MPC220SL/17 8/6/02 9:20 AM Page 1
Return your Warranty Registration card today to
User guide
ensure you receive all the benefits you're entitled to.
S M A R T . V E R Y S M A R T . • Once your Magnavox purchase is regis-
tered, you're eligible to receive all the
privileges of owning a Magnavox product.
MPC220SL
Warranty Owner
MPC225SL
Verification Confirmation
Registering your product Your completed
PORTABLE CD PLAYER within 10 days confirms Warranty Registration
your right to maximum Card serves as verifica-
protection under the tion of ownership in the
terms and conditions of event of product theft
your Magnavox warranty. or loss.
Read this manual first!
Return
If you have any problems, do not attempt
your Warranty
to return this product to the store.
Registration Card
For fast help, call us first! within 10 days
Know these
1-800-705-2000
s s a a f f e e t t y y
symbols
C A U T I O N
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This "bolt of lightning"
indicates uninsulated material
within your unit may cause an
electrical shock. For the safety of
everyone in your household, please
do not remove product covering.
The "exclamation point" calls
attention to features for which
you should read the enclosed litera-
ture closely to prevent operating and
maintenance problems.
English
Meet Magnavox at the Internet CONTROLS / POWER SUPPLY
http://www.magnavox.com
CONTROLS ( see figure 1 )
1 OPEN 2 ..............opens the CD lid
English 2 ∞ .......................skips and searches CD tracks backwards
3 § .......................skips and searches CD tracks forwards
Español
4 DBB.....................switches the bass enhancement on and off. This button also
switches acoustic feedback (the beep) on/off when it is
pressed for more than 2 seconds
5 PROG...................programs tracks and reviews the program
6 ............................display
7 MODE .................selects the different playing possibilities:
SHUFFLE REPEAT ALL
8 9.........................stops CD play, clears a program or switches the player off
9 2;.......................switches the player on, starts or pauses CD play
0 RESUME .............stores the last position of a CD track played
HOLD...................locks all buttons
OFF......................switches RESUME and HOLD off
! LINE OUT/p........3.5 mm headphone jack and LINE OUT jack to connect the
player to another audio input of an additional appliance.
@ VOL E ............adjusts the volume
# 4.5V DC...............jack for external power supply
CLASS 1
$ ............................type plate
LASER PRODUCT
CAUTION
Use of controls or adjustments or performance of procedures other than
herein may result in hazardous radiation exposure.
Printed in China
Batteries (supplied or optionally available)
QUICK START ENCENDIDO RAPIDO
You can use the following batteries with this CD-player:
1 2
p • normal batteries type LR6, UM3 or AA (preferably Philips), or
• alkaline batteries type LR6, UM3 or AA (preferably Philips).
Notes:– Old and new or different types of batteries should not be combined.
2.
– Remove batteries if they are empty or if the player is not going to be used for
a long time.
1.
Inserting batteries
1 Push OPEN 2 to open the CD lid.
2 Open the battery compartment and insert either 2
3
#
normal or alkaline batteries.
Battery indication
The approximate power level of your batteries is shown
in the display.
Battery full
Battery two-thirds full
4 5 PLAY 2; 6
HOLD OFF VOL Battery one-third full
Battery dead or empty.When the batteries are
dead or empty, the symbol A flashes,
bAtt is displayed, and the beep tone sounds repeatedly..
Batteries contain chemical substances, so they should be disposed
of properly.
!!!
IMPORTANT SAFETY INSTRUCTIONS
• So complete and return the Warranty
Registration Card enclosed with your
purchase at once, and take advantage
1.
Read these instructions.
of these important benefits.
2.
Model Keep these instructions.
Registration
3.
Heed all warnings.
Returning your Warranty
Registration Card right
4. Follow all instructions.
away guarantees you'll
receive all the information
5.
Do not use this apparatus near water.
and special offers which
you qualify for as the
6.
owner of your model. Clean only with dry cloth.
7.
Do not block any ventilation openings. Install in
For Customer Use F or Customer Use
accordance with the manufacturer´s instructions.
Enter below the Serial No. which is Enter below the Serial No. which is
located on the rear of the cabinet. Retain located on the rear of the cabinet. Retain
8.
this information for future reference. this inf ormation for future reference. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including amplifiers)
Model No. _____________________
Model No. _____________________
that produce heat.
Serial No. ______________________
Serial No. ______________________
9. Only use attachments/accessories specified by the man-
WARNING:
TO PREVENT FIRE
ufacturer.
OR SHOCK HAZARD, DO NOT
EXPOSE THIS EQUIPMENT TO RAIN
10.
Use only with the cart, stand, tripod, bracket,
OR MOISTURE.
or table specified by the manufacturer or sold with
CAUTION:
To prevent electric
the apparatus. When a cart is used, use caution
shock, match wide blade of plug to
wide slot, and fully insert. when moving the cart/apparatus combination
to avoid injury from tip-over.
MAC5097
POWER SUPPLY / GENERAL INFORMATION
Mains adapter (supplied or optionally available)
Use only a 4.5 V adapter (300 mA direct current, positive pole to the center pin).
Any other kind of adapter may damage the player.
1 Make sure the local voltage corresponds to the power
adapter's voltage.
2 Connect the power adapter to the 4.5V DC jack of the
player and to the wall outlet.
Note: Always disconnect the adapter when you are not
using it.
,
SHUFFLE
and SCAN
, REPEAT , REPEAT ALL
Environmental information
• All redundant packing material has been omitted. We have done our utmost to
make the packaging easily separable into two materials: cardboard (box) and
polyethylene (bags, protective foam sheet).
• Your set consists of materials which can be recycled if disassembled by a
specialized company. Please observe the local regulations regarding the
disposal of packing materials, dead batteries and old equipment.
Both the model number and production number are located on the
bottom of the set.
CD player and CD handling
• Do not touch the lens A of the CD player.
• Do not expose the unit, batteries or CDs to humidity, rain, sand or excessive
heat (caused by heating equipment or direct sunlight).
• You can clean the CD player with a soft, slightly
dampened, lint-free cloth. Do not use any cleaning
agents as they may have a corrosive effect.
• To clean the CD, wipe it in a straight line from the
center toward the edge using a soft, lint-free cloth. A
cleaning agent may damage the disc! Never write on
a CD or attach a sticker to it.
• The lens may cloud over when the unit is moved sud-
denly from cold to warm surroundings. Playing a CD is
not possible then. Leave the CD player in a warm environment until the mois-
ture has evaporated.
• Active mobile phones in the vicinity of the CD player may cause malfunctions.
• Avoid dropping the unit as this may cause damage.
Headphones
• Connect the supplied headphones to the LINE OUT/p
jack of the player.
Note: LINE OUT/p can also be used for connecting the player to your HiFi system
(with a signal lead) or to your car radio (with a cas-
sette adapter or signal lead). In both cases, the vol-
ume of the player must be set to position 8.
IMPORTANT!
Hearing safety: Do not play your headphones at a high vol-
ume. Hearing experts advise that continuous use at high vol-
ume can permanently damage your hearing.
Traffic safety: Do not use headphones while driving a vehicle. It may create a hazard
and it is illegal in many countries. Even if your headphones are an open-air type
designed to let you hear outside sounds, do not turn up the volume so high that you
cannot hear what is going on around you.
LIMITED WARRANTY
PORTABLE AUDIO
90 Days Free Exchange
This product must be carried in for an exchange.
11.
Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any way,
WHO IS COVERED?
You must have proof of purchase to exchange the product. A sales receipt or other doc-
such as power-supply cord or plug is damaged, liquid has been
ument showing that you purchased the product is considered proof of purchase. Attach it
to this owner's manual and keep both nearby.
spilled or objects have fallen into the apparatus, the apparatus
WHAT IS COVERED?
has been exposed to rain or moisture, does not operate nor-
Warranty coverage begins the day you buy your product. For 90 days thereafter, a defec-
tive or inoperative product will be replaced with a new, renewed or comparable product
mally, or has been dropped.
at no charge to you. A replacement product is covered only for the original warranty
period.When the warranty on the original product expires, the warranty on the replace-
CAUTION
12. ment product also expires.
Battery usage – To prevent battery leakage
which may result in bodily injury or damage to the unit: WHAT IS EXCLUDED?
Your warranty does not cover:
• labor charges for installation or setup of the product, adjustment of customer controls
Install all batteries correctly, + and - as marked on the unit. on the product, and installation or repair of antenna systems outside of the product.
• product repair and/or part replacement because of misuse, accident, unauthorized
repair or other cause not within the control of Magnavox.
Do not mix batteries (old and new or carbon and
• reception problems caused by signal conditions or cable or antenna systems outside
the unit.
alkaline, etc.).
• a product that requires modification or adaptation to enable it to operate in any coun-
try other than the country for which it was designed, manufactured, approved and/or
authorized, or repair of products damaged by these modifications.
Remove batteries when the unit is not used for a long time.
• incidental or consequential damages resulting from the product. (Some states do not
allow the exclusion of incidental or consequential damages, so the above exclusion
may not apply to you.This includes, but is not limited to, prerecorded material,
EL 6474-E003: 01/6
whether copyrighted or not copyrighted.)
• a product used for commercial or institutional purposes.
WHERE IS EXCHANGE AVAILABLE?
You may exchange the product in all countries where the product is officially distributed
by Magnavox. In countries where Magnavox does not distribute the product, the local
Magnavox service organization will attempt to provide a replacement product (although
there may be a delay if the appropriate product is not readily available).
Magnavox, P.O. Box 520890, Miami,
FL 33152, USA, (402) 536-4171
GENERAL INFORMATION / CD PLAY CD PLAY / FEATURES
In-car use (connections supplied or optionally available) Playback information
• If a CD-Recordable (CD-R) or a CD-Rewritable (CD-RW) is not recorded
Only use a 4.5 V DC car voltage converter (positive pole to the center pin) and
properly, nF dISC is displayed, indicating that the CD has not been
cassette car adapter. Any other converter may damage the set.
finalized. In that case, use FINALIZE on your CD recorder to complete the
recording.
1 Put the set on a horizontal, vibration-free and stable surface. Make sure it is
in a safe place, where the set is neither a dan-
• When playing a CD-Rewritable (CD-RW), please note that it takes 3–15
seconds after pressing 2; for sound reproduction to start.
ger nor an
obstacle to the driver and the passengers.
12 V DC
• Playback will stop if you open the CD lid.
2 Plug the voltage converter into the
• While the CD is read, 01 --:-- flashes in the display.
cigarette lighter jack (only for 12 V car
battery, negative grounding) , then connect
Volume and bass
the wired end with 4.5V DC input jack on the
4,5 V DC
set.
Volume adjustment
• Adjust the volume by using VOL E.
3 If necessary, clean the cigarette lighter jack to
obtain a good electrical contact.
4 Turn down the volume and connect the cassette adapter plug to LINE OUT/p
on the set.
Bass adjustment
• Press DBB to switch the bass enhancement on or
5 Carefully insert the cassette adapter into the car radio's cassette compartment.
off
6 Make sure the cord does not hinder your driving. yDBB
appears if the bass enhancement is
activated.
7 Decease the volume on the set, if necessary. Start playback on the set and
adjust the sound with the car radio controls.
• Always remove the voltage converter from the cigarette lighter jack-
when the set is not in use.
Note: If your car radio has a LINE IN jack, it is better to use it for the
car radio connection instead of the cassette.adapter. Connect the signal
lead to this LINE IN jack and to LINE OUT/p on the set.
Playing a CD Selecting a track and searching
This CD-player can play all kinds of Audio Discs such Selecting a track during playback
as CD-Recordables and CD-Rewritables. Do not try to play a CD-ROM, CDi, VCD, • Briefly press ∞ or § once or several times to skip to the current, previous or
DVD or computer CD.
next track.
yPlayback continues with the selected track, and
the track's number is displayed.
1 Push the OPEN 2 slider to open the player.
Selecting a track when playback is stopped
2 Insert an audio CD, printed side up, by pressing the
1 Briefly press ∞ or § once or several times to select
CD onto the hub.
the desired track. The track number is displayed.
3 Close the player by pressing the lid down.
2 Press 2; to start CD play.
4 Press 2; to switch the player on and start playback. yPlayback starts with the selected track.
yThe current track number and elapsed playing
time are displayed. Searching for a passage during playback
1 Keep ∞ or § pressed to find a particular passage in
• You can pause playback by pressing 2;.
a backward or forward direction.
yThe time at which playback was paused starts E S P
ySearching starts while playback continues at low
flashing.
volume. After 2 seconds the search speeds up.
• You can continue playback by pressing 2; again.
2 Release the button when you reach the desired passage.
yPlayback continues from this position.
5 Press 9 to stop playback.
E S P
yThe total number of tracks and the total playing
Notes: – If the player is in SCAN mode (see MODE chapter), searching is not
time of the CD are displayed.
possible.
– In shuffle, shuffle repeat all or repeat
6 Press 9 again to switch the player off.
while playing a program, searching is only possible within the
particular track.
• To remove the CD, hold it by its edge and press the
hub gently while lifting the CD.
Note: If there is no activity, the set will automatically
switch off after a while to save energy. 0
BEFORE REQUESTING EXCHANGE...
Please check your owner's manual before requesting an exchange. Adjustments of the
controls discussed there may save you a trip.
EXCHANGING A PRODUCT IN U.S.A.,
PUERTO RICO, OR U.S.VIRGIN ISLANDS...
Contact 1-800-705-2000 to arrange an exchange. Or, ship the product, insured and
freight prepaid, and with proof of purchase enclosed, to the address listed below.
Magnavox Exchange Program
Suite A
406 North Irish Street
Greeneville TN 37745
(In U.S.A., Puerto Rico, and U.S.Virgin Islands, all implied warranties, including implied war-
ranties of merchantability and fitness for a particular purpose, are limited in duration to
the duration of this express warranty. But, because some states do not allow limitations
on how long an implied warranty may last, this limitation may not apply to you.)
EXCHANGING A PRODUCT IN CANADA...
Please contact Magnavox at:
1-800-661-6162 (French Speaking)
1-800-705-2000 (English or Spanish Speaking)
(In Canada, this warranty is given in lieu of all other warranties. No other warranties are
expressed or implied, including any implied warranties of merchantability or fitness for a
particular purpose. Magnavox is not liable under any circumstances for any direct, indi-
rect, special, incidental or consequential damages, howsoever incurred, even if notified of
the possibility of such damages.)
REMEMBER...
Please record below the model and serial numbers found on the product. Also, please fill
out and mail your warranty registration card promptly. It will be easier for us to notify
you if necessary.
MODEL # ___________________________________________
SERIAL # ___________________________________________
This warranty gives you specific legal rights.You may have other rights
which vary from state/province to state/province.
EL6516T001 / 5-02
FEATURES
Programming track numbers
You can store up to 30 tracks to play in a program.
A single track may be stored more than once in the
program.
1 While playback is stopped, select a track with
∞ or §.
2 Press PROG to store the track.
yPROG lights up; the track number
E S P PROG
programmed and P with the total number of
stored tracks are displayed.
3 Select and store all desired tracks in this way.
4 Press 2; to start playback of your selected tracks.
yPROG is shown and playback starts.
• You can review the program by pressing PROG for
more than 2 seconds.
yThe display shows all the stored tracks in E S P
D B B
sequence.
Notes: – If you press PROG and there is no track selected, SELECt is dis-
played.
– If you try to store more than 30 tracks, FULL is displayed.
Clearing the program
• While playback is stopped, press 9 to clear program.
E S P PROG
yCLEAr is displayed once, PROG goes off, and
the program is cleared.
Note: The program will also be cleared if the power supply is interrupted, or if
the CD-player lid is opened, or if the set switches off automatically.
Selecting different playing possibilities MODE
It is possible to play tracks in random order, to repeat a single track or the entire
CD, and to play the first few seconds of each track.
1 Press MODE during playback as often as required in
order to activate one of the following 'modes'. The
active mode is shown in the display.
ySHUFFLE : All tracks of the CD are played in
random order until all of them have been played
once.
ySHUFFLE REPEAT ALL : All tracks of the CD
are played repeatedly in random order.
yREPEAT : The current track is played repeatedly.
yREPEAT ALL : The entire CD is played repeatedly.
SHUFFLE
E S P
REPEAT ALL
ySCAN: The first 10 seconds of each of the remain-
ing tracks are played in sequence.
2 Playback starts in the chosen mode after 2 seconds.
• To return to normal playback, press MODE repeatedly until the display shows
no active modes.
ESP
With a conventional portable CD-player you might have experienced that the
music stopped e.g. when you were jogging. The Electronic Skip Protection
prevents loss of sound caused by light vibrations and shocks. Continuous playback
mode (see MODE chapter), or
is ensured. However ESP does not prevent playback interruptions during vigorous
running. It also does not protect the unit against any damage caused by dropping!
In this set ESP is default ON. It is possible to set ESP off.
• Press MODE for more than 2 seconds.
y ESP disappears.
• Press MODE again for more than 2 seconds.
y ESP is displayed.
ESP on ESP off ESP on
7 6
5
8 4
3
9
2
0
!
@ 1
#
$ $
1
FEATURES / TROUBLESHOOTING
RESUME and HOLD
You can interrupt playback and continue (even after an
extended period of time) from the position where
playback stopped (RESUME) and you can lock all buttons
of the set so that no action will be executed (HOLD). Use
the RESUME–HOLD–OFF slider for these functions.
RESUME – continuing from where you have stopped
1 Switch the slider to RESUME during playback to acti-
E S P
vate RESUME. RESUME
yRESUME
is shown.
2 Press 9 whenever you want to stop playback.
3 Press 2; whenever you want to resume playback.
yRESUME is shown and playback continues from where you have
stopped.
• To deactivate RESUME, switch the slider to OFF.
yRESUME
goes off.
HOLD – locking all buttons
You can lock the buttons of the set by switching the slider to HOLD. Now, when a
key is pressed, no action will be executed. This is of use, for example, when
transporting the player in a bag. With HOLD activated, you can avoid accidental
activation of other functions.
1 Switch the slider to HOLD to activate HOLD.
E S P HOLD
yAll buttons are locked. HoLd is shown when
you press any button. If the set is switched off,
HOLD will be shown only when 2; is pressed.
2 To deactivate HOLD, switch the slider to OFF.
Note: If you deactivate HOLD by switching the slider to RESUME, you will be acti-
vating the RESUME function.
Troubleshooting
WARNING: Under no circumstances should you try to repair the set yourself as
this will invalidate the warranty. If a fault occurs, first check the points listed,
before taking the unit for repair. If you are unable to solve a problem by following
these hints, consult your dealer or service center.
The CD player has no power, or playback does not start
• Check that your batteries are not dead or empty, that they are inserted
correctly, that the contact pins are clean.
• Your adapter connection may be loose. Connect it securely.
• For in-car use, check that the car ignition is on. Also check player's batteries.
The indication no diSC is displayed
• Check that the CD is clean and correctly inserted (label-side upward).
• If your lens has steamed up, wait a few minutes for this to clear.
The indication nF diSC is displayed
• CD-RW (CD-R) was not recorded properly. Use FINALIZE on your CD-recorder.
The indication is on and/or there is no reaction to controls
HOLD
• If HOLD is activated, then deactivate it.
• Electrostatic discharge. Disconnect power or remove batteries for a few seconds.
The CD skips tracks
• The CD is damaged or dirty. Replace or clean the CD.
• RESUME, SHUFFLE or PROGRAM is active. Switch off whichever is on.
No sound or bad sound quality.
• PAUSE might be active. Press 2;.
• Loose, wrong or dirty connections. Check and clean connections.
• Volume might not be appropriately adjusted. Adjust the volume.
• Strong magnetic fields. Check player's position and connections. Also keep
away from active mobile phones.
• For in-car use, check that the cassette adapter is inserted correctly, that the car
cassette player's playback direction is correct (press autoreverse to change),
and that the cigarette lighter jack is clean. Allow time for temperature change.
