a call by Hold button. •...
Page 320: Repeater_Mode
5.3.30 Telephone Settings Description Specifies whether to enable blind transfer. Value Range • Y: Enable • N: Disable Default Value REPEATER_MODE Value Format BOOLEAN Description Specifies whether to turn the repeater mode on or off. Value Range • Y: Repeater on •...
Page 321: Pause_Input_Enable
5.3.30 Telephone Settings Description Specifies whether to enable or disable intercom menu. Value Range • Y: Enable • N: Disable Default Value PAUSE_INPUT_ENABLE Value Format BOOLEAN Description Specifies whether to enable or disable pause input. Value Range • Y: Enable •...
Page 322: Hs_Idle_Display_Type
5.3.30 Telephone Settings Default Value HS_IDLE_DISPLAY_TYPE Value Format INTEGER Description Specifies what is shown on the display in standby mode. Value Range • 0: Off • 1: Phone Number • 2: Phone Number and Handset Name • 3: Handset Name Default Value NOISE_REDUCTION_MODE_HSy Parameter Name Example...
Page 323: Soft_Key_Labelx
5.3.30 Telephone Settings Default Value Empty string Web User Interface Reference Group Call Pickup (Page 154) SOFT_KEY_LABELx Value Format STRING Description x=1–3 Specifies the text of the soft keys displayed on the screen for quick dialing. Note • This setting is available only when "DISCLOSE_FUNCTION_ENABLE"...
Page 324: Speaker_Volume_Level
5.3.30 Telephone Settings Value Range 1–6 Default Value SPEAKER_VOLUME_LEVEL Value Format INTEGER Description Specifies the speaker receiver’s volume level. Value Range 1–6 Default Value RINGER_VOLUME_LEVEL Value Format INTEGER Description Specifies the value of the ringer volume. Value Range 1–6 Default Value RINGER_VOL_OPERATION_ENABLE Value Format BOOLEAN...
Page 325: Tone Settings
5.3.31 Tone Settings 5.3.31 Tone Settings OUTSIDE_DIAL_TONE_FRQ Value Format Comma-separated Integer Description Specifies the dual-tone frequencies, in hertz, of Second Dial Tone using max. 2 whole numbers separated by a comma. Value Range 0, 200–2000(Hz) (0=No tone) Default Value OUTSIDE_DIAL_TONE_GAIN Value Format INTEGER Description...
Page 326: Tone_Len_Disconnect
5.3.31 Tone Settings Default Value TONE_LEN_DISCONNECT Value Format INTEGER Description Specifies the duration, in seconds, that a disconnect tone will be heard when the other party ends a call and the handset is being used. Value Range 1–15 (s) Default Value DIAL_TONE1_FRQ Value Format Comma-separated Integer...
Page 327: Dial_Tone2_Frq
5.3.31 Tone Settings Description Specifies the pattern, in milliseconds, of Dial Tone 1 using up to 10 whole numbers (off 1, on 1, off 2, on 2…) separated by commas. Note • It is recommended that you set a value of 60 milliseconds or more for the first value (off 1).
Page 328: Dial_Tone4_Frq
5.3.31 Tone Settings Description Specifies the pattern, in milliseconds, of Dial Tone 2 using up to 10 whole numbers (off 1, on 1, off 2, on 2…) separated by commas. Note • It is recommended that you set a value of 60 milliseconds or more for the first value (off 1).
Page 329: Busy_Tone_Frq
5.3.31 Tone Settings Description Specifies the pattern, in milliseconds, of Dial Tone 4 (stutter dial tones) to notify that a voice mail is waiting, using up to 22 whole numbers (off 1, on 1, off 2, on 2…) separated by commas. Note •...
Page 330: Busy_Tone_Timing
5.3.31 Tone Settings BUSY_TONE_TIMING Value Format Comma-separated Integer Description Specifies the pattern, in milliseconds, of busy tones using up to 10 whole numbers (off 1, on 1, off 2, on 2…) separated by commas. Note • It is recommended that you set a value of 60 milliseconds or more for the first value (off 1).
Page 331: Reorder_Tone_Timing
5.3.31 Tone Settings REORDER_TONE_TIMING Value Format Comma-separated Integer Description Specifies the pattern, in milliseconds, of reorder tones using up to 10 whole numbers (off 1, on 1, off 2, on 2…) separated by commas. Note • It is recommended that you set a value of 60 milliseconds or more for the first value (off 1).
Page 332: Ringback_Tone_Timing
5.3.31 Tone Settings RINGBACK_TONE_TIMING Value Format Comma-separated Integer Description Specifies the pattern, in milliseconds, of ringback tones using up to 10 whole numbers (off 1, on 1, off 2, on 2…) separated by commas. Note • It is recommended that you set a value of 60 milliseconds or more for the first value (off 1).
Page 333: Bell_Core_Pattern2_Timing
5.3.31 Tone Settings Default Value 2000,4000 BELL_CORE_PATTERN2_TIMING Value Format Comma-separated Integer Description Specifies the cadence, in milliseconds, of pattern ID 2, described in the LSSGR, GR-506-CORE, "Signaling for Analog Interfaces" section 14, using up to 8 whole numbers (on 1, off 1, on 2, off 2…) separated by commas.
Page 334: Bell_Core_Pattern5_Timing
5.3.32 Call Control Settings BELL_CORE_PATTERN5_TIMING Value Format Comma-separated Integer Description Specifies the cadence, in milliseconds, of pattern ID 5, described in the LSSGR, GR-506-CORE, "Signaling for Analog Interfaces" section 14, using up to 8 whole numbers (on 1, off 1, on 2, off 2…) separated by commas.
Page 335: Default_Line_Select_Hsy
5.3.32 Call Control Settings DEFAULT_LINE_SELECT_HSy Parameter Name Example DEFAULT_LINE_SELECT_HS1, DEFAULT_LINE_SELECT_HS2, …, DEFAULT_LINE_SELECT_HS8 Value Format Comma-separated Integer Description Specifies which lines (1–8) to seize automatically when going off-hook to make a call for each handset, using 8 whole numbers (0 or 1) separated by commas.
Page 336: Anonymous_Call_Enable_N
5.3.32 Call Control Settings Value Range 1–8 Default Value Web User Interface Reference Paging (Page 150) ANONYMOUS_CALL_ENABLE_n Parameter Name Example ANONYMOUS_CALL_ENABLE_1, ANONYMOUS_CALL_ENABLE_2, …, ANONYMOUS_CALL_ENABLE_8 Value Format BOOLEAN Description Specifies whether to make calls without transmitting the phone number to the called party. •...
Page 337: Hotline_Number_Hsy
5.3.32 Call Control Settings HOTLINE_NUMBER_HSy Parameter Name Example HOTLINE_NUMBER_HS1, HOTLINE_NUMBER_HS2, …, HOTLINE_NUMBER_HS8 Value Format STRING Description Specifies the Hot line number. Value Range Max. 32 characters Default Value Empty string Web User Interface Reference Handset 1–8 (Hotline Number) (Page 162) HOTLINE_TIM Value Format INTEGER...
Page 338: Vm_Number_N
5.3.32 Call Control Settings Value Range • Y (Send the SUBSCRIBE request) • N (Do not send the SUBSCRIBE request) Default Value Web User Interface Reference Send SUBSCRIBE to Voice Mail Server (Page 151) VM_NUMBER_n Parameter Name Example VM_NUMBER_1, VM_NUMBER_2, …, VM_NUMBER_8 Value Format STRING Description...
Page 339: Dial_Plan_Not_Match_Enable_N
5.3.32 Call Control Settings DIAL_PLAN_NOT_MATCH_ENABLE_n Parameter Name Example DIAL_PLAN_NOT_MATCH_ENABLE_1, DIAL_PLAN_NOT_MATCH_ENABLE_2, …, DIAL_PLAN_NOT_MATCH_ENABLE_8 Value Format BOOLEAN Description Specifies whether to enable dial plan filtering so that a call is not made when the dialed number does not match any of the dial formats specified in "DIAL_PLAN_n".
Page 340: Country_Calling_Code
5.3.32 Call Control Settings COUNTRY_CALLING_CODE Value Format STRING Description Specifies the country/area calling code to be used for comparative purposes when dialing a number from the incoming call log that contains a "+" symbol. Value Range Max. 8 characters (consisting of 0–9) Default Value Empty string Web User Interface Reference...
Page 341: Idle_Soft_Key_B
5.3.32 Call Control Settings IDLE_SOFT_KEY_B Value Format INTEGER Description Specifies the soft key (B) during IDLE state. • Value Range 1: Phonebook • 2: Menu • 3: Outgoing Call Log • 4: Incoming Call Log • 5: Redial • 6: Page •...
Page 342: Admin_Ability_Enable_Hsy
5.3.32 Call Control Settings ADMIN_ABILITY_ENABLE_HSy Parameter Name Example ADMIN_ABILITY_ENABLE_HS1, ADMIN_ABILITY_ENABLE_HS2, …, ADMIN_ABILITY_ENABLE_HS8 Value Format BOOLEAN Description Specifies admin rights for each handset. Note If you attempt to configure System Settings without enabling admin rights, an error will occur and configuration will not be possible. Value Range •...
Page 343: Call_Rejectionx_N
5.3.32 Call Control Settings CALL_REJECTIONx_n Parameter Name Example CALL_REJECTION1_1, CALL_REJECTION2_1, …, CALL_REJECTION20_1, CALL_REJECTION1_2, CALL_REJECTION2_2, …, CALL_REJECTION20_2, …, CALL_REJECTION1_8, CALL_REJECTION2_8, …, CALL_REJECTION20_8 Value Format STRING Description Specifies the rejected number per line. (Up to 20 rejected numbers) Value Range Max. 32 characters (except &, ", ', :, ;, <, >) Default Value Empty string Web User Interface Reference...
Page 344: Shared_Call_Enable_N
5.3.32 Call Control Settings SHARED_CALL_ENABLE_n Parameter Name Example SHARED_CALL_ENABLE_1, SHARED_CALL_ENABLE_2, …, SHARED_CALL_ENABLE_8 Value Format BOOLEAN Description Specifies whether to enable the Shared Call feature of the SIP server, which is used to share one line among the units. Note • Availability depends on your phone system.
Page 345: Moh_Server_Uri_N
Value Format INTEGER Description Specifies the mode of FWD/DND synchronizing with server. Value Range • 1: as feature event • 2: Panasonic original • 3: Entel Default Value HOLD_AND_CALL_ENABLE Value Format BOOLEAN Description Specifies whether making new call after holding the call or not.
Page 346: Auto_Call_Hold
5.3.32 Call Control Settings Default Value AUTO_CALL_HOLD Value Format BOOLEAN Description Specifies whether calls are disconnected or held when an other line is selected while having a conversation. Value Range • Y (Enable Auto Call Hold) • N (Disable Auto Call Hold) Default Value SIP_RESPONSE_CODE_DND Value Format...
Page 347: Return_Vol_Set_Default_Enable
5.3.32 Call Control Settings RETURN_VOL_SET_DEFAULT_ENABLE Value Format BOOLEAN Description Specifies whether the volume is returned to its default setting after each call. Value Range • Y (Volume returns to the default setting after each call) • N (Volume does not change after each call) Default Value CONFERENCE_SERVER_URI Value Format...
Page 348: Parallel_Modem
5.3.32 Call Control Settings Description Specifies the handset number for the paired handset (KX-TPA60) when connected in parallel. "m" refers to the master handset (KX-TPA65). For details, see 6.6 Pairing (Parallel Mode). Note • Be sure to designate the KX-TPA65 as the master handset and the KX-TPA60 as the slave handset.
Page 349: Dialplan_Replace_Log_Enable
5.3.32 Call Control Settings Value Range • Y: Hold the call • N: Do not hold the call Default Value DIALPLAN_REPLACE_LOG_ENABLE Value Format BOOLEAN Description Specifies whether to log the number after it was modified by the Dial Plan or the number as it was input. Value Range •...
Page 350: Talking_Soft_Key_B
5.3.32 Call Control Settings Value Range 0: Original 1: Mute 2: Menu 3: Blind 4: Redial 5: Conference 6: Flash/Recall 7: Incoming Log 8: Outgoing Log 9: Phonebook 10: Park 11: Intercom 12: Pause 13: Noise Reduction (KX-TPA60 only) 14: Private Hold Note •...
Page 351: Talking_Soft_Key_C
5.3.32 Call Control Settings Value Range 0: Original 1: Mute 2: Menu 3: Blind 4: Redial 5: Conference 6: Flash/Recall 7: Incoming Log 8: Outgoing Log 9: Phonebook 10: Park 11: Intercom 12: Pause 13: Noise Reduction (KX-TPA60 only) 14: Private Hold Note •...
Page 352: Display_Vm_With_Number
5.3.32 Call Control Settings Value Range 0: Original 1: Mute 2: Menu 3: Blind 4: Redial 5: Conference 6: Flash/Recall 7: Incoming Log 8: Outgoing Log 9: Phonebook 10: Park 11: Intercom 12: Pause 13: Noise Reduction (KX-TPA60 only) 14: Private Hold Note •...
Page 353: Retrive_Trans_Hold_Oper_Change
5.3.33 Logging Settings RETRIVE_TRANS_HOLD_OPER_CHANGE Value Format BOOLEAN Description Specifies the action for retrieving transfer-hold calls by pressing a Line key. Note • The action for retrieving a conference call on hold by pressing a Line key in the conference call sequence also follows this setting.
Page 354: Logging_Level_Dns
5.3.33 Logging Settings LOGGING_LEVEL_DNS Value Format INTEGER Description Specifies the log level of DNS. Value Range 0–6 Default Value LOGGING_LEVEL_NW1 Value Format INTEGER Description Specifies the log level of SNTP. Value Range 0–6 Default Value LOGGING_LEVEL_FILE Value Format INTEGER Description Specifies the log level of FILE downloading.
Page 355: Logging_Level_Stun
5.3.34 TWAMP Settings LOGGING_LEVEL_STUN Value Format INTEGER Description Specifies the log level of STUN. Value Range 0–6 Default Value LOGGING_LEVEL_NW2 Value Format INTEGER Description Specifies the log level of Xsi, XML, XMPP, LDAP. Value Range 0–6 Default Value LOGGING_LEVEL_CFGPARSE Value Format INTEGER Description Specifies the log level of configuration parse.
Page 356: Twamp_Control_Port
5.3.34 TWAMP Settings Web User Interface Reference Enable TWAMP (Page 109) TWAMP_CONTROL_PORT Value Format INTEGER Description Specifies the port for the TWAMP control session. Value Range 1–65535 Default Value Web User Interface Reference Control Port (Page 109) TWAMP_TEST_PORT Value Format INTEGER Description Specifies the port for the TWAMP test session.
Page 357: Twamp_Padding_Zero
5.3.34 TWAMP Settings TWAMP_PADDING_ZERO Value Format BOOLEAN Description Specifies the packet padding for the TWAMP test session. • Value Range Y: All zeros • N: Random Default Value Document Version 2017-07 Administrator Guide...
Page 358 5.3.34 TWAMP Settings Administrator Guide Document Version 2017-07...
Page 359: Useful Telephone Functions
Section 6 Useful Telephone Functions This section explains phone number settings, dial plan settings, the phonebook import/export function, the Broadsoft XSI function, the BroadCloud (Presence) function and Pairing (Parallel Mode). Document Version 2017-07 Administrator Guide...
Page 360: Line Settings
6.1.1 Multi Number Settings 6.1 Line Settings 6.1.1 Multi Number Settings A unit can be used with 8 handsets. You can assign a maximum of 8 different phone numbers for handsets. Each available phone number (line) can be assigned to handsets as desired to handle incoming and outgoing calls.
Page 361 Note • You can make a call with one of the phone numbers other than the default phone number. For details about the operations, refer to the Operating Instructions on the Panasonic Web site (® see Introduction). Document Version 2017-07...
Page 362: Phonebook Import And Export
6.2 Phonebook Import and Export 6.2 Phonebook Import and Export This section explains how to import and export phonebook data. Phonebook data of the cordless handset includes names and phone numbers. (The description below uses the KX-TPA60 cordless handset as an example.) Phonebook data on the cordless handset can be exported, edited with editor tools, and imported again.
Page 363 6.2 Phonebook Import and Export Importing the Same Phonebook Data to other Cordless handsets You can export the phonebook data created on a cordless handset to a PC, and then import it into other cordless handsets. You can also import phonebook data created on a PC to other cordless handsets. Import/Export File Format The file format used for importing and exporting the phonebook data is "TSV".
Page 364: Import/Export Operation
6.2.1 Import/Export Operation Phonebook Data in Text Format Aaron MacDowel 1234001 Barbara Nicolls 1234002 Carl O’Brien 1234003 Dorothy Parker 1234004 ···· ···· ···· ···· ···· ···· ···· ···· ···· ···· ···· ···· ···· ···· ···· ···· ···· ···· A Record ID (Unique ID: 1–500) B Tab C Name (up to 24 characters) D Tab...
Page 365: Editing With Microsoft Excel
6.2.2 Editing with Microsoft Excel On the "Now Processing File Data" screen, click the text "HERE" in the displayed message, or wait until File Download window appears. Note • Depending on the security settings of your Web browser, pop-up menus might be blocked. If the file cannot be exported successfully, try the export operation again or change the security settings of your Web browser.
Page 366 6.2.2 Editing with Microsoft Excel Select All Files for the file type, select the exported phonebook data file, and click Open. On the Text Import Wizard - Step 1 of 3 window, click Next. Note • Regardless of what is selected for File origin, the file will be processed normally if the format is appropriate.
Page 367: Exporting Data From Microsoft Outlook
6.2.3 Exporting Data from Microsoft Outlook On the Text Import Wizard - Step 3 of 3 window, select all columns in Data preview, select Text in Column data format, and then click Finish. The TSV file will be opened. Note •...
Page 368: Dial Plan
6.3.1 Dial Plan Settings Clear all items in the To list by clicking Clear Map. Then, drag only Last Name and Business Phone from the From list to the To list, and click OK. On the Export to a File window, click Finish. The data will be exported.
Page 369 6.3.1 Dial Plan Settings Element Available Value Description String 0–9, [, -, ], <, :, >, *, You can enter dial plan descriptions using a combination of the #, !, S, s, T, t, X, x, ., |, characters listed as available values. Digit 0–9, *, #, + Example: "123"...
Page 370 6.3.1 Dial Plan Settings Note • You can enter up to 1000 characters in [Dial Plan]. • You can assign up to 100 dial plans separated by "|" in [Dial Plan]. • You can assign up to 32 digits per dial plan in [Dial Plan]. •...
Page 371: Broadsoft Xsi (Xtended Services Interface)
IP phone (the KX-TGP600) to "Anonymous Call". (5) Call Forward The Call Forward function forwards incoming calls to an IP phone (the KX-TGP600) to a specified phone number. * When Feature Key Synchronization is set (FWD_DND_SYNCHRO_ENABLE_n="Y", see Page 344), the Call Forward function will not operate as an XSI function.
Page 372 6.4.2 XSI Service Settings Phone settings for using XSI services can be set using configuration parameters or the Web user interface (administrators only). See 4.3.7 Xtended Service Settings for making settings using the Web user interface. The following parameter names will be displayed and can be set as needed. Parameter Name Description Reference...
Page 373: Broadcloud (Presence)
[ ]/[ ]: "Remote Office","Anywhere","SimultaneousRing","Anonymous Call", or "Block Anonymous" ® 6.5 BroadCloud (Presence) 6.5.1 Outline The KX-TGP600 supports the following BroadCloud functions. (1) BroadCloud Buddies View the information of your Buddies. (2) BroadCloud Favorites View the information of your Buddies that have been marked as Favorites.
Page 374: Handset Operation Of Broadcloud (Presence) Functions
6.6.1 Outline 6.5.3 Handset Operation of BroadCloud (Presence) Functions Operations for Viewing the Buddies List [ ]/[ ]: "Buddies" ® The Buddies list is displayed. Operations for Viewing the Favorites List The Favorites list is displayed. Operations to Change Your Handset’s Presence [ ]/[ ]: "My phone"...
Page 375 Operation Description A call is made to Ext. 1201 from Phone C. When the base unit (KX-TGP600) receives the call, Phone A and Phone B both ring. The call can be answered from either Phone A or Phone B. Note •...
Page 376: Pairing (Parallel Mode) Settings
Handsets that are already paired cannot be set as a pair with another phone. (Note that functionality with such settings cannot be guaranteed.) Pairing Setting Example As an example, 4 handsets (KX-TPA60) with a KX-TGP600 base unit, along with 4 desktop phones (KX-TPA65) are in use. Here the maximum 4 pairing settings will be explained.
Page 377 Reference PARALLEL_HSNOm Specifies the paired handset. Page 347 Note For the paired handset, specify using the KX-TGP600’s ID number. PARALLEL_MODEm Specifies the operation mode for when one paired handset is Page 348 in a call and the other handset goes off hook.
Page 378 6.6.2 Pairing (Parallel Mode) Settings Note The ID number of the master desk phone is 5, so set PARALLEL_HSNO5 and PARALLEL_MODE5. <Pairing Group 3 Settings> Configuration Parameter Setting Handset 6 is paired as the master desk phone PARALLEL_HSNO6="3" together with Handset 3. Operation mode: Busy PARALLEL_MODE6="0"...
Page 379: Firmware Update
Section 7 Firmware Update This section explains how to update the firmware of the unit. Document Version 2017-07 Administrator Guide...
Page 380: Firmware Server Setup
7.2 Firmware Update Settings 7.1 Firmware Server Setup No special server is necessary for the firmware update. You can use an HTTP, HTTPS, FTP, or TFTP server as the firmware server by simply setting its URL. Updating the firmware of handsets takes approximately 15 minutes and up to 4 unused handsets can be updated simultaneously.
Page 381: Executing Firmware Update
For details about setting the timing of when configuration files are downloaded, see 2.2.4 Downloading Configuration Files. A Provisioning Server Address B Configuration File KX-TGP600 Provisioning Server Step 2 The unit compares the version number of the firmware in the configuration file to the unit’s current firmware version.
Page 382: Upgrade Firmware
"FIRM_FILE_PATH" in the configuration file. A http://firm.example.com/firm/01.050.fw B 01.050.fw KX-TGP600 Firmware Server Step 4 Once the newer firmware is downloaded, it is applied to the unit and the unit automatically restarts.
Page 383: Troubleshooting
Section 8 Troubleshooting This section provides information about troubleshooting. Document Version 2017-07 Administrator Guide...
Page 384: Troubleshooting
8.1 Troubleshooting 8.1 Troubleshooting If you still have difficulties after following the instructions in this section, disconnect the base unit from the AC outlet, then connect the AC adaptor again. If using PoE, disconnect the LAN cable, then connect the LAN cable again.
Page 385 8.1 Troubleshooting Base Unit STATUS Indicator Problem Cause/Solution The STATUS indicator continues flashing • An IP address may not have been acquired or the static IP in amber rapidly. address is not appropriate. Check the unit’s IP address (see 1.1.3 Basic Network Setup). It is recommended to perform the following.
Page 386 8.1 Troubleshooting Making/Answering Calls, Intercom Problem Cause/Solution The unit does not ring. • Check the VoIP status in the Web user interface and confirm that each line is registered properly (® see To check the setting status in the Web user interface in this section).
Page 387: Error Codes
8.1 Troubleshooting Time Problem Cause/Solution The time is not correct. • In the Web user interface, you can set NTP synchronization and DST (Summer Time) control to adjust the time automatically (® see 4.4.5 Time Adjust Settings). • If the time is still incorrect even after setting NTP synchronization, check the firewall and port forwarding settings on the router.
Page 388 8.1 Troubleshooting [ ]/[ ]: "Status" ® Export Logging File Export the log file using the Web user interface (see 4.7.5 Export Logging File). Administrator Guide Document Version 2017-07...
Page 389: Appendix
Section 9 Appendix Document Version 2017-07 Administrator Guide...
Page 390: Revision History
9.1.2 KX-TGP600 Software File Version 01.094 or later 9.1 Revision History 9.1.1 KX-TGP600 Software File Version 01.082 or later New Contents • 4.3.7.1 Xtended Service—SIP Credentials (Page 101) • 4.4.1.1 System—Enable SIP Trunk Service (Page 111) • 4.4.1.1 System—Enable Non-Registering SIP UA (Page 112) •...
Page 391: Kx-Tgp600 Software File Version 01.129 Or Later
9.1.4 KX-TGP600 Software File Version 01.148 or later Changed Contents • 5.3.15 SNMP Settings—SNMP_ENCRYPT_TYPE (Page 255) • 5.3.33 Logging Settings—LOGGING_LEVEL_FILE (Page 354) 9.1.3 KX-TGP600 Software File Version 01.129 or later New Contents • 4.4.9 Delete Handset (Page 128) • 5.3.2 Handset Registration Settings—NEXT_REGISTERED_HS_NUMBER (Page 211) •...
Page 392: Kx-Tgp600 Software File Version 02.100 Or Later
9.1.5 KX-TGP600 Software File Version 02.100 or later • 5.3.30 Telephone Settings—HS_IDLE_DISPLAY_TYPE (Page 322) • 5.3.30 Telephone Settings—NOISE_REDUCTION_MODE_HSy (Page 322) • 5.3.30 Telephone Settings—TALK_ON_CHARGE_MODE_HSy (Page 322) • 5.3.32 Call Control Settings—FWD_SYNCHRO_FORCE_DISABLE_n (Page 348) • 5.3.32 Call Control Settings—CONF_SERVER_HOLD_ENABLE (Page 348) 9.1.5 KX-TGP600 Software File Version 02.100 or later...
Page 393: Kx-Tgp600 Software File Version 03.000 Or Later
9.1.7 KX-TGP600 Software File Version 03.100 or later 9.1.6 KX-TGP600 Software File Version 03.000 or later New Contents • 4.6.2 Call Control—Missed Call Notification—Message (Page 126) • 4.6.2 Call Control—Missed Call Notification—LED (Page 126) • 4.6.2 Call Control—Voice Message Notification—Message (Page 126) •...
Page 394: Kx-Tgp600 Software File Version 04.000 Or Later
9.1.9 KX-TGP600 Software File Version 05.000 or later 9.1.8 KX-TGP600 Software File Version 04.000 or later New Contents • 5.3.1 System Settings—CODEC_VAD_CNG_ENABLE (Page 210) • 5.3.1 System Settings—ERROR_AUTO_REBOOT_TIME (Page 210) • 5.3.6 Provisioning Settings—CFG_BOOTUP_DURATION_ENABLE (Page 225) • 5.3.22 SIP Settings—SIP_DNSSRV_ENA_NAPTR_n (Page 294) •...
Page 395: Document Version
Notes Document Version 2017-07 Administrator Guide...
Page 396 1006, Oaza Kadoma, Kadoma-shi, Osaka 571-8501, Japan Panasonic Corporation 2015 PNQX6922TA DD0215SM6077...

Panasonic KX-TGP600 Administrator's Manual

1 Initial Setup

4 Web User Interface Programming

2 General Information on Provisioning

3 Phone User Interface Programming

5 Configuration File Programming

6 Useful Telephone Functions

Quick Links

Troubleshooting

Related Manuals for Panasonic KX-TGP600

Summary of Contents for Panasonic KX-TGP600
