- Page 1 2017 Quick Reference Guide...
-
Page 2: Basic Operation
For detailed operating and safety information, please refer to your owner’s Manual. basic opeRation Lock/Unlock doors Remote keyless entry system Locks both side doors The driver’s door will be unlocked. (To unlock other doors, briefly press the button a second time within 3 seconds.) Unlocks the trunk lid (press and hold) Sounds the alarm (press and hold) Remote... -
Page 3: Tilt/Telescopic Steering Wheel
adjust each component Front seat Seat position adjustment Seatback angle adjustment Vertical height adjustment (driver’s side only) Seatback fold strap Getting in the rear seats: Getting out the rear seats: Lift the seatback angle adjustment Pull the seatback fold strap. lever. -
Page 4: Start/Stop Engine
start/stop engine Push-button ignition switch (if equipped) Performing the following operations when carrying the access key on your person starts the engine or changes push-button ignition switch modes. Starting the engine; STEP1: Check that the parking brake is set. STEP2: Check that the select lever is set in P (AT models). Check that the shift lever is set in neutral (MT models). -
Page 5: Automatic Transmission - If Equipped
operate select lever/shift lever Automatic transmission (if equipped) P = Parking/Starting the engine R = Reversing N = Neutral D = Drive: For normal driving/Temporary manual mode driving M = Manual mode While the engine switch is in the ON position or the push-button ignition switch is in ON mode, move the select lever with the brake pedal depressed. -
Page 6: Windshield Wiper And Washer Switch
Main paRts anD opeRation Headlight switch/Turn signal lever/Front fog light switch (if equipped) Headlights High/low beam change, High beam flash Turn signal Front fog lights (if equipped) Windshield wiper and washer switch Wiper: To operate, push lever down/up to the following positions: : Temporary : Off : Intermittent : Low speed : High speed... -
Page 7: Hazard Warning Flasher Switch
Hazard warning flasher switch All the turn signal lights will flash. Use the switch to warn other drivers. Press Instrument panel light control dial Brighter Darker Windshield defogger/Rear window defogger switch Type B Type A Windshield defogger: The dehumidification function operates and fan speed increases. Set the outside/recirculated air mode button to outside air mode if the recirculated air mode is used. -
Page 8: Power Door Lock Switch
Trunk lid opener switch Engine hood lock release lever Press and hold Pull Power windows switches Closing One-touch closing* Opening One-touch opening* * : Pushing the switch in the opposite direction will stop window travel partway. Window lock switch Power door lock switch Locks both side doors Unlocks both side doors ◆... - Page 9 Fuel filler lid opener Pull up Front seatbelt guide To enable the seatbelt to be easily extended, pass the seatbelt through the guide. When getting in or out of the rear seats, release the seatbelt from the guide. Seat heater switches (if equipped) Rapid heating Normal heating...
-
Page 10: Cruise Control Switch
FUnction FoR MoRe coMFoRtabLe DRiVe Cruise control switch Use the cruise control to maintain a set speed without depressing the accelerator pedal. ON-OFF button: To activate and deactivate +RES▲/-SET▼: +RES▲ side: To increase the speed/To resume -SET▼ side : To set speed/To decrease the speed CANCEL: To cancel ◆... -
Page 11: Vehicle Stability Control (Vsc)/Trac Off Switch
Vehicle stability control (VSC)/TRAC off switch Turning off Traction Control System: To turn the TRAC system off, quickly press and release the button. The Traction Control System OFF indicator light will come on. Press the button again to turn the system back on. Quickly press and release Turning off both Traction Control System and Vehicle Stability Control (VSC) systems:... - Page 12 TRACK switch Your vehicle is equipped with two types of control modes to accommodate various driving preferences. The control modes can be selected with the TRACK switch. Normal mode allows secure and smooth normal driving. When the switch is pressed and held for 1 second or more, TRACK mode is activated. Control characteristics such as the Vehicle stability control (VSC) and TRAC are adjusted to afford maneuverability closer to what a driver may desire, while a sense of security is retained.
-
Page 13: Multi-Information Display (Monochrome Display)
Multi-information display (monochrome display) km/h MPH switch: press: The display inside the meter changes between km/h and MPH. ODO TRIP switch: press: Change displayed item. Odometer Trip meter A Trip meter B Setting screen for tachometer indicator needle movement function when starting the vehicle. -
Page 14: Multi-Information Display (Color Display)
Multi-information display (color display) Meter control switches: : Select menu icons : Change displayed content, scroll up/down the screen and move the cursor : Enter : Return to the previous screen ODO/TRIP switch: press: Change displayed item Odometer Trip meter A Menu icon Trip meter B Content display area... -
Page 15: Warning Lights
ON. Warning lights Refer to your Owner’s Manual for countermeasures when each warning light comes on. If necessary, consult your authorized SUBARU dealer. Malfunction indicator Indicates a malfunction in: • The electronic engine control system;... - Page 16 SRS airbag system warning • Indicates a malfunction in: • The SRS airbag system; • The seatbelt pretensioner system; • The front passenger occupant detection system. Automatic transmission fluid temperature warning (if equipped) Indicates that the automatic transmission fluid temperature is too high. Keyless access with push button start system indicator (if equipped) Flashing in YELLOW : Indicates a malfunction in the keyless access with push button start system.
-
Page 17: Indicator Lights
indicator lights The following indicators show the current status of your car. Refer to the Owner’s Manual for more information. Front fog light Turn signal Headlight high indicator indicator beam indicator (if equipped) Vehicle stability Security Airbag on-off control (VSC) indicator indicator off indicator... - Page 18 Notes ◆ Some functions are available on certain models. ◆ For detailed operating and safety information, please refer to your Owner’s Manual.
- Page 19 Notes...
- Page 20 Colours shown may vary due to reproduction variations in the printing process, and some vehicle parts cannot be shown in certain photographs. Subaru Canada, Inc. reserves the right to discontinue or make changes at any time, without notice or incurring obligations, to colours, materials, equipment, accessories, features, specifications and models, or to change their prices.
