Predator Engines 69727 Owner's Manual & Safety Instructions

Predator Engines 69727 Owner's Manual & Safety Instructions

212cc horizontal shaft gas engine

Advertisement

Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
Using an engine indoors
CAN KILL YOU IN MINUTES.
Engine exhaust contains carbon monoxide.
This is a poison you cannot see or smell.
NEVER use inside
a home or garage,
EVEN IF doors and
windows are open.
Email our technical support at: predator@harborfreight.com
Email our engine support at: predator@harborfreight.com
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
©
Copyright
2012 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
Only use OUTSIDE
and far away from
windows, doors,
and vents.
Visit our website at: http://www.harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
REV 16l

Advertisement

Table of Contents
loading

Summary of Contents for Predator Engines 69727

  • Page 1 Owner’s Manual & Safety Instructions Save This Manual Keep this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the back of the manual near the assembly diagram (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference.
  • Page 2: Table Of Contents

    The emissions control system for this Engine is warranted for standards set by the U.S. Environmental Protection Agency and by the California Air Resources Board (also known as CARB). For warranty information, refer to the last pages of this manual. Page 2 For technical questions, please call 1-888-866-5797. ITEM 69727...
  • Page 3: Safety

    Risk of Hearing Loss. Wear hearing protection. IMpORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS – This manual contains important instructions that should be followed during installation and maintenance of the generator and any batteries. ITEM 69727 For technical questions, please call 1-888-866-5797. Page 3...
  • Page 4: Operating Precautions

    20. Keep the engine and surrounding 8. Secure the engine on transport vehicles to area clean at all times. prevent it from rolling, slipping, and tilting. Page 4 For technical questions, please call 1-888-866-5797. ITEM 69727...
  • Page 5 To prevent FIRE, do not start the engine about your ability to perform safely or correctly. while the smell of fuel hangs in the air. 7. Store equipment out of the reach of children. SAVE THESE INSTRUCTIONS. ITEM 69727 For technical questions, please call 1-888-866-5797. Page 5...
  • Page 6: Setup

    Read the ENTIRE IMpORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. For item 69727: The emission control system for this Engine is warranted for standards set by the U.S.
  • Page 7 Fuel Cup Seal part Description Main Jet 3000-6000 ft. Mixing Tube Main Jet 6000-8000 ft. (might remain Bolt Seal inside carburetor) Fuel Cup Seal Main Jet Fuel Cup Bolt Seal Bolt ITEM 69727 For technical questions, please call 1-888-866-5797. Page 7...
  • Page 8: Operation

    6. Thread the dipstick back in clockwise. NOTICE: Do not run the engine with too little oil. Engine will shut off if engine oil level is too low. Page 8 For technical questions, please call 1-888-866-5797. ITEM 69727...
  • Page 9: Starting The Engine

    Inspect the equipment and engine. c. Fill the engine with the proper amount and type of both stabilizer-treated unleaded gasoline and oil. d. Read the Equipment Operation section in the equipment manual. ITEM 69727 For technical questions, please call 1-888-866-5797. Page 9...
  • Page 10: Manual Start

    Repeat until the engine starts. Note: Do not let the Starter Handle snap back against the engine. Hold it as it recoils so it doesn't hit the engine. Page 10 For technical questions, please call 1-888-866-5797. ITEM 69727...
  • Page 11: Stopping The Engine

    Slide the Throttle or Speed Control Lever to SLOW (the “turtle”). b. Turn the Engine Switch off. c. Close the Fuel Valve. NOTICE See Long-Term Storage on page 15 for complete storage instructions. ITEM 69727 For technical questions, please call 1-888-866-5797. Page 11...
  • Page 12: Maintenance

    4. Clean carbon build-up from combustion chamber Replace fuel line if necessary Service more frequently when used in dusty areas. These items should be serviced by a qualified technician. Page 12 For technical questions, please call 1-888-866-5797. ITEM 69727...
  • Page 13 Average outdoor temperature 8. Thread the dipstick back in clockwise. NOTICE: Do not run the engine with too little oil. Engine will not start with low or no engine oil. ITEM 69727 For technical questions, please call 1-888-866-5797. Page 13...
  • Page 14 If overtightened, the threads in the engine block will be damaged. 6. Apply dielectric spark plug boot protector (not included) to the end of the spark plug and reattach the cap securely. Page 14 For technical questions, please call 1-888-866-5797. ITEM 69727...
  • Page 15 Engine does not start. b. Clean out area around spark plug. Remove spark plug and pour one tablespoon of engine oil into cylinder through spark plug hole. ITEM 69727 For technical questions, please call 1-888-866-5797. Page 15...
  • Page 16: Troubleshooting

    2. Engine mounted on slope, 2. Operate engine on level surface. triggering low oil shutdown. Check engine oil level. Follow all safety precautions whenever diagnosing or servicing the equipment or engine. Page 16 For technical questions, please call 1-888-866-5797. ITEM 69727...
  • Page 17 Follow all safety precautions whenever diagnosing or servicing the equipment or engine. ITEM 69727 For technical questions, please call 1-888-866-5797. Page 17...
  • Page 18: Warranties

    This warranty gives you specific legal rights and you may also have other rights which vary from state to state. Emissions Control System Warranty - 69727 The California Air Resources Board and Harbor Freight Tools (HFT) are pleased to explain the emissions control system warranty on your 2017 Small Off-Road Engine, in addition to the Retail Warranty above.
  • Page 19: General Emissions Warranty Coverage

    Fuel caps, valves, canisters, filters, vapor hoses, c. Spark advance/retard system. clamps, connectors, belts, and assemblies. HFT provides with each product written instructions for the maintenance and use of the product by the owner. ITEM 69727 For technical questions, please call 1-888-866-5797. Page 19...
  • Page 20: Parts Lists And Diagrams

    Note: Some parts are listed and shown for illustration purposes only, and are not available Note: If product has no serial number, individually as replacement parts. record month and year of purchase instead. Page 20 For technical questions, please call 1-888-866-5797. ITEM 69727...
  • Page 21 ITEM 69727 For technical questions, please call 1-888-866-5797. Page 21...
  • Page 22 Mounting Hole Diagram Note: Not to scale. 6.38 in. / 162mm 2.6 in. / 66mm Page 22 For technical questions, please call 1-888-866-5797. ITEM 69727...
  • Page 23 Note: Not to scale. 2.43 in. / 61.7mm 5/16-24UNF 1.79 in. / 45.5mm 0.67 in. / 17mm 0.1875 in. / 4.78mm Ø0.75 in. / 19.05mm Ø3.625 in. / 92mm 4x5/16-24UNF ITEM 69727 For technical questions, please call 1-888-866-5797. Page 23...
  • Page 24 pLEASE READ THE FOLLOWING CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.
